产品描述：
CAMERON LEWCOWH-1612 mud pump, W-2214 mud pump, W-2215 mud pump, CMP-2200 mud pump, CMP-2000 mud pump, CMP-1600mud pump
QTY PER PUMP
OEM PART # MISSION PART #
8476-A FEM12PASSYSW FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1-23) 3
8476-2S FEM12PSUCSW MODULE, SUCTION STUDDED (INCLUDES ITEMS: 1,13,14,& 22) 3
8476-1D FEM12PDISSW MODULE, DISCHARGE STUDDED - (INCLUDES ITEMS: 2,3,4,5,6,7,8,13 & 14) 3
4018-17 12P160DSUCS STUD, DISCHARGE TO SUCTION MODULE 18
PEP55 NUT, DISCHARGE TO SUCTION STUD 18
4015-95 NAT12P160PFS STUD, POWER END 30
8P80TRSN NUT, POWER END STUD 30
8488-5 PEP70 PIN, DOWELL 6
4017-65 PEP75 CAPSCREW,LINER RETAINER SOCKET HEAD 18
8476-3 PP6021260SW PLATE, LINER WEAR 3
2988 1290344 GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
6476 12PLASW FLANGE, LINER RETAINER (LINER BUSHING) 3
6576 12PLANSW NUT, LINER RETAINER 3
4015-54 12PTRSSW STUD, THREADED RING 72
12P160TRSN NUT, THREADED RING STUD 72
4676-2A 12PVCSW PLUG, VALVE COVER (INCLUDES ITEMS 15,19,20,& 21) 6
4476 12PFLGSW RING, THREADED (THREADED FLANGE) 6
4597 12PCAPSW CAP, THREADED (SCREW GLAND) 6
P-107 07207107 SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
4776R 12PVGSWNS GUIDE, VALVE (INCLUDES ITEMS 19,& 20) 6
4700-I PZ789VGI BUSHING, VALVE GUIDE 6
4016-98 PEP73 SCREW, VALVE GUIDE 12
4018-19 700048511 CAPSCREW, SUCTION MANIFOLD API-4 ESN PISTON ROD NUT
4018-95 ROD CLAMP BOLT
4015-86 VALVE COVER STUD 379 549 758
4016-26 POWER END STUD 253 366 505
4016-61 LINER RETAINER STUD 757 1098 1514
4017-77 SUCTION MANIFOLD CAPSCREW 188 282 376
8377-51 OEM DISCHARGE CROSS FOR PZ-11, PZ-10, PZ-9, PZ-8,
PZ-7 GARDNER DENVER W/ 5" DISCHARGE LINE 1
2 8377-53 SPOOL FOR OEM PZ-11 DISCHARGE CROSS 1
3 8277-50 DISCHARGE STRAINER FOR OEM PZ-7 THRU PZ-11
PUMPS 1
4 4020-30 STUD FOR PZ-11 OEM DISCHARGE CROSS 5" 5000 PSI
CONNECTION 24
5 4020-31 STUD FOR PZ-11 OEM DISCHARGE CROSS F/ 3" 5000
PSI CONNECTION 8
6 4018-82 DISCHARGE CROSS SPECIAL STUD 8
7 HHN1500-8 1-1/2 - 8 HEAVY HEX NUT 24
8 HHN1125-8 1-1/8 - 8 HEAVY HEX NUT 8
9 HHN1250-8 1-1/4 - 8 HEAVY HEX NUT 8
10 R-35 RING GASKET, CARBON STEEL 1
11 R-39 RING GASKET, CARBON STEEL 2
12 R-44 R-44 RING JOINT GASKET FOR API CONNECTIONS 3
13 5000-5BFLANGE 5-1/8" 5000# BLIND RJT FLANGE
4017-74 DISCHARGE MANIFOLD STUD 379 549 758
AJO-419R 1540851 GASKET, SUCTION MANIFOLD 3
8376-2 NAT12PDSMA ADAPTER, DISCHARGE 2
2976-2 2410031437 SEAL, DISCHARGE ADAPTER 4
8376-1 NAT12PDSMC CONNECTOR, DISCHARGE 2
2976-1 2410031433 SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER 2
4018-18 700030711 CAPSCREW, DISCHARGE CONNECTOR (W /LOCKWASHER) 16
8376-3 1292175 RING, BACKUP (DISCHARGE CONNECTOR) 4
4018-39 7006685 CAPSCREW, SOCKET HEAD 16
07924540 KIT, MODULE SEAL: (KIT INCLUDES SUCTION MANIFOLD GASKET, TWO VALVE COVER GASKETS, SUCTION TO DISCHARGE MODULE GASKET, TWO DISCHARGE ADAPTING GASKETS, TWO DISCHARGE CONNECTING GASKETS, WEAR PLATE GASKET) 3
