316 SS Bolt No No Exempt 15/80S6-[ _ _ ]
316 SS Bolt No No Exempt A15/80S6-SA
316 SS Swing Bolts No No VIII, Div 1 AKSB-0280-2-SA
Carbon Steel Bolt/Nut No No VIII, Div 1 AHC-0180-[ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 ALN3-0128-[ _ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFN3-0128-[ _ _ _ ]
316 SS Swing Bolts Yes No VIII, Div 1 AKS-0280-[ _ _ ]
316 SS Swing Bolts No No VIII, Div 1 AKSB-0280-SA
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 ALF3-0128-[ _ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF3-0128-[ _ _ _ ]
Carbon Steel Swing Bolts Yes Yes VIII, Div 1 AKC-0280-[ _ _ ]
Carbon Steel Swing Bolts No No VIII, Div 1 AKH-0280-[ _ _ ]
Carbon Steel Bolt/Nut No No VIII, Div 1 AHC-0280-[ _ _ ]
316 SS Swing Bolts Yes No VIII, Div 1 AKS-0480-[ _ _ ]
316 SS Swing Bolts No No VIII, Div 1 AKSB-0480-SA
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 ALF4-0125-[ _ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF4-0125-[ _ _ _ ]
Carbon Steel Swing Bolts Yes Yes VIII, Div 1 AKC-0480-[ _ _ ]
Carbon Steel Swing Bolts No No VIII, Div 1 AKH-0480-[ _ _ ]
Carbon Steel Bolt/Nut No No VIII, Div 1 AHC-0480-[ _ _ ]
316 SS Swing Bolts Yes No VIII, Div 1 AKS-0880-[ _ _ ]
316 SS Swing Bolts No No VIII, Div 1 AKSB-0880-SA
Carbon Steel Swing Bolts Yes Yes VIII, Div 1 AKC-0880-[ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 ALF6-0136-[ _ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 ALF6-0328-[ _ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF6-0328-[ _ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF6-0136-[ _ _ _ ]
Carbon Steel Swing Bolts No No VIII, Div 1 AKH-0880-[ _ _ ]
Carbon Steel Bolt/Nut No No VIII, Div 1 AHC-0880-[ _ _ ]
AKH
Carbon Steel
3" - 10" Flange
Floor
Swing Bolts
665 psig
250
No
No
AHC
Carbon Steel
2" - 8" Flange
Floor
Bolt / Nut
1440 psig
330
No
No
AKS
316 SS :Housing Material
2" - 10" Flange :Port Size
Floor :Mounting
Swing Bolts :Closure Type
200 psig :Max Press
200 :Max Temp (°F)
Yes :Auto Drain
No :DPI
22
Compressed Air Filters
Quick Select Guide 8" - 16" Port Size
Model # Mount Port Size Port Type Max Temp Max Press
F
# of
Elements
A
Element
Size
AKS-1480-[ _ _ ] Floor 8 Flange 200 200 14 200-80
AKSB-1480-SA Floor 8 Flange 200 200 14 200-80
AKC-1480-[ _ _ ] Floor 8 Flange 250 200 14 200-80
AFF8-0428-[ _ _ _ ] Floor 8 Flange 225 250 4 510-28
AKH-1480-[ _ _ ] Floor 8 Flange 250 665 14 200-80
AHC-1480-[ _ _ ] Floor 8 Flange 130 1440 14 200-80
AKS-2280-[ _ _ ] Floor 10 Flange 200 200 22 200-80
AKSB-2280-SA Floor 10 Flange 200 200 22 200-80
AKC-2280-[ _ _ ] Floor 10 Flange 250 200 22 200-80
AFF10-0728-[ _ _ _ ] Floor 10 Flange 225 250 7 510-28
AKH-2280-[ _ _ ] Floor 10 Flange 250 665 22 200-80
AFF12-1128-[ _ _ _ ] Floor 12 Flange 225 250 11 510-28
AFF16-1528-[ _ _ _ ] Floor 16 Flange 225 250 15 510-28
[ _ _ ] = Element Grade (B on Filter Element Selection Chart)
15 / 80 15 / 80S AFF, AFN, ALN, ALF AKC
Housing Material: Alum /
Steel Stain. Steel Carbon Steel Carbon Steel
Port Size: 2" NPT 3" NPT - 16" Flange 3" - 10" Flange
Mounting: Line Line or Floor Floor
Closure Type: Nut / Stud Bolt / Nut Swing Bolts
Max Press: 250 psig 800 psig 200 - 250 psig 200 - 250 psig
Max Temp (°F): 130 400 225 230 - 250
Auto Drain: Yes No Yes Yes
DPI: Yes No Yes Yes
Instructions for calculating housing / element flow:
1.) Select housing based on line size, temperature,
and pressure
2.) Determine element size (A) from table above
3.) Determine desired filtration efficiency (C)
4.) Determine operating pressure (D)
5.) Determine the number elements in the
selected housing (F)
6.) Look up the flow of each element (E) in the table above
by correlating A, C, D
7.) Multiply the flow ( E ) above by the number of
elements in the housing (F) to determine the air flow
for the housing
8.) Multiply the result of #7 (above) by the correction factor
(G) for the gas being filtered
A B C Pressure
Drop at Rated
Flow PSIG
D
Element
Size
Element
Grade
Filtration
Efficiency
40 psig
MM SCFD SCFM
200-80 DX 93% @ .01m 2.0 0.8 595
BX 99.99% @ .01m 2.0 0.2 150
CI¹ Activated Carbon 3.0 0.1 77
SA 99.9999% @ .01m 3.0 0.2 150
510-28 HEC 99.97% @ .01m 1.5 1.0 715
HFC 99.5% @ .05m .25 1.7 1,187
850-25 HEC 99.97% @ .01m 1.5 1.4 954
HFC 99.5% @ .05m .25 2.3 1,583
850-36 HEC 99.97% @ .01m 1.5 2.1 1,431
HFC 99.5% @ .05m .25 3.4 2,375
Note¹: Activated carbon adsorption element
0.003 ppm (w) max remaining oil content
w/inlet challenge 0.05 ppm
E
G
Gas Correction Factor
Air 1
Hydrogen 3.8
Nitrogen 1
Natural Gas 1.3
Carbon Dioxide 0.81
Helium 2.7
Methane 1.35
Propane 0.81
Compressed
Air Filters
23
Compressed Air Filters
Quick Select Guide 8” - 16” Port Size
Housing Material Closure Type
Auto Drain
Included DPI Gauge ASME Model #
316 SS Swing Bolts Yes No VIII, Div 1 AKS-1480-[ _ _ ]
316 SS Swing Bolts No No VIII, Div 1 AKSB-1480-SA
Carbon Steel Swing Bolts Yes Yes VIII, Div 1 AKC-1480-[ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF8-0428-[ _ _ _ ]
Carbon Steel Swing Bolts No No VIII, Div 1 AKH-1480-[ _ _ ]
Carbon Steel Bolt/Nut No No VIII, Div 1 AHC-1480-[ _ _ ]
316 SS Swing Bolts Yes No VIII, Div 1 AKS-2280-[ _ _ ]
316 SS Swing Bolts No No VIII, Div 1 AKSB-2280-SA
Carbon Steel Swing Bolts Yes Yes VIII, Div 1 AKC-2280-[ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF10-0728-[ _ _ _ ]
Carbon Steel Swing Bolts No No VIII, Div 1 AKH-2280-[ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF12-1128-[ _ _ _ ]
Carbon Steel Bolt/Nut Yes Yes VIII, Div 1 AFF16-1528-[ _ _ _ ]
[ _ _ ] = Element Grade (B on Filter Element Selection Chart)
AKH
Carbon Steel
3" - 10" Flange
Floor
Swing Bolts
665 psig
250
No
No
AHC
Carbon Steel
2" - 8" Flange
Floor
Bolt / Nut
1440 psig
130
No
No
AKS
316 SS :Housing Material
2" - 10" Flange :Port Size
Floor :Mounting
Swing Bolts :Closure Type
200 psig :Max Press
200 :Max Temp (°F)
Yes :Auto Drain
No :DPI
D
100 psig 200 psig 400 psig 600 psig 1000 psig 1400 psig
MM SCFD SCFM MM SCFD SCFM MM SCFD SCFM MM SCFD SCFM MM SCFD SCFM MM SCFD SCFM
1.8 1,250 3.3 2,340 6.5 4,515 9.4 6,700 15.9 11,050 22.2 15,400
0.4 310 0.8 580 1.6 1,120 2.4 1,660 4.0 2,750 5.5 3,850
0.2 160 0.4 300 0.8 575 1.2 855 2.0 1,400 2.9 1,980
0.4 310 0.8 580 2.0 1,120 2.0 1,660 4.0 2,750 6.0 3,850
2.2 1,500 3.6 2,481
Flow per single element for air
(multiply times number of elements in housing)
3.6 2,490 6.7 4,661
2.9 2,000 5.4 3,744
4.8 3,320 8.9 6,215
4.3 3,000 8.1 5,616
7.2 4,980 13.4 9,322
E
Compressed
Air Filters
24
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Petrochemical Textiles Pulp and Paper Refineries
Product Features:
Balston Compressed Air Filters protect
your equipment and delicate instruments from the dirt, water, and oil
usually found in compressed air and
other gases. These filters will remove
contaminants at a very high efficiency -
up to 99.99% for 0.01 micron particles
and droplets. Liquid releases from the
filter cartridge to an automatic drain as
rapidly as it enters the filter. This allows the filter to continue removing liquids for an unlimited time without loss
of efficiency or flow capacity. Select
1/4” to 1” line filters are constructed of
304 stainless steel and are designed to
hold up to the harshest environments.
Stainless Steel Compressed Air
Filters for Harsh Environments
• All 304 stainless steel construction, ideal standing up
to aggressive washdown
chemicals
• Remove 99.99% of 0.01 micron
particles of oil, water, and dirt
from compressed air and other
gases
• For Sterile Air Requirements:
• USDA accepted for use in
federally inspected meat and
poultry plants
• Low pressure drop
• Continuously trap and drain
liquids
• Remove trace oil vapor with
adsorbent cartridges
Balston Stainless
Steel Compressed
Air Filter Assemblies:
25
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Filter Cartridge Description
Balston Filter Cartridges
Balston provides two grades of coalescing filter
cartridges, Grade DX and Grade BX. Singly or
in tandem, these filters satisfy all requirements
for removing liquid and solid contaminants from
compressed air. Balston also has an activated
carbon adsorbent CI-type cartridge for the removal
of trace oil vapors from a compressed air line. The
activated carbon cartridge is Grade 000.
How to Select the Filter Cartridge
and Housing
Single stage filtration. Use a Grade DX filter
cartridge
Two stage filtration is necessary. Use a
Grade DX followed by a Grade BX filter cartridge. As a general rule, a Grade BX filter
cartridge should not be used alone.
For rare instances where even a trace
amount of oil vapor can cause a problem,
three stage filtration is necessary. Use a
Grade DX followed by a Grade BX, and a
type CI cartridge.
General purpose
applications such as plant
compressed air
Filter Cartridge Description
Removal of trace compressor oil vapor
Instrument air and other
critical air requirements
How to Order the Filter Assembly
Temperature Range -40°F to 300°F (-40°C - 149°C)
Maximum Pressure
Differential Across Filter,
Inside-to-Outside Flow: 100 psi (7 barg)
Materials of Construction Borosilicate glass microfibers with
fluorocarbon resin binder. Resistant to
water, all hydrocarbon and synthetic
lubricants.
Physical Properties,
Microfibre Filter Cartridges
Retention Efficiency
Grade Efficiency for 0.01 Micron
Particles and Droplets
DX 93%
BX 99.99%
CI 99.99% Adsorption
SA 99.9999%
1 Decide which grade(s) of filter cartridges fits
the application (see selection boxes at left).
2 Select the filter housing with a port size equal
to the line size where the filter is to be located.
3 For a new installation in which the line size
has yet to be selected, determine the gas flow
rate and pressure at the point where the filter
will be located, and then refer to the flow chart
on the reverse side of this data sheet. NOTE:
The filter port size must be equal to or larger
than the line size (when specified).
1 Build your own custom filter assembly using
the guideline matrix on Page 16 and specify
your model number. Example: 1/2” filter with
DPI and Auto Drain with Grade DX Filter =
6004N-01A-DX.
2 Each assembly is shipped with the filter
cartridge installed. To order additional filter
cartridges, indicate the model number of the
cartridges, and the grade. Examples 050-
05-DX, 050-05-BX. The grade used for Type
CI cartridges is 000 (CI-100-12-000).
Note: Assemblies with CI Cartridges are shipped
with the adsorbent cartridge wrapped separately.
This shipping method prolongs the life of
the cartridge.
Stainless Steel Filters for Harsh Environments
26
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Models 6102, 6002, 6904
The 6102 and 6002 series models are 1/4” line size
filters designed for lower flow systems and installations with space limitations. It is offered with two drain
options, a manual drain or an auto float drain for maintenance free operation. The model 6904 offers 1/2” inlet
and outlet connections, for applications requiring 1/2”
pipe with space limitation requirements.
Model 6004
The 6004 series models are 1/2” line size filters designed for moderate flow rate systems. This series
has increased liquid holding capacity which safeguards
sensitive end use points from system upsets and morning start ups.
Models 6006 and 6008
The 6006 and 6008 series models are 3/4” and 1” line
size filters respectively. These are designed for high
flow rate systems servicing multiple end use points.
These are also offered with a high capacity auto float
drain option.
Models 6102, 6002, 6904 Model 6004
Models 6006 and 6008
How to Order the Filter Assembly*
Build your own custom filter assembly
using the guideline matrix below and
specify your model number. Example:
1/2” filter with Auto Drain and Grade DX
Filter = 6004N-0A1-DX.
*Consult Factory. Not all configurations are available.
N
NPT Thread Inlet &
Outlet Ports
0A2
Manual
Drain
0A1
Auto Drain
Filter Grade
000
SA
DX
BX
Leave blank for
no filter
Cartridge
Stainless Steel Filters for Harsh Environments
6102
1/4” Ports
6002
1/4” Ports
6904
1/2” Ports
Short Bowl
6004
1/2” Ports
6006
3/4” Ports
6008
1” Ports
27
Compressed Air Filters
www.parker.com/gsf
Compressed
Flow Rates
Air Filters
Filter Housing Port Filter Flow rates SCFM (Nm3
/hr), at 7 psi drop at indicated line pressure (over 3 stages). Refer to Principal
Model Size Cartridge Specification Charts in each product data sheet for maximum pressure rating of each housing
Grade psig (barg)
2 (0.14) 20 (1.4) 40 (3) 80 (6) 100 (7) 125 (9) 150 (10) 200 (14) 250 (17)
6102N 1/4” DX 3.5 (6) 8 (13) 11 (18) 20 (33) 25 (42) 30 (50) 36 (60) --- ---
BX 1 (2) 2 (3) 3.5 (6) 5.7 (10) 6.8 (11) 8 (13) 10 (17) --- ---
6002N 1/4” DX 9 (15) 19 (32) 39 (66) 51 (87) 63 (107) 76 (129) 90 (153) 117 (199) 145 (246)
6904N 1/2” BX 3 (5) 8 (14) 11 (19) 21 (36) 25 (42) 31 (53) 36 (61) 47 (80) 58 (99)
CI 2 (3) 5 (8) 7 (12) 12 (20) 15 (25) 18 (31) 22 (37) 28 (48) 35 (59)
SA --- 8 (14) 11 (19) 21 (36) 25 (42) 31 (53) 36 (61) --- ---
6004N 1/2” DX 19 (32) 41 (70) 65 (110) 113 (192) 137 (233) 166 (181) 196 (333) 257 (437) 316 (537)
BX 9 (15) 19 (32) 30 (51) 51 (87) 63 (107) 76 (129) 90 (153) 117 (199) 145 (246)
CI 6 (10) 12 (20) 19 (32) 32 (54) 39 (66) 48 (82) 56 (95) 73 (124) 90 (153)
SA --- 19 (32) 30 (51) 51 (87) 63 (107) 76 (129) 90 (153) --- ---
6006N 3/4” DX 37 (63) 78 (133) 123 (209) 214 (364) 259 (440) 315 (535) 371 (630) 484 (822) 596 (1013)
BX 10 (17) 21 (36) 34 (58) 56 (95) 70 (119) 85 (144) 101 (172) 131 (223) 162 (275)
CI 8 (14) 16 (27) 26 (44) 44 (75) 53 (90) 65 (110) 76 (129) 99 (168) 122 (207)
SA --- 21 (36) 34 (58) 56 (95) 70 (119) 85 (144) 101 (172) --- ---
6008N 1” DX 55 (93) 115 (195) 181 (308) 314 (533) 380 (646) 463 (787) 546 (928) 711 (1208) 877 (1490)
BX 11 (19) 23 (39) 37 (63) 64 (109) 77 (131) 94 (160) 111 (189) 144 (245) 178 (302)
CI 10 (17) 20 (34) 32 (54) 56 (95) 67 (114) 82 (139) 96 (163) 125 (212) 154 (262)
SA --- 23 (34) 37 (70) 64 (116) 77 (144) 94 (177) 111 (209) --- ---
Balston grade SA filter cartridges, rated at 99.9999+%
efficiency for 0.01 micron particles, is at least 30 times
better than the accepted standard for sterile air filters
developed by independent research organizations
in the U.S. and U.K. (request bulletin TI-105A for a
detailed discussion on Balston filter efficiency rating
procedure, and Bulletin TI-935 for an independent test
report on Balston Sterile Air Filters). Balston Sterile Air
Filters are in full compliance with the requirements of
the FDA.
Sterile Air Filters Steam Sterilization Procedure
In installations where the sterile air filter requires steam
sterilization, we recommend the following procedures:
The steam sterilization pressure should not exceed
60 psig (4 barg). Preferably, it should be held to 40 psig
(3 barg) or less. A typical sterilization cycle is 30 psig
(2 barg) steam for 30 minutes. Steaming time can be
increased as desired without harm to the filter cartridges.
The steam flow should not exceed the normal air flow
for the unit. To ensure no buildup of condensate in the
housing, condensate should be drained from the filter by
a condensate drain valve during the steaming process.
The cleanliness of the steam is an important factor influencing the life of the Sterile Air Filter cartridges. Parker
strongly recommends using Model 23 Steam Filters to
ensure optimum operating life. When autoclaving, the
Grade SA filter cartridges will tolerate temperatures to
300°F (149°C) in dry gas. Viton or other heat resistant
seals should be used in the housing.
Stainless Steel Filters for Harsh Environments
28
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Principal Specifications
Ordering Information | For assistance, call toll-free at 1-800-343-4048 | 8AM to 5PM Eastern Time
Stainless Steel Filters for Harsh Environments
Model 6102 6002 6904 6004 6006 6008
Port Size 1/4” NPT 1/4” NPT 1/2” NPT 1/2” NPT 3/4” NPT 1” NPT
Materials of Construction
Head 316 Stainless Steel 304 Stainless Steel
Bowl 316 Stainless Steel 304 Stainless Steel
Internals Acetal Stainless Steel
Seals Viton Buna-N Food Grade
Maximum Temperature 140°F (60°C) (1) 120°F (49°C) (1)
Maximum Pressure 150 psig (12.1 barg) (2) 175 psig (10.3 barg) (2)
Minimum Pressure 15 psig (1 barg) (3) 15 psig (1 barg) (3)
Shipping Weight 3.5 lbs. (1.6 Kg) 3.5 lbs. (1.6 Kg) 3.5 lbs. (1.6 Kg) 4.0 lbs. (1.8 Kg) 11 lbs. (4.9 Kg) 12 lbs. (5.4 Kg)
Dimensions 1.5”W x 4.2”L 3”W X 7”L 3”W X 7”L 3”W X 10”L 4”W X 10”L 4”W X 12”L
(3.8cm x 11.7cm) (7cm X 18cm) (7cm X 18cm) (7cm X 25cm) (10cm X 25cm) (10cm X 30cm)
Assembly Ordering Information
Model P/N Filter Tube Drain (Manual) Drain (Auto. Float) Mounting Bracket (stainless steel)
6102N-0A0-(?X) 070-063-(?X) SAP05481 N/A N/A
6102N-0A1-(?X) 070-063-(?X) N/A C02-2392 N/A
6002N-0A2-(?X) 100-12-(?X) C01-0108 N/A C01-0094
6002N-0A1-(?X) 100-12-(?X) N/A C01-0109 C01-0094
6002N-0A2-SA 100-12-SA C01-0108 N/A C01-0094
6002N-0A2-000 CI-100-12-000 C01-0108 N/A C01-0094
6904N-0A2-(?X) 100-12-(?X) C01-0108 N/A C01-0094
6904N-0A2-(?X) 100-12-(?X) N/A C01-0109 C01-0094
6904N-0A2-SA 100-12-SA C01-0108 N/A C01-0094
6904N-0A2-000 CI-100-12-000 C01-0108 N/A C01-0094
6004N-0A2-(?X) 100-18-(?X) C01-0108 N/A C01-0094
6004N-0A1-(?X) 100-18-(?X) N/A C01-0109 C01-0094
6004N-0A2-SA 100-18-SA C01-0108 N/A C01-0094
6004N-0A2-000 CI-100-18-000 C01-0108 N/A C01-0094
6006N-0A2-(?X) 200-176-(?X) C01-0108 N/A C01-0094
6006N-0A1-(?X) 200-176-(?X) N/A C01-0109 C01-0094
6006N-0A2-SA 200-176-SA C01-0108 N/A C01-0094
6006N-0A2-000 200-176-000 C01-0108 N/A C01-0094
6008N-0A2-(?X) 200-185-(?X) C01-0108 N/A C01-0094
6008N-0A1-(?X) 200-185-(?X) N/A C01-0109 C01-0094
6008N-0A2-SA 200-185-SA C01-0108 N/A C01-0094
6008N-0A2-000 200-185-000 C01-0108 N/A C01-0094
Replacement Filter Cartridge Ordering Information
Model P/N 6102 6002/6904 6004 6006 6008
Replacement Filter Cartridges
Number required 1 1 1 1 1
Box of 5 5/070-063-(?X) 5/100-12-(?X) 5/100-18-(?X) 5/200-176-(?X) 5/200-185-(?X)
Box of 10 070-063-(?X) 100-12-(?X) 100-18-(?X) 200-176-(?X) 200-185-(?X)
Box of 10 070-063-SA 100-12-SA 100-18-SA 200-176-SA 200-185-SA
CI Cartridges (box of 1) --- CI100-12-000 CI100-18-000 CI200-176-000 CI200-185-000
Notes:
1 Max. temperature with auto drain Max. temperature with manual drain is 275°F (135°C).
2 Max. pressure with auto drain. Max. pressure with manual drain is 250 psi (17 barg).
3 Required for proper operation of auto drain.
29
Compressed Air Filters
www.parker.com/gsf
Compressed
Models 9955-05-DX, 9955-11-DX,
Air Filters
9955-12-DX, AR-009-DX
Balston Filter/Silencers for air exhausts offer the combination of unusually effective sound attenuation and filtration of all visible oil mist from the exhaust air. The Filter/
Silencers are available in 1/8”, 1/4”, 1/2”, and 3/4” port
sizes. They contain a Grade DX Microfiber Filter
Cartridge sealed into a molded nylon or steel holder.
Balston Filter/Silencers are remarkably efficient sound
mufflers, far more efficient than the felts, pleated paper,
sintered plastic, and sintered metal products commonly
used in other exhaust silencers. A sound attenuation efficiency test comparing a 9955-12-DX, 1/2” Filter/Silencer
with a sintered polyethylene silencer is described below.
This silencing efficiency test simulates the action of an air
cylinder discharging rapidly to atmosphere. A length of
1/2” line between two ball valves is pressurized with air
to a controlled pressure. The upstream valve is closed
and then the downstream valve is opened rapidly to
discharge the fixed volume of air under pressure to
atmosphere. Noise levels were measured at a 3 foot
(1 meter) distance with no silencer on the end of the
line, with the Balston Filter Silencer, and with
competitive silencers.
Model 9955-11-DX
Model 9955-05-DX
Model 9955-12-DX
Model AR-009-DX
Without Silencer 102 102 101 99 95
With Balston
Silencer 70 70 69 67 65
With Sintered
Polyethylene Silencer 88 88 87 87 81
A similar test of the Model AR-009-DX on a 3/4” air line gave the
following results:
Without Silencer With Model AR-009-DX
113 dBA 94 dBA
Sound Level 3 ft. from 3/4” Air Line Discharging Air
At 100 PSIG Atmosphere
Noise Level Upstream Pressure psig (barg)
(dBA) 100 (7) 80 (5.5) 60 (4.3) 40 (2.7) 20 (1.5)
Disposable Filter Silencers
30
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Principal Specifications
Model 9955-05-DX 9955-11-DX 9955-12-DX AR-009-DX
Inlet Port 1/8” NPT (Male) 1/4” NPT (Male) 1/2” NPT (Male) 3/4” NPT (Female)
Drain Port 1/4” OD Tubing 1/4” OD Tubing 1/4” OD Tubing 1/8” NPT (Female)
Materials of Construction
Filter Cartridge Borosilicate glass microfibers with fluorocarbon resin binder
Holder Nylon Nylon Nylon Aluminum
Internals ––– ––– ––– Aluminum
Maximum Internal
Pressure at 110°F (43°F) 100 psig (7 barg) (1) 100 psig (7 barg) (1) 100 psig (7 barg) (1) 100 psig (7 barg) (1)
Maximum Temp. at
0 psig Internal Pressure 260°F (127°C) 260°F (127°C) 260°F (127°C) 300°F (149°C)
Shipping Weight 0.5 lb (0.2 kg) 0.5 lb (0.2 kg) 0.5 lb (0.2 kg) 1 lb (0.5 kg)
Dimensions 1.4” dia. X 2.0”h 1.4” dia. X 3.0”h 2.0” dia. X 3.7”h 3.95” dia. X 5.13”h
(4cm X 5cm) (4cm X 8cm) (5cm X 9cm) (10cm X 13cm)
Ordering Information
For assistance, call toll-free at 1-800-343-4048 | 8AM to 5PM Eastern Time
Model Description
9955-05-DX, 9955-11-DX, 9955-12-DX Standard Pack 10 Filter Silencers per box, individually wrapped
AR-009-DX Complete Assembly with one filter element
Replacement Element for AR-009-DX
2/BE200-168-DX Boxes of 2
BE200-168-DX Boxes of 10
Notes:
1 With the outlet open to atmosphere. Otherwise,
maximum internal pressure is 15 psig.
Flow Rates Flow Rate from Pressured Line through Filter to Atmosphere (cu. ft. per sec.)
Filter Housing Type 100 psig (6.9 barg) Line Pressure 60 psig (4.1 barg) Line Pressure 20 psig (1.4 barg) Line Pressure
9955-05-DX 3 (4.9) 1.2 (2.5) 0.2 (0.7)
9955-11-DX 10 (16.2) 4 (8.2) 0.7 (0.5)
9955-12-DX 35 (57) 14 (29) 2.2 (1)
AR-009-DX 105 (171) 42 (86) 6.6 (4)
Disposable Filter Silencers
Table 1
31
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Low Flow, Compact
Compressed Air Filters
Balston 92-800 Series
Compressed Air and Gas Filters
Safeguard critical end use points from
water, oil, rust and pipescale. The
92-800 series compressed air filters
are small and compact making them
ideal for portable pneumatics, instrumentation, and other applications requiring small pneumatic components.
The 92-800 Series are available with
anodized aluminum heads and polycarbonate bowls, anodized aluminum
bowls, or pyrex glass bowls. Capable
of up to 250 PSIG and 250°F, these
filters can be applied to the most demanding applications. High efficiency
filtration media is available from 93%
at 0.01 micron to 99.9999+% at 0.01
micron.
The 92-800 series are available with
1/4” and 1/2” NPT connections.
Product Features
• Small compact design
• Anodized aluminum with polycarbonate, Pyrex, or aluminum bowls
• Continuously trap and drain liquids
• Remove up to 99.9999+% of 0.01 micron particles of oil, water, and
dirt from compressed air and other gases
• High flow rate capacity
• Low pressure drop
The Parker Balston 92-800 Series offer the best protection to all your
pneumatic equipment and instrumentation. These high efficiency
filtration systems will eliminate costly maintenance and unexpected
downtime due to contaminated compressed air.
Applications
These filters are ideal for safeguarding critical production equipment from corrosive compressor
condensate that can cause catastrophic failures and unexpected
shutdowns. Ideal applications are:
• Instrumentation
• Air actuators and air cylinders
• Pneumatic packaging machines
• Pneumatic conveyors
• Air operated production
equipment
• Air operated lifts
32
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Low Flow, Compact
Compressed Air Filters
Principal Specifications and
Ordering Information
Principal Specifications
Model (1) 92-810A 92-810
Port Size 1/4” NPT 1/4” NPT
Material of Construction
Head Aluminum Aluminum
Bowl Aluminum Polycarbonate
Internals Aluminum Aluminum
Seals Buna-N Grade Buna-N Grade
Maximum Temperature 250°F (121°C) 130°F (54°C)
Maximum Pressure 250 pisg (17 barg) 150 psig (10 barg)
Shipping Weight 2 lbs. (0.9 kg) 2 lbs. (0.9 kg)
Dimensions 2.75”W x 5.64”L (7cm W x 14cm L) 2.75”W x 5.64”L (7cm W x 14cm L)
Ordering Information | For assistance, please call 1-800-343-4048 | 8AM to 5PM Eastern Standard Time
Model P/N (2) Description Replacement Cartridge
Box of 2 Box of 10
92-810A 1/4” NPT Ports with Aluminum Bowl 2/100-12-?X 100-12-?X
92-812A 1/2” NPT Ports with Aluminum Bowl 2/100-12-?X 100-12-?X
92-810 1/4” NPT Ports with Polycarbonate Bowl 2/100-12-?X 100-12-?X
92-812 1/2” NPT Ports with Polycarbonate Bowl 2/100-12-?X 100-12-?X
Notes:
1 For 1/2” NPT Ports, order 92-812
2 Filter housings are not supplied with filter cartridges
Filter Housing Port Size Filter Flow rates SCFM (Nm3
/hr), at 2 psi drop at indicated line pressure. Refer to Principal Specification Charts
Model Size Cartridge in each product data sheet for maximum pressure rating of each housing
Grade PSIG (barg)
2 (0.14) 20 (1.38) 40 (2.76) 80 (5.52) 100 (6.9) 125 (8.6) 150 (10.3) 200 (13.8) 250 (17.2)
Series 92-810/2 1/4” DX 12 (20.4) 26 (44.2) 40 (68.0) 70 (118.9) 85 (144.4) 103 (175.0) 122 (207.3) 159 (270.1) 196 (333.0)
1/2” BX 3 (5.1) 7 (11.9) 10 (17.0) 18 (30.6) 22 (37.4) 27 (45.9) 32 (54.4) 41 (69.7) 51 (86.6)
92-810A 92-810
33
Compressed Air Filters
www.parker.com/gsf
Compressed
Filter-Regulator Combinations
Air Filters
Balston Filter-Regulators combine a high efficiency
coalescing filter with a high quality pressure regulator.
Air flows through the filter, then to the pressure regulator. The filter is a Balston coalescing compressed air
filter (Grade BX) and will completely remove oil, water,
and dirt from compressed air and other compressed
gases. Flow direction through the element is insideto-outside for optimum oil and water removal. An
automatic drain is installed on the 3/8”, 1/2”, and 3/4”
models offering maintenance-free operation. Pressure
gauges are standard and are available in up to 4 different ranges (see ordering information).
AFR-940, AFR-940A
12E Series
Control Characteristics
Model AFR-940, AFR-940A Model 12E
Filter Regulators
0 0
Flow Characteristics
12E37E13A*
10 20 30 40 50
0
20
60
80
40
100
5 25 30
10 60 70
5 10 15 20
0
1
2
3
4
5
6
1/2 Inch Ports
100 PSIG (6.9 bar
Primary Pressure
Secondary Pressure -PSIG
Secondary Pressure -bar
Rated Flow - SCFM
Flow -dm /s
3
n
34
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Notes:
1 Minimum operating pressure for automatic
drain is 15 psig (1.03 barg).
2 Maximum pressure ratings are for temperatures to 130°F (54°C). Please consult
the factory for maximum pressure ratings at
elevated temperatures.
To order product with desired port size and Regulating
Pressure Range, select the indicator digits from the
matrix (at right). This will complete the entire model
number which is needed to place an order.
How to Order 12E 7 BX A
4 3/4” Ports
3 1/2” Ports
Auto
Drain
16 60 psig
18 125 psig
21 250 psig
With Gage
A non-rising
knob, relieving
Grade BX
Filter
Model AFR-940 AFR-940A 12E37 12E47
Port Size 1/4” NPT 1/4” NPT 1/2” NPT 3/4” NPT
Gauge Ports 1/8” NPT 1/8” NPT 1/4” NPT 1/4” NPT
Materials of Construction
Head Anod. Alum. Anod. Alum. Zinc Zinc
Bowl Polycarb. Anod. Alum. Zinc Zinc
Bonnet Polycarb. Polycarb. Plastic Plastic
Internals Brass/Buna Brass/Buna Zinc/Nitrile Zinc/Nitrile
Maximum Temperature 220°F (104°C) 220°F (104°C) 125°F (52°C) 125°F (52°C)
Maximum Pressure 150 psig (10.3 barg) (2) 250 psig (17.2 barg) (2) 250 psig (17.2 barg) (2) 250 psig (17.2 barg) (2)
Minimum Pressure ––– ––– 15 psig/1.03 barg (1) 15 psig/1.03 barg (1)
Shipping Weight 0.5 lbs. (0.2 kg) 0.5 lbs. (0.2 kg) 2.5 lbs. (1.1 kg) 2.5 lbs. (1.1 kg)
Dimensions 1.2”W X 6”L 1.2”W X 6”L 3.25”W X 13”L 3.25”W X 13”L
(3cm X 15cm) (3cm X 15cm) 8cm X 33cm) 8cm X 33cm)
Principal Specifications
Ordering Information
For assistance, call toll-free at 1-800-343-4048 | 8AM to 5PM Eastern Time
Model AFR-940 AFR-940A 12E37 12E47
Control Gauge Pressure Range
0-30 psig AFR-940-30 AFR-940A-30 see ordering matrix below
5-60 psig AFR-940-60 AFR-940A-60 see ordering matrix below
10-130 psig AFR-940-130 AFR-940A-130 see ordering matrix below
Auto. Drain N/A (1) N/A (1) Included (1) Included (1)
Replacement Filter Cartridges
Number Required 1 1 1 1
Box of 5 5/050-05-BX 5/050-05-BX 5/130-14-BX 5/130-14-BX
Box or 10 050-05-BX 050-05-BX 130-14-BX 130-14-BX
Mounting Bracket 11536 11536 PS807P PS807P
Filter Regulators
35
Compressed Air Filters
www.parker.com/gsf
Compressed
Model 17L Series
Air Filters
Many pneumatic system components and most
tools require oil lubrication for proper operation and
long service life. This lubricant is typically carried
by the air stream. Too little oil can cause excessive wear and premature failure. Too much oil is
wasteful and can become a contaminant. Use of
the proper lubricator can greatly extend the life of
expensive downstream pneumatic equipment.
The 17L Series Micro-Mist Lubricators offer proportional oil delivery over a wide range of air flows.
The precision needle valve assures repeatable oil
delivery and provides simple adjustment of delivery
rate. They are designed to generate oil droplets of
5 microns or smaller downstream to lubricate systems having complex piping arrangements.
The 17L series are ideal for low and high flow
applications with changing air flow.
Once the required flow is determined for a pneumatic application, the lubricator can be selected by using the flow chart. To read the lubricator flow chart,
first determine the inlet pressure that will be used.
Find the appropriate pressure curve on the graph.
Each graph will contain three pressure curves.
If the required inlet pressure is not on the graph,
interpolate a similar curve for the required pressure.
How to Select the Correct Lubricator
Next, determine the acceptable pressure drop across
the lubricator and locate it on the vertical axis. Find the
intersection point of the acceptable pressure drop and
the inlet pressure curve. At this point, follow a vertical
path downward to view the flow in SCFM. If the flow is
too low, select a larger port size or body size to give the
required flow. If the flow is higher than necessary, select
a smaller port size or body size to give the required flow.
Model 17L22B
17L Series
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70
0 0 10 20 30 40
7
1
2
3
4
5
6
0
.1
.2
.3
.4
50 60 70 80 90 100 110 120 130 140 150
Flow C haracteristics
17L32B* 1/2 Inch Ports
&
17L42B* 3/4 Inch Ports
Pressure D rop -PSIG
Pressure D rop -bar
35 PSIG 90 PSIG 150 PSIG Prim ary Pressure -PSIG
2.4 bar 6.2 bar 10.3 bar Prim ary Pressure -bar
Flow -SC FM
Flow -dm /s3
n
Mist Lubricators
36
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Model 17L22BE 17L32BE 17L42BE
Port Size 3/8” NPT 1/2” NPT 3/4” NPT
Gauge Ports 1/4” NPT 1/4” NPT 1/4” NPT
Materials of Construction
Head Zinc Zinc Zinc
Bowl Polycarbonate Polycarbonate Polycarbonate
Bowl Guard Steel Steel Steel
Collar Plastic Plastic Plastic
Seal Nitrile Nitrile Nitrile
Sight Dome Polycarbonate Polycarbonate Polycarbonate
Sight Gage Polyamide Polyamide Polyamide
Maximum Temperature 125°F (52°C) 125°F (52°C) 125°F (52°C)
Maximum Pressure 150 psig (10.3 barg) 150 psig (10.3 barg) 150 psig (10.3 barg)
Minimum Pressure 15 psig (1.03 barg) 15 psig (1.03 barg) 15 psig (1.03 barg)
Shipping Weight 1.9 lbs. (0.9 kg) 1.9 lbs. (0.9 kg) 1.9 lbs. (0.9 kg)
Dimensions 3.25”W X 9.27”L 3.25”W X 9.27”L 3.25”W X 9.27”L
(85mm X 235mm) (85mm X 235mm) (85mm X 235mm)
Principal Specifications
Ordering Information
For assistance, call toll-free at 1-800-343-4048 | 8AM to 5PM Eastern Time
Model 17L22BE (3/8”NPT) 17L32BE (1/2”NPT) 17L42BE (3/4”NPT)
Service Kit PS748P PS748P PS748P
Mist Lubricators
37
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Basic
Unit Series
Port Size (inches) Bowls
Capacity
Elements
(Micron) Page
1/8 1/4 3/8 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3 Poly Metal Metal
SG 5
F
I
L
T
E
R
S
FF10 X 316 Stainless Steel 4 oz.
(113 ml) Standard 37
10F X X X X X 1 oz.
(28 ml)
Grade 6 Std.,
Grade 10 Opt. 39
C
O
A
L
E
S
C
E
R
S
FF501 X 316 Stainless Steel 1 oz.
(28 ml) Grade 6 41
FF11 X 316 Stainless Steel 4 oz.
(113 ml) Grade 6 43
Product Selection Chart
Basic
Unit Series
Port Size (inches) Spring
Page 1/8 1/4 3/8 1/2 3/4 1 1-1/2 125
R
E
G
U
L
A
T
O
R
S
S
T
A
N
D
A
R
D
FR364 X Standard 45
05R X X Standard 47
FR10 X Standard 49
07R X X X Standard 51
P3NR X X X Standard 53
*Sight gauge
Selection Chart Prep-Air ®
II Air Preparation Units
38
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Product Selection Chart
Basic
Unit Series
Port Size Bowls
Capacity
Elements
(Micron) Spring Range
Page
1/8 1/4 3/8 1/2 3/4 1 1-1/2 Poly Metal Metal
SG 5 125
F
I
L
T
E
R
/
R
E
G
U
L
A
T
O
R
S
14E X X X X N/A 1 oz.
(28 ml) Standard Standard 55
FB548 X 316 Stainless
Steel
1 oz.
(28 ml) Standard Standard 57
06E X X X X X X 4.4 oz.
(125 ml) Standard Standard 59
FB11 X 316 Stainless
Steel
4 oz.
(113 ml) Standard Standard 61
*Sight gauge
Selection Chart Prep-Air ®
II Air Preparation Units
39
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
(Spitter Drain)
The diaphragm in this drain
pulses when there is a pressure differential such as
a valve cycling or cylinder
stroking downstream. This
action flexes the diaphragm
and allows the filter to drain
the entrapped water.
The float internal to this drain
rises with increased liquid
level. When the float rises, it
opens a seat area allowing
the trapped liquids to drain
through the bottom.
A manual override can be
pushed in the bottom of the
drain to unseat the float if
particulates create a block.
Accepts 1/8" NPT 1/8 I.D. Tubing
Accepts
3/16 I.D. Tubing
Automatic Pulse Drain Automatic Float Drain
Air Preparation Units - Drains
40
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
D E
C
B Dia.
Distance Required
To Remove All
Bowls Regardless
of Drain Option
F
A Dia.
Optional Sight Gauge
A1
1/8”
Female
Thread*
Port
Size
NPT without sight gauge NPT with sight gauge
Manual
Twist Drain
Automatic
Float Drain
Manual
Twist Drain
Automatic
Float Drain
1/2" FF10-04DGSS FF10-04DGRSS FF10-04WGSS FF10-04WGRSS
F10 Filter
Dimensions
A
2.38
(60)
A1
2.50
(64)
B
1.75
(44)
C
.56
(14)
D
5.00
(127)
E
5.56
(141)
F
2.12
(54)
inches
(mm)
Features
• Stainless steel construction
handles
most corrosive environments.
• Meets NACE specifications
MR-01-75/ISO 15156.
• 1/8" female threaded drain.
• High Flow: 1/2" - 70 SCFM
(119 Nm3
/hr) §
Air Preparation Units - FF10 Filter - Standard
1/2” NPT Ports
Ordering Information
FF10 - 04 W G SS
Material
SS Stainless Steel
Options
Blank Manual
Twist
Drain
R Automatic
Float
Drain
Element
G 5 Micron
Bowl
D Metal Bowl
without
Sight Gauge
W Metal Bowl
with
Sight Gauge
Port Size
04 1/2 Inch
Port Type
- NPT
§ SCFM = Standard cubic feet per minute at 90 PSIG inlet and 5 PSIG pressure drop.
Nm3
/hr= Normal cubic meters per hour.
41
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
0
1
2
3
4
5
0 10 20 30 40 50 60 70 80
Pressure Drop - PSIG
0
0 5 10 15 20 25 30 35
Flow - SCFM
Flow - dm /s
Pressure Drop - bar
3
n
.1
.2
.3
Flow Characteristics
FF10-04DGSS
1/2 Inch Ports
25 PSIG 50 PSIG 75 PSIG 100 PSIG
Primary Pressure - PSIG
1.7 bar 3.4 bar 5.2 bar 6.9 bar
Primary Pressure - bar
FF10 Filter Kits & Accessories
Drain Kit –
Automatic Float Drain......................................................SA602MDSS
Manual Twist Drain–
Small (Old) ................................................................. SA600Y7-1SS
Large (New) .....................................................................SAP05481
Filter Element Kits –
Particulate (5 Micron) Element..................................................... EK55G
Pipe Nipple – 1/2" 316 Stainless Steel .................................. 616A28-SS
Specifications
Bowl Capacity .............................................................4.0 Ounces (28 ml)
Filter Rating ...............................................................................5 Micron
Sump Capacity .........................................................................1.7 Ounce
Port Threads ...............................................................................1/2 Inch
Pressure & Temperature Ratings –
Manual Twist Drain (D-Bowl)..................0 to 300 PSIG (0 to 20.7 bar)
0°F to 180°F (-18°C to 82°C)
Manual Twist Drain (W-Bowl).................0 to 250 PSIG (0 to 17.2 bar)
0°F to 150°F (-18°C to 66°C)
Automatic Float Drain..............................15 to 175 PSIG (1 to 12 bar)
40°F to 125°F (4°C to 52°C)
Note: Air must be dry enough to avoid ice formation at temperatures
below 32°F (2°C).
Weight.............................................................................. 1.9 lb. (0.85 kg)
Materials of Construction
Body ..........................................................................316 Stainless Steel
Bowls ........................................................................316 Stainless Steel
Deflector ........................................................................................Acetal
Drain .........................................................................316 Stainless Steel
Element Holder .............................................................................Acetal
Filter Element .................................................................... Polyethylene
Seals ..................................................................................Fluorocarbon
Sight Gauge ................................................................................Isoplast
Air Preparation Units - FF10 Air Line Filters
Technical Information
42
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Air Preparation Units - 10F Coalescing Filters - Miniature
1/8”, 1/4” Basic 1/8” Body
Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatic
34
10F Coalescing Filters – Miniature
Prep-Air® II, 10F Series
1/8", 1/4" – Basic 1/8" Body
Catalog 0700P-3/USA
Miniature 10F Series
A
B
D
E
C
Distance Required
To Remove All Bowls
Regardless Of
Drain Option
F
Standard part numbers shown bold, with Grade 6 Elements (for
Grade 10 Elements, replace “E” with “H” in the 6th position). For
other models refer to ordering information below.
‡ For polycarbonate bowl see Caution on page 2.
§ SCFM = Standard cubic feet per minute at 90 PSIG inlet and 5 PSIG
pressure drop.
Nm3
/hr = Normal cubic meters per hour @ 6 barg inlet and 0.34 bar
pressure drop.
Accepts
1/8" Tubing
Automatic Drain
Features
• Removes liquid aerosols and sub-micron particles.
• Liquids gravitate to the bottom of the element
and will not re-enter the airstream.
• Oil free air for critical applications, such as
air gauging and pneumatic instrumentation
and controls.
• Interchangeable twist and
automatic pulse drains.
• Grade 6 element,
99.97% DOP efficiency.
• High Flow: Grade 6 Element
1/8" – 17 SCFM (29 Nm3
/hr) §
1/4" – 20 SCFM (34 Nm3
/hr) §
Grade 10 Element
1/8" – 19 SCFM (32 Nm3
/hr) §
1/4" – 24 SCFM (41 Nm3
/hr) §
10F Coalescing
Filter Dimensions
A
1.69
(43)
B
1.56
(39,6)
C
0.39
(10)
D
3.82
(97)
D†
3.67
(93)
E
4.21
(107)
E†
4.06
(103)
F
1.60
(41)
Port
Size
NPT
Twist Drain Automatic Pulse Drain
Poly Bowl ‡
1/8" 10F01E* 10F05E*
1/4" 10F11E* 10F15E*
Metal Bowl without Sight Gauge
1/8" 10F03E* 10F07E*
1/4" 10F13E* 10F17E*
Inches (mm)
† With Automatic Pulse Drain.
Bowl Options
Polycarbonate Bowl
1 Twist Drain
5 Automatic Pulse Drain
Metal Bowl
3 Twist Drain
7 Automatic Pulse Drain
10F 1 1 E * —
Elements
E Grade 6
H Grade 10
Port Size
0 1/8 Inch
1 1/4 Inch
Ordering Information
Port Type
Blank NPT
1 BSPP
2 BSPT
Engineering
Level
* Will be Entered
at Factory
NOTE: BOLD OPTIONS ARE STANDARD.
10F Coalescing
Filter
Dimensions
A
1.69
(43)
B
1.56
(39,6)
C
0.39
(10)
Inches (mm)
† With Automatic Pulse Drain.
E†
4.06
(103)
F
1.60
(41)
D
3.82
(97)
D†
3.67
(93)
E
4.21
(107)
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
43
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatic
34
10F Coalescing Filters – Miniature
Prep-Air® II, 10F Series
1/8", 1/4" – Basic 1/8" Body
Catalog 0700P-3/USA
Miniature 10F Series
A
B
D
E
C
Distance Required
To Remove All Bowls
Regardless Of
Drain Option
F
Standard part numbers shown bold, with Grade 6 Elements (for
Grade 10 Elements, replace “E” with “H” in the 6th position). For
other models refer to ordering information below.
‡ For polycarbonate bowl see Caution on page 2.
§ SCFM = Standard cubic feet per minute at 90 PSIG inlet and 5 PSIG
pressure drop.
Nm3
/hr = Normal cubic meters per hour @ 6 barg inlet and 0.34 bar
pressure drop.
Accepts
1/8" Tubing
Automatic Drain
Features
• Removes liquid aerosols and sub-micron particles.
• Liquids gravitate to the bottom of the element
and will not re-enter the airstream.
• Oil free air for critical applications, such as
air gauging and pneumatic instrumentation
and controls.
• Interchangeable twist and
automatic pulse drains.
• Grade 6 element,
99.97% DOP efficiency.
• High Flow: Grade 6 Element
1/8" – 17 SCFM (29 Nm3
/hr) §
1/4" – 20 SCFM (34 Nm3
/hr) §
Grade 10 Element
1/8" – 19 SCFM (32 Nm3
/hr) §
1/4" – 24 SCFM (41 Nm3
/hr) §
10F Coalescing
Filter Dimensions
A
1.69
(43)
B
1.56
(39,6)
C
0.39
(10)
D
3.82
(97)
D†
3.67
(93)
E
4.21
(107)
E†
4.06
(103)
F
1.60
(41)
Port
Size
NPT
Twist Drain Automatic Pulse Drain
Poly Bowl ‡
1/8" 10F01E* 10F05E*
1/4" 10F11E* 10F15E*
Metal Bowl without Sight Gauge
1/8" 10F03E* 10F07E*
1/4" 10F13E* 10F17E*
Inches (mm)
† With Automatic Pulse Drain.
Bowl Options
Polycarbonate Bowl
1 Twist Drain
5 Automatic Pulse Drain
Metal Bowl
3 Twist Drain
7 Automatic Pulse Drain
10F 1 1 E * —
Elements
E Grade 6
H Grade 10
Port Size
0 1/8 Inch
1 1/4 Inch
Ordering Information
Port Type
Blank NPT
1 BSPP
2 BSPT
Engineering
Level
* Will be Entered
at Factory
NOTE: BOLD OPTIONS ARE STANDARD.
Air Preparation Units - 10F Coalescing Filters
Technical Information
10F Coalescing Filter Kits & Accessories
Bowl Kits –
Poly Bowl – Automatic Pulse Drain.................................. PS408BP
Twist Drain .......................................................PS404P
Metal Bowl – Automatic Pulse Drain.................................. PS451BP
Twist Drain .................................................. PS447BP
Filter Element Kits – Grade 6 (Standard) ..................................PS446P
Grade 10 (Optional) PS456P
Mounting Bracket Kit PS417BP
Specifications
Automatic Pulse Drain Tube Barb............................................ 1/8 Inch
Bowl Capacity ............................................................... 1 Ounce (28 ml)
Operation –
Normal Operating Pressure Drop ......................... 2 PSIG (0.14 bar)
Maximum Recommended Pressure Drop .......... 10 PSIG (1.03 bar)
(Element should be replaced)
Port Threads ................................................................... 1/8, 1/4 Inch
Pressure & Temperature Ratings –
Polycarbonate Bowl...............................0 to 150 PSIG (0 to 10.3 bar)
32°F to 125°F (0°C to 52°C)
Metal Bowl.............................................0 to 250 PSIG (0 to 17.2 bar)
32°F to 175°F (0°C to 80°C)
Automatic Pulse Drain......................10 to 250 PSIG (0.7 to 17.2 bar)
at 125°F (52°C) or less
Weight ....................................................................... 0.41 lb. (0.18 kg)
Materials of Construction
Body .................................................................................................Zinc
Bowls ......................................................... Transparent Polycarbonate
Metal (Zinc) Without Sight Gauge
Drains – Twist Drain –
Body & Stem ........................................................... Plastic
Seals......................................................................... Nitrile
Automatic Pulse Drain –
Piston & Seals.......................................................... Nitrile
Stem, Seat, Adaptor & Washers ....................... Aluminum
Element Holder .......................................................................... Plastic
Filter Element –
Borosilicate & felt glass fibers 99.97% DOP efficiency
Largest Aerosol Particle Passed (Grade 6) .....................0.01 Micron
Largest Solid Particle Passed (Grade 6) .........................0.30 Micron
Seals ............................................................................................ Nitrile
Grade 6
0 5 10 15 20 25 30 35 40 45 50
35 PSIG 90 PSIG 150 PSIG Primary Pressure - PSIG
2.4 bar 6.2 bar 10.3 bar Primary Pressure - bar
0 5 10 15 20
Flow - SCFM
Flow - dm /s 3
n
Flow Characteristics
10F11H*
1/4 Inch Ports 0
1
2
3
4
5
6
7
8
10
9
Pressure Drop - PSIG
0
.1
Pressure Drop - bar .2
.3
.4
.5
.6
0 5 10 15 20 25 30 35 40 45
35 PSIG 90 PSIG 150 PSIG Primary Pressure - PSIG
2.4 bar 6.2 bar 10.3 bar Primary Pressure - bar
0 5 10 15 20
Flow - SCFM
Flow - dm /s 3
n
Flow Characteristic
10F01E*
1/8 Inch Ports 0
1
2
3
4
5
6
7
8
10
9
Pressure Drop - PSIG
0
.1
Pressure Drop - bar .2
.3
.4
.5
.6
0 5 10 15 20 25 30 35 40 45
35 PSIG 90 PSIG 150 PSIG Primary Pressure - PSIG
2.4 bar 6.2 bar 10.3 bar Primary Pressure - bar
0 5 10 15 20
Flow - SCFM
Flow - dm /s 3
n
Flow Characteristic
10F01E*
1/8 Inch Ports 0
1
2
3
4
5
6
7
8
10
9
Pressure Drop - PSIG
0
.1
Pressure Drop - bar .2
.3
.4
.5
.6
0 5 10 15 20 25 30 35 40 45
35 PSIG 90 PSIG 150 PSIG Primary Pressure - PSIG
2.4 bar 6.2 bar 10.3 bar Primary Pressure - bar
0 5 10 15 20
Flow - SCFM
Flow - dm /s 3
n
Flow Characteristic
10F01H*
1/8 Inch Ports 0
1
2
3
4
5
6
7
8
10
9
Pressure Drop - PSIG
0
.1
Pressure Drop - bar .2
.3
.4
.5
.6
Grade 10
44
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Ordering Information
D
F
C
E
A Dia.
Distance
Required
To Remove
All Bowls
1/8”
Female
Thread*
Port
Size
NPT
Manual Twist Drain
1/4" FF501-02DHSS
F501 Coalescing Filter
Dimensions
A
1.56
(40)
C
0.31
(8)
D
3.69
(94)
E
4.00
(102)
F
1.58
(40)
inches
(mm)
Standard part numbers shown bold. For other models refer to ordering
information below.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
Features
•Stainless steel construction handles
most corrosive environments.
•Meets NACE specifications
MR-01-75/ISO 15156.
• 1/8" female threaded drain*.
• High Flow: 1/4" - 16 SCFM (27 Nm3
/hr) §
Port Type
- NPT
Port Size
02 1/4 Inch
Bowl
D Metal Bowl
without
Sight Gauge
Element
H .3 Micron
Material
SS Stainless Steel
FF501 - 02 D H SS
Air Preparation Units
FF501 Coalescing Filter - Miniature 1/4” Ports
45
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
0
1
2
3
6
7
8
9
10
4
5
0 5 10 15 20 25 30 35
Pressure Drop - PSIG
0
0 5 10 15
Flow - SCFM
Flow - dm /s
Pressure Drop - bar
3
n
.2
.4
.6
Flow Characteristics
F501-02DHSS
1/4 Inch Ports
35 PSIG 90 PSIG 150 PSIG
Primary Pressure - PSIG
2.4 bar 6.2 bar 10.3 bar
Primary Pressure - bar
FF501 Filter Kits & Accessories
Filter Element Kits –
0.3 Micron...................................................................................EKF31
Manual Twist Drain –
Small (Old) ..................................................................... SA600Y7-1SS
Large (New) .........................................................................SAP05481
Pipe Nipple –
1/4" 316 Stainless Steel ......................................................616Y28-SS
Specifications
Bowl Capacity .............................................................1.0 Ounces (28 ml)
Filter Rating ............................................................................0.3 Micron
Port Threads ...............................................................................1/4 Inch
Pressure & Temperature Ratings –
Manual Twist Drain......................................0 to 300 PSIG (0 to 20.7 bar)
0°F to 180°F (-18°C to 82°C)
Note: Air must be dry enough to avoid ice formation at temperatures
below 32°F (2°C)
Sump Capacity .............................................................0.4 Ounce (11 ml)
Weight ............................................................................. 0.6 lb. (0.27 kg)
Materials of Construction
Body ..........................................................................316 Stainless Steel
Bowls ........................................................................316 Stainless Steel
Drain ........................................................................................................
316 Stainless Steel
Element Holder .............................................................................Acetal
Filter Element ............................................................Borosilicate Fiber
Seals ..................................................................................Fluorocarbon
Air Preparation Units - F501 Series Technical Information
46
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Ordering Information
D E
C
B Dia.
Distance Required
To Remove All
Bowls Regardless
of Drain Option
F
A Dia.
Optional Sight Gauge
A1
1/8”
Female
Thread*
F11 Coalescing Filter
Dimensions
A
2.38
(60)
A1
2.50
(64)
B
1.75
(44 )
C
0.56
(14)
D
5.00
(127)
E
5.56
(141)
F
2.12
(54)
inches
(mm)
Features
•Stainless steel construction handles
most corrosive environments.
•Meets NACE specifications
MR-01-75/ISO 15156.
• 1/8" female threaded drain*.
• High Flow: 1/2" - 45 SCFM (77 Nm3
/hr) §
* Beginning January 2008
Material
SS Stainless Steel
Element
J .01 Micron
Port Size
04 1/2 Inch
Port Type
- NPT
G BSPP
FF11 - 04 W J SS
Port
Size
NPT without sight gauge NPT with sight gauge
Manual
Twist Drain
Automatic
Float Drain
Manual
Twist Drain
Automatic
Float Drain
1/2" Metal Bowl With Sight Gauge
F11-04DJSS F11-04DJRSS F11G04WJSS F11G04WJRSS
Options
Blank Manual
Twist
Drain
R Automatic
Float
Drain
Bowl
D Metal Bowl
without
Sight Gauge
W Metal Bowl
with
Sight Gauge
Standard part numbers shown bold. For other models refer to ordering information below.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
Air Preparation Units - FF11 Coalescing Filter Standard
1/2” Ports
47
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
0
1
2
3
6
7
8
9
10
4
5
0 10 20 30 40 50 60 70 80
Pressure Drop - PSIG
0
0 5 10 15 20 25 30 35
Flow - SCFM
Flow - dm /s
Pressure Drop - bar
266HSHSSBA7 EZLS，0-16Mpa，Exd II CT6,1/2"NPTF ABB
Flow Characteristics
FF11-04DJSS
1/2 Inch Ports
35 PSIG 90 PSIG 150 PSIG
Primary Pressure - PSIG
2.4 bar 6.2 bar 10.3 bar
Primary Pressure - bar
F11 Filter Kits & Accessories
266HSHSSBA7 EZLS，0-16Mpa，Exd II CT6,1/2"NPTF ABB
1，桥式控制板64666606 G5330052(DSMB-02C)/Bridge Control Board, (DSMB-02C)
2，整流器辅板\ABB\DSAB-01C 64630199\顶部驱动系列号：534004 KK
3，二极管电源主板DSMB-02C系列号：5350094 KK
4，风机控制板DSMB-01，ABB的部件号为64691929
5，二极管电源连接器DSCB-01C系列号：5260345 KK
6，保护板64703714B
7，ABB电机 M3AA 180 M4
电制要求：
1、电压：480V；
2、频率：60HZ；
3、功率：22KW；
4、转速：1765r/min；
5、额定电流：37.5A，
6、功率因素：cosΦ:0.85；
7、防护等级：IP55，IEC 180 M/L 48；
8、prod code:3GAA182101-BDC.02
8，ABB断路器S202额定电流：4A \ S202P-C4 (DE)
Tested per ISO 12500-1 at 40 ppm inlet.
2
Add dry + wet for total pressure drop.
Grade
Designation
Coalescing
Efficiency
0.3 to 0.6
Micron
Particles
Maximum
Oil
Carryover1
PPM w/w
Micron
Rating
Pressure Drop
PSID (bar)
@ Rated Flow2
Flow:
SCFM
@3 PSID
Operating
Pressure
100 PSIG
Media
Dry
Media
Wet With
10-20 wt. oil
6 99.97% 0.008 0.01 1.0
(0.07)
2-3
(0.14-0.21) ??
10 95% 0.85 1.0 0.5
(0.03) 0.5 (0.03) ??
FF11 Media Specifications
Air Preparation Units - FF11 Series Technical Information
48
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Ordering Information
Features
•Stainless steel construction handles
most corrosive environments.
•Large diaphragm to valve area ratio for
precise regulation and high flow capacity.
•Meets NACE specifications
MR-01-75/ISO 15156.
•High Flow: 1/4" – 12 SCFM (20 Nm3
/hr)§
C1
E1
D
A
Dia.
Material
SS Stainless Steel
Pressure Range
C 0-125 PSIG
(0-8.5 bar)
Port Size
02 1/4 Inch
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
Series Adjustment
Type
Port
Size NPT
FR364 Knob 1/4" FR364-02CSS
R364 Regulator
Dimensions
A
1.56
(40)
C1
2.56
(65)
D
0.50
(13)
E1
3.06
(78)
inches (mm)
NOTE: 1.25 Dia.
(32mm) hole
required for panel
mounting.
FR364 - 02 C SS
Port Type
- NPT
Series
R364 Standard Knob
R364
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
R364
Air Preparation Units - FR364 Regulator -Miniature
1/4” Ports
49
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
R364 Regulator
Dimensions
A
1.56
(40)
C1
2.56
(65)
D
0.50
(13)
E1
3.06
(78)
inches (mm)
NOTE: 1.25 Dia.
(32mm) hole
required for panel
mounting.
0
20
30
50
10
40
60
70
90
80
100
0 2 4 6 8 10 12 14 16 18 20
Pressure Drop - PSIG
0
0 .1 .3 .5 .7 .9 1.1 1.3
Flow - SCFM
Flow - dm /s
Pressure Drop - bar
3
n
1
2
3
4
5
6
Flow Characteristics
1/4 Inch Ports
100 PSIG (6.9 bar Primary Pressure
Operation
Specifications
Gauge Port ..................................................................................1/4 Inch
Operation ....................................................... Fluorocarbon Diaphragm
Port Threads ...............................................................................1/4 Inch
Pressure & Temperature Ratings – ................. 300 PSIG Max (20.7 bar)
40°F to 150°F (4°C to 66°C)
Weight.............................................................................. 0.5 lb. (0.23 kg)
Materials of Construction
Adjustment Mechanism / Springs ...........................316 Stainless Steel
Adjusting Knob (R364) ......................................................Polypropylene
Body ..........................................................................316 Stainless Steel
Bonnet (R364) ................................................................................Acetal
Bottom Plug ..............................................................316 Stainless Steel
Poppet .......................................................................316 Stainless Steel
Seals ..................................................................................Fluorocarbon
FR364 Regulator Kits & Accessories
R364 Bonnet Kit (Knob Included) ........................................CKR364YSS
Gauge –
160 PSIG (0 to 1100 kPa)...........................................K4515N14160SS
Panel Mount Bracket (Stainless)............................................161X57-SS
Panel Mount Nut –
Stainless ............................................................................R05X51-SS
Plastic...................................................................................R05X51-P
Service Kit –
Relieving ............................................................................RKR364YSS
Springs –
0-125 PSIG Range.................................................... SPR-377-1-SS
Technical Information
With the adjusting knob (A) turned fully counter-clockwise (no
spring load), and pressure supplied to the regulator inlet port, the
valve poppet assembly (B) is closed. Turning the adjusting knob
clockwise applies a load to control spring (C). This load causes
the diaphragm (D) and the valve poppet assembly (B) to move
downward allowing flow across the seat area (E) created between
the poppet assembly and the seat. Pressure in the downstream
line is sensed below the diaphragm (D) and offsets the load of
spring (C). As downstream pressure rises, poppet assembly (B)
and diaphragm (D) move upward until the area (E) is closed and
the load of the spring (C) and pressure under diaphragm (D) are
in balance. A reduced outlet pressure has now been obtained,
depending on spring load. Creating a demand downstream, such
as opening a valve, results in a reduced pressure under the diaphragm (D). The load of control spring (C) now causes the poppet
assembly to move downward opening seat area (E) allowing air to
flow to meet the downstream demand. The flow of downstream
air is metered by the amount of opening (E).
Should downstream pressure exceed the desired regulated pressure, the excess pressure will cause the diaphragm (D) to move
upward against control spring (C), open vent hole (F), and vent the
excess pressure to atmosphere through the hole in the bonnet
(H). (This occurs in the relieving type regulator only.)
H
F
E
A
D
C
B
FR364
CAUTION:
REGULATOR PRESSURE ADJUSTMENT –
The working range of knob adjustment is designed
to permit outlet pressures within their full range.
Pressure adjustment beyond this range is also
possible because the knob is not a limiting device.
This is a common characteristic of most industrial
regulators, and limiting devices may be obtained
only by special design.
For best performance, regulated pressure should
always be set by increasing the pressure up to the
desired setting.
Air Preparation Units FR364 Air Line Regulators
Technical Information
50
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Features
• Secondary aspiration plus balanced poppet provides
quick response and accurate pressure regulation.
• Rolling diaphragm for extended life.
• Removable non-rising knob for panel mounting
and tamper resistance.
• Easily serviced.
• Reverse Flow.
• High Flow: 1/4" – 30 SCFM (51 Nm3
/hr)§
3/8" – 40 SCFM (68 Nm3
/hr)§
NOTE: 1.53 Dia. (39mm) hole required for panel mounting.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
A
B PUSH TO LOCK
C
D
E
1/4" NPT
Gauge Ports
(2)
Options
Blank No Options
Preset / Pressure
Limited
Blank None
Port Type
Blank NPT
Port Size
1 1/4 Inch
2 3/8 Inch
Pressure Range
Without Gauge
13 125 PSIG/
8.62 barg
With Gauge**
18 125 PSIG/
8.62 barg
05R 1 13 A * — — ---
Port Size NPT
Without Gauge
1/4" 05R113A*
3/8" 05R213A*
With 160 PSI Gauge
1/4" 05R118A*
3/8" 05R218A*
05R Regulator
Dimensions
A
2.00
(51)
B
2.06
(52)
C
3.16
(80)
D
1.28
(32)
E
4.44
(113)
Inches (mm)
Ordering Information
** Includes 1-1/2"
Dial Face Gauge
Engineering
Level
* Will be
Entered at
Factory
† Inlet Pressure is 100 PSIG.
For other pressures,
contact factory.
Relief
A Relieving
* 1/4 & 3/8 inch
meet ISO 1179-1
Standard.
Air Preparation Units - 05R Regulators - Economy
1/4”, 3/8” NPT - Basic 1/4” Body
51
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Specifications
Gauge Ports (2) ...........................................................................1/4 Inch
Port Threads ........................................................................1/4, 3/8 Inch
Primary Pressure Rating –
Maximum Primary Pressure .......................250 PSIG (17.2 bar) Max.
For Secondary Pressure Ranges see above charts.
Temperature Rating ....................................32°F to 175°F (0°C to 80°C)
Low Temperature .................................-4°F to 125°F (-20°C to 52°C)
Weight ............................................................................ 1.1 lb. (0.49 kg)
Materials of Construction
Adjusting Stem .............................................................................. Brass
Bonnet ...........................................................................................Plastic
Body ...................................................................................................Zinc
Collar, Knob ...................................................................................Plastic
Diaphragm .....................................................................................Nitrile
Poppet & Cap ................................................................................Plastic
Seals ...............................................................................................Nitrile
Springs – Poppet & Control.............................................................Steel
05R Regulator Kits & Accessories
Bonnet Assembly Kit .................................................................. PS915P
Control Knob ................................................................................P04420
Gauges – 1-1/2" Dial Face ????
30 PSIG (0 to 2.1 bar)....................................... K4515N14030
60 PSIG (0 to 4.1 bar)....................................... K4515N14060
160 PSIG (0 to 11.0 bar)................................... K4515N14160
300 PSIG (0 to 20.0 bar)................................... K4515N14300
2" Dial Face
60 PSIG (0 to 4.1 bar) ..................................... K4520N14060
160 PSIG (0 to 11.0 bar) ..................................K4520N14160
Mounting Bracket Kit ................................................................PS963P
Panel Mount Nut – Metal ........................................................... PS964P
Springs – 1-30 PSIG Range ........................................................P04427
1-60 PSIG Range ........................................................P04426
2-125 PSIG Range ......................................................P04425
2-200 PSIG..................................................................P02934
Service Kit – Relieving ............................................................ PS908P
0
15
30
45
60
75
90
105
120
10 0 10 20 30 40 50 60 70 80
Relief and Flow Characteristi cs
05R113A*
5 5 0 10 15 20 25 30 35
Flow (SCFM)
Flow - dm /s 3
n
0
1
Secondary Pressure - PSIG
Secondary Pressure - bar 2
3
4
5
6
7
8
1/4 Inch Ports
Primary Pressure 100 PSIG (6.9 bar)
0
15
30
45
60
75
90
105
120
10 0 10 20 30 40 50 60 70 80
Relief and Flow Characteristi cs 05R213A*
5 5 0 10 15 20 25 30 35
Flow (SCFM)
Flow - dm /s 3
n
0
1
Secondary Pressure - PSIG
Secondary Pressure - bar 2
3
4
5
6
7
8
3/8 Inch Ports
Primary Pressure 100 PSIG (6.9 bar)
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
CAUTION:
REGULATOR PRESSURE ADJUSTMENT – The working
range of knob adjustment is designed to permit outlet
pressures within their full range. Pressure adjustment
beyond this range is also possible because the knob is not
a limiting device. This is a common characteristic of most
industrial regulators, and limiting devices may be obtained
only by special design.
For best performance, regulated pressure should always be
set by increasing the pressure up to the desired setting.
Air Preparation Units 05R Air Line Regulators
Technical Information
52
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Ordering Information
A
B
C
E
D
Features
•Stainless steel construction handles
most corrosive environments.
•Large diaphragm to valve area
ratio for precise regulation and
high flow capacity.
•Meets NACE specifications
MR-01-75/ISO 15156.
•Low temperature version available.
•High Flow: 1/2" – 80 SCFM (136 Nm3
/hr)§
Port
Size NPT
1/2" FR10-04CSS
Material
SS Stainless Steel
Pressure Range
C 0-125 PSIG
(0-8.5 bar)
Port Size
04 1/2 Inch
FR10 - 04 C SS
Port Type
- NPT
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
R10, R11 Regulator
Dimensions
A
2.34
(60)
B
2.43
(62)
C
3.59
(91)
D
1.38
(35)
E
4.97
(126)
inches (mm)
NOTE: 1.75 Dia. (44mm) hole
required for panel mounting.
Series
R10 Standard Knob
R10
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
R10
Air Preparation Units - FR10 Regulator - Standard
1/2” Ports
53
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
0
20
30
50
10
40
60
70
90
80
100
0 10 20 30 40 50 60 70 80 90 100
Pressure Drop - PSIG
0
0 5 10 15 20 25 30 35 40 45
Flow - SCFM
Flow - dm /s
Pressure Drop - bar
3
n
1
2
3
4
5
6
Flow Characteristics
1/2 Inch Ports
100 PSIG (6.9 bar Primary Pressure
Specifications
Gauge Port ..................................................................................1/4 Inch
Operation ....................................................... Fluorocarbon Diaphragm
Port Threads ...............................................................................1/2 Inch
Pressure & Temperature Ratings – ................. 300 PSIG Max (20.7 bar)
0°F to 150°F (-18°C to 66°C)
Note: Air must be dry enough to avoid ice formation at temperatures
below 32°F (2°C).
Weight............................................................................ 1.79 lb. (0.81 kg)
Materials of Construction
Adjustment Mechanism / Springs ...........................316 Stainless Steel
Body ..........................................................................316 Stainless Steel
Bonnet / Knob (R10) ......................................................................Acetal
Bottom Plug ..............................................................316 Stainless Steel
Poppet .......................................................................316 Stainless Steel
Seals ..................................................................................Fluorocarbon
FR10 Regulator Kits & Accessories
R10 Bonnet Kit (Knob Included) ............................................CKR10YSS
Gauge –
160 PSIG (0 to 1100 kPa), 2" Face.............................K4520N14160SS
Panel Mount Bracket (Stainless)............................................161X57-SS
Panel Mount Nut –
Stainless ............................................................................R10X51-SS
Plastic...................................................................................R10X51-P
Service Kit –
Relieving ..............................................................................RKR10YSS
Springs –
0-125 PSIG Range ........................................................ SPR-389-1-SS
Operation
D
A
C
B
H
F
E
Technical Information
With the adjusting knob (A) turned fully counter-clockwise (no
spring load), and pressure supplied to the regulator inlet port, the
valve poppet assembly (B) is closed. Turning the adjusting knob
clockwise applies a load to control spring (C). This load causes
the diaphragm (D) and the valve poppet assembly (B) to move
downward allowing flow across the seat area (E) created between
the poppet assembly and the seat. Pressure in the downstream
line is sensed below the diaphragm (D) and offsets the load of
spring (C). As downstream pressure rises, poppet assembly (B)
and diaphragm (D) move upward until the area (E) is closed and
the load of the spring (C) and pressure under diaphragm (D) are
in balance. A reduced outlet pressure has now been obtained,
depending on spring load. Creating a demand downstream,
such as opening a valve, results in a reduced pressure under
the diaphragm (D). The load of control spring (C) now causes
the poppet assembly to move downward opening seat area (E)
allowing air to flow to meet the downstream demand. The flow of
downstream air is metered by the amount of opening (E).
Should downstream pressure exceed the desired regulated
pressure, the excess pressure will cause the diaphragm (D) to
move upward against control spring (C), open vent hole (F), and
vent the excess pressure to atmosphere through the hole in the
bonnet (H). (This occurs in the relieving type regulator only.)
CAUTION:
REGULATOR PRESSURE ADJUSTMENT –
The working range of knob adjustment is designed
to permit outlet pressures within their full range.
Pressure adjustment beyond this range is also
possible because the knob is not a limiting device.
This is a common characteristic of most industrial
regulators, and limiting devices may be obtained
only by special design.
For best performance, regulated pressure should
always be set by increasing the pressure up to the
desired setting.
Air Preparation Units FR10 Air Line Regulators
Technical Information
54
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
C
E
D
B
A
PUSH TO LOCK
1/4" NPT
Gauge Ports
(2)
Features
• Secondary aspiration plus balanced poppet provides
quick response and accurate pressure regulation.
• Rolling diaphragm for extended life.
• Two high flow 1/4" gauge ports can be used as additional outlets.
• Easily serviced.
• Removable non-rising knob for panel mounting
and tamper resistance.
• High Flow: 3/8" – 70 SCFM (119 Nm3
/hr) §
1/2" – 90 SCFM (153 Nm3
/hr) §
3/4" – 90 SCFM (153 Nm3
/hr) §
NOTE: 2.00 Dia. (51mm) hole required for panel mounting.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
Options
Blank No Options
Preset / Pressure
Limited
Blank None
† Inlet Pressure is 100 PSIG/
6.89 barg. For other
pressures, contact factory.
Port Type
Blank NPT
Port Size
2 3/8 Inch
3 1/2 Inch
4 3/4 Inch
Pressure Range
Without Gauge
13 125 PSIG/
8.6 barg
Relief
A Relieving
07R 3 13 A * — — ---
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
Port Size NPT
Without Gauge
3/8" 07R213A*
1/2" 07R313A*
3/4" 07R413A*
Ordering Information
Engineering
Level
* Will be
Entered at
Factory
07R Regulator
Dimensions
A
3.24
(82)
B
2.74
(70)
C
4.79
(122)
D
1.61
(41)
E
6.40
(163)
Inches (mm)
* 3/8 & 1/2 inch
meet ISO 1179-1
Standard.
Air Preparation Units - 07R Regulators - Standard
3/8”, 1/2”, 3/4” NPT - Basic 1/2” Body
55
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Air Preparation Units - 07R Regulators - Standard
3/8”, 1/2”, 3/4” NPT - Basic 1/2” Body
07R Regulator Kits & Accessories
Bonnet Assembly Kit .................................................................. PS715P
Control Knob ............................................................................. P04069B
Gauges – 60 PSIG (0 to 4.1 bar)...................................... K4520N14060
160 PSIG (0 to 11.0 bar) .................................. K4520N14160
Mounting Bracket Kit(Includes Panel Mount Nut) .................... PS807P
Panel Mount Nut – Plastic ........................................................P04082
Metal....................................................... P04079B
Service Kit – Relieving (Includes Poppet) ............................... PS808P
Springs – 2-125 PSIG Range ...............................................P04063
Tamperproof Kit ......................................................................... PS737P
Specifications
Gauge Ports (2) ...........................................................................1/4 Inch
(Can be used as additional High Flow 1/4 Inch Outlet Ports)
Port Threads .................................................................3/8, 1/2, 3/4 Inch
Primary Pressure Rating –
Maximum Primary Pressure.................................250 PSIG (17.2 bar)
Secondary Pressure Range –
Standard Pressure.................................... 2 to 125 PSIG (0 to 8.6 bar)
Temperature Rating ....................................32°F to 175°F (0°C to 80°C)
Weight 2.5 lb. (1.1 kg)
Materials of Construction
Adjusting Stem ............................................................................... Steel
Body ...................................................................................................Zinc
Bonnet, Piston Stem, Valve Poppet & Cap ..................................Plastic
Collar, Knob ...................................................................................Plastic
Diaphragm .....................................................................................Nitrile
Seals ...............................................................................................Nitrile
Springs – Poppet ....................................................................Stainless
Control...........................................................................Steel
0 0
Relief And Flow Characteristics
07R213A*
10 30 50 70 90 0
20
60
80
40
100
1
2
3
4
5
6
10 110 130
5 1 0 5 4 5 25 35 5 55
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
n
3/8 Inch Ports
100 PSIG (6.9 bar) Primary Pressure
0 0
Relief And Flow Characteristics
07R313A*
10 30 50 70 90 0
20
60
80
40
100
1
2
3
4
5
6
10 110 130
5 1 0 5 4 5 25 35 5 55
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
n
1/2 Inch Ports
100 PSIG (6.9 bar) Primary Pressure
0 0
Relief And Flow Characteristics
07R413A*
10 30 50 70 90 0
20
60
80
40
100
1
2
3
4
5
6
10 110 130 150 17
5 1 0 5 4 5 25 35 5 55 65 75
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
n
3/4 Inch Ports
100 PSIG (6.9 bar) Primary Pressure
CAUTION:
REGULATOR PRESSURE ADJUSTMENT –
The working range of knob adjustment is designed
to permit outlet pressures within their full range.
Pressure adjustment beyond this range is also
possible because the knob is not a limiting device.
This is a common characteristic of most industrial
regulators, and limiting devices may be obtained
only by special design.
For best performance, regulated pressure should
always be set by increasing the pressure up to the
desired setting.
Air Preparation Units 07R Air Line Regulators
Technical Information
56
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Features
• Port blocks (PB) available to provide 1-1/2"
port extension to 1" ported bodies.
• Self relieving feature plus balanced poppet
provides quick response and accurate pressure regulation.
• Solid control piston for extended life.
• High Flow: 3/4" – 200 SCFM (340 Nm3
/hr) §
1" – 300 SCFM (510 Nm3
/hr) §
1½" – 300 SCFM (510 Nm3
/hr) §
B
C
E
D
A
A (PB)
PUSH TO LOCK
1/4" NPT
Gauge Ports
(2)
P3N R A 9 8 B N N
Pressure Gauge
Without Gauge
N 125 PSI (0 to 8 bar)
Adjustment
N Non-Rising
Knob
Relief
B Relieving
Port Size
6 3/4" (w/o
Port Blocks)
8 1" (w/o
Port Blocks)
P 1-1/2" Port
Blocks (w/ 1"
Ported Body)
Port Type
9 NPT Female
Design
Level
NOTE: 2.00 Dia. (51mm) hole required for panel mounting.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
Port Size NPT
Without Gauge
3/4" P3NRA96BNN
1" P3NRA98BNN
1½ P3NRA9PBNN
Ordering Information
P3NR Regulator
Dimensions
A
3.62
(92)
A(PB)
5.91
(150)
B
3.62
(92)
C
6.38
(162)
D
2.08
(53)
E
8.46
(215)
Inches (mm)
* 3/4 & 1 inch meet ISO
1179-1 Standard.
Air Preparation Units - P3NR Regulators - High Flow
3/4”, 1”, 1 1/2” NPT - Basic 1” Body
57
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
† 1" Port Body with 1½" Port Block.
P3NR Regulator Kits & Accessories
Control Knob P3NKA00PN
Gauges – 60 PSIG (0 to 4.1 bar)...................................... K4520N14060
160 PSIG (0 to 11.0 bar) .................................. K4520N14160
Mounting Bracket Kit* .......................................................P3NKA00MW
Service Kit – Relieving ..................................................... P3NKA00RR
Springs – 2-125 PSIG Range ..................................................C10A1308
Specifications
Gauge Ports (2) ...........................................................................1/4 Inch
(Can be used as additional High Flow 1/4 Inch Outlet Ports)
Port Threads ................................................................ 3/4, 1, 1-1/2 Inch
Primary Pressure Rating –
Maximum Primary Pressure ................................250 PSIG (17.2 bar)
Secondary Pressure Range –
Standard Pressure.................................... 2 to 125 PSIG (0 to 8.6 bar)
Temperature Rating ....................................32°F to 175°F (0°C to 80°C)
0
15
30
45
60
75
120
105
90
-100 0 100 200 300 400 500 600
-50 0 50 100 150 200 250
Flow - SCFM
Pressure Drop - PSIG
0
1
Pressure Drop - bar 2
3
4
5
7
6
8
3/4 Inch Ports
Primary Pressure 100 PSIG (6.9 ba
Relief And Flow Characteristi cs
P3NR
Flow - dm /s 3
n
0
15
30
45
60
75
120
105
90
-100 0 100 200 300 400 500 600 700
Pressure Drop - PSIG
0
1
-50 0 50 100 150 200 250 300
Flow - SCFM
Pressure Drop - bar 2
3
4
5
7
6
8
1 Inch Ports
Primary Pressure 100 PSIG (6.9 bar
Relief And Flow Characteristi cs P3NR
Flow - dm /s 3
n
0
15
30
45
60
75
120
105
90
-100 0 100 200 300 400 500 600 700
Pressure Drop - PSIG
0
1
-50 0 50 100 150 200 250 300
Flow - SCFM
Pressure Drop - bar 2
3
4
5
7
6
8
1-1/2 Inch Ports
Primary Pressure 100 PSIG (6.9 bar)
Relief And Flow Characteristi cs
P3NR
Flow - dm /s 3
n
CAUTION:
REGULATOR PRESSURE ADJUSTMENT –
The working range of knob adjustment is designed
to permit outlet pressures within their full range.
Pressure adjustment beyond this range is also
possible because the knob is not a limiting device.
This is a common characteristic of most industrial
regulators, and limiting devices may be obtained
only by special design.
For best performance, regulated pressure should
always be set by increasing the pressure up to the
desired setting.
Weight – 3/4".................................................................... 4.2 lb. (1.9 kg)
1" ....................................................................... 4.2 lb. (1.9 kg)
1½" † ................................................................. 5.3 lb. (2.4 kg)
Materials of Construction
Adjusting Stem ................................................................................Steel
Body .........................................................................................Aluminum
Bonnet .....................................................................................Aluminum
Knob ..............................................................................................Plastic
Piston.............................................................................................Plastic
Poppet Assembly ........................................................................... Brass
Seals ...............................................................................................Nitrile
Springs – Poppet & Control..........................................................Steel
Air Preparation Units - P3NR Air Line Regulators
Technical Information
58
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
14E 1 1 B 13 F * — — ---
Port Size
0 1/8 Inch
1 1/4 Inch
Bowl Options
Polycarbonate Bowl
1 Twist Drain
5 Automatic Drain
Metal Bowl
3 Twist Drain
7 Automatic Drain
Elements
B 5 Micron
Relief
F Relieving
Pressure Range
13 125 PSIG
Port Type
Blank NPT
† Inlet Pressure is 100 PSIG. For
other pressures, contact factory.
Preset / Pressure
Limited
Blank None
Options
Blank No Options
Features
• Excellent water removal efficiency.
• Unbalanced poppet standard.
• Solid control piston for extended life.
• Space saving package offers both filter
and regulator features in one integral unit.
• Non-rising adjustment knob.
• Two full flow 1/8" gauge ports.
• High Flow: 1/8" – 16 SCFM (27 Nm3
/hr) §
1/4" – 18 SCFM (31 Nm3
/hr) §
‡For polycarbonate bowl see Caution on page A2.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
NOTE: 1.218 Dia. (31mm) hole required for panel mounting.
Port
Size
NPT
Twist Drain Automatic Pulse Drain
Poly Bowl‡
1/8" 14E01B13F* 14E05B13F*
1/4" 14E11B13F* 14E15B13F*
Metal Bowl
1/8" 14E03B13F* 14E07B13F*
1/4" 14E13B13F* 14E17B13F*
Ordering
Information
A
B
D
E
C
Distance Required
To Remove All Bowls
Regardless Of
Drain Option
F
1/8" NPT
Gauge Ports
(2)
Accepts
1/8" Tubing
Automatic Dra
14E Filter / Regulator Dimensions
A
1.62
(41)
B
1.58
(40)
C
2.42
(61)
D
3.79
(96)
D†
3.64
(92)
E
6.21
(158)
E†
6.06
(154)
F
1.60
(41)
Inches (mm)
† With Auto Drain
Engineering
Level
* Will be
Entered at
Factory
Air Preparation Units - 14E Filter/Regulator - Miniature
1/8”, 1/4” NPT - Basic 1/8” Body
59
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
14E Filter / Regulator Kits & Accessories
Bowl Kits –
Poly Bowl – Automatic Drain ..............................................PS408BP
Twist Drain......................................................... PS404P
Metal Bowl – Automatic Drain ..............................................PS451BP
Twist Drain.......................................................PS447BP
Filter Element Kits – 5 Micron.................................................. PS403P
Gauges - 30 PSIG (0 to 2.1 bar)....................K4515N18030
60 PSIG (0 to 4.1 bar)....................K4515N18060
160 PSIG (0 to 11.0 bar)................ K4515N18160
Mounting Bracket Kit (Includes Panel Mount Nut) .................PS417BP
Panel Mount Nut .........................................................................P78652
Poppet Kit – Unbalanced......................................................PS424BP
Service Kit – Relieving ............................................................ PS423P
Springs – 2- 125 PSIG Range (Gold)..........................................P01173
Specifications
Automatic Pulse Drain Tube Barb .............................................1/8 Inch
Bowl Capacity .............................................................................1 Ounce
Gauge Ports (2) (Can be used for Full Flow)..............................1/8 Inch
Port Threads ........................................................................1/8, 1/4 Inch
Pressure & Temperature Ratings –
Polycarbonate Bowl
0 to 150 PSIG (0 to 10.3 bar), 32°F to 125°F (0°C to 52°C)
Metal Bowl
0 to 250 PSIG (0 to 17.2 bar), 32°F to 175°F (0°C to 80°C)
Secondary Pressure Ranges –
Standard Pressure.............................. 2 to 125 PSIG (0 to 8.6 bar)
Weight.............................................................................. 0.4 lb. (0.18 kg)
Materials of Construction
Adjusting Nut ................................................................................. Brass
Adjusting Stem & Spring ................................................................Steel
Body ...................................................................................................Zinc
Bonnet, Knob, Seat, Piston, Holder & Deflector ........................Plastic
Bowls Available – Transparent ..................................... Polycarbonate
Metal (Without Sight Gauge) ...........................Zinc
Drains – Manual – Twist Type
Body & Stem.............................................................Plastic
Seals...........................................................................Nitrile
Automatic – Pulse Type
Piston & Seals ...........................................................Nitrile
Stem, Seat, Adaptor & Washers ........................Aluminum
Filter Elements – 5 Micron (Standard)........................................Plastic
Seals ............................................................................................Nitrile
0 0
20
60
80
40
100
1
2
3
4
5
6
0 4 8 12 16 20 24 28 32
0 2 4 6 8 10 12 14
Relief And Flow Characteristics
14E01B13F*
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
n
1/8 Inch Ports
100 PSIG (6.9 bar) Primary Pres
0
0
4 8 12 16 20 24 28 32
0
0
20
60
80
40
100
1
2
3
4
5
6
2 4 6 8 10 12 14
Relief And Flow Characteristics 14E11B13F*
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
n
1/4 Inch Ports
100 PSIG (6.9 bar) Primary Pres
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
CAUTION:
REGULATOR PRESSURE ADJUSTMENT – The working range
of knob adjustment is designed to permit outlet pressures
within their full range. Pressure adjustment beyond this range
is also possible because the knob is not a limiting device. This
is a common characteristic of most industrial regulators, and
limiting devices may be obtained only by special design.
For best performance, regulated pressure should always be set
by increasing the pressure up to the desired setting.
Air Preparation Units - Prep Air II, 14E Filter/Regulators
Technical Information
60
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Reduced
Pressure
Range
C 0-125 PSIG
(0-8.5 bar)
Ordering Information
Features
•Stainless Steel Construction Handles
Most Corrosive Environments
•Large Diaphragm To Valve Area Ratio
For Precise Regulation And High Flow
Capacity
•1/8" Female Threaded Drain*
•Meets NACE Specifications
MR-01-75/ISO 15156.
•High Flow: 1/4" – 12 SCFM (20 Nm3
/hr) §
* Beginning January 2008
D
C1
E1
A Dia.
Distance
Required
To Remove
All Bowls
F
1/8”
Female
Thread
Port
Size NPT
1/4" FB548-02DGCSS
Port Type
- NPT
Port Size
02 1/4 Inch
Bowl
D Metal Bowl
without
Sight Gauge
Element
G 5 Micron
Options
Blank Relieving
Material
SS Stainless Steel
FB548 - 02 D G C SS
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
FB548 Piggyback
Dimensions
A
1.56
(40)
C1
2.17
(55)
D
3.63
(92)
E1
3.06
(78)
F
1.58
(40)
inches (mm)
NOTE: 1.25 Dia. (32mm) hole
required for panel mounting.
B548
Series
B548 Standard
Knob
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
Air Preparation Units - FB548 Filter/Regulator - Miniature
1/4” Ports
61
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
0
20
30
50
10
40
60
70
90
80
100
0 2 4 6 8 10 12 14 16 18 20
Pressure Drop - PSIG
0
0 .1 .3 .5 .7 .9 1.1 1.3
Flow - SCFM
Flow - dm /s
Pressure Drop - bar
3
n
1
2
3
4
5
6
Flow Characteristics
1/4 Inch Ports
100 PSIG (6.9 bar Primar y Pressure
Operation
Specifications
Bowl Capacity ...............................................................1.0 Ounces/28 ml
Filter Rating ...............................................................................5 Micron
Gauge Port ..................................................................................1/4 Inch
Operation ....................................................... Fluorocarbon Diaphragm
Port Threads ...............................................................................1/4 Inch
Pressure & Temperature Ratings – ................. 300 PSIG Max (20.7 bar)
0°F to 150°F (-18°C to 66°C)
Note: Air must be dry enough to avoid ice formation at temperatures
below 32°F (2°C).
Sump Capacity .............................................................0.4 Ounce (11 ml)
Weight.............................................................................. 0.6 lb. (0.27 kg)
Materials of Construction
Adjustment Mechanism / Springs ...........................316 Stainless Steel
Body ..........................................................................316 Stainless Steel
Bonnet (B548) ................................................................................Acetal
Bottom Plug ..............................................................316 Stainless Steel
Knob (B548) ......................................................................Polypropylene
Poppet .......................................................................316 Stainless Steel
Seals ..................................................................................Fluorocarbon
FB548, Regulator Kits & Accessories
FB548 Bonnet Kit (Knob Included) ......................................CKR364YSS
Filter Element Kits –
Particulate (5 Micron).............................................................EK504VY
Gauge –
160 PSIG (0 to 1100 kPa), 2" Face.............................K4515N14160SS
Manual Twist Drain ........................................................... SA600Y7-1SS
Panel Mount Bracket (Stainless)............................................161X57-SS
Panel Mount Nut –
Stainless ............................................................................R05X51-SS
Plastic...................................................................................R05X51-P
Service Kit –
Relieving .............................................................................. RK549YSS
Springs –
0-125 PSIG Range ........................................................ SPR-377-1-SS
Technical Information
L
F
G
D
A
B K
C
E
J
H
Turning the adjusting knob clockwise applies a load to control spring
(B) which forces diaphragm (C) and valve poppet assembly (D) to
move downward allowing filtered air to flow through the seat area
(E) created between the poppet assembly and the seat. “First stage
filtration”. Air pressure supplied to the inlet port is directed through
deflector plate (F) causing a swirling centrifugal action forcing liquids
and coarse particles to the inner bowl wall (G) and down below the
lower baffle (H) to the quiet zone. After liquids and large particles
are removed in the first stage of filtration “second stage filtration”
occurs as air flows through element (J) where smaller particles are
filtered out and retained. The air flow now passes through seat area
(E) to the outlet port of the unit. Pressure in the downstream line is
sensed below the diaphragm (C) and offsets the load of spring (B).
When downstream pressure reaches the set-point, poppet valve
assembly (D) and diaphragm (C) move upward closing seat area (E).
Should downstream pressure exceed the desired regulated pressure,
the excess pressure will cause the diaphragm (C) to move upward
opening vent hole (K) venting the excess pressure to atmosphere
through the hole in the bonnet (L). (This occurs in the standard
relieving type filter/regulators only.)
CAUTION:
REGULATOR PRESSURE ADJUSTMENT – The working range
of knob adjustment is designed to permit outlet pressures
within their full range. Pressure adjustment beyond this range
is also possible because the knob is not a limiting device. This
is a common characteristic of most industrial regulators, and
limiting devices may be obtained only by special design.
For best performance, regulated pressure should always be
set by increasing the pressure up to the desired setting.
Air Preparation Units - FB548 Filter/Regulators
Technical Information
62
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Features
• Space saving package offers both filter and
regulator features for optimal performance.
• Excellent water removal efficiency.
• Rolling diaphragm for extended life.
• Quick response, and accurate pressure regulation
regardless of changing flow or inlet pressure.
• Two high flow 1/4" gauge ports can be used as
additional outlets.
• Shown with recommended metal bowl guard.
• High Flow: 1/4" – 46 SCFM (78 Nm3
/hr) §
3/8" – 55 SCFM (93 Nm3
/hr) §
1/2" – 61 SCFM (104 Nm3
/hr) §
‡For polycarbonate bowl see Caution on page 2.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
NOTE: 2.00 Dia. (50.8 mm) hole required for panel mounting. Max. panel thickness 1/4".
PUSH TO LOCK
A
B
D
E
C
Distance Required
To Remove All Bowls
Regardless Of
Drain Option
F
1/4" NPT
Gauge Ports
(2)
06E 1 2 B 13 A * — — --- Ordering
Information
Port Size
1 1/4 Inch
2 3/8 Inch
3 1/2 Inch
Polycarbonate Bowl
2 Metal Bowl Guard /
Twist Drain
6 Metal Bowl Guard /
Auto Float Drain
Port Type
Blank NPT
Options
Blank No Options
† Inlet Pressure is 100 PSIG.
For other pressures, contact
factory.
Preset
Blank None
Relief
A Relieving
Elements
B 5 Micron
Pressure
Range
13 125 PSIG
Metal Bowl
4 Sight Gauge /
Twist Drain
8 Sight Gauge /
Auto Float Drain
Bowl Options
Port
Size
NPT
Twist Drain Automatic Float Drain
Poly Bowl‡ / Metal Guard
1/4" 06E12B13A* 06E16B13A*
3/8" 06E22B13A* 06E26B13A*
1/2" 06E32B13A* 06E36B13A*
Metal Bowl / Sight Gauge
1/4" 06E14B13A* 06E18B13A*
3/8" 06E24B13A* 06E28B13A*
1/2" 06E34B13A* 06E38B13A*
06E Filter / Regulator
Coalescing filter Article No. 035.5543.700, Drawing No.: 21494h , Specification: ScandGlas TI-APM, 575x575x120 Scandfilter 035.5543.700
Coalescor filter scandfilter Article No 035.5543.700, Drawing no: 21494h, Specification: ScandGlas TI-APM, 575x575x120, reference: project no. 5013, customer: samsung heavy industries project no 7072 po. no a803a00361.Coarse air filter. Scandfilter 035.5543.700
Fine filter TMPC F7 scandfilterArticle No: 385.6521.401 , Drawing no.: 21494h , Specification: Fine filter TMPC F7 592x592x300, reference: project no. 5013, customer: samsung heavy industries project no 7072 po. no a803a00361.Fine air filter. Scandfilter 385.6521.401
FILTER KIT, DALAMATIC p/n 159632 DLM V3/700mm, AISI 304L CONSISTING OF; M08 V4332-DP30-A0051
Filtr Element, p/n 912-2,Doc. V4333-Z-MC-001
CHECK RETURN FILTER ELEMENT, p/n 100002365 Halliburton
FLTR,HYDR,INLINE,2 IN NOM,2 IN NPT (6 PIECE ADVANTAGE HPU OIL TANK FILLER), SAP N 120072768, PN 70.76800 Halliburton
Filter Element Bypass, p/n 100021969 Halliburton
Filter element, p/n 932612 Halliburton
Oil filter № 912-2 Spare Parts List BA-C0960-403
FILTER PRES. REG. AS3-FRE 1,5-8BAR 1/2" p/n 20054938
FILTER ELEMENT, №37485 Spare Parts List for 3 years operation V4141-Z-MC-002
Magnetic filters catchers. Manufacturing Record Book for Anchor and Mooring System Samsung Heavy Industries Co. Ltd. Hull 7072 (draw. 110400V. draw/art № 316989)
"Magnetic bar arr. Manufacturing Record Book for Anchor and Mooring System
Samsung Heavy Industries Co. Ltd. Hull 7075 (draw. 110400H pos. drw. №14. 316989)"
Filter. Filter. Part № F35-0B-C28 (Dwg. MHP2679) Item № 575 Ingersoll Rand F35-0B-C28, F35581-410, http://www.pumpsandinstrumentations.com/F35581-410
Filter. Filter. Part № F35-0B-C28 (Dwg. MHP2679) Item № 575 Ingersoll Rand F35-0B-C28, F35581-410, http://www.pumpsandinstrumentations.com/F35581-410
Filter. Filter. Part № F35-0B-C28 (Dwg. MHP2679) Item № 575 Ingersoll Rand F35-0B-C28, F35581-410, http://www.pumpsandinstrumentations.com/F35581-410
Filter. Filter. Part № F35-0B-C28 (Dwg. MHP2679) Item № 575 Ingersoll Rand F35-0B-C28, F35581-410, http://www.pumpsandinstrumentations.com/F35581-410
Pos. H-10, Breather Filter, Item No. 66029, V4355-D1161-H0003 310948 007L 003P 45/12, 61800593822
Pos. H-10, Breather Filter, Item No. 66029, V4155-D1161-H0003 310948 007L 003P 45/12, 61800593822
Filter insert NOV P/N 69254. Руководство по эксплуатации V4306-Z-MC001.Main tag number 304-BX200. Olmsted P/N 1333
Hydraulic filter element, P/N 150826, Operation/Manual V4160-Z-MC-001 939062Q, 1070Z122A
High pressure filter, P/N 21860, Operation Manual V4167-Z-MC-001 7022010001, 170Z222A
Combinations: Air Filter (UPF)+Regulator (UPR)+Lubricator (UPL), model: U PC400-04DG, port size NPT, 1/2" for Wilden pump U PC400-04DG
FILTER ELEMENT, HYDRAULIC, p/n 21872, Manual V4369-D1117-H0001 7022010001, P567011, HYDAC 1311663.
Filter/Regulator Lubricator Combinations P33CA16GEANGLNW Catalogue PDE2600PNUK 2013 стр 343 P33CA16GEANGLNW
Filter insert NOV P/N 69254. Руководство по эксплуатации V4306-Z-MC001.Main tag number 304-BX200. Olmsted P/N 1333
Filter, p/n 0520123, Operation Manual №29101506 FJE-5-40
Filter Insert, P/N 039513 J.P. Sauer & Sohn Maschinenbau GMBH 1140ZP
Filter Insert, P/N 036395 J.P. Sauer & Sohn Maschinenbau GMBH 036395
Filter element HP, p/n 039 513, Catalogue of SPTA for compressors WP5000 38329992, G7/350ZP
Filter assy, 3" sae flg, w/epoxy cvr & diffuser, P/N 0521151, Operation Manual 29101505 FJE-626802 J B
Filter element, 17 micron, ss ends, fiberglass, 3000 P, P/N 7400688, Operation Manual 29101505 "Pall Corporation
HC9601FDT8HY923"
Filter cartridge, 100 mech size, f/1hfc series, hsg +nn, P/N 20031328, Operation Manual 29101517 "Pall Ultipleat High Fliow
Item: P 2086257
p.n.: HFU620UY1000V"
Filter, suction, 1-1/4", Donaldson, high pressure BOP test unit, P/N SHE-20-1.1/4-100-RV3, drawing № MI7324840-1, № MI7324840-IQ, Operation Manual 29101517 Faifiltri SE095M90BN84
Filter, air, 1"NPT, 50 micron, metal bowl, auto, gen, P/N 0500321, Operation Manual №29101510 "NORGREN
F17-800-A3MA"
Filter, p/n 0520123, Manual №29101506
Filter unit, P/N 29829, Dwg. № V4123-D1105-H1801
Filter element, P/N 69254, Operation/Manual V4123-Z-MC-001 Olmsted P/N 1333
Filter Element Assembly, p/n 0521160, V4338, 29101505, User Manual, Rev A FJE - 626802
Filter cartridge, P/N 69254, Operation/Manual V4106-Z-MC-001 Olmsted P/N 1333
Filtering elements (meshes): perforated stainless steel 316, diameter of holes 10 mm, thickness of sheet 3 mm
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
Secondary Pressure Range –
Standard Pressure............................................... 2 to 125 PSIG (0 to 8.6 bar)
Sump Capacity...................................................................................1.75 Ounces
Weight.............................................................................................1.6 lb. (0.7 kg)
Materials of Construction
Adjusting Stem ............................................................................................. Steel
Body ................................................................................................................Zinc
Bonnet, Internal Parts ...............................................................................Plastic
Bowls Available – Transparent................................................. Polycarbonate
Metal (With or Without Sight Gauge) ..........................Zinc
Bowl Guard ................................................................................................... Steel
Collar ..........................................................................................................Plastic
Diaphragm...................................................................................................Nitrile
Drains – Manual Twist Drain Standard
Body & Nut ............................................................................Plastic
Automatic Float Drain Optional
(Interchangeable for Field Conversions)
Operating Range.............................. 10 to 250 PSIG (.7 to 17.2 bar)
Housing, Float .......................................................................Plastic
Seals .......................................................................................Nitrile
Springs, Push Rod................................................... Stainless Steel
Knob .........................................................................................................Plastic
Filter Elements – 5 Micron (Optional)................................................... Plastic
Seals ....................................................................................Nitrile
Sight Gauge ..........................................................................................Polyamide
Springs – Poppet ................................................................................Stainless
Control...................................................................................... Steel
06E Filter / Regulator Kits & Accessories
Bonnet Assembly Kit................................................................................PS715P
Bowl Guard Kit .........................................................................................PS705P
Bowl Kits –
Poly Bowl – Automatic Float Drain .................................................PS722P
Twist Drain...................................................................PS732P
Metal Bowl – Sight Gauge / Automatic Drain ...................................PS723P
Sight Gauge / Twist Drain............................................PS735P
Control Knob........................................................................................... P04069B
Drain Kit – Automatic Float Drain .................................................PS506P
Twist Drain...................................................................PS512P
Filter Element Kits – 5 Micron................................................................... PS702
Gauges – 60 PSIG (0 to 4.1 bar).........................................K4520N14060
160 PSIG (0 to 11.0 bar) .....................................K4520N14160
Mounting Bracket Kit (Includes Panel Mount Nut)................................PS707P
Panel Mount Nut .......................................................................................P04082
Service Kits – Non-Relieving (Includes Poppet) .................................PS711P
Relieving (Includes Poppet)..........................................PS710P
Seat Insert Kit ..........................................................................................PS713P
Spring – 2- 125 PSIG Range.................................................................P04063
Tamperproof Kit (Key Lock) .....................................................................PS737P
Specifications
Bowl Capacity ....................................................................... 4.4 Ounces (125 ml)
Gauge Ports (2) ........................................................................................1/4 Inch
(Can be used as Additional Full Flow 1/4" Outlet Ports)
Port Threads ............................................................................. 1/4, 3/8, 1/2 Inch
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
4
5
6
Relief And Flow Characteristics
06E32A13A*
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
n
1/2 Inch Ports
100 PSIG (6.9 bar) Primary Pressure
0 0 10 20 30 40 50
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
Relief And Flow Characteristics
06E12A13A*
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
1.25-12G5CJ-F225E-107 6 手动 -
2 1.5-12G5ZJ-F225F-5627 1 DREHMO DMC-59A 42 Nm
3 1.5-12G5CJ-F225F-5112 2 手动 -
4 1.5-12G5ZJ-F225F-5627 1 DREHMO DMC-59A 44 Nm
5 1.5-12G5CJ-F225F-5112 2 手动 -
6 1.5-12G5ZJ-F225F-5627 5 DREHMO DMC-59A 42 Nm
7 1.5-12G5ZJ-F225F-5627 1 DREHMO DMC-59A 42 Nm
8 1.5-12G5CJ-F225F-5112 1 手动 -
9 1.5-12G5CJ-F225F-5112 5 手动 -
10 2.5-13G5ZJ-1058H-7646 1 DREHMO DMC-249A 140 Nm
11 3.0-13G5ZJ-F228H-8618 1 DREHMO DMC-249A 140 Nm
12 3.0-13G5CJ-F228H-8102 1 手动 -
13 1.5-12G5ZJ-F225F-5627 1 DREHMO DMC-59A 43 Nm
14 1.5-12G5ZJ-F225F-5627 1 DREHMO DMC-59A 43 Nm
15 1.5-12G5CJ-F225F-5112 1 手动 -
16 1.5-12G5CJ-F225F-5112 1 手动 -
17 1.5-12G5CJ-F225F-5112 4 手动 -
18 1.5-12G5ZJ-F225F-5627 4 DREHMO DMC-59A 43 Nm
19 1.25-12G5CJ-F225F-110 2 手动 -
20 1.25-12G5ZJ-F225F-4644 1 DREHMO DMC-59A 42 Nm
21 1.25-12G5CJ-F225F-110 2 手动 -
22 1.25-12G5ZJ-F225F-4644 1 DREHMO DMC-59A 44 Nm
23 2.5-13G5CJ-1058H-7107 1 手动 -
24 4.0-13G5CJ-1059J-9101 2 手动 -
25 1.5-12G5ZJ-F225F-5628 1 DREHMO DMC-59A 42 Nm
26 1.25-13G5CJ-F225E-110 1 手动 -
27 1.25-13G5CJ-F915E-109 2 手动 -
28 1.25-12G5CJ-F225F-112 2 手动 -
29 1.5-13G5CJ-F915E-5112 2 手动 -
30 1.5-13G5ZJ-F915E-5647 2 DREHMO DMC-59A 33 Nm
31 1.25-12G5ZJ-F225F-4651 1 DREHMO DMC-59A 42 Nm
32 1.25-13G5ZJ-F915E-4624 1 DREHMO DMC-59A 33 Nm
33 1.5-13G5CJ-F225E-5106 2 手动 -
34 1.25-13G5ZJ-F225E-4625 1 DREHMO DMC-59A 33 Nm
35 1.5-13G5ZJ-F225E-5648 2 DREHMO DMC-59A 33 Nm
36 1.5-12G5CJ-F225E-5106 1 手动 -
37 2.5-14G5CJ-F228G-7106 1 手动 -
38 1.5-12G5ZJ-1055F-5628 1 DREHMO DMC-59A 45 Nm
39 1.5-12G5CJ-1055F-5113 1 手动 -
40 1.5-11G5CJ-1055F-5114 2 手动 -
41 1.5-11G5ZJ-1055F-5629 2 DREHMO DMC-30A 24 Nm
42 1.5-11G5ZJ-F915F-5629 2 DREHMO DMC-30A 24 Nm
43 1.5-11G5CJ-F915F-5114 2 手动 -
44 1.25-11G5ZJ-F915F-4645 1 DREHMO DMC-30A 26 Nm
45 1.25-11G5CJ-F915F-111 1 手动 -
46 1.5-12G5ZJ-F225F-5627 1 DREHMO DMC-59A 44 Nm
47 1.5-12G5CJ-F225F-5112 1 手动 -
48 1.25-11G5ZJ-1055F-4646 1 DREHMO DMC-30A 24 Nm
49 .50-13G4CJ-F913C-1124 5 手动 -
50 .50-13G4CJ-F913C-1125 5 手动 -
51 .50-13G4CJ-F913C-1124 1 手动 -
52 .50-13G4CJ-F913C-1125 1 手动 -
53 .50-11G4CJ-F913D-1127 1 手动 -
54 .50-11G4CJ-F913D-1128 1 手动 -
55 .50-11G4CJ-F913D-1127 3 手动 -
56 .50-11G4CJ-F913D-1128 4 手动
1/4 Inch Ports
100 PSIG (6.9 bar) Primary Pressure
NIM插针 1001020P 500
NIM插孔 10051016S
NIM插座 111-20853-1
NIM插头 111-20654
Relief And Flow Characteristics 06E22A13A*
Secondary Pressure - PSIG
Secondary Pressure - bar
Rated Flow - SCFM
Flow - dm /s 3
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
阀芯\7064415\KAMMER KAMMER
阀座环\706S/N70644154415\7064415\KAMMER KAMMER
气动调节器\43AP-FA45C/IAS-AG/PC/GID\20～100kPa\PI\20～100kPa\200kPa\FOXBORO FOXBORO 1
3/8 Inch Ports
100 PSIG (6.9 bar) Primary Pressure
CAUTION:
REGULATOR PRESSURE ADJUSTMENT – The working range
of knob adjustment is designed to permit outlet pressures
within their full range. Pressure adjustment beyond this range
is also possible because the knob is not a limiting device. This
is a common characteristic of most industrial regulators, and
limiting devices may be obtained only by special design.
For best performance, regulated pressure should always be
set by increasing the pressure up to the desired setting.
Air Preparation Units - 06E Filter/Regulators
Technical Information
64
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Series
FB11 Standard
Knob
Features
•Stainless steel construction
handles most corrosive
environments.
•Large diaphragm to valve
area ratio for precise
regulation and high flow
capacity.
•1/8" female threaded drain.
•Meets NACE specifications
MR-01-75/ISO-15156.
•Low temperature version
available.
•High Flow: 1/2" – 72 SCFM (122 Nm3
/hr) §
Ordering Information
D
E
C
B Dia.
Distance Required
To Remove All
Bowls Regardless
of Drain Option
F
A
Optional Sight Gauge
A1
1/8”
Female
Thread
Port Type
- NPT
Port Size
04 1/2 Inch
Bowl
D Metal Bowl
without
Sight Gauge
W Metal Bowl
with
Sight Gauge
Element
G 5 Micron
Reduced
Pressure
Range
C 0-125 PSIG
(0-8.5 bar)
Options
Blank Relieving
Material
SS Stainless Steel
FB11 - 04 W G C — SS
Port
Size
Adjustment
Type
NPT BSPP
Manual Twist
Drain
Automatic Float
Drain Manual Twist Drain Automatic Float Drain
1/2" Metal Bowl with Sight Gauge
Knob FB11-04WGCSS FB11-04WGCRSS FB11G04WGCSS FB11G04WGCRSS
Standard part numbers shown bold. For other models refer to
ordering information below.
§ SCFM = Standard cubic feet per minute.
Nm3
/hr= Normal cubic meters per hour.
FB11 Piggyback
Dimensions
A
2.34
(60)
A1
2.50
(64)
B
1.75
(44)
C
3.59
(91)
D
5.00
(127)
E
8.59
(218)
F
2.12
(54)
inches (mm)
NOTE: 1.75 Dia. (44mm) hole
required for panel mounting.
B11
FB11
! WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
Air Preparation Units - FB11 Filter/Regulator - Standard
1/2” Ports
65
Compressed Air Filters
www.parker.com/gsf
Material
SS Stainless Steel
Compressed
Air Filters
F
G
J
B
D
K
A
H
C
L
E
0
20
30
50
10
40
60
70
90
80
100
0 10 20 30 40 50 60 70 80 90 100
Pressure Drop - PSIG
0
0 5 10 15 20 25 30 35 40 45
Flow - SCFM
Flow - dm /s
Pressure Drop - bar
3
n
1
2
3
4
5
6
Flow Characteristics
FB11-04DGC-SS
1/2 Inch Ports
100 PSIG (6.9 bar Primary Pressure
Specifications
Bowl Capacity .............................................................4.0 Ounces/114 ml
Filter Rating ...............................................................................5 Micron
Gauge Port ..................................................................................1/4 Inch
Operation ....................................................... Fluorocarbon Diaphragm
Port Threads ...............................................................................1/2 Inch
Pressure & Temperature Ratings –
Metal Bowl (D)............................................... 300 PSIG Max (20.7 bar)
0°F to 150°F (-18°C to 66°C)
Metal Bowl (W) ........................................0 to 250 PSIG (0 to 17.2 bar)
0°F to 150°F (-18°C to 66°C)
Automatic Float Drain..............................15 to 175 PSIG (1 to 12 bar)
40°F to 125°F (4°C to 52°C)
Note: Air must be dry enough to avoid ice formation at temperatures
below 32°F (2°C).
Sump Capacity .........................................................................1.7 Ounce
Weight............................................................................ 2.42 lb. (1.09 kg)
Operation
Technical Information
Turning the adjusting knob clockwise applies a load to control
spring (B) which forces diaphragm (C) and valve poppet assembly
(D) to move downward allowing filtered
air to flow through the seat area (E) created between the poppet
assembly and the seat. “First stage filtration”.
Air pressure supplied to the inlet port is directed through
deflector plate (F) causing a swirling centrifugal action forcing
liquids and coarse particles to the inner bowl wall (G) and down
below the lower baffle (H) to the quiet zone. After liquids and
large particles are removed in the first stage of filtration “second
stage filtration” occurs as air flows through element (J) where
smaller particles are filtered out and retained. The air flow
now passes through seat area (E) to the outlet port of the unit.
Pressure in the downstream line is sensed below the diaphragm
(C) and offsets the load of spring (B). When downstream
pressure reaches the set-point, poppet valve assembly (D)
and diaphragm (C) move upward closing seat area (E). Should
downstream pressure exceed the desired regulated pressure, the
excess pressure will cause the diaphragm (C) to move upward
opening vent hole (K) venting the excess pressure to atmosphere
through the hole in the bonnet (L). (This occurs in the standard
relieving type filter/regulators only.)
CAUTION:
REGULATOR PRESSURE ADJUSTMENT – The working range
of knob adjustment is designed to permit outlet pressures
within their full range. Pressure adjustment beyond this range
is also possible because the knob is not a limiting device. This
is a common characteristic of most industrial regulators, and
limiting devices may be obtained only by special design.
For best performance, regulated pressure should always be
set by increasing the pressure up to the desired setting.
Air Preparation Units - FB11 Filter/Regulators
Technical Information
FB11 Regulator Kits & Accessories
FB11 Bonnet Kit (Knob Included) ..........................................CKR10YSS
Drain Kit –
Automatic Float Drain......................................................SA602MDSS
Manual Twist Drain ........................................................ SA600Y7-1SS
Filter Element Kit –
Particulate (5 Micron).............................................................EKF10VY
Gauge –
160 PSIG (0 to 1100 kPa), 2" Face.............................K4520N14160SS
Panel Mount Bracket (Stainless)...........................................R10Y57-SS
Panel Mount Nut –
Stainless ............................................................................R10X51-SS
Plastic...................................................................................R10X51-P
Service Kit –
Relieving ..............................................................................RKR10YSS
Spring –
0-125 PSIG Range ........................................................ SPR-389-1-SS
Materials of Construction
Adjustment Mechanism / Springs ...........................316 Stainless Steel
Body ..........................................................................316 Stainless Steel
Bonnet / Knob (B11) ......................................................................Acetal
Bottom Plug ..............................................................316 Stainless Steel
Poppet .......................................................................316 Stainless Steel
Seals ..................................................................................Fluorocarbon
Sight Gauge ................................................................................Isoplast
66
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
20-440
20-211
High Capacity Electric Solenoid Drain
The Balston Automatic Drain Assembly, P/N 20-440
automatically removes water from Balston filter housings.
The autodrain consists of a solenoid valve and an automatic timer that can be adjusted to the desired cycle time
and is powered by 120 VAC. To drain receiving tanks,
use any commercially available Y-strainer (ex. Keystone
911 Series or Watts Model 7771) to protect the 20-440.
High Capacity Non-Electrical Float Drain
In the 20-211 design, a sealed stainless steel float operates a needle valve by means of a lever. All internal
parts are stainless steel. The 20-211 drain is a rugged
design for high volumes of liquid.
Normal Capacity Non-Electrical Float Drain
In the 20-402 design, a float rises to operate a pilot-controlled valve when the liquid level in the body of the drain
reaches a predetermined level. The float is reseated by
the force of line pressure as soon as the liquid is drained. 20-402
Principal Specifications and Ordering Information
Model 20-211 20-440 20-402
Port Size 1/2” NPT 1/4” NPT 1/4” NPT
Maximum Pressure 440 psig (27.6 barg) 300 psig (20.7 barg) 200 psig (13.8 barg)
Minimum Pressure 10 psig (0.69 barg) 20 psig (14 barg) 40 psig (2.8 barg)
Maximum Temperature 500°F (260°C) 122°F (50°C) 130°F (54°C)
Shipping Weight 2 lbs. (0.9 kg) 2 lbs. (0.9 kg) 2 lbs. (0.9 kg)
Dimensions 2.5”W X 7.3”L 3”W X 4”L 3”W X 4L
(6cm X 19cm) (7cm X 10cm) (7cm X 10cm)
Automatic Drains - High and Normal Capacity
67
Compressed Air Filters
www.parker.com/gsf
Compressed
What is a zero air loss condensate drain?
Air Filters
Zero air loss condensate drains are designed for economical removal
of unwanted water, oil emulsions, and other liquids. These drains will
only open when liquid is present and will not allow any compressed air
to escape from the system.
• Condensate is always present in a compressed air system.
• If condensate is not removed from a compressed air system, it will
adversely affect product quality and production efficiency and will
eventually lead to costly downtime.
Why are they needed?
How does the Zero Air Loss Condensate drain compare to other drains?
Condensate Removal Method Disadvantages of Other Drains Advantages of ZLD
Manual Drain
(operators must manually open valves to
discharge condensate)
Float Drain
(uses a float connected to a drain valve that
opens when enough condensate is present and
closes when condensate has been removed)
Solenoid Operated
Drain Valves
(uses a timer which allows user to open and
close valve at specified intervals)
• Requires constant attention
• Always leads to excess air loss because air
escapes when the valve is left open to drain the condensate
• Float is susceptible to blockage from particulate
contamination in condensate
• Often sticks in open (leaks excess air) or closed position
(no condensate is drained)
• The period for which the valve is open might not be long
enough for adequate drainage of accumulated condensate
• The valve will operate even if little or no condensate is
present, resulting in air loss
• Often requires a strainer to remove particulate contamination
which can block the inlet and outlet ports
• Automatically drains condensate
• When a minimum level of condensate is reached, the
valve closes in time before compressed air can escape
• Includes an integrated dirt screen between the level
measurement and drain valve to protect the diaphragm
valve
• Particulate contamination is removed by the integrated
dirt screen before fouling the moving parts
• Drain will remove condensate when liquid reaches the
high level sensor
• The drain will not operate until the liquid level reaches
the high level sensor
• Particulate contamination is removed by the integrated
dirt screen before fouling the outlet port
Compressor with Aftercooler Receiver Tank Filter Air Dryer Drip Leg
Removes the condensate that is
collected after the air cools in the
aftercooler
Removes the
condensate that is
collected when the
air cools inside of
the receiver tank
Removes the
condensate
that is
collected in the
filter bowl
Removes the
condensate that is
collected in the air
dryer
Point-of-use applications:
removes the condensate
from compressed air pipes
in a plant
Finite®
Finite®
Finite®
Finite®
Finite®
Where are condensate drains used?
Condensate Drains - Zero Air / Zero Energy Loss
68
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
The cost of compressed air when using a timed drain valve
The annual cost of compressed air was calculated using data from the U.S. Department of Energy and several compressed air consultants. The average annual energy cost to
maintain a compressed air system is 0.23 per 1000 ft3
. If a timed solenoid drain valve opens 3-4 times per hour, the cost of the wasted air will be 80 per valve, per year.
Zero Loss Drains don’t waste any compressed air and have a payback of approximately 6 months - 1 year.
Annual Savings of a Zero Air Loss Drain Versus Timed Solenoid Drain Valves
83
828
1,656
2,484
3,312
4,140
0
500
1,000
1,500
2,000
2,500
3,000
3,500
4,000
4,500
0 10 20 30 40 50
Number of Drain Valves in Facility
Annual Energy Costs
This collection vessel stores condensate until it is drained away.
This electronic level controller continuously monitors the liquid level
inside the drain.
This depicts the electric drain valve. As soon as the electronic level
controller detects a buildup of liquid, the valve opens and condensate is drained. When a minimum liquid level is reached, the valve
closes before compressed air can escape.
The diaphragm valve ensures that contaminants are flushed out
and that the condensate is prevented from forming an emulsion that
would need expensive condensate treatment.
If an error has occurred (i.e. if the condensate cannot be discharged), the electronic control board (5) of the condensate drain
generates an alarm signal. This allows timely detection of a problem
and helps avoid excessive costs associated with condensate carryover to downstream components.
Unique swivel inlet connection for easy adaptability on 20-613 and
20-623. This allows the condensate line to be connected from the
top or the rear. The 20-606 has a fixed inlet port with dynamic seal
which allows the filter bowl to be removed while the drain is attached
(not shown).
An additional liquid inlet on the 20-623 allows for the connection of a
balance or vent line. This provides new connections so that condensate can no longer back up into the feed lines.
6
7
1
3
4
5
2
How does this drain work?
Easy
installation &
servicing!
Condensate Drain - Zero Air / Zero Energy Loss
1
2
4
6
7 3
5
69
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Model
Number
Maximum
Compressor
Capacity
Maximum
Refrigerated
Dryer Capacity*1
Maximum
Filter
Capacity*2
Pressure
Range
Temperature
Range
Connection
Size
Drain Capacity Electrical
Requirement
20-606 Not Recommended Not
Recommended
424 SCFM
(720 m3
/h)
3 - 232 PSIG
(0.2 - 16 bar)
35 -140°F
(2 – 60 °C)
3/8” NPT 6 Gallons/23 liters
per day
120VAC
(60Hz)
20-613 141 SCFM
(240 m3
/h)
283 SCFM
(480 m3
/h)
1413 SCFM
(2,400 m3
/h)
3 - 232 PSIG
(0.2 - 16 bar)
35 -140°F
(2 – 60 °C)
1/2” NPT 13 Gallons/49 liters
per day
120VAC
(60Hz)
20-623 247 SCFM
(420 m3
/h)
494 SCFM
(840 m3
/h)
2472 SCFM
(4,200 m3
/h)
3 - 232 PSIG
(0.2 - 16 bar)
35 -140°F
(2 – 60 °C)
1/2” NPT 23 Gallons/87 liters
per day
120VAC
(60Hz)
*1Based on 100 psi (6.9 bar) working pressure, air compressor inlet at 77°F (25°C) at 60% RH, air discharge temperature of 95°F (35°C) following the aftercooler, pressure
dewpoint of 37°F (2.8°C) after the refrigerated dryer.
*2 Condensate from aftercooler or refrigerated dryer to be drained upstream – only for residual oil content or small quantities of condensate.
Note: Drains are available with BSP threads; 24V/50 - 60Hz versions are available; 24V DC on request. A 6 ft. (2 m) line cord will be included with each drain.
20-606
11 cm
6.66 cm
12.8 cm
14.6 cm
1.2 cm
/0.89 cm
/0.79 cm
Dimensions (Inches/cm)
10.1 cm
6.66 cm
12.1 cm
13.9 cm
1.2 cm
11.1 cm
/0.89 cm
/0.79 cm
Dimensions (Inches/cm)
12.2 cm
4.95 cm
6.66 cm
12.3 cm
1.2 cm
/0.79 cm
/0.89 cm
Dimensions (Inches/cm)
Dimensions and Specifications
20-613 20-623
Condensate Drain - Zero Air / Zero Energy Loss
70
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Balston Differential Pressure Indicator
The Balston Differential Pressure Indicator (DPI)
is used to monitor the pressure drop across the
filters or other components in a compressed air
system. The DPI is sensitive in the range of 0 to
5 psi differential.
Note
1 Installation kit includes fittings and tubing
necessary for line-mounting the 41-070 DPI
Principal Specifications & Ordering Information
Model 41-070 C02-2377
Differential Pressure Indicator 41-070 C02-2377
Indicator and Installation Kit (1) 41-071 N/A
Port Size 1/8” NPT 3/8”-24
Maximum Pressure 250 psig (17.2 barg) 250 psig (17.2 barg)
Maximum Temperature 130°F (54°C) 130°F (54°C)
Dimensions 1.7”W X 1.8”H 2.9”W X 2.25”H
(4cm X 5cm) (7cm X 6cm)
Differential Pressure Indicator Kit
C02-2377
41-070
41-070 Mounted on Filter Assembly
71
Compressed Air Filters
www.parker.com/gsf
Compressed
Air Filters
Model
99XX-05
Models 9922-05, 9933-05, 4433-05 and
9900-05
The 99XX-05 Models are the smallest Disposable Filter Units with 0.4 oz (11.7 ml) internal volume. These
models are used in low flow gas or liquid sampling applications, such as liquids to specific-ion analyzers or
gases to personal samplers. The Model 4433-05 has
1/4” and 3/8” barb connections molded into the inlet/
outlet ports. The 9900-05 and 4433-05 are available
with a color indicator that turns red when saturated
with oil.
Models 9922-11 and 9933-11
Models 9922-11 and 9933-11 are used for applications similar to the smaller DFUs (Models 9922-05 and
9933-05) which require greater solids holding capacity
and can tolerate the increased retention time.
Model 8833-11
These Disposable Filter Units are used as continuous
coalescing filters with a third port serving as the drain,
slip-stream, or by-pass port.
Flow Rates Air Flow at 2 psi (0.14 bar) drop, standard cu. ft. (normal cubic meters) per min. SCFM (Nm3
/hr) at indicated line pressure
Table 1
Filter Volume of Filter Flow Rate (CFM)
Housing Housing Tube At 10” Water Press. 2 psig 20 psig 40 psig 60 psig 80 psig 100 psig 125 psig
Type (CU. FT.) Grade Drop., 0 PSIG (barg) (0.14 barg) (1.4 barg) (2.8 barg) (4.1 barg) (5.5 barg) (6.9 barg) (8.6 barg)
9900-05 DQ 0.2 (0.23) 1.2 (1.40) 2.5 (2.92) 3.9 (2.56) 5.4 (6.32) 6.8 (7.96) 8.3 (9.71) 10.1 (11.82)
9922-05 0.0004
9933-05 BQ/BK (1) 0.1 (0.12) 0.8 (0.94) 1.6 (1.87) 2.6 (3.04) 3.5 (4.09) 4.5 (5.26) 5.4 (6.32) 6.6 (7.72)
4433-05
8822-11 DX 0.4 (0.47) 1.8 (2.11) 3.6 (4.21) 6 (7.02) 8 (9.36) 10 (11.70) 12 (14.04) 14.6 (17.08)
8833-11 0.0007
9922-11 BX 0.2 (0.23) 0.9 (1.05) 1.8 (2.11) 3 (3.51) 4 (4.68) 5 (5.85) 6 (7.02) 7.3 (8.54)
For connections to low pressure plastic tubing
Tubing with 1/4” ID may be slipped over the DFU end fittings and held with tubing
clamps. Parker Hannifin Corp. supplies plastic barbs to connect the DFU to smaller
diameter plastic tubing. The connection is suitable for pressures to 50 psig.
DFU to 1/16” ID tubing P/N 14000 (bag of 20 barbs)
DFU to 1/8” ID tubing P/N 14001 (bag of 20 barbs)
Parker Hannifin Corp. also offers a manual drain valve for removal of coalesced
liquids from the Type 8833-11-DX
Drain Valve 1/8” NPT (male) x 1/8” ID tubing
(requires fitting part 11977)
P/N 20120
Model
9922-05
Model
8833-11
Retention Efficiency
Model Efficiency for 0.01 Micron Particles and Droplets
DX, DQ 93%
BX, BK, BQ 99.99%
Miniature Disposable Filter Units Constructed of
Nylon and PVDF
Installation Information
Compression fittings for 1/4” O.D. tubing may be obtained from the following
manufacturers: Hoke, Inc. (Gyrolock); Crawford Fitting Co.
(Swagelok); Parker-Hannifin Corp. (CPI); Legris, Inc. (push-on
fittings); Jaco Mfg. Co. (plastic fittings).
The following brass fittings seal by O-ring compression and may be completely
recovered and reused when changing filters. They may be purchased from Parker
Hannifin Corp.
Connector 1/4” tubing to 1/4” NPT, female - P/N 11970
Connector 1/4” tubing to 1/4” tubing - P/N 11971
Elbow 1/4” tubing to 1/8” NPT female (for manual drain
on Type 8833-11) - P/N 11972
1 BK = Red color indicator when saturated with oil.
72
Compressed Air Filters
1-800-343-4048
Compressed
Air Filters
Principal Specifications
Model 9922-05 9900-05, 9933-05 4433-05 9922-11 9933-11 8833-11
Inlet and Outlet Ports 1/4” Tubing 1/4” Tubing 1st Tier/Barb 1/4” Tube 1/4” Tubing 1/4” Tubing 1/4” Tubing
2nd Tier/Barb 3/8” Tube
Drain None None None None None 1/4” Tubing
Material of Construction PVDF Nylon Nylon PVDF Nylon Nylon
Filter Cartridge Length 1.25” (3.2 cm) 1.25” (3.2 cm) 1.25” (3.2 cm) 2.25” (5.7 cm) 2.25” (5.7 cm) 2 1/4”
Maximum Temperature 275°F (135°C) (1) 230°F (110°C) (1) 230°F (110°C) (1) 275°F (135°C) (1) 230°F (110°C) (1) 230°F (110°C) (1)
Maximum Pressure 125 psig/8.62 barg (2) 125 psig/8.62 barg (2) 125 psig/8.62 barg (2) 125 psig/8.62 barg (2) 125 psig/8.62 barg (2) 125 psig/8.62 barg (2)
Dimensions 1.0”D X 3.25”L 1.0”D X 3.25”L 1.0”D X 3.43”L 1.4”D X 4.6”L 1.4”D X 4.6”L 1.4”D X 4.6”L
(2.5 cm X 6 cm) (2.5 cm X 6 cm) (2.5 cm X 8.72 cm) (9.1 cm X 12 cm) (9.1cm X 12 cm) (9.1 cm X 12 cm)
Ordering Information
For assistance, call toll-free at 1-800-343-4048 | 8AM to 5PM Eastern Time
Model 9922-05 9900-05 4433-05 9933-05 9922-11 9933-11 8833-11
Filter Cartridges 9922-05-¨ (3) 9900-05-¨ (3) 4433-05-¨ (3) 9933-05-¨ (3) 9922-11-¨ (3) 9933-11-¨ (3) 8833-11-¨ (3)
Box of 10
Available in types Q and X
Notes:
派克过滤器 产品编号035.5543.700，图纸编号：21494h，规格：ScandGlas TI-APM，575x575x120
派克过滤器 产品编号035.5543.700，图纸编号：21494h，规格：ScandGlas TI-APM，575x575x120
派克过滤器 精细过滤器TMPC F7 scandfilter货号：385.6521.401，图号：21494h，规格：精细过滤器TMPC F7 592x592x300
ABB 差压变送器 266HSHQSBA7LSB6TB 266HSHQSBA7LSB6TB
266HSH.Q.S.B.A.7-....LS.....TB 测量范围：0~6MPa HART协议 266HSHQSBA7LSB6TB
266DSH.B.S.H.A.1.A.7-....LS.....TB 测量范围：-0.5~+0.5KPa HART协议 266DSHBSHA1A7LSB1TB
266HSH.P.S.B.A.7-....LS.....TB 测量范围：0~2MPa HART协议 266HSHPSBA7LSB6TB
266HSH.M.S.B.A.7-....LS.....TB测量范围：0~0.1MPa HART协议 266HSHMSBB7LSR1B6TB
266HSHHSBA7LSB6TB可以参考这个型号）
266HSH.E.S.B.A.7-....LS.....TB 测量范围：-2.0~+1.0KPa HART协议 266HSHESBA7LSB6TB
266DSH.F.S.S.A.1.A.7-....LS.....TB 量程0~40KPa刻度范围：0~40t/hHART协议， 266DSHFSS A1A7LSB1TB
266DSH.E.S.S.A.1.A.7-....LS.....TB 量程调整为：0~10KPa刻度范围：0~5000Nm3/h 266DSHESSA1A7LSB1TB
差压变送器 266DSHFSSA1A7LSB1TB
压力变送器 266HSHQSBA7LSB6TB
YCMN-3500C YCMN-3500Z
YCMN-3500C YCMN-3500Z266HSH.Q.S.B.A.7-....LS.....TB 测量范围：0~6MPa HART协议 266HSHQSBA7LSB6TB
266DSH.B.S.H.A.1.A.7-....LS.....TB 测量范围：-0.5~+0.5KPa HART协议 266DSHBSHA1A7LSB1TB
266HSH.P.S.B.A.7-....LS.....TB 测量范围：0~2MPa HART协议 266HSHPSBA7LSB6TB
266HSH.M.S.B.A.7-....LS.....TB测量范围：0~0.1MPa HART协议 266HSHMSBB7LSR1B6TB
266HSHHSBA7LSB6TB可以参考这个型号）
266HSH.E.S.B.A.7-....LS.....TB 测量范围：-2.0~+1.0KPa HART协议 266HSHESBA7LSB6TB
266DSH.F.S.S.A.1.A.7-....LS.....TB 量程0~40KPa刻度范围：0~40t/hHART协议， 266DSHFSS A1A7LSB1TB
266DSH.E.S.S.A.1.A.7-....LS.....TB 量程调整为：0~10KPa刻度范围：0~5000Nm3/h 266DSHESSA1A7LSB1TB
差压变送器 266DSHFSSA1A7LSB1TB
压力变送器 266HSHQSBA7LSB6TB
266HSH.Q.S.B.A.7-....LS.....TB 测量范围：0~6MPa HART协议 266HSHQSBA7LSB6TB
YCMN-3500C YCMN-3500Z
266DSH.B.S.H.A.1.A.7-....LS.....TB 测量范围：-0.5~+0.5KPa HART协议 266DSHBSHA1A7LSB1TB
266HSH.P.S.B.A.7-....LS.....TB 测量范围：0~2MPa HART协议 266HSHPSBA7LSB6TB
266HSH.M.S.B.A.7-....LS.....TB测量范围：0~0.1MPa HART协议 266HSHMSBB7LSR1B6TB
266HSHHSBA7LSB6TB可以参考这个型号）
266HSH.E.S.B.A.7-....LS.....TB 测量范围：-2.0~+1.0KPa HART协议 266HSHESBA7LSB6TB
266DSH.F.S.S.A.1.A.7-....LS.....TB 量程0~40KPa刻度范围：0~40t/hHART协议， 266DSHFSS A1A7LSB1TB
266DSH.E.S.S.A.1.A.7-....LS.....TB 量程调整为：0~10KPa刻度范围：0~5000Nm3/h 266DSHESSA1A7LSB1TB
差压变送器 266DSHFSSA1A7LSB1TB
压力变送器 266HSHQSBA7LSB6TB
3 To designate the grade of filter tube in the DFU, insert Grade letters after DFU designation.
For example, to obtain a grade BQ filter tube in a DFU 9922-05, order: 9922-05-BQ. Please
note the following limitations:
Supplied 变桨驱动器|DCS800
DFU These Grades 变桨驱动器|DCS800||LR106580
4433-05, 9900-05, 9922-05, 9933-05 DQ, BQ, AQ (BK) (4)
9922-11, 9933-11 DX, BX, AQ
8822-11, 8833-11 DX, BX
sick/stegman CNS50-AZA0-S01
siemens 3RV 1901-1A
siemens 3VL3725-2SB36-0AB1
siemens 6ES7 138-4FB02-0AB0 D0_4 F-D0
siemens 6ES7-321-1BH02-0AA0 DI-16DI
siemens 7MD1001-1AA00-1FA0
siemens SIMATIC S7-400 6ES7414-3XJ00-0AB0 CPU 414-3 v1.2.0
sontheimer NLT16/3E Z33
taipack -207 - -207
tmachinery 273000888 P 210 200.1x1.8FH-NG
weidemann 5101001520
wila Wila ( ) BIU-023/1
.
Meets FMVSS-121 requirements.
.
All ports are NPTF unless otherwise noted.
REPLACEMENT PARTS:
For treadle only, see page 49.
DELIVERY 1
DELIVERY 2
Meritor WABCO Haldex Brake Systems (Midland) PORTS MOUNTING STUDS REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N DEL. SUP. THD. LENGTH
RKN22150 961 899 001 0 KN22150 N30099LA 3/8 3/8 5/16-24 5/8 With studs, nuts, lockwashers
RKN22150 961 899 002 0 KN22150 N30099LB 3/8 3/8 — — No studs
RKN22151 961 899 003 0 KN22151 N30099LJ * * — — With stoplight switches
RKN22150 961 899 011 0 KN22150 N30099LA 3/8 3/8 5/16-24 5/8 With studs, nuts, lockwashers. Mack application
RKN22150 961 899 015 0 KN22150 N30099LR 3/8 3/8 M8 x 1.25 mm 7/8 With mounting adaptor
RKN22150 961 899 016 0 KN22150 N30099LS 3/8 3/8 5/16-18 1-inch
PTC = Push-to-Connect .ttings
* = 961 899 003 0 has two delivery and supply port sizes: Delivery 3/8 and 1/2 PTC, Supply 3/8 and 1/2 PTC.
Revised 12-02 Page 10 PB-9926
FOOT OPERATED VALVES Single or Dual Circuit Foot Valve and Pedal
DUAL
.
Features either a single or dual circuit foot valve with pedal attachment.
.
An easy way to replace the entire assembly.
.
Interchanges with competitive models with a minimum of modi.cations.
.
Weight: Single Circuit 3.4 lbs. Dual Circuit 4.4 lbs.
REPLACEMENT PARTS:
For treadle only, see page 49.
KN22501 Pictured
Meritor WABCO Haldex Brake Systems (Midland) PEDAL ANGLE TYPE REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN22600 961 899 004 0 KN22600 N30072FA 45° Single Off-Highway application
RKN22521 961 899 005 0 KN22521 N30072HB 34° Dual N30072HC supersedes N30072GC
RKN22501 961 899 006 0 KN22501 N30072HC 45° Dual N30072HB supersedes N30072GB
RKN22508 961 899 007 0 KN22508 N30072HD 50° Dual
RKN22610 961 899 009 0 KN22610 N30072FC 27° Single Off-Highway application
Revised 12-02 Page 11 PB-9926
GLADHANDS Hose Couplers (Gladhands) Conventional Style
.
Aluminum body/steel face and cast iron units available.
.
Heavy duty aluminum body/steel face units.
.
Economical — helps lower .eet maintenance cost.
.
Universal and polarized con.gurations available for .eet choice.
.
Filtered units help keep air lines free of valve damaging contaminants.
.
Polarized units have the letter “S” or “E” die-cast into the body of the gladhand for easy identi.cation of emergency or service.
.
Steel face is zinc yellow dichromate and aluminum body is chromate conversion coated for corrosion resistance.
.
Interchangeable with competitive gladhands.
.
See page 13 for part numbers.
Revised 12-02 Page 12 PB-9926
GLADHANDS Hose Couplers (Gladhands) Conventional Style
SEALS
TYPE I TYPE II TYPE III
Meritor WABCO Haldex Brake Systems (Midland) MATERIAL COMPOSITION CONFIGURATION SEAL TYPE FILTER
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
R11450 952 899 001 0 11450 N20415MA Aluminum/Steel Universal I No
R11460 952 899 002 0 11460 N20415MB Aluminum/Steel Universal I Yes
R11463 952 899 003 0 11463 N20415MC Aluminum/Steel Universal III Yes
R11402 952 899 004 0 11402 N13048 No Vent Dummy and Chain Assembly — —
R11401 952 899 005 0 11401 N13048A No Vent Dummy and Chain Assembly — —
R11451 952 899 100 0 11451 N20415NA Aluminum/Steel Emergency I No
R11451 952 899 101 0 11451 N20415ND Aluminum/Steel Emergency II No
R11452 952 899 200 0 11452 N20415PA Aluminum/Steel Service I No
R11452 952 899 201 0 11452 N20415PD Aluminum/Steel Service II No
R11465 952 899 202 0 11465 N20415NC Aluminum/Steel Emergency III No
R11464 952 899 203 0 11464 N20415PC Aluminum/Steel Service III No
Revised 12-02 Page 13 PB-9926
GOVERNORS Piston Type Governor
.
Operates in conjunction with the compressor unloading mechanism.
.
Automatically controls the air pressure in the air supply system between the desired predetermined maximum and minimum pressures.
.
Direct compressor or remote governor mounting.
.
Direct replacement for D-2 governor.
.
0.336 diameter mounting holes.
NOTE: Service units are supplied with dust cover.
NOTE: Service units are sent with a factory set cut-in pressure of 105 +5/-0 psi.
NOTE: Service units are sent with all ports open. Plugs are included in the package.
See page 15 for part numbers.
GOVERNORS Piston Type Governor
Meritor WABCO Haldex Brake Systems (Midland) PORT THREAD SIZE RES. PORT THREAD SIZE UNL. PORT THREAD SIZE EXH. CUT-IN PRESSURE (+5.0) PORTS A B C D E F G REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN18530 975 499 001 0 .KN18530 .N30190A 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 95 O O O O O O O —
RKN18532 975 499 002 0 KN18530 N30190AM 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 105 O O O O O O O —
RKN18530 975 499 003 0 KN18530 N30190C 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 105 P P O P P O O —
RKN18531 975 499 004 0 KN18531 N30190H 1/4-18NPTF 1/8-27NPTF 1/8-27NPTF 105 P O P P O O P —
RKN18530 975 499 005 0 KN18530 N30190HA 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 105 O O O O O O O Mack Application
RKN18530 975 499 006 0 KN18530 N30190L 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 105 P P O P P O O —
RKN18530 975 499 007 0 KN18530 N30190GB 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 110 . 10 O O O O O B O Non-Adjusting
RKN18532 975 499 010 0 .KN18532 .N30190AA 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 105 O O O O O B O Water Resistant
RKN18530 975 499 011 0 KN18530 N30190AJ 1/8-27NPTF 1/8-27NPTF 1/8-27NPTF 105 O P P O P O O —
. Service/OEM part numbers appearing in “BOLDFACE” type are exact replacement units. O = Open P = Plugged B = Breather
Revised 12-02 Page 15 PB-9926
HAND OPERATED VALVES Trailer Brake Control
.
In-column mount.
.
Made of durable EGC (Engineering Grade Composite).
.
Handle and knob NOT supplied with service unit.
.
All ports are NPTF unless otherwise noted.
Meritor WABCO Haldex Brake Systems (Midland) PORTS TYPE TRAVEL HANDLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20542 961 799 001 0 KN20542 N30103BL 1/4 Self-Return 70° No
RKN20542 961 799 003 0 KN20542 N30103BF 1/4 Self-Return 70° Yes
RKN20542 961 799 004 0 KN20542 N30103BH 1/4 Self-Return 70° Yes
RKN20541 961 799 005 0 KN20541 N30103BN 1/4 Holding 70° Yes*
RKN20542 961 799 006 0 KN20542 N30103BY 1/4 Self-Return 70° Yes
RKN20545 961 799 007 0 KN20545 N30103FC 3/8 PTC / 1/4 PTC exhaust Self-Return 50° Yes
RKN20546 961 799 010 0 KN20546 N30103BZ 1/4 Self-Return 70° Yes*
RN30103FE 961 799 015 0 N30103FE N30103FE 3/8 PTC / 1/4 PTC exhaust R.H. Drive 50° Yes
RKN20542 967 799 015 0 KN20542 N30103BS 1/4 Self-Return 61° Yes
RKN20541 967 799 016 0 KN20541 N30103BC 1/4 Holding 70° Yes
Revised 12-02 Page 16 PB-9926
PTC = Push-to-Connect .ttings
* Includes mounting brackets
HAND OPERATED VALVES Trailer Brake Control
.
External steering column mount.
.
Handle applies 70° maximum.
.
Chrome handle.
.
All ports 1/4 NPTF.
Meritor WABCO Haldex Brake Systems (Midland) TYPE DESCRIPTION
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20561 961 799 002 0 KN20561 N30161AH Holding With handle, bracket and mounting bolts
RKN20562 — KN20562 N30161AJ Self-Ret. With handle, bracket and mounting bolts
Revised 12-02 Page 17 PB-9926
HAND OPERATED VALVES Trailer Brake Control
.
Panel mount.
.
All ports 1/4 NPTF.
.
Contact original equipment manufacturer for knob replacement not covered below.
.
58° travel.
SUPPLY
Meritor WABCO Haldex Brake Systems (Midland) MAXIMUM DELIVERY TYPE DESCRIPTION
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20580 961 799 011 0 KN20580 N30105B 80 psi Self-Returning With 2-inch lever and knob
RKN20590 961 799 012 0 KN20590 N30105C 50 psi Self-Returning With 2-inch lever and knob
RKN20581 961 799 013 0 KN20581 N30105D Sys. Pres. Holding With 5-inch lever, no knob
RN30105H 961 799 014 0 KN20585 N30105H 65-75 psi Self-Returning With 5-inch lever, no knob
Revised 12-02 Page 18 PB-9926
HAND OPERATED VALVES Single Flipper Style Valves
POSITION A POSITION B
HANDLE Y HANDLE Z
.
Panel mount.
.
Made of durable EGC (Engineering Grade Composite).
.
An on-off, non-automatic two position valve.
.
All ports 1/8 NPTF.
.
All mounting holes are #10-24 except where noted.
.
Mounting holes 1.50-inch centers, except where noted.
.
Weight 0.18 lb.
.
Handle: STYLE Y: Chrome or black .nish
STYLE Z: Bowden wire, 5 swivel, reversible with machine screw
SUPPLY
Meritor WABCO Haldex Brake Systems (Midland) RELEASE POSITION TYPE HANDLE FINISH REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20001 934 190 002 0 KN20001 N13440DA A Y Chrome
RKN20001 934 190 003 0 KN20001 N13440DB A Y Chrome Mounting holes: (1) #10-24, (1) .22 dia.
RKN20001 934 190 004 0 KN20001 N13440DC B Y Black Mounting holes: (1) #10-24, (1) .22 dia.
RKN20041 934 190 005 0 KN20041 N13440DD A Z — Mounting holes: (1) #10-24, (1) .22 dia.
RKN20041 934 190 006 0 KN20001 N13440DJ A Z Chrome (with face plate)
RKN20001 934 190 007 0 KN20001 N13440DL A Y Chrome
RKN20001 934 190 013 0 KN20001 RVN13440DL A Y Chrome
Revised 12-02 Page 19 PB-9926
HAND OPERATED VALVES Double Flipper Style Valves
EXHAUST
DELIVERY
DELIVERY 1DELIVERY 2
.
Panel mount.
.
Directional air control valve.
.
May be used for control of push-pull air cylinders or various other air operated devices.
.
All units supplied with handle.
.
Four mounting holes — #10-24.
.
All ports are NPTF.
.
Applied/Hold Positions (See Chart Below):
1.
3 Position with MANUAL RELEASE ONLY.
2.
3 Position with AUTOMATIC RELEASE when Delivery 2 is APPLIED.
3.
2 Position with MANUAL RELEASE ONLY.
Meritor WABCO Haldex Brake Systems (Midland) PORT SIZES
SERVICE P/N OEM P/N SERVICE P/N OEM P/N APPLIED/HOLD POSITIONS SUPPLY A B DELIVERY 2 PLACES
RKN20080 934 190 008 0 KN20080 N15791D 1 1/4 1/4 1/8
RKN20090 934 190 009 0 KN20090 N15791F 2 1/4 1/4 1/8
RN15791H* 934 190 010 0 N15791H N15791H 2 Plug 1/4 1/8
RN15791T 934 190 011 0 N15791T N15791T 3 1/8 1/8 1/8
RN15791V* 934 190 012 0 N15791V N15791V 2 Plug 1/4 1/8
* With face plate
Revised 12-02 Page 20 PB-9926
HAND OPERATED VALVES Park Brake Valves, 2-Knob
TRACTOR TRACTOREXHAUST
DELIVERY AUX. EXHAUST
DELIVERY AUX. SUPPLY SUPPLY
TRACTOR DELIVERY RESERVOIR 2 TRACTOR RESERVOIR 2
DELIVERY RESERVOIR 1
RESERVOIR 1
.
One piece body construction.
.
Smaller valve size offers more room behind the dash for hoses and accessibility.Made of durable EGC (Engineering Grade Composite). All ports have molded in identi.cation.
.
Direct replacement for the MV2 or MV3 valves.
.
All ports are NPTF unless otherwise noted.
.
Weight 1.5 lbs.
.
Includes red and yellow knobs.
.All have the following PSI performance spec: TRAILER VALVE — 40 ± 5 PARKING VALVE — 30 ± 5 NON-OVERRIDE FUNCTION — 25 ± 5
REPAIR KIT: RRN31BF (Haldex RN31BF)
Meritor WABCO Haldex Brake Systems (Midland) 4-MOUNTING HOLES THREADED INSERTS MOUNTING/ KNOB ORIENTATION PORTS REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20615 934 649 021 0 KN20615 N4400 .28 dia. Horizontal 1/4 —
RKN20606 934 649 022 0 KN20606 N4400M 1/4-20 UNC-2B Horizontal 1/4 Volvo/GM cover part; standard mounting pattern
RKN20607 936 640 012 0 KN20607 N4400S M6 x 1-6H Vertical 3/8 PTC Volvo Application
RKN20603 936 649 003 0 KN20603 N4400G M6 x 1-6H Horizontal 1/4 Metric mounting threads
RKN20612 936 649 004 0 KN20612 N4400A 10-24 UNC-2B Horizontal 1/4 —
RKN20611 936 649 005 0 KN20611 N4400B 1/4-20 UNC-2B Horizontal 1/4 —
RKN20608 936 649 011 0 KN20608 N4400R 1/4-20 UNC28 Horizontal 3/8 PTC Volvo (1/4 NPTF Exhaust)
RKN20622 936 649 018 0 KN20622 N4400BC 5/16 dia. Vertical 3/8 PTC Freightliner Application
RKN20619 936 649 026 0 KN20619 N4400BA .24 dia. Horizontal 3/8 PTC Volvo Application
Revised 12-02 Page 21 PB-9926
PTC = Push-to-Connect
HAND OPERATED VALVES Park Brake Valves, 1-Knob
.
Controls parking/emergency brakes.
.
Bulkhead mount — 7/8-inch. 7/8-inch mounting hole required.
.
Made of durable EGC (Engineering Grade Composite).
.
Won’t rust or corrode.
.
Direct replacement for the PP-1 valve.
.
All ports 1/8-27 NPTF.
Meritor WABCO Haldex Brake Systems (Midland) POP PRESSURE REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20021 936 649 001 0 KN20021 N20960 35 ± 10 psi
RKN20021 936 649 009 0 KN20021 N20960 35 ± 10 psi
RN20960A 936 649 014 0 N20960A N20960A 35 ± 10 psi Truck only
RKN20624 936 649 102 0 KN20624 N4400DC 30 ± 5 psi
Revised 12-02 Page 22 PB-9926
HAND OPERATED VALVES Push-Pull Style Valves
TRAILER AIR SUPPLY VALVE
.
Controls tractor protection valve and trailer parking brakes.
.
Bulkhead mount — 7/8-inch.
.
Made of durable EGC (Engineering Grade Composite).
.
Won’t rust or corrode.
.
Direct replacement for the PP-7.
.
Exhaust and delivery 1/4-18 NPTF.
.
Supply and control 1/8-27 NPTF.
Meritor WABCO Haldex Brake Systems (Midland) POP PRESSURE NON-OVERRIDE PRESSURE REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20025 936 649 002 0 KN20025 N20961 35 psi 25 psi With knob, 7/8” mounting hole required
Revised 12-02 Page 23 PB-9926
HAND OPERATED VALVES Push-Pull Style Valves
.
Controls TRACTOR ONLY parking.
.
Bulkhead mount — 7/8-inch.
.
Made of durable EGC (Engineering Grade Composite).
.
Direct replacement for the PP-8.
.
Will not stay in half-on – half-off position.
.
Won’t rust or corrode.
.
All ports 1/8-27 NPTF.
SUPPLY PORT
DELIVERY PORT 2 PLACES
EXHAUST PORT
Meritor WABCO Haldex Brake Systems (Midland) POP PRESSURE REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20035 936 649 015 0 KN20035 N20964 17.5 ± 12.5 psi With knob, 7/8” mounting hole required
Revised 12-02 Page 24 PB-9926
HAND OPERATED VALVES Push-Pull Style Valves
.
Known as “Hostler Valve.”
.
Panel or bulkhead mount.
.
Requires 3/4-inch mounting hole.
.
1/4 delivery and exhaust ports.
EXHAUST (THREADED)
Meritor WABCO Haldex Brake Systems (Midland) POP PRESSURE REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN20010 934 649 016 0 KN20010 N14488 25/40 psi With N14515 knob
RN14488R 934 649 017 0 N14488R N14488R 0 psi Knob, plate and mounting screws are shipped loose
RKN20020 934 899 013 0 KN20020 N14488AK 25/40 psi No knob (no face plate)
Revised 12-02 Page 25 PB-9926
INVERSION VALVES
2–LINE
PRIMARY SECONDARY
BALANCE PORT CONTROL PORT
DELIVERY PORT
EXHAUST SUPPLY
CHECK VALVE PORT
INVERSION VALVE (2-LINE)
.
All ports NPTF unless otherwise noted.
.
Used prior to March 1, 1998 on any truck or bus brake system.
.
Used after March 1, 1998 on truck or bus brake systems that have two control lines to a rear service relay valve that has a double check built in.
.
Direct replacement for SR-1 valve.
1–LINE
NEW INVERSION VALVE (1-LINE)
. Used after March 1, 1998 on truck or bus brake systems that have one control line to the rear service relay valve.
DELIVERY
TO SPRING
CONTROL
BRAKE
INLET
DASH VALVE SUPPLY
PRIMARY RESERVOIR
SUPPLY
Meritor WABCO Haldex Brake Systems (Midland) LINES REQUIRED PORTS REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N SECONDARY CONTROL PRIMARY BALANCE
RKN28030 971 899 001 0 KN28030 N20950AA Yes No 1/4
RKN28032 971 899 002 0 KN28032 N20950CA Yes Yes 1/4
RKN28030 971 899 004 0 KN28030 N20950AA Yes No 1/4
RKN28030 971 899 005 0 KN28030 N20950AA Yes No 1/4 Mack Application
RKN28033 971 899 007 0 KN28033 N20950CD Yes Yes 1/4 PTC
RKN28034 971 899 008 0 KN28034 N20950AB Yes No 1/4 PTC
Revised 12-02 Page 26 PB-9926
PTC = Push-to-Connect .ttings
PRESSURE RELIEF VALVES
BODY STYLE 1
BODY STYLE 2
.
Made of brass and stainless steel.
.
Won’t rust or corrode.
BODY STYLE 3 BODY STYLE 4 BODY STYLE 5
Meritor WABCO Haldex Brake Systems (Midland) PIPE THREAD SIZE BODY STYLE PSI (Factory Set)
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN31300 963 880 001 0 KN31250 N1178AB 3/8 1 150
RKN31300 963 880 003 0 KN31300 N1178AC 1/2 1 150
RKN31200 963 880 004 0 KN31200 N1178BA 1/4 sealant 1 150
RKN31250 963 880 005 0 KN31250 N1178BB 3/8 sealant 1 150
RKN31250 963 880 006 0 KN31250 N1178BB 3/8 sealant 1 150
RKN31200 963 880 007 0 KN31200 N1178BA 1/4 sealant 1 150
RKN31200 963 880 008 0 KN31200 N1178AA 1/4 1 150
RKN31400 963 880 010 0 KN31400 N1178CA 1/4 2 150
S963 880 011 0 963 880 011 0 — — 1/4 4 Compressor Application, 400°F
S963 880 012 0 963 880 012 0 — — 16 mm 5 150
RKN31528 963 880 020 0 KN31528 N1178EC 1/4 sealant 3 170
Revised 12-02 Page 27 PB-9926
QUICK RELEASE VALVES
.
Used wherever a quick release function is required in the air brake system.
.
Made of durable EGC (Engineering Grade Composite).
.
Corrosion and weather resistant.
.
Utilizes an oil resistant diaphragm for longer life.
.
Aids in meeting FMVSS-121 timing requirements.
.
Direct replacement for competitive models, including QR-1, QRN and QRN-2.
.
All ports are NPTF unless otherwise noted.
INLET
OUTLET (DELIVERY)
OUTLET (DELIVERY)
Meritor WABCO Haldex Brake Systems (Midland) INLET PORT OUTLET DELIVERY PORTS DIFFERENTIAL PSI
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN32060 973 899 001 0 KN32060 N20959DB 3/8 3/8 6
RKN32011 973 899 002 0 KN32011 N20959EA 1/2 3/8 0
RKN32005 973 899 003 0 KN32005 N20959EB 3/8 3/8 0
RKN32006 973 899 004 0 KN32006 N20959HB 3/8 3/8 3
RKN32003 973 899 007 0 KN32003 N20959HA 1/2 3/8 3
RKN32050 973 899 008 0 KN32050 N20959DA 1/2 3/8 6
RKN32071 973 899 010 0 KN32071 N20959LA 1/2 PTC 3/8 PTC 0
RKN32011 973 899 011 0 KN32011 N20959MA 1/2 3/8 0
Revised 12-02 Page 28 PB-9926
QUICK RELEASE VALVES
(continued)
Meritor WABCO Haldex Brake Systems (Midland) INLET PORT OUTLET DELIVERY PORTS DIFFERENTIAL PSI
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN32003 973 899 012 0 KN32003 N20959HC 3/8 3/8 3
RKN32008 973 899 013 0 KN32008 N20959ME 1/2 PTC 1/2 PTC 0
RKN32014 973 899 019 0 KN32014 N20959MF 1/2 1/2 PTC 0
RKN32061 973 899 020 0 KN32061 N20959NE 1/2 PTC, 90° 1/2 PTC 3
RKN32062 973 899 021 0 KN32062 N20959NF 1/2 PTC, 90° 1/2 PTC 6
RKN32015 973 899 022 0 KN32015 N20959MH 1/2 PTC, 90° 1/2 PTC 0
PTC = Push-to-Connect .ttings 90° = Elbow
Revised 12-02 Page 29 PB-9926
QUICK RELEASE VALVES Quick Release Valve with Two-Way Check
.
Used in spring brake control circuits to prevent compounding on trucks and tractors.
.
Contains a quick release valve with a built-in two-way check valve.
.
Replaces two valves with one.
.
The diaphragm and disc are oil resistant for longer life.
.
1.50-inch mounting centers.
.
Direct replacement for QR-1C valve.
.
All ports are NPTF unless otherwise noted.
Meritor WABCO Haldex Brake Systems (Midland) INLET OR CONTROL DELIVERY BRACKET POSITION
SERVICE P/N OEM P/N SERVICE P/N OEM P/N 1 — FROM PARK CONTROL VALVE 2 — FROM REAR AXLE SERVICE BRAKE
RKN32041 934 099 010 0 KN32041 N20952AD 1/4 1/4 3/8 3/8 Up
RKN32041 934 099 015 0 KN32041 N20952AF 1/4 1/4 3/8 3/8 Up (Volvo)
RKN32041 934 099 020 0 KN32041 N20952AE 1/4 1/4 3/8 3/8 Down
RKN32040 934 099 024 0 KN32040 N20952AB 1/4 1/4 1/4 1/4 Up
RKN32043 934 099 026 0 KN32043 N20952BA 3/8 PTC 3/8 PTC 3/8 3/8 Up
PTC = Push-to-Connect .ttings
Revised 12-02 Page 30 PB-9926
QUICK RELEASE VALVES In-Line
.
Valve designed for mounting in-line at the tractor protection valve or at the tractor’s gladhand, in either the service or supply line, on heavy truck air brake systems.
.
Style A available with or without .ttings.
.
See page 32 for part numbers.
QUICK RELEASE VALVES In-Line
Meritor WABCO NIPPLE TRACTOR SIDE VIBRA-SEAL TRACTOR SIDE NIPPLE OR BUSHING TRAILER SIDE VIBRA-SEAL TRAILER SIDE PROTECTIVE SCREEN VALVE STYLE
SERVICE P/N OEM P/N
S973 899 023 0 973 899 023 0 No No Yes No Yes A
S973 899 024 0 973 899 024 0 No No Yes No Yes A
S973 899 025 0 973 899 025 0 Yes Yes No No Yes A
S973 899 026 0 973 899 026 0 Yes Yes No No Yes A
S973 899 027 0 973 899 027 0 Yes Yes No No Yes A
S973 899 028 0 973 899 028 0 Yes Yes No No Yes A
S973 899 029 0 973 899 029 0 No No Yes No Yes A
S973 899 030 0 973 899 030 0 No No Yes Yes Yes A
S973 899 031 0 973 899 031 0 No No Yes Yes Yes A
S973 899 032 0 973 899 032 0 Yes Yes No No Yes A
S973 899 033 0 973 899 033 0 Yes Yes No No Yes A
S973 899 034 0 973 899 034 0 No No Yes Yes Yes A
S973 899 035 0 973 899 035 0 No No Yes No No A
S973 899 036 0 973 899 036 0 No No No No Yes A
S973 899 037 0 973 899 037 0 No No No No Yes A
S973 899 038 0 973 899 038 0 Yes Yes Yes No Yes B
Revised 12-02 Page 32 PB-9926
REGULATING VALVES Air Regulating Valves
ADJUSTABLE
.
For auxiliary systems only. Not used in the brake system.
.
Used in air systems where reduced levels are required.
.
Pressure settings are based on 100 psi supply. Factory pre-set as charted.
.
Designed for constant supply, not on-off applications.
.
A popular use is with air cylinders on bus door operators.
Meritor WABCO Haldex Brake Systems (Midland) FACTORY PRESSURE SETTING (± 5 PSI) INLET OUTLET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RN15817A 934 499 001 0 RN15817A N15817A 20 psi 1/4 1/4 A
RKN31050 934 499 002 0 KN31050 N15817E 40 psi 1/4 1/4 A
RKN31050 934 499 003 0 KN31050 N15817F 45 psi 1/4 1/4 A
RKN31060 934 499 004 0 KN31060 N15817M 75 psi 1/4 1/4 A
RKN31060 934 499 005 0 KN31060 N15817K 65 psi 1/4 1/4 A
RN13680BC 934 499 006 0 N13680BC N13680BC 35 psi 3/8 1/4 B
RKN31082 934 499 007 0 KN31082 N13680BK 85 psi 3/8 1/4 B
RKN31080 934 499 008 0 KN31080 N13680BL 60 psi 3/8 1/4 B
RN13680BZ 934 499 009 0 N13680BZ N13680BZ 50 psi 3/8 1/4 B
RKN31050 934 499 010 0 KN31050 N15817G 50 psi 1/4 1/4 A
RKN31081 934 499 012 0 KN31081 N13680BD 100 psi 3/8 1/4 B
Revised 12-02 Page 33 PB-9926
RELAY VALVES Bracket Styles
RELAY VALVES RG-2
.
Meets or exceeds all FMVSS-121 timing requirements.
.
Cover may be rotated without affecting performance or warranty.
.
One 1/2-inch pipe plug is included.
.
All ports are NPTF unless otherwise noted.
Meritor WABCO Haldex Brake Systems (Midland) CONTROL SUPPLY DELIVERY CRACK PRESSURE COVER POSITION BRACKET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G H
RKN28520 973 298 014 0 KN28520 N30108AH 1/4 1/2 plug 1/2 1/2 6.0 psi 90° I
RKN28500 973 298 015 0 KN28500 N30108BC 1/4 3/8 3/8 3/8 3/8 6.0 psi 90° I
RKN28510 973 298 016 0 KN28510 N30108BL 1/4 1/2 plug 3/8 3/8 6.0 psi 90° I
RKN28500 973 298 022 0 KN28520 N30108A 1/4 1/2 plug 1/2 1/2 6.0 psi 90° I
Revised 12-02 Page 35 PB-9926
RELAY VALVES Service
.
A multi-purpose, high capacity, straight relay.
.
Meets or exceeds all FMVSS-121 timing requirements.
.
All ports are NPTF unless otherwise noted.
Meritor WABCO Haldex Brake Systems (Midland) CONTROL SUPPLY DELIVERY CRACK PRESSURE COVER POSITION BRACKET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G H
RKN28060 973 298 004 0 KN28060 N30096F 3/8 1/2 1/2 3/8 3/8 4.6 psi 0° I
RKN28061 973 298 005 0 KN28061 N30096J 3/8 1/2 1/2 1/2 1/2 4.6 psi 180° I
RKN28061 973 298 006 0 KN28061 N30096L 3/8 1/2 1/2 1/2 1/2 4.6 psi 0° I
RKN28061 973 298 007 0 KN28061 N30096M 3/8 1/2 plug 3/8 3/8 4.6 psi 0° I
RKN28080 973 298 008 0 KN28080 N30096N 3/8 1/2 plug 3/8 3/8 3/8 3/8 7.0 psi 0° I
Revised 12-02 Page 36 PB-9926
RELAY VALVES Service
(continued)
Meritor WABCO Haldex Brake Systems (Midland) CONTROL SUPPLY DELIVERY CRACK PRESSURE COVER POSITION BRACKET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G H
RKN28085 973 298 009 0 KN28085 N30096P 3/8 1/2 plug 3/8 3/8 3/8 3/8 4.6 psi 0° I
RKN28300 973 298 010 0 KN28300 N30096PA 3/8 1/2 1/2 1/2 1/2 0 psi I
RKN28061 973 298 011 0 KN28061 N30096T 3/8 1/2 1/2 1/2 1/2 7.0 psi 0° I
RN30106C 973 298 012 0 N30106C N30106C 1/4 1/2 1/2 1/2 1/2 7.0 psi 270° A
RKN28131 973 298 013 0 KN28131 N30106F 1/4 1/2 1/2 1/2 1/2 4.0 psi 270° A
RKN28140 973 298 020 0 KN28140 N30100AP 1/4 1/2 plug 1/2 1/2 4.6 psi 0° B
RKN28132 973 298 021 0 KN28132 N30106D 3/8 1/2 1/2 1/2 1/2 7.0 psi 0° I
RKN28066 973 298 035 0 KN28066 N30100JA 1/4 1/2 1/2 1/2 1/2 1/2 1/2 4.6 psi 0° D
RKN28067 973 298 036 0 KN28067 N30100JB 1/4 1/2 1/2 1/2 1/2 1/2 1/2 4.6 psi 0° E
RKN28066 973 298 037 0 KN28066 N30100JC 1/4 1/2 1/2 1/2 1/2 1/2 1/2 4.6 psi 0° F
RKN28066 973 298 038 0 KN28066 N30100JD 1/4 1/2 1/2 1/2 1/2 1/2 1/2 4.6 psi 0° J
RKN28086 973 298 051 0 KN28086 N30096FA 3/8 PTC 5/8 PTC 5/8 PTC 3/8 PTC 3/8 PTC 4.6 psi 0° I
RKN28087 973 298 052 0 KN28087 N30096FB 3/8 PTC 5/8 PTC 5/8 PTC 1/2 PTC 1/2 PTC 4.6 psi 0° I
RKN28088 973 298 053 0 KN28088 N30096FC 3/8 PTC 5/8 PTC 5/8 PTC 3/8 PTC 3/8 PTC 3/8 PTC 3/8 PTC 4.6 psi 0° I
RKN28089 973 298 054 0 KN28089 N30096FD 3/8 PTC 5/8 PTC 5/8 PTC 1/2 PTC 1/2 PTC 1/2 PTC 1/2 PTC 4.6 psi 0° I
RKN28085 973 298 056 0 KN28085 N30100JE 1/4 1/2 1/2 1/2 1/2 1/2 1/2 4.6 psi 0° G
RKN28064 973 298 060 0 KN28064 N30100JF 1/4 1/2 1/2 1/2 1/2 1/2 1/2 4.6 psi 0° C
PTC = Push-to-Connect .ttings
Revised 12-02 Page 37 PB-9926
RELAY VALVES Service with Optional Top Port Control
.
Meets or exceeds all FMVSS-121 timing requirements.
.
Cover may be rotated without affecting performance or warranty.
.
All ports are NPTF unless otherwise noted.
NOTE: 973 898 005 0 relay valve is NOT illustrated.
CONTROL A
CONTROL B
SUPPLY SUPPLY
CD
DELIVERY DELIVERY HG DELIVERY DELIVERY EF
Meritor WABCO Haldex Brake Systems (Midland) CONTROL SUPPLY DELIVERY CRACK PRESSURE COVER POSITION BRACKET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G H
RKN28065 973 898 001 0 KN28065 N30100AR 1/4 1/4 1/2 1/2 1/2 1/2 4.6 psi 90°/270° B
RKN28140 973 898 005 0 KN28140 N30100AG 1/4 1/4 plug 1/2 1/2 1/2 4.6 psi 270° B
Revised 12-02 Page 38 PB-9926
RELAY VALVES Service with Biased Pressure
.
High capacity.
.
Meets or exceeds all FMVSS-121 timing requirements.
.
Includes double check valve for truck and bus rear service system.
.
Direct replacement for R-12DC.
Meritor WABCO Haldex Brake Systems (Midland) CONTROL SUPPLY DELIVERY CRACK PRESSURE COVER POSITION BRACKET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G H
RKN30111 973 298 031 0 RN30111 N30111 1/4 1/4 1/2 1/2 1/2 1/2 1/2 1/2 0° J
RKN28051 973 298 032 0 KN28051 N30111A 1/4 1/4 1/2 1/2 1/2 1/2 1/2 1/2 Primary control port 0° D
RKN28051 973 298 033 0 KN28051 N30111B 1/4 1/4 1/2 1/2 1/2 1/2 1/2 1/2 4.6 psi 0° E
RKN28052 973 298 034 0 KN28052 N30111C 1/4 1/4 1/2 1/2 1/2 1/2 1/2 1/2 0° F
RKN28055 973 298 048 0 KN28055 N30111D 1/4 1/4 1/2 1/2 1/2 1/2 1/2 1/2 Secondary 0° B
RKN28055 973 298 050 0 KN28055 N30111E 1/4 1/4 1/2 1/2 1/2 1/2 control port 9.6 psi 0° B
RKN28053 973 298 057 0 KN28053 N30111F 1/4 1/4 1/2 1/2 1/2 1/2 1/2 1/2 0° G
Revised 12-02 Page 39 PB-9926
RELAY VALVES Spring with Double Check Valve
.
Low differential — high capacity.
.
Meets or exceeds all FMVSS-121 timing requirements.
.
Bracket style may be down (as illustrated) or up.
.
Includes double check valve for anti-compounding in spring brake system.
.
Direct replacement for R-14.
SUPPLY D
(DELIVERY H*) DELIVERY F
DELIVERY E
*When used
Meritor WABCO Haldex Brake Systems (Midland) CONTROL SUPPLY DELIVERY CRACK PRESSURE COVER POSITION BRACKET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G H
RKN28071 973 298 001 0 KN28071 N30100AD 1/4 1/8 1/2 plug 1/2 1/2 4.6 psi 90° B down
RKN27502 973 298 017 0 KN27502 N30100LC 3/8 PTC 3/8 PTC plug 1/2 1/2 1/2 4.6 psi 90° B down
RKN28072 973 298 040 0 KN28072 N30100KA 1/4 1/8 plug 1/2 1/2 1/2 4.6 psi 90° B down
RKN28072 973 298 041 0 KN28072 N30100KB 1/4 1/8 1/2 plug 1/2 1/2 4.6 psi 90° B up
RKN28043 973 298 042 0 KN28043 N30100KC 1/4 1/8 1/2 plug 1/2 1/2 4.6 psi 270° B down
RKN28073 973 298 043 0 KN28073 N30100KD 1/4 1/8 1/2 plug 1/2 1/2 4.6 psi 90° E down
RKN28074 973 298 044 0 KN28974 N30100KE 1/4 1/8 1/2 plug 1/2 1/2 4.6 psi 90° F
Revised 12-02 Page 40 PB-9926
RELAY VALVES Spring with Double Check Valve
(continued)
Meritor WABCO Haldex Brake Systems (Midland) CONTROL SUPPLY DELIVERY CRACK PRESSURE COVER POSITION BRACKET STYLE
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G H
RKN28074 973 298 045 0 KN28074 N30100KF 1/4 1/8 1/2 1/2 1/2 1/2 4.6 psi 90° H
RKN28073 973 298 046 0 KN28073 N30100KG 1/4 1/8 1/2 plug 1/2 1/2 4.6 psi 90° E
RKN28074 973 298 047 0 KN28074 N30100KH 1/4 1/8 1/2 1/2 1/2 1/2 4.6 psi 270° J
RKN28041 973 298 055 0 KN28041 N30100MA 1/4 1/8 1/2 plug 1/2 1/2 1/2 1/2 4.6 psi 270° B
RKN28069 973 298 058 0 KN28069 N30100MB 1/4 1/4 1/2 1/2 3/8 3/8 3/8 3/8 4.6 psi 0° G
RKN28063 973 298 061 0 KN28063 N30100MC 1/4 1/4 1/2 1/2 3/8 3/8 3/8 3/8 4.6 psi 0° C
RKN28140 973 898 006 0 KN28071 N30100HH 1/4 1/8 1/2 1/2 1/2 1/2 4.6 psi 0° I
PTC = Push-to-Connect .ttings
Revised 12-02 Page 41 PB-9926
TRACTOR PROTECTION VALVESTractor Protection Valves Two-Line
.
Two-line non-automatic.
.
Must be used with pressure sensing dash control valve.
.
Quick release feature eliminates the need for an extra valve.
.
Will not allow trailer brake compounding.
.
Direct replacement for the TP-3 valve.
.
All ports are NPTF unless otherwise noted.
TRACTOR EMERGENCY
Meritor WABCO Haldex Brake Systems (Midland) TRACTOR SERVICE TRACTOR EMERGENCY TRAILER SERVICE TRAILER EMERGENCY
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RKN34061 934 899 002 0 KN34061 N20949CF 3/8 1/4 1/2 1/2
RKN34060 934 899 011 0 KN34060 N20949CA 3/8 1/4 1/2 1/2
RKN34065 939 899 029 0 KN34065 N20949DA 3/8 PTC 3/8 PTC 1/2 1/2
PTC = Push-to-Connect .ttings
Revised 12-02 Page 42 PB-9926
TRACTOR PROTECTION VALVESTractor Protection Valves Two-Line (Manifold Style)
. Includes: tractor protection, two double check valves, stoplight switch
port, and built-in quick release, all in one valve.
PORT E
.
Can replace up to four valves on competitive systems.
.
All ports are NPTF unless otherwise noted.
PORT B
COVER IS SHOWN AT 0°
FOOT CONTROL TRAILER HAND
Meritor WABCO Haldex Brake Systems (Midland) PORTS EXHAUST FITTINGS (H) REMARKS COVER POSITION
SERVICE P/N OEM P/N SERVICE P/N OEM P/N A B C D E F G
RKN34110 934 899 003 0 KN34110 N30162MA 3/8 3/8 3/8 1/4 1/2 1/2 3/8 YES TRAC. EM 3/8 0°
RKN34110 934 899 009 0 KN34110 N30162PA 3/8 3/8 3/8 1/4 1/2 1/2 1/2 YES TRAC. EM 3/8 0°
RKN34130 934 899 010 0 KN34130 N30162PC 3/8 3/8 3/8 1/4 1/2 1/2 3/8 YES — 180°
RKN34100 934 899 020 0 KN34100 N30162NA 3/8 3/8 3/8 1/4 3/8 3/8 3/8 NO 0°
RKN34111 934 899 022 0 KN34111 N30162ME 3/8 3/8 3/8 1/4 1/2 1/2 3/8 NO 0°
RKN34103 934 899 025 0 KN34103 N30162PB 3/8 3/8 3/8 1/4 1/2 1/2 1/2 YES Navistar application Special
RKN34104 934 899 028 0 KN34104 N30162PD 3/8 3/8 3/8 1/4 1/2 1/2 3/8 YES 0°
RKN34101 934 899 030 0 KN34101 N30162RD 1/2 PTC 3/8 PTC 3/8 PTC 1/4 1/2 1/2 3/8 PTC NO 0°
Revised 12-02 Page 43 PB-9926
PTC = Push-to-Connect .ttings
TRACTOR PROTECTION VALVESTractor Protection Valves Three-Line
.
Three-line automatic tractor protection with quick release.
.
Can replace two valves on some competitive systems.
.
Available with standard thread .ttings.
.
All ports are NPTF unless otherwise noted.
FROM TRACTOR
(EMERGENCY)
TRAILER
EMERGENCY C
SERVICE B
Meritor WABCO Haldex Brake Systems (Midland) PORTS REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N TYPE A B C D E F
RKN34071 934 899 017 0 KN34071 N30073GE 3-Line 3/8 1/2 1/2 3/8 1/8 1/4 —
Revised 12-02 Page 44 PB-9926
ACCESSORIES — ELECTRICAL Electro-Pneumatic Switches
PARK BRAKE SWITCH LOW AIR SWITCH
. Actuates at 55 psi. . Actuates at 70 ± 5 psi.
. Single pole, two terminal design. . Single pole, two terminal design.
. Circuit normally closed at 0 pressure. . Circuit normally closed at 0 pressure.
Meritor WABCO Haldex Brake Systems (Midland)
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RBE13240 894 041 608 2 BE13240 13240A
Revised 12-02 Page 45 PB-9926
ACCESSORIES — ELECTRICAL Electro-Pneumatic Switches
SERVICE CIRCUIT STOPLIGHT SWITCH
.
Actuates at 3-5 psi.
.
Single pole, two terminal design.
.
Circuit normally open at 0 pressure.
.
Solid state contacts.
.
Snap action design to increase switch life.
.
Tested at one million cycles at 30 Amps.
Meritor WABCO Haldex Brake Systems (Midland)
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RBE13250* 894 041 605 2* BE13250 3250
R325010 894 041 607 2 325010 325010
RBE13250 894 041 610 2* BE13250 325011
* with nuts
TRAILER EMERGENCY STOPLIGHT SWITCH
.
Actuates at 55 psi.
.
Single pole, double throw, three-terminal design.
.
Circuits normally one open, one closed.
Meritor WABCO Haldex Brake Systems (Midland)
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RBE13255 894 041 612 2 BE13255 13255A
R1325550* 894 041 616 2* 1325550 1325550
R300629A** 894 041 619 2** 300629A 300629A
RBE13255 894 041 620 2 BE13255 N15364F
* with nuts ** with pigtail connector
Revised 12-02 Page 46 PB-9926
ACCESSORIES
Bulkhead Fitting (Frame Nipple)
Meritor WABCO
SERVICE P/N OEM P/N DESCRIPTION
S893 891 003 2 893 891 003 2 Frame Nipple
In-Line Filters
Meritor WABCO Haldex Brake Systems (Midland)
SERVICE P/N OEM P/N SERVICE P/N OEM P/N DESCRIPTION
RKN31026 899 381 282 4 KN31026 N10083F 2 female ports (1/4” ports)
RN10083K 899 381 283 4 KN31025 N10083K 1 female port, 1 male port (1/4” ports)
Revised 12-02 Page 47 PB-9926
ACCESSORIES Knobs Meritor WABCO Haldex Brake Systems (Midland)
SERVICE P/N OEM P/N SERVICE P/N OEM P/N REMARKS
PUSH TOENGAGEDIFF-LOCK R102684A 936 649 671 4 102684-A 102684-A Dash Control, 1/4-28 UNF, Black body
FRONT BRAKELIMITING PULLWETROAD PUSHDRYROAD R1155903 936 649 672 4 1155903 1155903 Front Brake Limiting (wet road), 1/4-28 UNF, Yellow body
PARKINGBRAKE PULLTOAPPLY PUSHTO RELEASE R12503 936 649 673 4 12503 1175003 Park, 1/4-20 UNF, Yellow body
PARKINGBRAKE PULLTOAPPLY PUSHTO RELEASE R12509 936 649 674 4 12509 1175013 Park, 1/4-28 UNF, Black body
RN15285P 936 649 678 4 N15285P N15285P 5/16-24 UNF, Black body
Revised 12-02 Page 48 PB-9926
ACCESSORIES — TREADLES Aluminum Treadles
.
Meritor WABCO Haldex Brake Systems (Midland) PEDAL ANGLE REMARKS
SERVICE P/N OEM P/N SERVICE P/N OEM P/N
RSN4017E 961 899 710 2 SN4017E N30056BX 34° —
RSN4017A 961 899 711 2 SN4017A N30056BL 50° International Truck application
RSN4017A 961 899 712 2 SN4017A N30056BR 45° —
RSN4017F 961 899 713 2 SN4017F N30056BW 27° —
RSN4017A 961 899 714 2 SN4017A N30056CB 50°
RKN21051 961 899 715 2 KN21051 N21051 — Plate only
RN21052 961 899 716 2 N21052 N21052 Treadle only. Mack application
RSN4017A 961 899 718 2 SN4017A N30056BK 41°
DEIF DEIF SIRER212.8
DEIF DEIF TE Q1E FA 80 M6B-40H
DEIF DEIF VTR-5-NB 4-12-20mA LOAD:0.6V
DEIF DEIF WQR96(MK11)
DEIF DEIF XL144
DEIF DEIF XL192 ORDER NO:400047948.140
DEIF DEIF XL192 ORDER NO:600048653.160
DEIF DEIF XL96 100163014.10
HC 36/24 230 V AC 60Hz
HC 36/24 12 36V DC
HC48 230V AC 50 Hz
HC48 10-48V DC -
HC48 400V AC 60 Hz
Weidmuller 1336700000 SM 35/18 K MC NE GR
CARLO GAVAZZI FURA3-20/S40
AUTOMATION DIRECT F2-04AD-1
ZF 416110920101replaces416111102201
AUTOMATION DIRECT ZL-P3-CBL20-2P
lovato 11BF8000440
lovato 11BF654012060
Carlo Gavazzi RGS1P60AA50E
Carlo Gavazzi RGS1P60AA92E
Carlo Gavazzi RGS1P60K50ED
Carlo Gavazzi RGS1P60K92ED
Carlo Gavazzi RGS1P60V50EA
Carlo Gavazzi RGS1P60V50ED
Carlo Gavazzi RGS1P60V92EA
Carlo Gavazzi RGS1P60V92ED
Carlo Gavazzi RGS1S60D31GKEP
BTR耦合模块 LTM-E16, lamp test module, for 7 lampsBTR耦合模块 KRS-C12 3 VHR, 24 V AC/DC - 3 changeover contactsBTR耦合模块 PT-C12, potential seperator 24 V AC/DCBTR耦合模块 PT-C12, potential seperator 24 V AC/DC, current output adjustmentBTR耦合模块 PTi-C12, potential seperator, 230V ACBTR耦合模块 PTi-C12, potential seperator, 230V AC, current output adjustmentBTR耦合模块 RM 21, coupling module, 230 V AC - 1 changeover–BTR耦合模块 RM 21, coupling module, 24 V AC - 1 changeover–BTR耦合模块 RM 21, coupling module, 24 V DC - 1 changeover–BTR耦合模块 RM 21/21, coupling module, 230 V A - 2 changeover contactsBTR耦合模块 RM 21/21, coupling module, 24 V AC - 2 changeover contactsBTR耦合模块 RM 21/21, coupling module, 24 V DC - 2 changeover contactsBTR耦合模块 RM 21/21, coupling module, 12 V DC - 2 changeover contactsBTR耦合模块 RM 1L, coupling module, 24 V DCBTR耦合模块 RM3, coupling module, 230V AC, 2 changeover contacts, with LED and strapBTR耦合模块 RM3, coupling module, 24V AC, 2 changeover contacts, with LED and strapBTR耦合模块 RM3, coupling module, 24V DC, 2 changeover contacts, with LED and strapBTR耦合模块 relay module 41F-230, 230V, 1 changeoverBTR耦合模块 relay module 41F-24, 24V, 1 changeoverBTR耦合模块 SMM-E16, annunciator module, 230 V AC - 1 changeover–BTR耦合模块 SMM-E16, annunciator module, 24 V AC/DC - 1 changeover–BTR耦合模块 STM-C12, annunciator module, 24 V AC/DCBTR耦合模块 KRA-S12/21-21-21, coupling module, 24 V AC/DC - 3 changeover contactsBTR耦合模块 KRA-S-M6/21, coupling module, 24 V AC/DC - 1 changeover–BTR耦合模块 KRA-M4/1, coupling module, 230 V ACBTR耦合模块 KRA-M4/1, coupling module, 24 V AC/DCBTR耦合模块 KRA-M4/1, coupling module, 24 V DCBTR耦合模块 KRA-M4/1, coupling module, 12 V AC/DCBTR耦合模块 KRA-M6/21, coupling module, 230 V AC - 1 changeover–BTR耦合模块 KRA-M6/21, coupling module, 24 V AC/DC - 1 changeover–BTR耦合模块 KRA-M6/21, coupling module, 24 V DC - 1 changeover–BTR耦合模块 KRA-M6/21, coupling module, 12 V AC/DC - 1 changeover–BTR耦合模块 KRA-M6/1-1, coupling module, 230 V AC, 2 - NO contacts–BTR耦合模块 KRA-M6/1-1, coupling module, 24 V AC/DC - 2 NO contacts–BTR耦合模块 KRA-M6/1-2, coupling module, 230 V - 1 NO contact / 1 NC contactBTR耦合模块 KRA-M6/1-2, coupling module, 24 V AC/DC - 1 NO contact / 1 NC contactBTR耦合模块 KRA-M8/21-21, coupling module, 230 V AC - 2 changeover contactsBTR耦合模块 KRA-M8/21-21, coupling module, 24 V AC/DC - 2 changeover contactsBTR耦合模块 KRA-M8/21-21, coupling module, 24 VDC - 2 changeover contactsBTR耦合模块 KRA-M8/21-21, coupling module, 12 V AC/DC - 2 changeover contactsBTR耦合模块 KRA-M8/21-21, coupling module, 48 V AC/DC - 2 changeover
6SL3985-5HX01-0AA0
3RT1276-6AV36
6SY7000-0AD85
6SL3352-1AE41-0DA1
6SB2071-3BA00-0AA0
3RT1264-6AP36
6SL3983-6PX00-0AA0
3UG4632-1AW30
3RT1264-6AM36
6SL3995-6LX00-0AA0
6SL3995-6AX00-0AA0
Gate Valves
42-10 RS - Backflow Protection Check Valve
42-10 RS - Backflow Protection
SAMSON AKTIENGESELLSCHAFT · Weismüllerstraße 3 · 60314 Frankfurt am Main, Germany
Phone: +49 69 4009-0 · Fax: +49 69 4009-1507 · samson@samsongroup.com · www.samsongroup.com
Edition January 2021
Types 3222/5857, 3222/5824, 3222/5825, 3222/5757-3, 3222/5757-7,
3222/5724-3, 3222/5724-8, 3222/5725-3, 3222/5725-7, 3222/5725-8
Electric Control Valves
Type 3222/2780 Pneumatic Control Valve · Single-seated Type 3222 Globe Valve
Hgrs / Bar Hangers & Outlet Box Accy / MULB 11522 – 4-11/16 SQ 1/2D RCPT CVR
MULB 11522 – 4-11/16 SQ 1/2D RCPT CVR
S8VK-C48024 Omron Single Phase PSU 24V 480W S8VK C Series
S8VK-G01505 Omron Automation and Safety AC/DC CONVERTER 5V 15W
S8VK-G01512 Omron Automation and Safety PWR SUPPLY 15W 12V1.2AVAC100-240
S8VK-G01524 Omron Automation and Safety PWR SUPPLY 15W 24V0.65AVAC100
S8VK-G03005 Omron Automation and Safety AC/DC CONVERTER 5V 30W
S8VK-G03012 Omron Automation and Safety PWR SUPPLY 30W 12V2.5AVAC100-240
S8VK-G03024 Omron Automation and Safety PWR SUPPLY 30W 24V1.3AVAC100-240
S8VK-G06012 Omron Automation and Safety PWR SUPPLY 60W 12V4.5AVAC100-240
S8VK-G06024 Omron Automation and Safety PWR SUPPLY 60W 24V2.5AVAC100-240
S8VK-G12024 Omron Automation and Safety PWR SUPPLY 120W 24V5AVAC100-240
S8VK-G24024 Omron Automation and Safety PWR SUPPLY 240W 24V10AVAC100-240
S8VK-G24048 Omron Automation and Safety PWR SUPPLY 240W 48V5AVAC100-240
S8VK-G48024 Omron Automation and Safety PWR SUPPLY 480W 24V20AVAC100-240
S8VK-G48048 Omron Automation and Safety PWR SUPPLY 480W 48V10AVAC100-240
MJ25C13192 : 50 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, PRESS FIT Specifications: Applications: Card Edge ; Gender: Female ; Termination Types: PRESS FIT ; Number of Contacts: 50
MJ47C25192 : 94 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, PRESS FIT Specifications: Applications: Card Edge ; Gender: Female ; Termination Types: PRESS FIT ; Number of Contacts: 94
MJ50D11192 : EDGE CONNECTOR,PCB MNT,RECEPT,100 CONTACTS,0.125 PITCH,COMPLIANT FIT TERMINAL Specifications: Applications: Card Edge
MJS11E11192 : EDGE CONNECTOR,PCB MNT,RECEPT,22 CONTACTS,0.156 PITCH,COMPLIANT FIT TERMINAL Specifications: Applications: Card Edge
NJ22C34195 : 44 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, PRESS FIT Specifications: Applications: Card Edge ; Gender: Female ; Termination Types: PRESS FIT ; Number of Contacts: 44
NJ34C33192 : 68 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, PRESS FIT Specifications: Applications: Card Edge ; Gender: Female ; Termination Types: PRESS FIT ; Number of Contacts: 68
NJ38C11192 : 76 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, PRESS FIT Specifications: Applications: Card Edge ; Gender: Female ; Termination Types: PRESS FIT ; Number of Contacts: 76
755E-00-12 : BRASS, PCB TERMINAL Specifications: Terminal Type: PCB TERMINAL ; Material: BRASS
Same catergory
0-142095-3 : TWO PART BOARD CONNECTOR. s: Connector Type: TWO PART BOARD CONNECTOR.
0354648000 : PHOSPHOR BRONZE, WIRE TERMINAL. s: Terminal Type: Wire Connector ; Material: PHOSPHOR BRONZE ; North American: 18 AWG.
086212005010800 : 5 CONTACT(S), FEMALE, RIGHT ANGLE FFC/FPC CONNECTOR, SURFACE MOUNT. s: Connector Type: FPC/FFC ; Gender: Female ; Termination Types: PCBSolder ; Number of Contacts: 5.
09661513511 : 9 CONTACT(S), FEMALE, D SUBMINIATURE CONNECTOR, SOLDER. s: Connector Type: D-Sub ; Gender: Female ; Termination Types: SOLDER ; Number of Contacts: 9.
AA-1120 : 1 mm2, BRASS, WIRE TERMINAL. s: Terminal Type: Wire Connector ; Material: BRASS ; North American: 18 AWG ; International: 1 mm2.
C075ANSG : CABLE TERMINATED, RF RIGHT ANGLED ADAPTER. s: Frequency: 15.000 GHz ; VSWR: 1.2 1.
MOD-YSJ88D03C+ : 8 CONTACT(S), FEMALE, STRAIGHT TELECOM AND DATACOM CONNECTOR, SOLDER, JACK. s: Applications: Telecom / Data / Network Connectors ; Gender: Female ; Termination Types: SOLDER ; Number of Contacts: 8 ; RoHS Compliant: RoHS.
MR009N02-26E1-M46 : CONNECTOR,D-SHELL,CABLE MNT,RECEPT,9 CONTACTS,PIN,0.05 PITCH,SOLDER TERMINAL,nb2-56.
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V
变频器(士林) SS2-043- 0.75K 1HP 460V
变频器（士林） SS2-043-1.5K 2HP 460V
變頻器（士林） SS2-043-2.2K 3HP 460V
变频器（士林） SS2-043-3.7K 5HP 460V
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V
变频器（士林） SS2-043-3.7K 5HP 460V
保险丝座 1P SF-111 (轨道式)
保险丝盖 1P 250V (附霓虹灯式)#
保险丝盖 TFBN-101 DC24V (附霓虹灯式) #
变频器(士林) SS2-043- 0.75K 1HP 460V
變頻器（士林） SS2-043-3.7K 5HP 460V
变频器 SE3-043-11K 15HP
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V
MARATHON ELECTRIC
GE
MARATHON ELECTRIC
德莱赛安全阀 ：密封圈4848140安全阀 39PV07-2-CC-K-GS-60\API520
5KC49RN0666X
362A1053P031
5KC49RN0666X
1F11 : MALE, STRAIGHT TWO PART BOARD CONNECTOR, PRESS FIT, PLUG. s: Connector Type: TWO PART BOARD CONNECTOR ; Gender: Male ; Termination Types: PRESS FIT.
RDS-HS3FM3IG 0-0.6M
204763 : 26 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, SURFACE MOUNT. s: Connector Type: BOARD STACKING CONNECTOR ; Gender: Female ; Termination Types: PCBSolder ; Number of Contacts: 26.
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V 5.000
变频器(士林) SS2-043- 0.75K 1HP 460V 15.000
变频器（士林） SS2-043-1.5K 2HP 460V 6.000
變頻器（士林） SS2-043-2.2K 3HP 460V 5.000
变频器（士林） SS2-043-3.7K 5HP 460V 8.000
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V 4.000
变频器（士林） SS2-043-3.7K 5HP 460V 4.000
保险丝座 1P SF-111 (轨道式) 48.000
保险丝盖 1P 250V (附霓虹灯式)# 20.000
保险丝盖 TFBDalmec 00.79.0214
00.79.0219
N-101 DC24V (附霓虹灯式) # 28.000
变频器(士林) SS2-043- 0.75K 1HP 460V 1.000
變頻器（士林） SS2-043-3.7K 5HP 460V 4.000
变频器 SE3-043-11K 15HP 3.000
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V 6.000
RDS-HS3FM3IG 0-0.6M
284191 : 64 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART EURO CONNECTOR, PRESS FIT. s: Connector Type: TWO PART EURO CONNECTOR ; Gender: Female ; Termination Types: PRESS FIT ; Number of Contacts: 64 ; RoHS Compliant: RoHS.
激振电机UVF11W-A2.1
31FXV-RSM1-GAN-ETF : 31 CONTACT(S), FEMALE, RIGHT ANGLE FFC/FPC CONNECTOR, SURFACE MOUNT. s: Connector Type: FPC/FFC ; Gender: Female ; Termination Types: PCBSolder ; Number of Contacts: 31.
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V
变频器(士林) SS2-043- 0.75K 1HP 460V
变频器（士林） SS2-043-1.5K 2HP 460V
變頻器（士林） SS2-043-2.2K 3HP 460V
变频器（士林） SS2-043-3.7K 5HP 460V
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V
变频器（士林） SS2-043-3.7K 5HP 460V
保险丝座 1P SF-111 (轨道式)
保险丝盖 1P 250V (附霓虹灯式)#
保险丝盖 TFBN-101 DC24V (附霓虹灯式) #
变频器(士林) SS2-043- 0.75K 1HP 460V
變頻器（士林） SS2-043-3.7K 5HP 460V
变频器 SE3-043-11K 15HP
变频器（士林）单相 SS2-021-0.4K 0.5HP 220V
Dalmec 00.79.0214
00.79.0219
Copley Controls Brushless Servo Amp 7226AC
Infranor PAC-ET-230/11 in UNITED STATES
Mavilor MO-300 00300.001.0099.E5 DC Servo Motor 54V 3000RPM .4 KW
Mavilor MO-300 00300.001.0099.E5 DC Servo Motor 54V 3000RPM .4 KW
INFRANOR - XtrapulsPac Pac-et 230/11
Kaiser Systems Inc. S25-250 P/N: 1102384-2 Power Supply
Kaiser Systems Inc. S25-250 P/N: 1102384-2 Power Supply
THK SSR25XV2SS+617LY-II Linear Rail and Bearing Blocks NEW
THK SSR25XV2SS+617LY-II Linear Rail and Bearing Blocks NEW
PAC-et 230/11 FCL-ST 219100XX021100FC BLS 111
BLS 112
BLS 113
BLS 114
BLS 115
BLS 141
BLS 142
BLS 143
BLS 144
BLS 53
BLS 55
BLS 71
BLS 72
BLS 73
BLS 74
BLT 111
BLT 112
BLT 113
BLT 114
BLT 115
BLT 141
BLT 142
BLT 143
BLT 144
BLT 53
BLT 55
BLT 71
BLT 72
BLT 73
BLT 74
FP-0023
FP-0034
FP-0055
FP-0105
FP-0207
FP-0307
FP-0409
FP-0609
FP-0711
FP-0911
FP-1111
FP-1311
FP-1714
FP-3314
FP-5019
FP-8019
HDD 09E
HDD 09J
HDD 09N
HDD 09Q SMTBD1/1A 220/30-WT.BS INFRANOR
HDD 14J
HDD 14N
LH055-1
LH055-2SMTB.SI220/17
CD1-A-400/14
CD1-K2400/14-P3
E13886
E13887 BS073A.00.0105.D2 INFRANOR SERVOMOTOR
MP/DR100
SMT-BD1/1A
SMT-BD1/1H 220/30W.T.BS
SMT100/05
RACK BF/400-45/2-2-E U/400 I/45 INFRANOR
LH055-3
LH055-4
LH086-1
LH086-2
LH086-3
LH086-4
LH097-1
LH097-2
LH097-3
LH142-1
LH142-2
LH142-3
LH142-4
Meivac Vari-Q Throttle Valve VQ250ISOUMK 10’ with MKS 153 Control Valve
Meivac Vari-Q Throttle Valve VQ250ISOUMK 10’ with MKS 153 Control Valve
Dalmec
00.79.0214
00.79.0219
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7000-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7001-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7002-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7003-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7006-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7007-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7008-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7009-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7010-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7011-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7012-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7013-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7028-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7043-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7044-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7061-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7072-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7077-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7078-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7079-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7311-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7312-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7313-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7314-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7315-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7316-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7317-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7318-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7319-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7320-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7321-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7328-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7330-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7015-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7017-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7019-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7020-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7021-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7026-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7047-C
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 024703-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 024704-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2000-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2000-B-10PACK
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2000-B-RJ45PACK
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2330-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 023040-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 024390-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 024400-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 024700-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 024701-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 024702-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 025240-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB3000-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB3000-B-10PACK
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB3003-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB3010-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB3010-B-10PACK
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2001-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2001-B-10PACK
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2030-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2030-B-10PACK
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2031-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2031-B-10PACK
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB2300-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AWB3300-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 SP1872
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 020570-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 021220-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 021620-B
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7500-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7501-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7502-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7503-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7504-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7505-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7506-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7507-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7508-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7509-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7510-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7511-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7512-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7513-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7515-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7516-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7517-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7518-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7519-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7521-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7522-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7524-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7525-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7526-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7527-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7528-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7529-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7530-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7531-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7985-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7953-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7954-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
白炽舱顶灯 DC-128
白炽舱顶灯 DC-128A
白炽舱顶灯 DC-129A
白炽舱顶灯 DC-3
LED 舱顶灯 DCL-187
LED 舱顶灯 DCL-188
防爆灯 DF-103B-25-2
防爆灯 DF-103B-60-2
右舷灯(绿色) DH-101A
左舷灯(红色) DH-102A
补给信号灯 DH-105B
应急灯 DH-105B
艏旗杆灯 DH-13
升降信号探照 DX-106
信号灯 DX-2
闪光信号灯 DX-5
双层艉灯 CXH4-10B
铜质双层艉灯 CXH4-10B2
LED 防爆灯 BFC8183
应急 LED 蓬顶 CSC3021
LED 蓬顶灯 CSE3021
LED 蓬顶灯 HG.LED-P2CQA
射灯 12V100W
示位灯 BSW9812
信号灯 CXH-12-02
信号灯 CXH-12-03
桅顶灯 CXH5-3
探照灯 TF8212
搜索灯 WS97-80H
搜索灯 WS97-80H
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7955-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7956-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7957-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7958-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7959-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7960-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7961-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7962-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7963-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7964-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7970-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7972-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7979-F
HMS价格表Anybus网关，Anybus无线，IXXAT嵌入式控制硬件 AB7980-F
x-gateway AB7832-C
N4L PPA1500
TESA 310009
白炽舱顶灯 DC-128 220V 60W
白炽舱顶灯 DC-128A 220V 60W
白炽舱顶灯 DC-129A 220V 60W
白炽舱顶灯 DC-3 220V 15W
LED 舱顶灯 DCL-187 220V 2*10W
LED 舱顶灯 DCL-188 220V 3*10W
防爆灯 DF-103B-25-2 24V 25W
防爆灯 DF-103B-60-2 220V 60W
右舷灯(绿色) DH-101A 220V 2*65W 绿色
左舷灯(红色) DH-102A 220V 2*65W 红色
补给信号灯 DH-105B 220V 65W
应急灯 DH-105B 220V 65W
艏旗杆灯 DH-13 220V 25W
升降信号探照 DX-106 220V 1000W
信号灯 DX-2 24V 70W
闪光信号灯 DX-5 220V 300W
双层艉灯 CXH4-10B 220V 65W*2
铜质双层艉灯 CXH4-10B2 220V 65W*2
LED 防爆灯 BFC8183 /
应急 LED 蓬顶 CSC3021 /
LED 蓬顶灯 CSE3021 /
LED 蓬顶灯 HG.LED-P2CQA /
射灯 12V100W /
示位灯 BSW9812 /
信号灯 CXH-12-02 DC24V 25W 绿
信号灯 CXH-12-03 DC24V 25W 红
桅顶灯 CXH5-3 /
探照灯 TF8212 /
搜索灯 WS97-80H /
搜索灯 WS97-80H /
Baumer 卫生级支架 HI11-1H
OTT-JAKOB 工件夹具 95.601.048.9.2
Bussmann 保险丝 TCF60(相当小包装12)
Ｄeibold74.TER.32.14
英国牛顿N4L PPA-5530功率分析仪
Danfoss 变频器 FC-051P1K5T4E20H3BXCXXXSXXX
Ｄeibold74.TER.32.16
bernstein 607.3200.011
EMG-1970数字式放大器SPC1501
GKN Stromag 联轴器 VN 43021
Imopac 自动连接器 IMOPT1603
Baumer 卫生级支架 HI11-1H
Meister SPKR 桨式流量监视器用于液体
Ｄeibold74.TER.25.06
德国Ｄeibold-HSK主轴HSG-S 240.12-27.AK (Sy)
Baumer 微型传感器 IFRM 04N15B1/KS35PL
N4L PPA5500-TE
Ｄeibold74.TER.16.03
OTT拉刀杆 1K-GD-HD
THK 丝杠 BTK 2806-5.3ZZ+688L C7 T
Leybold 泵 Vacuum pump SV65B
PSM1700 frequency response analyzer
ANYBUS 总线 AB6212提供选型
Ｄeibold7/24锥度的主轴检棒72.150.740.100*BT30JISB633932230
德国Ｄeibold160.501.500
OTT-JAKOB 适配器 95.600.073.9.2 HSK A63
德国Ｄeibold-HSK主轴HSG-S 200.20-16.AK (Sy)
SATA 套筒12MM 11312
Schneider 隔离开关 INT125/3P 100A(INT100/3P 100A)
Peak-System 线缆 PCAN-Term CAN端子适配器
SITEMA KRP25SITEMA 制动器 KRP25
OTT-JAKOB 适配器 9510158892
OTT拉刀杆 1K-GDR-LC
leine&linde 编码器 IHA 607 58 ?12hs 9-36V 13bit SPB Ra.cab 3xM12
ALTHEN P981-0002-Z1
Ｄeibold球头检棒72.160.742.100BT4030150
OTT-JAKOB 分配器 9560007392 HSK-A 63/B 80
ANYBUS 总线 AB6312 提供选型
德国Ｄeibold060.500.350
Norgren 比例阀 40-881-19 （4088119.7053.01200）
N4L PSM1700
德国Ｄeibold-HSK刀柄72.563.503.1006,09,012,036,050,024,0--50000
德国Ｄeibold060.140.260
conatex 热电偶 W002287
Peak-System 线缆 PCAN-Explorer 4 Add-in: CANdb Import Add-in 2 IPES-004086 赵劲松报价
Ｄeibold球头检棒72.585.742.100HSK-A10030150
GKN Stromag 联轴器 VN 54951
Ｄeibold7/24锥度的主轴检棒72.060.740.100SK40DIN6987140320
Siemens 电机启动器 3RK1304-5KS40-5AA0
Lapp 电缆 QUATTRO 41GO,75 30米
OTT拉刀缸 Unclamp Unit LE 119-P
Baumer 微型传感器 IFRM 04N15B1/KS35PL
Hawe 紧凑式液压泵站 HK34DT/3M-H2.5-A1/25
Danfoss 冷冻油 丹佛斯压缩机专用 2.5L装
德国Ｄeibold锥度检测仪76.701.080
AllenBradleyPointIO数字量8点标准输出模块12V/24V1734－OB8E
OMAL SPA 2/2阀 VNC2005
Burkert 阀 2002◇DN20◇2|2◇NF◇G3|4◇NBR (00186578)
Deublin接头旋转接头1116-048-463
Regloplas P160MD 加压水式模温机比较高使用温度160度
德国Ｄeibold刀柄72.172.560.810
WOERNER Smeersystemen BV 压力传感器 KFE-A/E/C/W/X/70/X/N
Phoenix 模块 2832933
英国牛顿N4L LPA05
Ｄeibold球头检棒72.575.742.100HSK-A6330150
Ｄeibold74.TER.25.08
Sika 流量传感器 VTR 1025 Art No.VS2575VA0000A5 SN:14153 PN 250
LUBBERING 套筒齿轮（开口） 70964959
Peak-System CAN卡 IPEH-002004 Hub集线器
意大利REER 安全编码器SAFECODER SC3 05B2048R 订货号Code: 1100105
路由器带Phoenix 连接器 IPEH-002210-P 转换器 Peak-System
德国Ｄeibold050.500.070
Kraus＆Naimer开关 L400
walther接头 CT-012-2-VR021-02-2
Ｄeibold7/24锥度的主轴检棒72.160.740.200BT40JISB633940320
Stasto 紧凑型磁缸 NSKU50-60-M
KBELECTRONICS/KB变频驱动器9958N
OTT 适配器 ADAPTER/95.101.586.9.2
德国Ｄeibold-HSK主轴HSG 202.30-19.AK
OTT V型密封 SEAL/16*24*5.5 L=6 V3664 0.926030.109
OTT-JAKOB 刀架 9560003726 SPANNSATZ HS-A100/B125-B-
Ｄeibold74.TER.11.06
OTT-JAKOB 卡爪 SK50-A1-2-M16X1,5-A=1,0；9510129732
N4L 功率分析仪PPA-510高精度数字功率计
ALTHEN P981-0002-Z1
OTT-JAKOB 测力计 95.103.135.9.2
德国ANYBUS 接口ControlNet AB7314
Ｄeibold 锥度检测仪76.701.032
LEGRIS 7776-10-00
OTT拉刀杆 1K-GD-HS-IK
Ｄeibold球头检棒72.579.742.100HSK-F6330150
OTT拉刀杆 1K-GDR
OTT旋转接头 Rotary Union 2KL
德国Ｄeibold-HSK刀柄72.568.500.070515 svbdx202060M6-542000
Hilscher 板卡CIF 50-COMPC卡PCI1050.500赵劲松报价
Walther Prazision 接头 LP-006-2-SL013-22-1
OTT-JAKOB 夹紧装置 IFH63-AB-5-GS5821-0735 Nr；9560060110
KOPF 2660型微定位直接驱动高速25mm行程
德国库伯勒KUBLER 8.0010.4700.0000
Ｄeibold74.TER.25.14
OTT-JAKOB 衬套 9560030532
英国牛顿N4L PPA4500
OTT拉刀缸 Unclamp Unit LE 124 F-B
OTT-JAKOB 芯片 95.600.075.9.6
Ｄeibold 刀柄锥度检测仪76.701.025
霍伯纳HUBNER POG10DN1024I 1788596
Nelson Bolzenschweiss-Technik GmbH & Co. KG 主板 Leiterplatine Netzteil N3 Art.-Nr. 66-06-60
SIKO 磁性传感器 MSK5000
英国牛顿N4L PPA500三相功率分析仪
Stasto 紧凑型磁缸 NSKU63-15-M
Omron 接近开关 E2EX18MF1
英国牛顿N4L PPA520高精度功充分析仪PPA-520
SMW-AUTOBLOK KNCS-NBX快换爪动力卡盘
Ｄeibold74.TER.25.10
AB7072-B
AB7010-B
AB7001-C
AB7003-B
AB7061-C
AB7007-C
AB7306-B
AB7317-B
AB7318-B
HMS-EN2MB-R
HMS-EN2PB-R
HMS-EN2SE-R
sDC-7301-001
sDC-7103-059
sDC-7123-109
sDC-7133-003
sDC-7143-029
sDC-7295-001
sDC-7188-005
sDC-7254-002
sDC-7233-004
sDS-7099-083
SP1190
SP1191
SP1192
SP1193
SP1194
SP1196
SP1197
SP11981，桥式控制板64666606 G5330052(DSMB-02C)/Bridge Control Board, (DSMB-02C)
2，整流器辅板\ABB\DSAB-01C 64630199\顶部驱动系列号：534004 KK
3，二极管电源主板DSMB-02C系列号：5350094 KK
4，风机控制板DSMB-01，ABB的部件号为64691929
5，二极管电源连接器DSCB-01C系列号：5260345 KK
6，保护板64703714B
7，ABB电机 M3AA 180 M4
电制要求：
1、电压：480V；
2、频率：60HZ；
3、功率：22KW；
4、转速：1765r/min；
5、额定电流：37.5A，
6、功率因素：cosΦ:0.85；
7、防护等级：IP55，IEC 180 M/L 48；
8、prod code:3GAA182101-BDC.02
8，ABB断路器S202额定电流：4A \ S202P-C4 (DE)
SP1199
SP1432
SP1306
SP1307
SP1308
SP1309
SP1310
SP1313
SP1312
SP1314
SP1315
SP1316
SDC-7099-0061019
AB7300-B
ABX-COP-ECT ABS-ECT
AB7301-B
ABX-COP-PDP ABS-PDP
AB7302-B
ABX-COP-DEV ABS-DEV
AB7303-B
ABX-COP-CNT ABS-CNT
AB7304-B
ABX-COP-COPS ABS-COPS
AB7306-B
ABX-COP-EIP2 ABS-EIP2/EIT2
AB7307-B
ABX-COP-PRTABS-PRT
AB7308-B
ABX-COP-EIT2 ABS-EIP2/EIT2
AB7309-B
ABX-COP-PIR ABS-PIR
AB7310-B
ABX-COP-CCLABS-CCL
Model No.
Designation
Secondary board
AB7311-B
ABC-CAN-ECT ABS-ECT
AB7312-B
1，桥式控制板64666606 G5330052(DSMB-02C)/Bridge Control Board, (DSMB-02C)
2，整流器辅板\ABB\DSAB-01C 64630199\顶部驱动系列号：534004 KK
3，二极管电源主板DSMB-02C系列号：5350094 KK
4，风机控制板DSMB-01，ABB的部件号为64691929
5，二极管电源连接器DSCB-01C系列号：5260345 KK
6，保护板64703714B
7，ABB电机 M3AA 180 M4
电制要求：
1、电压：480V；
2、频率：60HZ；
3、功率：22KW；
4、转速：1765r/min；
5、额定电流：37.5A，
6、功率因素：cosΦ:0.85；
7、防护等级：IP55，IEC 180 M/L 48；
8、prod code:3GAA182101-BDC.02
8，ABB断路器S202额定电流：4A \ S202P-C4 (DE)
ABC-CAN-PDP ABS-PDP
AB7313-B
ABC-CAN-DEV ABS-DEV
AB7314-B
ABC-CAN-CNT ABS-CNT
AB7315-B
ABC-CAN-COPS ABS-COPS
AB7317-B
VEGASN62 CXAGHKMXX
VEGAFX81 ADUTBFHXD1XX L=10M
ABB 64666606 G5330052(DSMB-02C)Bridge Control Board, (DSMB-02C)
ABB DSAB-01C系列号：534004 KK整流器辅板\ABB\DSAB-01C 64630199\顶部驱动
ABB DSMB-02C系列号：5350094 KK
ABB 646488896 F
ABB DSCB-01C系列号：5260345 KK
ABB 64703714B
ABB M3AA 180 M4
ABB S202-C4
Trelleborg 特瑞堡
ABB-3HAC7148-1 Assembly Comp. Enclosure
ABB-3HAC7149-1 GEAR BOX
ABB-3HAC7149-3 Axis 1-3 compl. w motors
ABB-3HAC7150-1 Lower arm
ABB-3HAC7151-1 Cable bracket
ABB-3HAC7156-2 Motor
ABB-3HAC7157-2 Motor
ABB-3HAC7165-1 Cover mech.stop 1
ABB-3HAC7166-1 Cover unit,SMB
ABB-3HAC7167-1 Upperarm
ABB-3HAC7169-1 Parallel bar
ABB-3HAC7181-1 Locking liquid, 5 ml co
ABB-3HAC7191-1 0-ring sealingple
ABB-3HAC7236-1 Boot Cable
ABB-3HAC7242-1 Cover Wirefeder 2400L
ABB-3HAC7253-1 Supportwasher
ABB-3HAC7255-1 Inner floppy bracket
ABB-3HAC7258-1 Connector ple
ABB-3HAC7272-3 Filter unit panelboard
ABB-3HAC7273-1 Cover
ABB-3HAC7290-1 Connector cover
ABB-3HAC7294-1 Cable box axis 1-3
ABB-3HAC7301-1 Reducing nipple
ABB-3HAC7310-1 CABLE MOTOR 2
ABB-3HAC7315-1 Pinion Ax.4-6
ABB-3HAC7328-1 Connectorcover, USA
ABB-3HAC7336-1 Support washer
ABB-3HAC7340-1 Motor ax.3 compl.
ABB-3HAC7343-1 Ring
ABB-3HAC7344-1 Mains line filter unit
ABB-3HAC7349-1 Lock nut
ABB-3HAC7363-1 CanBus Cable 7m
ABB-3HAC7363-5 CanBus Cable 15m
ABB-3HAC7363-6 CanBus Cable 22m
ABB-3HAC7363-7 CanBus Cable 30m
ABB-3HAC7367-1 Cable holder
ABB-3HAC7370-1 Cable harness
ABB-3HAC7376-9 Multipole connector male
ABB-3HAC7391-1 Belt shield
ABB-3HAC7404-1 Can Bus Cable
ABB-3HAC7406-1 Ring
ABB-3HAC7407-1 Lock nut
ABB-3HAC7409-1 Washer
ABB-3HAC7416-1 CAN bus cable I/O 1-4
ABB-3HAC7419-1 Expansion cable jib
ABB-3HAC7427-1 Gasket
ABB-3HAC7434-1 Adapter 12p
ABB-3HAC7434-2 Adapter 23p
ABB-3HAC7434-4 Adapter 4p
ABB-3HAC7437-3 Receptacles for pin 12p
ABB-3HAC7437-4 Receptacles for pin 23p
ABB-3HAC7446-1 Receptacle for socket 4p
ABB-3HAC7446-3 Receptacle for socket 12p
ABB-3HAC7446-4 Receptacle for socket 23p
ABB-3HAC7455-1 Multipole conn. 4p (pin)
ABB-3HAC7455-3 Multipole conn. 12p (pin)
ABB-3HAC7455-4 Multipole conn. 23p (pin)
ABB-3HAC7457-3 Ballscrew
ABB-3HAC7458-1 Cage
ABB-3HAC7465-2 Multip. conn. 8p (socket)
ABB-3HAC7465-3 Multip. conn. 12p(socket)
ABB-3HAC7465-4 Multip. conn. 23p(socket)
ABB-3HAC7489-1 Cabeling lower CP/CS
ABB-3HAC7491-1 Cabling motor 2
ABB-3HAC7492-1 Cabling motor 3
ABB-3HAC7493-1 Cabling upper froc-con
ABB-3HAC7497-1 Cabling motor 5 2.8-3.0
ABB-3HAC7498-1 Cabling motor 6 2.8-3.0
ABB-3HAC7501-1 CAN bus cablel I/O 1-2
ABB-3HAC7504-1 BEARING
ABB-3HAC7505-1 Hex socket head cap screw
ABB-3HAC7520-1 Bracket DSQC 507
ABB-3HAC7526-2 Lubricor
ABB-3HAC7527-1 Damper ax. 1
ABB-3HAC7530-1 Cover spring
ABB-3HAC7531-1 Couerweight
ABB-3HAC7547-1 Wingknob with locking cyl
ABB-3HAC7553-1 Docume.IRB2400/M2000
ABB-3HAC7561-1 Dustcap f. receptecles 4p
ABB-3HAC7561-3 Dustcap f receptacles 12p
ABB-3HAC7561-4 Dustcap f receptacles 23p
ABB-3HAC7574-1 Pin
ABB-3HAC7574-2 Pin
ABB-3HAC7575-1 Socket
ABB-3HAC7575-2 Socket
ABB-3HAC7579-1 Product Manual IRB 640
ABB-3HAC7580-1 Product Manual IRB 640
ABB-3HAC7581-1 Product Manual IRB 640
ABB-3HAC7582-1 Product Manual IRB 640
ABB-3HAC7583-1 Product Manual IRB 640
ABB-3HAC7584-1 Product Manual IRB 640
ABB-3HAC7585-1 Product Manual IRB 640
ABB-3HAC7586-1 Product Manual IRB 640
ABB-3HAC7587-1 Product Manual IRB 640
ABB-3HAC7588-1 Product Manual IRB 340
ABB-3HAC7618-1 Product Manual IRB 1400
ABB-3HAC7619-1 Product Manual IRB 1400
ABB-3HAC7621-1 Product Manual IRB 1400
ABB-3HAC7622-1 Product Manual IRB 1400
ABB-3HAC7623-1 Product Manual IRB 1400
ABB-3HAC7624-1 Product Manual IRB 1400
ABB-3HAC7625-1 Product Manual IRB 1400
ABB-3HAC7646-1 Product Manual IRB 6400
ABB-3HAC7647-1 Product Manual IRB 6400
ABB-3HAC7648-1 Product Manual IRB 6400
ABB-3HAC7649-1 Product Manual IRB 6400
ABB-3HAC7650-1 Product Manual IRB 6400
ABB-3HAC7651-1 Product Manual IRB 6400
ABB-3HAC7652-1 Product Manual IRB 6400
ABB-3HAC7653-1 Product Manual IRB 6400
ABB-3HAC7654-1 Product Manual IRB 6400
ABB-3HAC7655-1 Mountingset I/O pos. 1-4
ABB-3HAC7659-1 Harness Customer signal
ABB-503876880 Swivel 2-K MTC 500/750/2000/5000
ABB-503876881 SVIVEL 4-K DIAM. 75
ABB-503880001 Screw, CurreCollector
ABB-503882001 Nippel 1/4
ABB-503883005 Cover elec. Swivel MIC 1
ABB-503883006 Cover elec. Swivel MIC 2
ABB-503886883 SWIVELPART MTC 750
ABB-503892001 SVIVELADAPTER MIC 1
ABB-503893001 C-RING SVIVEL MIC1 / MIC2
ABB-503917006 CABLE CHAIN
ABB-503939001 Limit switch disc MIC 2
ABB-503941001 100it switch ple MIC 2
ABB-503951885 RESOLVER CABLE L=14 M
ABB-504024002 MIRROR SET
ABB-504048880 COROLLER IF
ABB-504049880 COROLLER IF
ABB-504058880 LIM.SW.
ABB-504071880 POS.IF
ABB-504072880 POS IF
ABB-504077880 CABLE W111.1 HOME POS
ABB-504100880 SENSELEDNING SMARTAC/WEL-
ABB-504168880 Cable
ABB-504168881 CABLE
ABB-504168882 KABEL W61/63/65 RES. 1.1M
ABB-504168883 Cable
ABB-504171880 CABLE
ABB-504171881 CABLE
ABB-504174881 CABLE
ABB-3HAC7664-1 Gamma sealing
ABB-3HAC7676-1 Harness position switch
ABB-3HAC7677-1 Product Manual IRB 6400R
ABB-3HAC7678-1 Product Manual IRB 6400R
ABB-3HAC7679-1 Product Manual IRB 6400R
ABB-3HAC7680-1 Product Manual IRB 6400R
ABB-3HAC7681-1 Harness customer con.
ABB-3HAC7682-1 Product Manual IRB 6400R
ABB-3HAC7683-1 Product Manual IRB 6400R
ABB-3HAC7684-1 Product Manual IRB 6400R
ABB-3HAC7685-1 Product Manual IRB 6400R
ABB-3HAC7686-1 Product Manual IRB 6400R
ABB-3HAC7696-1 RAP Protocol Spec
ABB-3HAC7697-1 RAP Service Spec
ABB-3HAC7699-1 Sensor Ierface
ABB-3HAC7700-1 Weld timer ierface
ABB-3HAC7701-1 DiscreteApplicions
ABB-3HAC7702-1 User's Guide PickMaster
ABB-3HAC7703-1 Developer's Fuctions
ABB-3HAC7704-1 Advanced Motion
ABB-3HAC7705-1 Advanced Motion
ABB-3HAC7706-1 Advanced Motion
ABB-3HAC7707-1 Advanced Motion
ABB-3HAC7708-1 Advanced Motion
ABB-3HAC7709-1 Advanced Motion
ABB-3HAC7710-1 Advanced Motion
ABB-3HAC7712-1 Advanced Motion
ABB-3HAC7714-1 ProcessWare ArcWare
ABB-3HAC7715-1 ProcessWare ArcWare
ABB-3HAC7716-1 ProcessWare ArcWare
ABB-3HAC7717-1 ProcessWare ArcWare
ABB-3HAC7718-1 ProcessWare ArcWare
ABB-3HAC7719-1 ProcessWare ArcWare
ABB-3HAC7720-1 ProcessWare ArcWare
ABB-3HAC7722-1 ProcessWare ArcWare
ABB-3HAC7727-1 ArcWare Plus
ABB-3HAC7728-1 ArcWare Plus
ABB-3HAC7729-1 ArcWare Plus
ABB-3HAC7730-1 ProcessWare SpotWare
ABB-3HAC7731-1 ProcessWare SpotWare
ABB-3HAC7733-1 ProcessWare SpotWare
ABB-3HAC7734-1 ProcessWare SpotWare
ABB-3HAC7735-1 ProcessWare SpotWare
ABB-3HAC7737-1 ProcessWare SpotWare
ABB-3HAC7738-1 ProcessWare SpotWare
ABB-3HAC7740-1 ProcessWare SpotWare
ABB-3HAC7741-1 SpotWare Plus
ABB-3HAC7742-1 SpotWare Plus
ABB-3HAC7753-1 PalletWare Manual
ABB-3HAC7754-1 PalletWare Manual
ABB-3HAC7756-1 Conveyor Tracking
ABB-3HAC7758-1 Conveyor Tracking
ABB-3HAC7759-1 Conveyor Tracking
ABB-3HAC7767-1 Loadld&CollDetect
ABB-3HAC7768-1 Loadld&CollDetect
ABB-3HAC7769-1 Loadld&CollDetect
ABB-3HAC7770-1 Loadld&CollDetect
ABB-3HAC7771-1 Loadld&CollDetect
ABB-3HAC7773-1 Loadld&CollDetect
ABB-3HAC7774-1 System Dypes/Routines
ABB-3HAC7775-1 System Dypes/Routines
ABB-3HAC7776-1 System Dypes/Routines
ABB-3HAC7777-1 System Dypes/Routines
ABB-3HAC7778-1 System Dypes/Routines
ABB-3HAC7779-1 System Dypes/Routines
ABB-3HAC7780-1 System Dypes/Routines
ABB-3HAC7782-1 System Dypes/Routines
ABB-3HAC7783-1 RAPID Overview
ABB-3HAC7784-1 RAPID Overview
ABB-3HAC7785-1 RAPID Overview
ABB-3HAC7786-1 RAPID Overview
ABB-3HAC7787-1 RAPID Overview
ABB-3HAC7788-1 RAPID Overview
ABB-3HAC7789-1 RAPID Overview
ABB-3HAC7791-1 RAPID Overview
ABB-3HAC7793-1 User's Guide
ABB-3HAC7794-1 User's Guide
ABB-3HAC7795-1 User's Guide
ABB-3HAC7796-1 User's Guide
ABB-3HAC7797-1 User's Guide
ABB-3HAC7798-1 User's Guide
ABB-3HAC7799-1 User's Guide
ABB-3HAC7800-1 User's Guide
ABB-3HAC7801-1 User's Guide
ABB-3HAC7802-1 ProcessWare DispenceWare
ABB-3HAC7803-1 ProcessWare DispenceWare
ABB-3HAC7804-1 ProcessWare DispenceWare
ABB-3HAC7805-1 ProcessWare DispenceWare
ABB-3HAC7806-1 ProcessWare DispenceWare
ABB-3HAC7807-1 ProcessWare DispenceWare
ABB-3HAC7808-1 ProcessWare DispenceWare
ABB-3HAC7809-1 ProcessWare DispenceWare
ABB-3HAC7811-1 Male connector
ABB-3HAC7816-1 Protection cover 40-p
ABB-3HAC7817-1 Sealing assembly
ABB-3HAC7818-1 Protection cover 64-p
ABB-3HAC7819-1 Signal cable SMB
ABB-3HAC7823-1 Rubber protection
ABB-3HAC7827-1 Plate, earth fault break
ABB-3HAC7827-2 Plate
ABB-3HAC7832-1 Loadld&CollDetect
ABB-3HAC7833-1 Loadld&CollDetect
ABB-3HAC7835-1 Foundry Logotype
ABB-3HAC7841-1 Rot. ac motorwith pinion
ABB-3HAC7842-1 rot. ac motorwith pinion
ABB-3HAC7844-1 Ethernet Services
ABB-3HAC7866-1 Rot. ac motor incl pinion
ABB-3HAC7867-1 Gasket upper arm cover
ABB-3HAC7868-1 Gasket console-cover
ABB-3HAC7869-1 Gasket lower-arm cover
ABB-3HAC7870-1 Gasket base-cover
ABB-3HAC7877-1 Sealing ring
ABB-3HAC7877-2 Sealing ring
ABB-3HAC7880-1 Damper ax. 2
ABB-3HAC7881-1 Damper ax. 3
ABB-3HAC7892-1 Brake release unit
ABB-3HAC7907-1 Multipole conn. 4p (pin)
ABB-3HAC7907-3 Multipole conn. 12p (pin)
ABB-3HAC7907-4 Multipole conn. 23p (pin)
ABB-3HAC7926-1 Termin. coact XS6
ABB-3HAC7933-1 Termin. coact XS7
ABB-3HAC7939-1 Clamping unit
ABB-3HAC7941-19 Set of shim, bevelgear
ABB-3HAC7941-28 Set of shim, motor
ABB-3HAC7950-1 Washer
ABB-3HAC7953-1 Sealing Plug
ABB-3HAC7956-1 Wrist housing
ABB-3HAC7957-1 Gasket, manipulorcable
ABB-3HAC7961-1 Harness assembly axis 5
ABB-3HAC7962-1 Harness assemb ax 5, Jong
ABB-3HAC7963-1 Harness assembly ax 6
ABB-3HAC7964-1 Harness assemb ax 6, Jong
ABB-3HAC7966-1 Ejector Unit
ABB-3HAC7970-1 Fan holder
ABB-3HAC7984-1 Shaft
ABB-3HAC7997-1 Pos. switch cable 7m
ABB-3HAC7997-2 Pos. switch cable 15m
ABB-3HAC7997-3 Pos. switch cable 22m
ABB-3HAC7997-4 Pos. switch cable 30m
ABB-3HAC7998-1 Corol cable signal 7m
ABB-3HAC7998-2 Corol cable signal 15m
ABB-3HAC7998-3 Corol cable signal 22m
ABB-3HAC7998-4 Corol cable signal 30m
ABB-3HAC7998-7 Corol cable signal 40m
ABB-3HAC7998-8 Corol cable signal 50m
ABB-3HAC8004-1 I. Cable Fans 1-4
ABB-3HAC8009-1 Harness assembly manip.
ABB-3HAC8010-1 Harness assembly manip.
ABB-3HAC8011-1 Harness assembly CP/CS a3
ABB-3HAC8012-1 Harness assembly CP/CS a4
ABB-3HAC8013-1 Harness assembly CP/CS a3
ABB-3HAC8014-1 Harness assembly CP/CS a4
ABB-3HAC8015-1 Pos SW 1 function
ABB-3HAC8016-1 Pos SW 2 functions
ABB-3HAC8017-1 Pos SW 3 functions
ABB-3HAC8027-1 Product Spec. RobotWare
ABB-3HAC8030-2 Pump unit
ABB-3HAC8030-3 Vacuum Switch
ABB-3HAC8030-4 Valve Unit repair kit
ABB-3HAC8030-5 Connecting Ple
ABB-3HAC8039-1 Position switch 1
ABB-3HAC8040-1 Position switch 1-2
ABB-3HAC8041-1 Position switch 1-3
ABB-3HAC8057-1 Bracket Position switch
ABB-3HAC8059-1 Air Filter Magazine
ABB-3HAC8074-1 Ext. Cable Jib Fans
ABB-3HAC8080-1 Cover gearunit z2-3/5
ABB-3HAC8081-10 Coverwith gasket
ABB-3HAC8081-11 Cover with gasket
ABB-3HAC8081-6 Gasket
ABB-3HAC8082-1 Service Cover
ABB-3HAC8083-1 Floppy cover
ABB-3HAC8084-2 Belt W 75
ABB-3HAC8103-1 Protection box
ABB-3HAC8117-1 Harness filter unit
ABB-3HAC8122-1 Connector female
ABB-3HAC8122-2 Connector female
ABB-3HAC8123-1 Connector male
ABB-3HAC8123-2 Connector male
ABB-3HAC8124-1 Socket diameter 2,4 mm
ABB-3HAC8124-2 Socket diameter 2,4 mm
ABB-3HAC8125-1 Pin diameter 2,4 mm
ABB-3HAC8125-2 Pin diameter 2,4mm
ABB-3HAC8131-1 Protection sheet
ABB-3HAC8158-1 Corol Cable Power 7m
ABB-3HAC8159-1 Corol Cable Power 15m
ABB-3HAC8160-1 Corol Cable Power 22m
ABB-3HAC8162-1 Corol Cable Power 30m
ABB-3HAC8182-1 Corol cable power L=7m
ABB-3HAC8182-2 Corol cable power L=15m
ABB-3HAC8182-3 Corol cable power L=22m
ABB-3HAC8182-4 Corol cable power L=30m
ABB-3HAC8183-1 Cust. cable pow.-sign.7m
ABB-3HAC8183-2 Cust. cable pow.-sign.15m
ABB-3HAC8183-3 Cust. cable pow.-sign.22m
ABB-3HAC8183-4 Cust. cable pow.-sign.30m
ABB-3HAC8184-1 Corol cable power L=7m
ABB-3HAC8184-2 Corol cable power L=15m
ABB-3HAC8184-3 Corol cable power L=22m
ABB-3HAC8184-4 Corol cable power L=30m
ABB-3HAC8185-1 CP/CS CAN Cable 7m
ABB-3HAC8185-2 CP/CS CAN Cable 15m
ABB-3HAC8185-3 CP/CS CAN Cable 22m
ABB-3HAC8185-4 CP/CS CAN Cable 30m
ABB-3HAC8207-1 Harness assembly manip.
ABB-3HAC8208-1 Dust Protection DB9
ABB-3HAC8212-1 Outlet hood
ABB-3HAC8213-1 Dust Protection Modular
ABB-3HAC8225-1 Instruction ple
ABB-3HAC8234-1 Dust Protection USB
ABB-3HAC8238-1 Profibus User's Guide
ABB-3HAC8239-1 Profibus User's Guide
ABB-3HAC8240-1 Ierbus-S User's Guide
ABB-3HAC8253-1 3-phase main switch 40A
ABB-3HAC8253-2 3-phase sw 40A +aux 11
ABB-3HAC8253-3 3-phase sw 40A +aux 20
ABB-3HAC8256-1 Foundry Plus Logotype
ABB-3HAC8264-1 FroPle
ABB-3HAC8266-1 Disconnect label
ABB-3HAC8271-1 Bracket
ABB-3HAC8272-1 Hood, IP68
ABB-3HAC8272-2 Hood, 1P68
ABB-3HAC8272-3 Hood, 1P68
ABB-3HAC8272-4 Hood, 1P68
ABB-3HAC8272-8 Hood 1P68 M40
ABB-3HAC8299-1 Cover
ABB-3HAC8304-1 Cable unit ax. 4-6
ABB-3HAC8306-1 Cover
ABB-3HAC8310-1 Fuse label
ABB-3HAC8311-1 Fuse label
ABB-3HAC8311-2 Fuse label 65kA, 25kA
ABB-3HAC8321-1 Cover
ABB-3HAC8367-1 Door Ierlock Rotary sw
ABB-3HAC8402-1 Fan holder, 2 fans
ABB-3HAC8405-1 I. cable fans 1-2
ABB-3HAC8409-2 Hood
ABB-3HAC8414-1 Harness assembly manip.
ABB-3HAC8415-1 User's Guide PickMaster
ABB-3HAC8440-1 Lifting Tool
ABB-3HAC8441-1 Lyftredskap 180 kg
ABB-3HAC8445-1 Lifting acc. lower arm IRB660/6600/760
ABB-3HAC8466-1 Protective earth cable
ABB-3HAC8470-1 Corol cable signal 7m
ABB-3HAC8470-2 Corol cable signal 15m
ABB-3HAC8493-1 Pos SW ax1 Mtrl. set
ABB-3HAC8497-2 Axis 4 , complete
ABB-3HAC8497-3 Axis 4 , complete
ABB-3HAC8500-6 Harness power supply
ABB-3HAC8517-4 Priing instrconn ple
ABB-3HAC8534-1 Weldconnector bracket
ABB-3HAC8534-2 Weldconnector bracket
ABB-3HAC8606-1 Motor
ABB-3HAC8606-2 Motor
ABB-3HAC8607-1 Gear set unit
ABB-3HAC8607-2 Gear set unit
ABB-3HAC8608-1 Gear unit
ABB-3HAC8608-2 Gear unit
ABB-3HAC8609-1 Ierm. Wheel Unit Z4,5/5
ABB-3HAC8609-2 Ierm. Wheel Unit Z4,5/5
ABB-3HAC8613-1 Protecting ple
ABB-3HAC8628-1 CoverA
ABB-3HAC8629-1 Cover B
ABB-3HAC8630-1 Cover C
ABB-3HAC8632-1 Plug
ABB-3HAC8633-1 Distans screw
ABB-3HAC8639-1 Cage
ABB-3HAC8674-1 Connection box axis 4-6
ABB-3HAC8726-1 Instruction ple
ABB-3HAC8756-1 Mtrl set Cover FM640/6400S
ABB-3HAC8806-1 Clamp
ABB-3HAC8812-1 Cage
ABB-3HAC8820-1 Customer conn. axis 4
ABB-3HAC8822-1 PalletWizard
ABB-3HAC8826-1 Belt roller
ABB-3HAC8851-1 Sync.fixture
ABB-3HAC8863-1 Drive shaft
ABB-3HAC8864-1 Adjustable shaft
ABB-3HAC8869-1 Customer conn. axis 4
ABB-3HAC8894-1 Roller W=75
ABB-3HAC8898-1 Ple middle
ABB-504177882 KABEL W1/W2 5000L, 15M
ABB-504180880 CABLE
ABB-504180881 CABLE
ABB-504180882 KABEL W51/53/55 MOT. 1.1M
ABB-504180883 Cable
ABB-504183880 Cable W52/W54 Mot. 3.1 m
ABB-504186880 Cable Res. W62/W64 3.1 m
ABB-504186881 Cable W62/64 Res. 4.3M
ABB-504186883 CABEL
ABB-504198501 POLARITY PIN SEALOK
ABB-504212880 SUPPORT BEARING
ABB-504213001 Shaft
ABB-504214001 Disc
ABB-504215880 STEP BEARING
ABB-504217001 Disc
ABB-504218001 Flange bearing 250
ABB-504218002 Flange bearing 500/750
ABB-504405883 BEAM LENGTH = 2500
ABB-504417010 Cable Channel
ABB-504456880 Currecollector MTC 500,750
ABB-504456881 CURRECOLLECTOR
ABB-504458001 Connection Bar, MTC 250
ABB-504458002 Connection Bar, MTC 250
ABB-504463881 Screen
ABB-504475003 Nipple 90deg.
ABB-504476003 Coupling
ABB-504477003 Hose Nipple 3/8 M18X1.5
ABB-504478001 Hose 1/4
ABB-3HAC8899-1 Sweep inner
ABB-3HAC8901-2 Cylinder
ABB-3HAC8901-4 Reconditioning set
ABB-3HAC8907-32 Prot. ple, with nonie
ABB-3HAC8943-1 Drive shaft
ABB-3HAC8947-1 Bearing holder
ABB-3HAC8948-1 Clamping unit
ABB-3HAC8953-1 Spring
ABB-3HAC8954-1 Bearing bushing
ABB-3HAC8972-3 Automic Lubric. Unit
ABB-3HAC8981-1 Mandrel
ABB-3HAC8982-1 Reconditioning kit
ABB-3HAC8983-1 Reconditioning kit
ABB-3HAC8992-1 Mech stop Z
ABB-3HAC8994-1 Cover ple
ABB-3HAC8999-1 Bottom ple
ABB-3HAC9003-1 Product Manual IRB 4400
ABB-3HAC9021-1 Lubricion parts
ABB-3HAC9030-1 Cable bracket
ABB-3HAC9037-1 Arm
ABB-3HAC9038-1 Corol cable power L=7m
ABB-3HAC9038-2 Corol cable power L=15m
ABB-3HAC9038-3 Corol cable power L=22m
ABB-3HAC9038-4 Corol cable power L=30m
ABB-3HAC9039-1 Product Spec. S4Cplus
ABB-3HAC9040-1 Product Spec. IRB 6400R
ABB-3HAC9041-1 Product Spec. IRB 140
ABB-3HAC9047-1 Bush
ABB-3HAC9063-1 Hose clip
ABB-3HAC9070-1 Multipole con. I/O XS8
ABB-3HAC9079-1 Inductive switch
ABB-3HAC9103-1 Position switch 1-3
ABB-3HAC9104-1 Position switch 1-2
ABB-3HAC9107-1 Limit switches assembly
ABB-3HAC9112-1 Product Spec. IRB 2400
ABB-3HAC9117-1 Product Spec. IRB 4400
ABB-3HAC9120-1 Product Spec. IRB 6400PE
ABB-3HAC9121-1 Product Spec. IRB 6400S
ABB-3HAC9160-1 Arm ext. 345 Foundry
ABB-3HAC9161-1 Arm ext. 550 Foundry
ABB-3HAC9173-1 Fan unit,4 fans
ABB-3HAC9174-1 Fan unit,2 fans
ABB-3HAC9181-1 Oil tank
ABB-3HAC9186-1 Oil tank
ABB-3HAC9191-1 Warning label
ABB-3HAC9193-1 Arm stop
ABB-3HAC9197-1 Roller
ABB-3HAC9198-1 0-ring
ABB-3HAC9200-1 0-ring
ABB-3HAC9202-1 Single row bearing
ABB-3HAC9203-1 Shaft
ABB-3HAC9205-1 Ang.co.ball bearing
ABB-3HAC9216-1 Product Spec. IRB 340
ABB-3HAC9217-1 Product Spec. IRB 640
ABB-3HAC9218-1 Product Spec. RobotWare
ABB-3HAC9219-1 Cover
ABB-3HAC9236-1 Upper arm, foundry
ABB-3HAC9246-1 Cylinder
ABB-3HAC9258-1 Indicor lamp
ABB-3HAC9265-1 esc.Shaft, pl. bearing
ABB-3HAC9265-4 Shaft
ABB-3HAC9265-7 Plain Bearing
ABB-3HAC9267-1 Guide pin
ABB-3HAC9272-1 Valve
ABB-3HAC9276-1 Flow corol valve
ABB-3HAC9277-1 Cylinder switch
ABB-3HAC9286-1 T-connection
ABB-3HAC9287-1 Tube nipple
ABB-3HAC9288-1 CanBus Cable 7m
ABB-3HAC9288-2 CanBus Cable 15m
ABB-3HAC9288-3 CanBus Cable 22m
ABB-3HAC9288-4 CanBus Cable 30m
ABB-3HAC9299-1 External Axis
ABB-3HAC9301-1 ExternalAxis
ABB-3HAC9303-1 External Axis
ABB-3HAC9313-1 Distance
ABB-3HAC9316-1 Iernal Corol cable 7m
ABB-3HAC9316-3 Iern. Corol cable 15m
ABB-3HAC9316-4 Iern.Corol cable 22 m
ABB-3HAC9316-5 Iern.Corol Cable 30 m
ABB-3HAC9328-1 Cable unit ax.4-6
ABB-3HAC9330-1 Cable ax.4-6
ABB-3HAC9353-1 Sealing Plug
ABB-3HAC9362-1 Cover Foundry
ABB-3HAC9365-1 Motor T0-1,9 Nm
ABB-3HAC9368-1 Cover
ABB-3HAC9376-1 Product Spec. IRB 1400
ABB-3HAC9380-1 COVER
ABB-3HAC9386-1 Cable Gland
ABB-3HAC9387-1 Junction box complete
ABB-3HAC9397-1 Drive unit comp. (ringt)
ABB-3HAC9398-1 Drive unit comp. (left)
ABB-3HAC9401-2 Adjust. roller complete
ABB-3HAC9402-1 Turning roller complete
ABB-3HAC9403-1 Turning roller complete
ABB-3HAC9404-1 Turning roller complete
ABB-3HAC9410-2 Drive unit axis 4
ABB-3HAC9415-1 Clamp
ABB-3HAC9435-1 Guide rail block
ABB-3HAC9436-1 Guide rail block
ABB-3HAC9484-1 Balance unit type A
ABB-3HAC9485-1 Balancing unit type B
ABB-3HAC9494-1 Motor UnitAxis 1-3
ABB-3HAC9507-1 Spring Washer Conical
ABB-3HAC9508-1 Warning label
ABB-3HAC9519-1 Guide Bushing
ABB-3HAC9521-1 Drive System i. cable
ABB-3HAC9526-1 Warning label
ABB-3HAC9527-1 Instruction label
ABB-3HAC9528-1 Cleanroom Logotype
ABB-3HAC9534-1 Balancing unit set
ABB-3HAC9544-1 Sealing
ABB-3HAC9565-1 24V Filter unit
ABB-3HAC9578-1 Label layout UL/UR
ABB-3HAC9596-1 Calibrion tool
ABB-3HAC9609-2 CS/CP/IERB.f Cable 15m
ABB-3HAC9609-3 CS/CP/IERB.f Cable 22m
ABB-3HAC9609-4 CS/CP/IERB.f Cable 30m
ABB-3HAC9611-2 Wrist
ABB-3HAC9613-1 CP,CS,PROFIB.f Cable 7 m
ABB-3HAC9613-2 CP,CS,PROFIB.f Cable 15 m
ABB-3HAC9613-4 CP,CS,PROFIB.f Cable 30 m
ABB-3HAC9625-1 Leher bellow
ABB-3HAC9642-1 Tubular shaft
ABB-3HAC9658-1 Product Manual IRB 6400R
ABB-3HAC9659-1 Bracket for motor
ABB-3HAC9667-1 Harness Ethernet
ABB-3HAC9701-1 Wrist kit
ABB-3HAC9710-1 Heexchanger unit
ABB-3HAC9717-1 Ext axis limit conn.
ABB-3HAC9754-1 Receptacle for socket
ABB-3HAC9754-2 Receptacle for socket
ABB-3HAC9754-3 Receptacle for socket
ABB-3HAC9760-10 Cable cover 450mm
ABB-3HAC9760-9 Cable cover 250mm
ABB-3HAC9790-1 Cable chain support
ABB-3HAC9792-1 Jumper plug
ABB-3HAC9793-1 Guide rail block complete
ABB-3HAC9794-1 Guide rail block complete
ABB-3HAC9798-1 Guide rail block complete
ABB-3HAC9799-1 Multipole connector (pin)
ABB-3HAC9799-2 Multipole connector (pin)
ABB-3HAC9799-3 Multipole connector (pin)
ABB-3HAC9803-1 Product Manual IRB 340A
ABB-3HAC9819-1 Connectionbox CBUS
ABB-3HAC9841-1 Motor Incl. pinion
ABB-3HAC9858-1 Rail complete axis 1
ABB-3HAC9858-7 Cam
ABB-3HAC9858-8 Rail axis 2
ABB-3HAC9858-9 Rail axis 3
ABB-3HAC9859-2 CP,CS,PROFIBUS Cable 15 m
ABB-3HAC9859-4 CP,CS,PROFIBUS Cable 30 m
ABB-3HAC9860-1 Protecting ple
ABB-3HAC9871-1 Harness assembly weld i
ABB-3HAC9877-1 Harness assembly CP/CS a3
ABB-3HAC9878-1 Harness assembly CP/CS a4
ABB-3HAC9880-1 Signal cable
ABB-3HAC9909-15 Threaded bar
ABB-3HAC9938-1 Measuring Tool Axis 2-3
ABB-3HAC9953-1 Syncple with nonie
ABB-3HAC9962-1 Market ax. 1
ABB-3HAC9969-1 Bush
ABB-3HAC9989-1 Ext. cust. conn. harness
ABB-3HAC9990-1 Time relay unit
ABB-3HAC9993-1 Nipple for grease gun
ABB-3HEA193715-117 Lock for frame
ABB-3HEA367233-906 WELDING GUN PSF 315R +100
ABB-3HEA418159-026 Flange
ABB-3HEA441922-012 COACT NOZZLE
ABB-3HEA501152-002 FITTING PG36 45 DEG
ABB-3HEA502940-287 Single CoreAWG 18 BU
ABB-3HEA503375-002 Push button white
ABB-3HEA503375-160 Lamp push buttom
ABB-3HEA505666-005 Hose pack. double separion
ABB-3HEA506260-001 Motor unit, MU 10
ABB-3HEA506261-001 Motor unit, MU 20
ABB-3HEA506262-001 Motor unit, MU 30
ABB-3HEA506534-881 Cable W61/W62 Resolverflex.7,5m
ABB-3HEA506534-882 Cable W61/W62 Resolverflex. 9m
ABB-3HEA506534-883 Cable W61/W62 Resolverflex. 15m
ABB-3HEA506536-881 Cable W51/W52 Motor flex.7,5m
ABB-3HEA506536-882 Cable W51/W52 Motor flex. 9m
ABB-3HEA506536-883 Cable W51/W52 Motor flex. 15m
ABB-3HEA506538-881 Cable W1 Motorconn. box,lOm
ABB-3HEA800056-003 Connection terminal WDU 2,5
ABB-3HEA800063-001 Power Supply Qui-PS-100-240AC/24DC/5
ABB-3HEA800065-004 Busmodul DO
ABB-3HEA800065-005 End module
ABB-3HEA800072-001 Buscable Unitronic-bus L2/FIP
ABB-3HEA800073-001 Cable Chainflex CF140 5x0,75
ABB-3HEA800133-001 Sign Warning Swingframe
ABB-3HEA800357-008 Holding Clamp Binzel & Dinse
ABB-3HEA800437-001 BracketAxis Selector Ple
ABB-3HEA800438-001 Axis Selector Ple
ABB-3HEA800439-001 DeviceNet DC I/O 7+12
ABB-3HEA800439-002 Drive Module I/O RS485
ABB-3HEA800442-001 Axis Selector IRBP K/R
ABB-3HEA800447-001 Coactor DILM12-10 (24VDC)
ABB-3HEA800447-003 Auxiliary Coact 1NO/3NC DILA-XHI13
ABB-3HEA800447-008 Coactor DILM12-10 (230VAC)
ABB-3HEA800448-001 Relay D2,5/5-R121 L 24VDC LED
ABB-3HEA800449-001 Harness Drive Unit
ABB-3HEA800450-001 Harness Motor
ABB-3HEA800451-001 Harness C / C-Index
ABB-3HEA800452-001 Harness L
ABB-3HEA800453-001 Harness K/R
ABB-3HEA800454-001 Harness K/R 1-ax
ABB-3HEA800455-001 Harness A
ABB-3HEA800456-001 Harness B/D
ABB-3HEA800457-001 Harness RTTA/L/S, K/R 1-ax
ABB-3HEA800461-001 Cable MS XS41 / XS41.2
ABB-3HEA800462-001 Cable I/O
ABB-3HEA800464-001 SIB V Opt.2 PreReset
ABB-3HEA800516-001 Jumper 1xA/L 12Pol
ABB-3HEA800521-001 Cable Motor
ABB-3HEA800521-002 Cable Motor I. 1.1M
ABB-3HEA800521-003 Cable Motor I.
ABB-3HEA800521-004 Cable Motor I.
ABB-3HEA800521-007 Cable Motor I. 5.5m
ABB-3HEA800522-001 Cable Resolver i.
ABB-3HEA800522-002 CABLE RESOLVER I.
ABB-3HEA800522-003 Cable Resolver I. 2.2M
ABB-3HEA800522-004 CABLE RESOLVER I.
ABB-3HEA800523-001 Cable Motor I. Flexible 3.1M
ABB-3HEA800523-002 Cable Motor I. Flexible 4.3M
ABB-3HEA800523-003 Cable Motor I. Flexible
ABB-3HEA800524-001 Cable Res. I. Flexible 3.1M
ABB-3HEA800524-002 Cable Res. I. Flexible
ABB-3HEA800524-003 Cable Res. I. Flexible 5.3M
ABB-3HEA800531-001 Cable Motor 500, 1000 C 7M
ABB-3HEA800531-002 Cable Motor 500, 10000 1OM
ABB-3HEA800531-003 Cable Motor 500, 1000 C 15M
ABB-3HEA800532-001 Cable Motor 250, 500 C-Index 7M
ABB-3HEA800532-002 Cable Motor 250, 500 C-Index 1OM
ABB-3HEA800532-003 Cable Motor 250, 500 C-Index 15M
ABB-3HEA800533-001 Cable Motor 250-750 K/R 7M
ABB-3HEA800533-002 Cable Motor 250-750 K/R
ABB-3HEA800533-003 Cable Motor 250-750 K/R 15M
ABB-3HEA800534-001 Cable Motor 250-750 B/D
ABB-3HEA800534-003 Cable Motor 250-750 B/D 15M
ABB-3HEA800535-001 Cable Motor 250-750 A 7M
ABB-3HEA800535-002 Cable Motor 250-750 A
ABB-3HEA800535-003 Cable Motor 250-750 A 15M
ABB-3HEA800536-001 Cable Motor 250-2000 L / MTC 7M
ABB-3HEA800536-002 Cable Motor 250-2000 L / MTC
ABB-3HEA800536-003 Cable Motor 250-2000 L / MTC
ABB-3HEA800536-004 Cable Motor 250-2000L/MTC 20m
ABB-3HEA800537-001 Cable Motor 5000 L 7M
ABB-3HEA800537-002 Cable Motor 5000 L 1OM
ABB-3HEA800537-003 Cable Motor 5000 L 15M
ABB-3HEA800538-001 Cable Motor Flexible 7M
ABB-3HEA800538-002 Cable Motor Flexible 1OM
ABB-3HEA800538-003 Cable Motor Flexible
ABB-3HEA800538-005 Cable Motor Flexible
ABB-3HEA800538-006 Cable Motor Flexible
ABB-3HEA800538-007 Cable Motor Flexible 18M
ABB-3HEA800538-008 Cable Motor Flexible 20M
ABB-3HEA800538-009 Cable Motor Flexible 22M
ABB-3HEA800538-010 Cable Motor Flexible 24M
ABB-3HEA800580-001 Connection PTC IRBPA
ABB-3HEA800631-001 tachme
ABB-3HEA800647-001 tachme
ABB-3HEA800648-001 Plastic bushing
ABB-3HEA800649-001 Shaft
ABB-3HEA800675-001 Ceral lubricion cable, 2m (carriage)
ABB-3HEA800675-002 Ceral lubricion cable, 20m (chain)
ABB-3HEA800678-002 Power cable (chain) 6m
ABB-3HEA800678-006 Power cable (chain) 10m
ABB-3HEA800678-007 Power cable (chain)
ABB-3HEA800736-001 Power cable (floor) 7m
ABB-3HEA800736-002 Power cable (floor) 15m
ABB-3HEA800736-003 Power cable (floor) 22m
ABB-3HEA800736-004 Power cable (floor) 30m
ABB-3HEA800781-001 Cable PB Complete
ABB-3HEA800781-003 Cable PB Complete
ABB-3HEA800782-001 Cable Ge Switch 7m
ABB-3HEA800782-003 Cable Ge Switch 15m
ABB-3HEA800784-001 Cable Home Pos. / Stn Ind. External
ABB-3HEA800785-001 Cable Limit Switch Complete
ABB-3HEA800786-001 Cable SMB, Connection in Box
ABB-504478002 Hose 3/8
ABB-504479001 Bulkheadfitting
ABB-504480883 Swivel set
ABB-504481883 Swivel set
ABB-504504880 Weldingreturn cable 2x50mm2
ABB-504504890 Weldingreturn cable 95mm2
ABB-504504891 Welding return cable
ABB-504504892 Weldingreturn cable 95mm2
ABB-504504893 Welding return cable 95mm2 L=2,OM
ABB-504504894 Welding return cable 95mm2 L=0,9M
ABB-504504896 Weldingreturn cable 95mm2
ABB-504504900 Return Cable 120MM2 L=2,7M
ABB-504504901 Return Cable 120MM2 L=3,1M
ABB-504504902 Return Cable 120MM2 L=5,8M
ABB-504540880 Returncable 95 mm2.L=7 m
ABB-504540881 Returncable 95 mm2.L=10 m
ABB-504540882 Returncable 95 mm2.L=15 m
ABB-504540883 Returncable 95MM2 L = 22M
ABB-504552004 Label IRBP 750 R
ABB-504558881 Marking Stn number
ABB-504676882 FOOT COMPL.
ABB-504677880 ROBOTFOOT H=225
ABB-504692001 Isolor
ABB-504720880 Cableset Ext. IRBP C 7M
ABB-504720882 Cableset Ext.
ABB-504722880 CABLE SET EXTERNAL
ABB-504722881 CABLE SET EXTERNAL
ABB-504723882 Cableset Ext.
ABB-3HEA800787-001 Cable SMB
ABB-3HEA800788-001 Cable LRC
ABB-3HEA800800-001 Control cable signal 10m
ABB-3HEA800800-004 Control cable signal 25m
ABB-3HEA800803-001 Resolver/Power cab,Inline
ABB-3HEA800803-002 Resolver/Power cab, 90deg
ABB-3HEA800803-003 Resolv/Power cable,180deg
ABB-3HEA800805-001 BRB
ABB-3HEA800806-001 BRB (foundry) 1P66
ABB-3HEA800824-001 POWER CABLE
ABB-3HEA800824-002 POWER CABLE (FLOOR)
ABB-3HEA800824-003 Power cable (floor)
ABB-3HEA800824-004 Power cable (floor)
ABB-3HEA800826-001 Power cable (chain)
ABB-3HEA800826-002 Power cable (chain)
ABB-3HEA800826-003 Power cable (chain)
ABB-3HEA800826-004 Power cable (chain) 8m
ABB-3HEA800826-006 Power cable (chain) 1 Om
ABB-3HEA800826-009 Power cable (chain) 13m
ABB-3HEA800876-001 Option Light Beam
ABB-3HEA800877-001 Option Pre Reset
ABB-3HEA800878-001 Option Reset Unit
ABB-3HEA800896-001 Power cable (floor)
ABB-3HEA800896-002 Power cable (floor)
ABB-3HEA800896-003 Power cable (floor)
ABB-3HEA800896-004 Power cable (floor)
ABB-3HEA800897-002 Dust cap, bayonet
ABB-3HEA800897-005 Dust cap, bayonet
ABB-3HEA800906-001 NODE SPLITTER
ABB-3HEA800908-002 SMB box compl.IRBP L/MTC
ABB-3HEA800925-001 Screen ple
ABB-3HEA800956-001 Insule flange
ABB-3HEA800964-001 SMB 1AXIS, STANDARD IP65
ABB-3HEA800964-003 SMB 2axis, standard 1P65
ABB-3HEA800964-005 SMB 4axis, standard 1P65
ABB-3HEA800970-004 Product manual IRBT 4003S/6003S french
ABB-3HEA801001-001 Isolor for returncable
ABB-3HEA801008-005 Receptacle, 23p, pin (wall m.)
ABB-3HEA801138-001 Jumper plug, LS.BRU/SMU
ABB-3HEA801171-001 BRACKET FOR DRIVEUNIT
ABB-3HEA801176-001 Rotary unit
ABB-3HEA801177-001 Rotary unit
ABB-3HEA801178-001 Rotary unit
ABB-3HEA801179-001 Rotary unit
ABB-3HEA801180-001 Rotary unit
ABB-3HEA801195-001 Cableset
ABB-3HEA801212-002 Manual, Iroduction & Safety, Swedish
ABB-3HEA801270-001 Power cable (floor)
ABB-3HEA801270-002 Power cable (floor)
ABB-3HEA801270-003 Power cable (floor) 22m
ABB-3HEA801270-004 Power cable (floor)
ABB-3HEA801277-001 Customer Cable, CP/CS/Parallel
ABB-3HEA801277-003 Customer Cable, CP/CS/Parallel, 7 m
ABB-3HEA801277-004 Customer Cable, CP/CS/Parallel, 8m
ABB-3HEA801277-005 Customer Cable, CP/CS/Parallel, 9m
ABB-3HEA801277-006 Customer Cable, CP/CS/Parallel, 1 Om
ABB-3HEA801277-007 Customer cable CP/CS/Parallel,l l m
ABB-3HEA801277-008 Customer cable CP/CS/Parallel,26m
ABB-3HEA801277-009 Customer cable CP/CS/Parallel,12m
ABB-3HEA801277-010 Customer cable CP/CS/Parallel,13m
ABB-3HEA801277-011 Customer cable CP/CS/Parallel,14m
ABB-3HEA801277-012 Customer cable CP/CS/Parallel
ABB-3HEA801277-013 Customer cable CP/CS/Parallel,16m
ABB-3HEA801278-004 Customer Cable, CP/CS/Ierbus, 8m
ABB-3HEA801278-006 Customer Cable, CP/CS/Ierbus, 1 Om
ABB-3HEA801278-007 Customer Gable CP/CS/Ierbus,l l m
ABB-3HEA801278-008 Customer cable CP/CS/Ierbus,12m
ABB-3HEA801278-009 Customer cable CP/CS/Ierbus,13m
ABB-3HEA801278-012 Customer cable CP/CS/Ierbus,16m
ABB-3HEA801279-001 Customer Cable, CP/CS/DeviceNet/Can
ABB-3HEA801279-002 Customer Cable, CP/CS/DeviceNet/Can
ABB-3HEA801279-003 Customer Cable, CP/CS/DeviceNet/Can
ABB-3HEA801279-005 Customer Cable, CP/CS/DeviceNet/Can
ABB-3HEA801279-006 Customer Cable, CP/CS/DeviceNet/Can, 1 Om
ABB-3HEA801279-008 Customer Cable, CP/CS/DeviceNet/Can, 18m
ABB-3HEA801279-009 Customer cable,CP/CS/DeviceNet/Can,12m
ABB-3HEA801279-010 Customer cable,CP/CS/DeviceNet/Can,13m
ABB-3HEA801279-012 Customer cable,CP/CS/DeviceNet/Can
ABB-3HEA801279-014 Customer cable,CP/CS/DeviceNet/Can
ABB-3HEA801280-002 Customer Cable, CP/CS/Profibus, 6m
ABB-3HEA801280-003 Customer Cable, CP/CS/Profibus, 7m
ABB-3HEA801280-005 Customer Cable, CP/CS/Profibus, 9m
ABB-3HEA801280-006 Customer Cable, CP/CS/Profibus
ABB-3HEA801280-009 Customer cable CP/CS/Profibus,13m
ABB-3HEA801280-012 Customer cable CP/CS/Profibus,16m
ABB-3HEA801280-014 CUSTOMER CABLE CP/CS/PROFIBUS
ABB-3HEA801280-015 CUSTOMER CABLE CP/CS/PROFIBUS
ABB-3HEA801325-003 Receptacle, 12p, pin (bulk head)
ABB-3HEA801326-003 Receptacle, 12p, socket (bulk head)
ABB-3HEA801331-001 Cable Res. Flex.
ABB-3HEA801331-002 Cable Res. Flex. 5m
ABB-3HEA801331-003 Cable Res. Flex. 6m
ABB-3HEA801331-004 Cable Res. Flex.
ABB-3HEA801331-005 Cable Res. Flex.
ABB-3HEA801331-006 Cable Res. Flex. 9m
ABB-3HEA801331-007 Cable Res. Flex. 10m
ABB-3HEA801331-008 Cable Res. Flex. 11m
ABB-3HEA801331-009 Cable Res. Flex. 12m
ABB-3HEA801331-010 Cable Res. Flex. 13m
ABB-3HEA801331-011 Cable Res. Flex. 14m
ABB-3HEA801331-012 Cable Res. Flex. 15m
ABB-3HEA801331-013 Cable Res. Flex. 22m
ABB-3HEA801331-016 Cable Res. Flex. 30m
ABB-3HEA801331-017 Cable Res. Flex. 18m
ABB-3HEA801331-018 Cable Resolver Flex. 20m
ABB-3HEA801331-020 Cable Resolver Flex. 24m
ABB-3HEA801337-004 Cable Resolver Flexible 14m (Thread)
ABB-3HEA801337-005 Cable Resolver Flexible 15m (Thread)
ABB-3HEA801337-008 Cable Resolver Flexible 18m (Thread)
ABB-3HEA801337-012 Cable Resolver Flexible 22m (Thread)
ABB-3HEA801337-019 Cable Resolver Flexible 36m (Thread)
ABB-3HEA801339-001 Cable Motor 5000 L/MTC Flexible 7m
ABB-3HEA801339-002 Cable Motor 5000 L/MTC Flexible 1 Om
ABB-3HEA801339-003 Cable Motor 5000 L/MTC Flexible 15m
ABB-3HEA801340-001 Cable Resolver Flexible 7m
ABB-3HEA801340-002 Cable Resolver Flexible 10m
ABB-3HEA801340-005 Cable Resolver Flexible
ABB-3HEA801340-007 Cable Resolver Flexible
ABB-3HEA801340-010 Cable Resolver Flexible 20m
ABB-3HEA801340-014 Cable Resolver Flexible
ABB-3HEA801340-019 Cable Resolver Flexible 30m
ABB-3HEA801372-001 Driveunit for IRB6400R/IRB6400
ABB-3HEA801377-004 Cabelset IRB2400 18m M2004
ABB-3HEA801442-002 Cable W100 RTT L=14m
ABB-3HEA801442-006 Cable W100 RTT L=22m
ABB-3HEA801442-009 Cable W100 RTT L=28m
ABB-3HEA801446-002 Junction Box 6-pol
ABB-3HEA801446-003 Junction Box 12-pol
ABB-3HEA801461-001 Power cable
ABB-3HEA801461-002 POWER CABLE (FLOOR)
ABB-3HEA801461-003 Power cable (floor)
ABB-3HEA801461-004 Power cable
ABB-3HEA801622-001 SHELF
ABB-3HEA801625-001 Bracket Robotfoot
ABB-3HEA801632-001 Guide rail 45 L=1,0 m std.
ABB-3HEA801632-002 Guide rail 45 L=1,5 m std
ABB-3HEA801632-003 Guide rail 45 L=2,0 m std
ABB-3HEA801632-004 Guide rail 45 L=1,0 m foundry
ABB-3HEA801632-005 Guide rail 45 L=1,5 m foundry
ABB-3HEA801632-006 Guide rail 45 L=2,0 m foundry
ABB-3HEA801651-001 Gear rack 1,0 m
ABB-3HEA801651-002 Gear rack 0,5 m
ABB-3HEA801652-001 Joibracket
ABB-3HEA801658-001 Set of seals for size 45
ABB-3HEA801660-001 Mechanical stop IRBT
ABB-3HEA801665-001 Rubber buffert
ABB-3HEA801668-001 Gearwheel IRBT 4004/6004/7004
ABB-3HEA801676-008 Cablegland short
ABB-3HEA801681-001 Bracket for cablechain
ABB-3HEA801685-001 Bracket for cablechain
ABB-3HEA801691-001 Wirefeeder Cable
ABB-3HEA801710-001 Wirefeeder cable
ABB-3HEA801723-001 ADAPTER
ABB-3HEA801730-002 Filter MigRob500
ABB-3HEA801780-001 BOBIN COMPLETE
ABB-3HEA801780-002 Marhon Complete Hood
ABB-3HEA801780-003 Marhon Comp.Octagon
ABB-3HEA801808-001 SWITCH HOUSING
ABB-3HEA801809-001 MANOEUVRE HEAD
ABB-3HEA801859-001 Friction washer TM 1
ABB-3HEA801864-002 CPS/CBus Cable IRBT 8m
ABB-3HEA801915-001 Mouing ple J1 IRBT 6004/7004
ABB-3HEA801942-001 Gear wheel protection
ABB-3HEA801943-001 Gearwheel protection upper
ABB-3HEA801996-001 Shaft
ABB-3HEA802066-001 Gearbox, Spare part kit
ABB-3HEA802067-001 Gearbox, Spare port kit.
ABB-3HEA802068-001 Gearbox, Spare part kit
ABB-3HEA802069-001 Gearbox, Spare port kit
ABB-3HEA802070-001 Gearbox, Spare port kit.
ABB-3HEA802136-001 Top cover for IRBT
ABB-3HEA802148-001 Marking Set Safety
ABB-3HEA802171-001 Safety IF B/C/D/K/R
ABB-3HEA802177-001 Box 160x240x90
ABB-3HEA802181-001 OP-Panel 2 OP-ready Incl. Stand
ABB-3HEA802183-001 3-way RJ45 8P/8C shielded MPK402
ABB-3HEA802189-001 Harness Man Jog IRBP K/R
ABB-3HEA802191-001 Harness Safety B/C/Ci/D/K/R
ABB-3HEA802195-001 Harness SafetyA/L/S
ABB-3HEA802196-001 Harness SIB B/C/Ci/D/K/R
ABB-3HEA802201-001 Cable I/O RS485
ABB-3HEA802203-001 Cable Can Bus 7m
ABB-3HEA802203-003 Cable Can Bus 15m
ABB-3HEA802203-005 Cable Can Bus
ABB-3HEA802205-001 Cable Pos.Sign.B/C/Ci/D/K/R
ABB-3HEA802211-001 Cable Power IRB 4400 6M
ABB-3HEA802211-002 Cable Power IRB 4400 7M
ABB-3HEA802211-003 Cable Power IRB 4400 8M
ABB-3HEA802211-004 Cable Power IRB 4400 9M
ABB-3HEA802211-005 Cable Power IRB 4400 1OM
ABB-3HEA802211-006 Cable Power IRB 4400 11M
ABB-3HEA802215-001 Cable Pch
ABB-3HEA802217-003 Cable Man Jog 15m
ABB-3HEA802219-001 Cable Power IRB 4400F 6M
ABB-3HEA802221-001 Cable Feed 1 2,2m
ABB-3HEA802221-002 Cable Feed 1
ABB-3HEA802223-001 Cable Feed 2 2,2m
ABB-3HEA802223-002 Cable Feed 2
ABB-3HEA802225-002 Cable Signal MigRob
ABB-3HEA802225-003 Cable Signal MigRob
ABB-3HEA802227-002 Cable Can Bus MigRob
ABB-3HEA802227-003 Cable Can Bus MigRob
ABB-3HEA802229-001 Cable Safety Sign. 7m
ABB-3HEA802229-002 Cable Safety Sign.
ABB-3HEA802229-003 Cable Safety Sign.
ABB-3HEA802237-002 Cable TSC
ABB-3HEA802239-001 Cable 230VAC+Syst. 7m
ABB-3HEA802239-002 Cable 230VAC+Syst.
ABB-3HEA802239-003 Cable 230VAC+Syst.
ABB-3HEA802243-001 7th axis Power exteion cable
ABB-3HEA802244-001 7th axis signal exteion cable
ABB-3HEA802304-001 Aluminium rod
ABB-3HEA802305-001 Flug
ABB-3HEA802330-001 Guideple for cablechain
ABB-3HEA802330-002 Guideple for cablechain
ABB-3HEA802338-001 tachmeSingle
ABB-3HEA802341-001 tachme
ABB-3HEA802357-001 Distance for cable tray
ABB-3HEA802359-001 Protection ple for cable chain
ABB-3HEA802366-001 tachmefor SMB box
ABB-3HEA802372-012 Cable Power, R1.MP (Chain)
ABB-3HEA802377-001 Cable tray low for cable chain
ABB-3HEA802385-001 Guideple with for cable chain
ABB-3HEA802402-001 Cable Power IRBT XP7-J1.XS7 (Floor) 7m
ABB-3HEA802402-002 Cable Power IRBT XP7-J1.XS7 (Floor) 15m
ABB-3HEA802402-003 Cable Power IRBT XP7-J1.XS7 (Floor) 22m
ABB-3HEA802402-004 Cable Power IRBT XP7-J1.XS7 (Floor) 30m
ABB-3HEA802403-001 Cable Power IRBT J1.XP7-M7 (Chain) 5.5m
ABB-3HEA802403-002 Cable Power IRBT J1.XP7-M7 (Chain) 6.5m
ABB-3HEA802403-003 Cable Power IRBT J1.XP7-M7 (Chain) 7.5m
ABB-3HEA802403-004 Cable Power IRBT J1.XP7-M7 (Chain) 8.5m
ABB-3HEA802403-005 Power IRBT J1.XP7-M7 (Ch) 9.5m
ABB-3HEA802403-006 Cable Power IRBT J1.XP7-M7 (Chain) 10.5m
ABB-3HEA802403-007 Cable Power IRBT J1.XP7-M7 (Chain) 11.5m
ABB-3HEA802403-008 Cable Power IRBT J1.XP7-M7 (Chain) 12.5m
ABB-3HEA802403-009 Cable Power IRBT J1.XP7-M7 (Chain) 13.5m
ABB-3HEA802403-010 Cable Power IRBT J1.XP7-M7 (Chain) 14.5m
ABB-3HEA802403-011 Cable Power IRBT J1.XP7-M7 (Chain) 15.5m
ABB-3HEA802403-014 Cable Power IRBT J1.XP7-M7 (Chain) 30m
ABB-3HEA802403-015 Cable Power IRBT J1.XP7-M7 (Chain) 17.5m
ABB-3HEA802403-017 Cable Power IRBT J1.XP7-M7 (Chain) 20.5m
ABB-3HEA802403-019 Cable Power IRBT J1.XP7-M7 (Chain) 24.5m
ABB-3HEA802409-001 Cable Signal IRB R1.SMB (Chain) 6m
ABB-3HEA802409-002 Cable Signal IRB R1.SMB (Chain) 7m
ABB-3HEA802409-003 Cable Signal IRB R1.SMB (Chain) 8m
ABB-3HEA802409-004 Cable Signal IRB R1.SMB (Chain) 9m
ABB-3HEA802409-005 Cable Signal IRB R1.SMB (Chain) 10m
ABB-3HEA802409-006 Cable Signal IRB R1.SMB (Chain) 11m
ABB-3HEA802409-007 Cable Signal IRB R1.SMB (Chain) 12m
ABB-3HEA802409-008 Cable Signal IRB R1.SMB (Chain) 13m
ABB-3HEA802409-009 Cable Signal IRB R1.SMB (Chain) 14m
ABB-3HEA802409-010 Cable Signal IRB R1.SMB (Chain) 15m
ABB-3HEA802409-011 Cable Signal IRB R1.SMB (Chain) 16m
ABB-3HEA802409-012 Cable Signal IRB R1.SMB (Chain) 22m
ABB-3HEA802409-014 Cable Signal IRB R1.SMB (Chain) 30m
ABB-3HEA802409-015 Cable Signal IRB R1.SMB (Chain) 18m
ABB-3HEA802409-018 Cable Signal IRB R1.SMB (Chain) 25m
ABB-3HEA802426-001 Guide for zonedivision
ABB-3HEA802432-001 End cam
ABB-3HEA802433-001 Cam for zonedivision
ABB-3HEA802459-001 Bracket for pos switch
ABB-3HEA802470-001 Connecting piece for cams
ABB-3HEA802545-001 Screw full thread
ABB-3HEA802549-004 Cable Safety Sign.Flex
ABB-3HEA802551-004 Cable 230VAC+Syst. Flex
ABB-3HEA802553-009 Cable CanBus MRob Flex 29m
ABB-3HEA802560-003 Cable and hose set
ABB-3HEA802586-002 Gland ple with gasket
ABB-3HEA802587-003 Cable grommet 8-9 mm
ABB-3HEA802587-004 Cable grommet 7-8 mm
ABB-3HEA802587-008 Blind grommet
ABB-3HEA802587-010 Cable grommet 6-7 mm
ABB-3HEA802588-001 Straight coupling M6-06
ABB-3HEA802589-001 Double-tube clamp 06
ABB-3HEA802590-001 Bracket for lubricion block
ABB-3HEA802591-001 Straight adaptor R1/8
ABB-3HEA802592-001 Tube coupling 90° R1/8-06
ABB-3HEA802600-001 Hydraulic tube 06x1
ABB-3HEA802601-001 Hydraulic tube 06x1
ABB-3HEA802602-001 Hydraulic tube 06x1
ABB-504723883 Cableset Ext.
ABB-504724881 Cableset
ABB-504724882 Cableset
ABB-504730881 Cable
ABB-504730882 Cable
ABB-504736881 Cable
ABB-504760880 Cable
ABB-504760881 Cable W71/72 Slipring L=0.8M
ABB-504760882 Cable W71/72 Slipring L=2,6M
ABB-504763880 Slipring Complete
ABB-504763881 Slipring Complete
ABB-504763882 Slipring Complete MTC 2000
ABB-504763883 Slipring Complete MTC 5000
ABB-504763884 Slipring Complete MIC1/MIC2
ABB-504765880 Cable
ABB-504765881 Cable W73/74 Slipring L=3,7
ABB-504771880 OPCOM IF B/D/C/K/R/E/F
ABB-504773880 OPCOM IFA/L/S/T
ABB-504774880 Jumper OPCOM
ABB-504776880 OP Panel 1 OP-Ready
ABB-504782880 OP-Panel 1 OP-Ready
ABB-504783880 OP-Panel 2 OP-Ready
ABB-504808001 MOTOR WITH TACHO
ABB-504809880 CABLESET DRIVE UNIT
ABB-504810880 FEED UNIT
ABB-504985882 W92 Doorswitch Comp.
ABB-504988882 Cable W70 OP Panel
ABB-504994880 SIB V
ABB-3HEA802605-001 Bulkhead Straight
ABB-3HEA802616-001 Carriage table IRBT6004/7004
ABB-3HEA802617-001 Carriage table IRBT 4004
ABB-3HEA802619-001 Hydraulic hose 6m
ABB-3HEA802619-005 Hydraulic hose 10m
ABB-3HEA802619-008 Hydraulic hose 13m
ABB-3HEA802619-010 Hydraulic hose 15m
ABB-3HEA802619-011 Hydraulic hose 22m
ABB-3HEA802619-012 Hydraulic hose 30m
ABB-3HEA802646-001 Hydraulic tube 06x1
ABB-3HEA802647-001 Hydraulic tube 06x1
ABB-3HEA802666-001 End protection
ABB-3HEA802668-001 Two-piece viton seal
ABB-3HEA802673-003 Lubrication system local adaption
ABB-3HEA802681-001 Mounting plate J1
ABB-3HEA802714-001 Pos switch with bracket
ABB-3HEA802717-001 Hydraulic tube
ABB-3HEA802718-001 Hydraulic tube
ABB-3HEA802719-001 Nipple block
ABB-3HEA802746-001 Grease distribution block
ABB-3HEA802753-001 Mounting plate
ABB-3HEA802757-001 Calibration Tool
ABB-3HEA802766-001 Pos switch complete
ABB-3HEA802778-001 Cable chain part 5 links
ABB-3HEA802779-001 Cable chain part, 10 links
ABB-3HEA802791-001 Std contact plate 6004/7004
ABB-3HEA802793-002 Riser 4004
ABB-3HEA802796-001 Riser 6004 / 7004
ABB-3HEA802796-002 Riser 6004
ABB-3HEA802798-001 Corol unit grease pump
ABB-3HEA802798-007 Corol unit grease pump
ABB-3HEA802810-001 Cable harness grease pump
ABB-3HEA802813-001 Steel laminar cover
ABB-3HEA802813-002 Steel laminar cover
ABB-3HEA802813-003 Steel laminar cover
ABB-3HEA802813-004 Steel laminar cover
ABB-3HEA802813-005 Steel laminar cover
ABB-3HEA802813-006 Steel laminar cover
ABB-3HEA802813-007 Steel laminar cover
ABB-3HEA802813-008 Steel laminar cover
ABB-3HEA802813-009 Steel laminar cover
ABB-3HEA802813-010 Steel laminar cover
ABB-3HEA802813-011 Steel laminar cover
ABB-3HEA802813-012 Steel laminar cover
ABB-3HEA802813-013 Steel laminar cover
ABB-3HEA802813-014 Steel laminar cover
ABB-3HEA802813-015 Steel laminar cover
ABB-3HEA802813-016 Steel laminar cover
ABB-3HEA802813-017 Steel laminar cover
ABB-3HEA802813-018 Steel laminar cover
ABB-3HEA802813-019 Steel laminar cover
ABB-3HEA802813-020 Steel laminar Cover
ABB-3HEA802817-001 Safety valve
ABB-3HEA802820-001 Cover rail 45
ABB-3HEA802820-002 COVER RAIL 30
ABB-3HEA802824-001 Pump complete
ABB-3HEA802827-001 Instruction label
ABB-3HEA802828-002 Media hose 7m
ABB-3HEA802828-003 Media hose 8m
ABB-3HEA802828-006 Media hose 11m
ABB-3HEA802828-007 Media hose 12m
ABB-3HEA802828-009 Media hose 14m
ABB-3HEA802835-001 8 axis power cable 6m
ABB-3HEA802835-002 8 axis power cable 7 M
ABB-3HEA802835-004 8 axis power cable 9m
ABB-3HEA802835-005 8 axis power cable 1 Om
ABB-3HEA802835-010 8 axis power cable 15m
ABB-3HEA802835-011 8 axis power cable 16m
ABB-3HEA802850-001 Electrical Kit BRB
ABB-3HEA802854-001 Connector bracket
ABB-3HEA802870-001 End brackets complete
Board VCM 232.2
P/N:415-2257 SERVOVALVE
Part No.: 029.359.088
VME-Manager Master
SIEMENS
垫圈\MARATHON\058-8738\升降系统 垫圈\制造厂或品牌:MARATHON\厂家配件号:058-8738\设备名称:升降系统
密封环\MARATHON\060-3120\升降系统 密封环\制造厂或品牌:MARATHON\厂家配件号:060-3120\设备名称:升降系统
轴承\MARATHON\077-1513\升降系统 轴承\制造厂或品牌:MARATHON\厂家配件号:077-1513\设备名称:升降系统
轴承\MARATHON\073-5318\锚机 轴承\制造厂或品牌:MARATHON\厂家配件号:073-5318\设备名称:锚机
垫圈\MARATHON\058-8739\升降系统 垫圈\制造厂或品牌:MARATHON\厂家配件号:058-8739\设备名称:升降系统
CLAMP RING\MARATHON\079-1486 CLAMP RING\制造厂或品牌:MARATHON\厂家配件号:079-1486\设备名称:JACKING SYSTEM
齿轮\MARATHON\055-9810\升降系统 齿轮\制造厂或品牌:MARATHON\厂家配件号:055-9810\设备名称:升降系统
轴承\MARATHON\073-5319\升降系统 轴承\制造厂或品牌:MARATHON\厂家配件号:073-5319\设备名称:升降系统
丝堵\MARATHON\040-3840\升降系统 丝堵\制造厂或品牌:MARATHON\厂家配件号:040-3840\设备名称:升降系统
CAPSCREW\MARATHON\400-1889 CAPSCREW\制造厂或品牌:MARATHON\厂家配件号:400-1889\设备名称:JACKING SYSTEM
调节螺母\MARATHON\053-7956\升降系统 调节螺母\制造厂或品牌:MARATHON\厂家配件号:053-7956\设备名称:升降系统
NYLON PELLET\MARATHON\053-7945 NYLON PELLET\制造厂或品牌:MARATHON\厂家配件号:053-7945\设备名称:JACKING SYSTEM
轴承盖\MARATHON\200-9674\升降系统 轴承盖\制造厂或品牌:MARATHON\厂家配件号:200-9674\设备名称:升降系统
密封环\MARATHON\200-9673\升降装置 密封环\制造厂或品牌:MARATHON\厂家配件号:200-9673\设备名称:升降装置
卡环\MARATHON\201-2120\升降装置 卡环\制造厂或品牌:MARATHON\厂家配件号:201-2120\设备名称:升降装置
防尘环\MARATHON\097-4633\升降系统 防尘环\制造厂或品牌:MARATHON\厂家配件号:097-4633\设备名称:升降系统
开口环\MARATHON\053-7798\升降系统 开口环\制造厂或品牌:MARATHON\厂家配件号:053-7798\设备名称:升降系统
油封\MARATHON\401-3493\升降装置 油封\制造厂或品牌:MARATHON\厂家配件号:401-3493\设备名称:升降装置
轴承\MARATHON\039-1515\锚机 轴承\制造厂或品牌:MARATHON\厂家配件号:039-1515\设备名称:锚机
PIPE PLUG\MARATHON\006-2313 PIPE PLUG\制造厂或品牌:MARATHON\厂家配件号:006-2313\设备名称:JACKING SYSTEM
Art.No.
Art.No.
lypc
40"IRH
60"IRH
RAEM 40
1861860
1861870
64
RAEM 60
2256760
2256770
3
RAKM125 M101861720
1861730
COOLANT PUMP W/ MOTOR/GRUNDFOS MTR32-4/1-A-F-A-HUUV 440D, 60Hz
RAEM 125,M12
2256140
2256150
RAEM 350M12
2256440
22564501861790
RAEM 800
1861840
1861850
RAEM 1500
2255400
2255410
RAEM 2500
2255420
2255430
4 Pcs MG1/80-G28-A1 Q1Q1PGG
4 Pcs MS30/90-00 EBPGG
6 Pcs MS30/100-00 EBPGG
6 Pcs MG1/90-G28-A1 Q1Q1PGG
8Pcs MG1/55-G1-E2-A1 Q1Q1PGG
铁路刚性分段绝缘器G-FD-CWL-1800、接触网分段处分相绝缘器
铁路FYFH-1.6AT分段绝缘器（翼式A型）分相绝缘器
铁路翼式A/B型分相分段绝缘器TKXFFP-1.6TG低价出售
三级电力承试资质 SF6气体微水测试仪 微水仪 SF6气体微水测量仪
中正ANJ扭矩扳手检定仪扳手扭力检测校准
承试类一级SF6气体微水测试仪1台可出售可租赁
铁路XFFP-1.60NB100501HD消弧分段绝缘器高铁地铁绝缘器
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
中正TCS-5五轮校直机、接触线正弯机、接触线校直器、五轮导线正弯器
东方红704 70马力 四驱 50kw拖拉机电站 拖拉机多功能移动
中正防扭钢丝绳电力无纽牵引绳不旋转电缆收放线绳镀锌绳11-15mm
电缆拖头 电缆施工工具 现货直销
承装、承修、承试大型牵引机280KN一级到五级资质升级
漏水检测器 LEAKAGE WATER SENSOR\制造厂或品牌:SIEMENS\厂家配件号:ABRU-GL，详细信息如下:
中间冷却器和后冷却器(空气冷却器)，产品编号:SAFV21100-G02,品牌：三星泰科
ASIN： B01DBYLVVS
生产厂商编号： LDX：L0079810
INFRANOR XtrapulsPac Pac-ET-230/11
Control Unite VME
A32/D32 COP 232.2.029.232.446
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
CAN BOARD 232.2
029.356 519
4X CAN el
锚机减震器
ABB
266HSHSSBA7 EZLS，0-16Mpa，Exd II CT6,1/2"NPTF
ULVABond
ULVABond is a one component contact adhesive specifically formulated for application with the ULVAShield system.
ULVABond is brush applied with many applicators preferring to utilise the ULVABond Applicator Can.
ULVABond produces a finished joint that is stronger than than the base sheet.
266HSHSSBA7 EZLS，0-16Mpa，Exd II CT6,1/2"NPTF
50
266HSHSSBA7 EZLS，0-16Mpa，Exd II CT6,1/2"NPTF
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
锚机减震器/VIBRATION DAMPERS NOVIBRA RA 800 EM A
双法兰差压变送器 FKXT93V5-QFQBY-YOF5W 富士
ABC-CAN-EIP2 ABS-EIP2/EIT2
AB7318-B
ABC-CAN-PRT ABS-PRT
AB7319-B
ABC-CAN-EIT2 ABS-EIP2/EIT2
AB7320-B
ABC-CAN-PIR ABS-PIR
AB7321-B
ABC-CAN-CCL ABS-CCL
3WL10102F33, SIEMENS
3WL10102F33, SiemensMinimum order: 1 ..1
SIPOS 2SA5511-5EE00-4BB3-Z
SIPOS 2SA5521-5EE00-4BB3-Z??20-60NM
SIPOS 2SA5521-0CE00-4BB3-Z
SIPOS 2SA5531-0CE00-4BB3-Z
SIPOS 2SA5031-2CE10-3BA3-Z
SIPOS 2SA5511-0CE00-4BB3-Z
SIPOS 2SA5543-2CE10-4BB3-Z
SIPOS 2SA5043-2CE10-3BA3-Z
SIPOS 2SA5531-2CE10-4BB3-Z
SIPOS aassf2SA5031-9DE10-4BB4-ZH4AY99??37--125Nm??S2-15min EN50034
SIPOS 2SA5031-5EE00-3BA3+GS160.3-GZ160.3(4:1) 2SA5031-5EE00-3BA4 +GS 160.3/GZ 160.3 4:1-F30-UN-F10-RR
SIPOS 2SA5531-5EE00-4BB3+GS160.3-GZ160.3(4??1) 2SA5531-5CE00-4BB4 + GS 160.3/GZ 160.3 4:1-F30-UN-F10-RR-BZ
SIPOS 2SA5031-5EE00-3BA3+GS125.3-VZ4.3 2SA5031-5EE00-3BA4 +GS 125.3/VZ 4.3-F25-UN-F10-RR
SIPOS 2SA5531-5EE00-4BB3+GS125.3-VZ4.3 2SA5531-5CE00-4BB4 +GS 125.3/VZ 4.3-F25-UN-F10-RR-BZ
SIPOS 2SA5031-5EE00-3BA3+GS160.3-GZ160.3(4:1)
SIPOS 2SA5531-5EE00-4BB3+GS160.3-GZ160.3(4??1)
SIPOS 2SA5031-5EE00-3BA3+GS125.3-VZ4.3
SIPOS 2SA5531-5EE00-4BB3+GS125.3-VZ4.3
SIPOS 2SA5010-5CE00-4BB3-Z 2SA501
SIPOS GF50.3 com nr:30079770 GF 50.3;nr:84834025
SIPOS Aktorik GmbH 2SA5531-5EE00-4BB3+GS125.3-VZ4.3
SIPOS Aktorik GmbH 2SA5031-5EE00-3BA3+GS125.3-VZ4.3
SIPOS Aktorik GmbH 2SA5531-5EE00-4BB3+GS160.3-GZ160.3(4??1)
SIPOS Aktorik GmbH 2SA5031-5EE00-3BA3+GS160.3-GZ160.3(4:1)
SIPOS Aktorik GmbH 2SA5031-5EE00-3BA3+GS160.3-GZ160.3(4:1)
SIPOS Aktorik GmbH 2SA5531-5EE00-4BB3+GS160.3-GZ160.3(4??1)
SIPOS Aktorik GmbH 2SA5031-5EE00-3BA3+GS125.3-VZ4.3
SIPOS Aktorik GmbH 2SA5531-5EE00-4BB3+GS125.3-VZ4.3
SIPOS 2SA5531-5EE00-4BB3-Z 2SA503
SIPOS 2SY5010-1LB02
SIPOS 2SA5054-2DE10-3BA3-Z NO N.630016160010 2SY5018
SIPOS 2SA5031-OCE13-3BA3-Z NO N.6300205500102 2SY5012
SIPOS 2SA5054-2DE10-3BA3-Z NO N.6300205500102 2SY5016
SIPOS 2SA5054-2DE10-3BA3-Z NO N.6300205500102 2SY5018
SIPOS 2SA5054-2DE10-3BA3-Z NO N.630016160010 2SY5016
SIPOS 2SA5054-2DE10-3BA3-Z NO N.630016160010 2SY5012
SIPOS 2SA5043-2CE10-3BA4-Z
SIPOS 2SA5031-5EE00-4BB3-Z
SIPOS 2SA5543-2DE10-4BB4-ZY99-A99AY
SIPOS 2SA5564-2DE10-4BB4-ZY99-A99AY
SIPOS 2SA5533-2DE10-4BB4-ZY99-A99AY
SIPOS 2SA5543-2DE10-4BB4-ZY99-A99AY
SIPOS 2SA5564-2DE10-4BB4-ZY99-A99AY
SIPOS 2SA5533-2DE10-4BB4-ZY99-A99AY
SIPOS RSY5010-OLB02 220V
SIPOS RSY5010-OLB04 380V
SIPOS RSY5010-OLB05
SIPOS 2SA5031-2CE10-2BA3-Z/6300511800108
SIPOS Aktorik GmbH Actuator control board/2SA5021-2CD10-4AB3-Z,20-60N.M,AC220V,5/7/10/14/20/28/50 1/min
SIPOS Aktorik GmbH Actuator Power Board/for Dispensed actuator,2SA5021-2CD10-4AB3-Z,20-60N.M,AC220V,5/7/10/14/20/28/50 1/min
SIPOS 2SA5064-9DE10-4DBB4-ZH4A
SIPOS 2SA5031-3BA3
Sipos 2SY5010-1LB05
Sipos 2SY5010-1LB04
SIPOS GF160.3-GZ160.3
SIPOS GF125.3-VZ4.3
SIPOS Aktorik GmbH 2SA5531-5DE003-4BB3-Z380V
SIPOS 2SA5053-0CE10-3BA3-Z
SIPOS 2SA5531-2CE00-4CB4-Z
SIPOS DN25,2SA5511-2CE00-4BB3-Z
SIPOS DN40,2SA5511-2CE00-4BB3-Z
SIPOS DN50,2SA5511-2CE00-4BB3-Z
SIPOS DN65,2SA5521-2CE00-4BB3-Z = 1 set
SIPOS 2SA5521-5CE
SIPOS Aktorik GmbH 2SY5010-0LB04
SIPOS Aktorik GmbH 2SY5010-0LB05
SIPOS Aktorik GmbH 2SY5016-1SB00
SIPOS Aktorik GmbH 2SY5016-2SB00
SIPOS 5FLOSH25A5021-5EE00-4AB3-2B16
SIPOS Aktorik GmbH 2SA5543-2DE10-4BB4-ZY99-A99AY
SIPOS Aktorik GmbH 2SA5564-2DE10-4BB4-ZY99-A99AY
SIPOS Aktorik GmbH SA5533-2DE10-4BB4-ZY99-A99AY
SIPOS 2SA5521-5CE10-4BA3-Z
SIPOS R657500
SIPOS 2SA5021-5ED00-4AB3-Z
sipos 750W,IP67,
SIPOS GS80.3,
SIPOS 2SA5010-5CD00-4BB3+GF50.3(220V)
sipos 2SA5500-5.5-380-HY
sipos 2SA5500-1.5-380-HY
SIPOS Aktorik GmbH 2SA5043-2CE10-3BA3-Z
SIPOS 2SA5021-5EE00-4AD3-Z
SIPOS Y1LBG10AA101
SIPOS Y1GAC10AA101
SIPOS Y2LBG10AA101
SIPOS Y2GAC10AA101
SIPOS 1LCQ10AA202
SIPOS Y1LBG10AA101
SIPOS Y1GAC10AA101 Starter 1GJE0050 LC1-D40004M7┇/
继电器 1GKB0164 RXN41G12-BD┇/
电机风叶 1GML0055 Y90L-4型电机风叶┇/
相序保护继电器 1GKN0003 RM4TG20┇/
接线端子 1GED0263 ┇土黄色，10mm2，三个一组短接起来/要求耐高温
接线端子 1GEA0066 ┇土黄色，16mm2，二个一组短接起来/要求耐高温
接线端子 1GED0259 ┇土黄色，25mm2/要求耐高温
UNIDRIVE 变频器 1NSA0013 UNI 1403 LFT┇/
熔断器熔芯 1NZA0197 RT14-20;4A┇/
AMMETER电流表 1NPB0023 E24401CG IN 75mV.DC.300A┇/
接触器 1NQA0266 LC2-D2501M7┇/AC-3;25A;1P 250V; 50HZ
变送器 1GWA0171 BD-4E┇/输入：AC 6300/100V 750/1A 输出 Ia对应：0~750A/DC 4~20mA Ib对应：0~750A/DC 4~20mA Ic对应：0~750A/DC 4~20mA Q对应：-2~5MVar/DC 4~20mA
变送器 1GWA0172 BD-4E┇/输入：AC 6300/100V 750/1A 输出 Uab对应：0~7.5kV/DC 4~20mA Ubc对应：0~7.5kV/DC 4~20mA Uac对应：0~7.5kV/DC 4~20mA P对应：0~6.2MW/DC 4~20mA
变送器 1GWA0173 BD-4E┇/输入：AC 6300/100V 750/1A 输出 Ua对应：0~5.4kV/DC 4~20mA Ub对应：0~5.4kV/DC 4~20mA Uc对应：0~5.4kV/DC 4~20mA F对应：45~55HZ/DC 4~20mA
指针式电压表 1NPA0050 CP-96;量程0～450V AC;精度1.5级┇/
电压继电器Voltage relay 1GKU0015 A1939/175┇/230/400V AC
电容器 1GCA0090 B25673A5102A020 MKK525-D-10-02┇/
压敏电阻 1NZD0334 B40K460┇/
电机 1GMB0619 MG160MD2-42FF300-F1┇/15.0kW
按钮 1NLC0021 ABW110W┇/
二极管模块 1GRB0122 MDD44-18N1B┇/
电源开关带辅助接点 1GSF0044 NC 100L 40A (NO27626)+OF(NO27132)┇/380V 50HZ
电源开关带辅助接点 1GSF0045 NC 100H 10A (NO27627)+OF(NO27132)┇/380V 50HZ
电源开关带辅助接点 1GSF0046 DPN N 10A(NO19266)+OF(NO26924)┇/220V 50HZ
控制回路空开（交流）带辅助接点 1NZJ0183 DPN N 16A+OF┇/AC220V 50HZ
控制回路空开（直流）带辅助接点 1NZJ0184 C32H-DC 10A +OF┇/DC220V
变送器 1GWA0153 MCR-UI-UI-UP-SP┇/
监视继电器 1GKX0131 TSG912×22L22 220DC┇/
电流表AMMETER 1NPB0022 E24401CG┇/IN:75-0-75mV;SC:100-0-100A
轴承 1HBS0353 6308-2Z┇/
小型继电器 1GKA0173 MY4NJ AC220V┇/
电压传感器(电压变送器) 1NMA0288 BS4U┇/INPUT:440V OUTPUT:4~20mA AUX. POWER:220VAC/DC
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
仪表针型阀\SS-6NBSW8T-G\DN6\600℃\32MPa\316L焊接
中压疏水阀\1.50-11G5ZJ-F225F\1-1/2"\进口 含执行机构
阀杆阀芯组件\11G4RJ-1055F\高压截止阀
低压止回阀\H41H-16P\DN50\GB/T12235
阀芯\1749WB DA04119\安全阀\ASME B16.34\德莱赛
阀芯阀杆组件\1"\高压截止阀 11G5CJ-F225E\ASME B16.34
中压闸阀\NKZ41Y-25C\DN500\GB/T12234
低压闸阀\PZ641X-16C\DN900\GB/T12234\含执行机构
低压闸阀\SCZ641Y-10V\DN300\GB/T12234\含执行机构
SIPOS Y2LBG10AA101
SIPOS Y2GAC10AA101
SIPOS 1LCQ10AA202
SIPOS 2SY5012-0LB15
SIPOS 2SY5012-1LB55
sipos 2SA5511-2CE00-4BB3-Z B16
SIPOS 2SY5012-OLB15
Sipos 2SA5531-2CE00-4BB3-Z
SIPOS 2SA5021-9DD03-4AB3-ZH4A
SIPOS 2SA5062
Sipos 2SA5064-2CE11-4AA3-z
SIPOS 2SA5011-5EE10-3BA3-Z
SIPOS 2SA5021-5CE10-4BB3-Z
SIPOS 2SY5012-0LB15
SIPOS 2SY5012-2XD00 5.5KW
SIPOS 2SY5012-0LB15 1.5KW
SIPOS 2SY5012 1.5KW
SIPOS cable 10M FOR POS3
SIPOS 2SA5021-5EE01-3BA3-ZT+GS125.3 S41+R72
Sipos 2SA5010-2CD11-4DA4
Sipos 2SA5010-2CD11-4DA4
Sipos 2SA5031-2DE10-3BA3-A
SIPOS 2SA5521/GS125.3;380V
SIPOS 2SA5064-9DE10-4BB3-ZH4A+Y99+Y01+Y02-Y07+B00
SIPOS 5 FLASH actuator 2SA5031-9DE10-4BB3-ZH4A+Y99+Y01+Y02-Y07+B00
SIPOS 2SA5520-SY56-LU251
SIPOS 2SB15-ZK71-YCD02 380V
sipos 2SD15-ZK71-YCD02 380V
SIPOS 2SY5016-YD-01
SIPOS 2SY5014-YD
SIPOS 2SY5010-YD0LB05
SIPOS 26.600-6001-R-1-100-300-1-000, 0-6BAR,4-20MA,12-360DC
sipos SIPOS:2SY5012-0LB15 ??1.5KW??
sipos SIPOS:2SY5016-2SB00 used for electric door??2SA5521-5CE00-4BB3-Z??
sipos 2SY5018-0PM15 ??1.5KW?? with silicone
sipos 2SY5016-1SB00 used for electric ??2SA5064-2DE11-3BA4??
sipos 2SY5012-1LB55
sipos 2SY5018-0PM55 ??5.5KW?? with silicone
sipos 2SA5510-5CE00-4BB3-Z
SIPOS 2SY5012-0LB15
SIPOS 2SY5016-2SB00
SIPOS 2SY5018-0PM15
SIPOS 2SY5016-1SB00
SIPOS 2SY5012-1LB55
SIPOS 2SY5018-0PM55
SIPOS 2SA5510-5CE00-4BB3-Z
SIPOS 2SA5511/GF63.3S41+R72
SIPOS 2SA5531-5EE00-4BB3-ZB16 40-125NM
SIPOS 2sa5564-de10-zh
SIPOS 2SY5018-OPM55(5.5KW,380V)
SIPOS 2SY5018-OPM55(1.5KW,380V)
SIPOS 2SY5018-OPM55(5.5KW,380V)
SIPOS 2SY5018-OPM55(1.5KW,380V)
sipos R786590
sipos ZSY5017
SIPOS 2SA5010-5CE00-4AB3-Z
SIPOS 2SA5010-2CD11-4DA3
SIPOS 2SA5021-5CE00-4BB3-Z
SIPOS R786591/V1
SIPOS 2SA5521-5EEOO-4BB3-Z K51+BJ+GF125.3-VZ4.3
Sipos 2AS5510-5CE00-4BB3
SIPOS 2SA3532-2FA10-6ER5
AMF-175DD
2-25204 Stage one planet gear (3) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2-25205 Stage one planet gear shaft (3) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2-25235 Grease cup (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2P-24834 Stage one gear carrier SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-91412 Needle bearing, stage one (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-91520 Roll pin (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-93079-002 Gear shim (2) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
SIPOS Aktorik GmbH 2SA5521-2CE00-4AB3-Z
SIPOS Aktorik GmbH SI-070130
SIPOS Aktorik GmbH BP-070208
SIPOS 2SA5021-5CE10-3BA3-Z??s-nr:6800464600101
sipos 2SA5521-5EE00-4BB3-ZB16
SIPOS 2SA5510-5CE00-4AB3+GF50.3 150-350Nm
SIPOS 2SA5531-5EE00-4AB4+GS160.3-GZ160.3+Connection accessories 30S sipos5 flash
SIPOS 2SA5521-5EE00-4CB4+GS125.3-VZ4.3 30S
SIPOS 2SA5521-2CD00-4BB3-Z,18-60NM
SIPOS Aktorik 2SB55110CD002AB0-Z
SIPOS Aktorik 2SY5012
SIPOS Aktorik 2SY5016 2SA5533 2CEOO-4AB3-2
SIPOS 2SA5511-5CD00-4BB3+GS63.3
Sipos 2SA5064-9DE10-4BB4-Z H4A Y99
SIPOS R786573-V5 30.04FRI
3WL10102F43, SIEMENS
3WL10102F43, SiemensMinimum order: 1 ..1
1
3WL10102F53, SIEMENS
3WL10102F53, SiemensMinimum order: 1 ..1
1
3WL10103.A33...., SIEMENS
3WL10103.A33...., SiemensMinimum order: 1 ..1
2-25204 Stage one planet gear (3) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2-25205 Stage one planet gear shaft (3) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2-25235 Grease cup (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2P-24834 Stage one gear carrier SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-91412 Needle bearing, stage one (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-91520 Roll pin (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-93079-002 Gear shim (2) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
3WL10103.A43...., SIEMENS
3WL10103.A43...., SiemensMinimum order: 1 ..1
1
3WL10103.A53...., SIEMENS
3WL10103.A53...., SiemensMinimum order: 1 ..1
1
3WL10103.B33...., SIEMENS
3WL10103.B33...., SiemensMinimum order: 1 ..1
1
3WL10103.B43...., SIEMENS
3WL10103.B43...., SiemensMinimum order: 1 ..1
1
3WL10103.B53...., SIEMENS
3WL10103.B53...., SiemensMinimum order: 1 ..1
1
3WL10103.C33...., SIEMENS
3WL10103.C33...., SiemensMinimum order: 1 ..1
2-25204 Stage one planet gear (3) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2-25205 Stage one planet gear shaft (3) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2-25235 Grease cup (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
2P-24834 Stage one gear carrier SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-91412 Needle bearing, stage one (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-91520 Roll pin (6) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
9-93079-002 Gear shim (2) SECTION 7.0 - PAGES ATT-4 ATT-5 Maker : TDI TURBOSTAT TWO DIESEL GENERATOR YANMAR, 6N21L-UV [6N21L]AIR MOTOR, FIG.8 [FIG-8]
3WL10103.C43...., SIEMENS
3WL10103.C43...., SiemensMinimum order: 1 ..1
1
3WL10103.C53...., SIEMENS
3WL10103.C53...., SiemensMinimum order: 1 ..1
1
3WL10103.D33...., SIEMENS
3WL10103.D33...., SiemensMinimum order: 1 ..1
1
3WL10103.D43...., SIEMENS
3WL10103.D43...., SiemensMinimum order: 1 ..1
1
3WL10103.D53...., SIEMENS
3WL10103.D53...., SiemensMinimum order: 1 ..
Danfoss 冷冻油 丹佛斯压缩机专用 2.5L装
OTT-JAKOB 夹爪 95.600.033.2.6
N4L PPA3500
OMAL 阀门 M376E16F69 DN50
Jumo 传感器 404366/000-460-405-571-20-61/000
ＤeiboldHSK主轴的检棒/跳动测试轴72.579.740.200HSK-F63?40346
EMG 传感器 KLW600.012
德国Ｄeibold-HSK主轴HSO 120.42-18.AK
OTT-JAKOB 芯片 95.600.077.9.6
Norgren 比例阀 40-881-19 （4088119.7053.01200）
OTT拉刀杆 1K-GDP 1K-GD-CM
OTT旋转接头 Rotary Union 2KLR
ANYBUS 总线 ® CompactCom B40现货
Bosch旗下Etas品牌汽车总线标定接口模块和线缆，Deutronic充电机系列,Hilscher赫优讯网关，HMS,Anybus网关，Peak-system, Heidenhain海德汉光栅尺,ROSS阀，Hilma,Roemheld油缸,Kraus&naimer奥地利蓝系列开关，Walther prazision 接头，Walther werke工业插 头，Goorui风机，sitema制动器,PRIMES激光能量测试单元，美国Opal Kelly，美国皮尔森Pearson，美国仙童(Fairchild)，Bosch, 力士乐 rexroth，德国CAB工业打印机 ，Zimmer ，nekoosa（GXP-1000系列） ，KOBOLD ，
GEMU ，Prosoft ，microsonic ，KEM ，ZIEHL ，ATLAS 电动工具，菲尼克斯,baumer engler宝盟 ， jumo久茂，巴鲁夫baluff，费斯托festo，microsonic的超声波传感器，EGE, Burkert, TWK ,ASCO,Parker,Danfoss,美国Copeland,德国kemkraft,
美国Lynair,
ABB，施耐德，西门子，FESTO，巴鲁夫，邦纳，PILZ，CKD ， 威纶通
,基恩士，SICK，倍福，诺冠，P+F，山武，劳易测，海德汉，力士乐液压-伺服电 机，安士能，AB，罗克韦尔，JUMO久茂，OMRON欧姆龙，派克，三菱，SMC，富士 ，松下，研华，艾默生，丹佛斯，和泉，威图，魏德米勒，台达，威纶通，雷普 ，德力西，明纬，正泰，奥托尼克斯，菲尼克斯，巴斯曼，LS产电，天水二一三 ，安川，英威腾，希望森兰，APT，穆勒，人民电器.上银，费斯托，步科，普洛菲斯，摩 莎，倍加福，西克，宜科，福禄克，万高，罗宾康，天逸，，起帆，安 科瑞，华为逆变器，哈希，图尔克，世达，史丹利，日精（电机），机器人 （ABB、KUKA、安川、发那科）
美国AIRTROL,
美国Northstart
,美国AUTOFLOW等等
订货号：LI0050 订货号：AB6670 订货号: AB6605 订货号：AB6600
AB7013
接口模块（CAN转Ethernet）AB7838-F
AB9000 AB9000-B
AB7646 AB7303 AB7013 AB7670
AB7632 021620B
AB7501
白炽舱顶灯 DC-128 220V 60W
白炽舱顶灯 DC-128A 220V 60W
白炽舱顶灯 DC-129A 220V 60W
白炽舱顶灯 DC-3 220V 15W
LED 舱顶灯 DCL-187 220V 2*10W
LED 舱顶灯 DCL-188 220V 3*10W
防爆灯 DF-103B-25-2 24V 25W
防爆灯 DF-103B-60-2 220V 60W
右舷灯(绿色) DH-101A 220V 2*65W 绿色
左舷灯(红色) DH-102A 220V 2*65W 红色
补给信号灯 DH-105B 220V 65W
应急灯 DH-105B 220V 65W
艏旗杆灯 DH-13 220V 25W
升降信号探照 DX-106 220V 1000W
信号灯 DX-2 24V 70W
闪光信号灯 DX-5 220V 300W
双层艉灯 CXH4-10B 220V 65W*2
铜质双层艉灯 CXH4-10B2 220V 65W*2
LED 防爆灯 BFC8183 /
应急 LED 蓬顶 CSC3021 /
LED 蓬顶灯 CSE3021 /
LED 蓬顶灯 HG.LED-P2CQA /
射灯 12V100W /
示位灯 BSW9812 /
信号灯 CXH-12-02 DC24V 25W 绿
信号灯 CXH-12-03 DC24V 25W 红
桅顶灯 CXH5-3 /
探照灯 TF8212 /
搜索灯 WS97-80H /
搜索灯 WS97-80H /
Starter 1GJE0050 LC1-D40004M7┇/
继电器 1GKB0164 RXN41G12-BD┇/
电机风叶 1GML0055 Y90L-4型电机风叶┇/
相序保护继电器 1GKN0003 RM4TG20┇/
接线端子 1GED0263 ┇土黄色，10mm2，三个一组短接起来/要求耐高温
接线端子 1GEA0066 ┇土黄色，16mm2，二个一组短接起来/要求耐高温
接线端子 1GED0259 ┇土黄色，25mm2/要求耐高温
UNIDRIVE 变频器 1NSA0013 UNI 1403 LFT┇/
熔断器熔芯 1NZA0197 RT14-20;4A┇/
AMMETER电流表 1NPB0023 E24401CG IN 75mV.DC.300A┇/
接触器 1NQA0266 LC2-D2501M7┇/AC-3;25A;1P 250V; 50HZ
变送器 1GWA0171 BD-4E┇/输入：AC 6300/100V 750/1A 输出 Ia对应：0~750A/DC 4~20mA Ib对应：0~750A/DC 4~20mA Ic对应：0~750A/DC 4~20mA Q对应：-2~5MVar/DC 4~20mA
变送器 1GWA0172 BD-4E┇/输入：AC 6300/100V 750/1A 输出 Uab对应：0~7.5kV/DC 4~20mA Ubc对应：0~7.5kV/DC 4~20mA Uac对应：0~7.5kV/DC 4~20mA P对应：0~6.2MW/DC 4~20mA
变送器 1GWA0173 BD-4E┇/输入：AC 6300/100V 750/1A 输出 Ua对应：0~5.4kV/DC 4~20mA Ub对应：0~5.4kV/DC 4~20mA Uc对应：0~5.4kV/DC 4~20mA F对应：45~55HZ/DC 4~20mA
指针式电压表 1NPA0050 CP-96;量程0～450V AC;精度1.5级┇/
电压继电器Voltage relay 1GKU0015 A1939/175┇/230/400V AC
电容器 1GCA0090 B25673A5102A020 MKK525-D-10-02┇/
压敏电阻 1NZD0334 B40K460┇/
电机 1GMB0619 MG160MD2-42FF300-F1┇/15.0kW
按钮 1NLC0021 ABW110W┇/
二极管模块 1GRB0122 MDD44-18N1B┇/
电源开关带辅助接点 1GSF0044 NC 100L 40A (NO27626)+OF(NO27132)┇/380V 50HZ
电源开关带辅助接点 1GSF0045 NC 100H 10A (NO27627)+OF(NO27132)┇/380V 50HZ
电源开关带辅助接点 1GSF0046 DPN N 10A(NO19266)+OF(NO26924)┇/220V 50HZ
控制回路空开（交流）带辅助接点 1NZJ0183 DPN N 16A+OF┇/AC220V 50HZ
控制回路空开（直流）带辅助接点 1NZJ0184 C32H-DC 10A +OF┇/DC220V
变送器 1GWA0153 MCR-UI-UI-UP-SP┇/
监视继电器 1GKX0131 TSG912×22L22 220DC┇/
电流表AMMETER 1NPB0022 E24401CG┇/IN:75-0-75mV;SC:100-0-100A
轴承 1HBS0353 6308-2Z┇/
小型继电器 1GKA0173 MY4NJ AC220V┇/
电压传感器(电压变送器) 1NMA0288 BS4U┇/INPUT:440V OUTPUT:4~20mA AUX. POWER:220VAC/DC
GE
362A1053P031
Infranor 伺服驱动器和运动控制 xtrapulspac pac-ak-230/11
INDICATOR,DIGITAL DISPLAY=== TYPE OR USAGE : PRESSURE CONTROLLER DISPLAY DATA : 4 DIGIT, 7 SEGMENT LED CAPACITY : -1999 TO 9999 POWER SUPPLY : 220VAC SPECIFICATION/STD DATA : IP65 Manufacture Reference SIEMENS : RWF40- 000A97 SIEMENS : RWF55.50A9
44-079-10C : HEADER CONNECTOR,PCB MNT,PLUG,44 CONTACTS,SKT,0.079 PITCH,PC TAIL TERMINAL. s: Connector Type: TWO PART BOARD CONNECTOR.
4729515101400 : 1 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER. s: Connector Type: TWO PART BOARD CONNECTOR ; Gender: Female ; Termination Types: SOLDER ; Number of Contacts: 1.
50819-1006E : 24 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, RECEPTACLE. s: Connector Type: TWO PART BOARD CONNECTOR ; Gender: Female ; Termination Types: SOLDER ; Number of Contacts: 24.
6779753103411-R : 3 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT. s: Connector Type: TWO PART BOARD CONNECTOR ; Gender: Female ; Termination Types: PCBSolder ; Number of Contacts: 3.
71764-0204 : 4 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER. s: Connector Type: TWO PART BOARD CONNECTOR ; Gender: Male ; Termination Types: SOLDER ; Number of Contacts: 4 ; RoHS Compliant: RoHS.
78085-001LF : 6 CONTACT(S), MALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER. s: Applications: Telecom / Data / Net
