产品描述：
—Ultra Fast Response (UFR) (in addition to the above):
—Cycle-by-cycle reactive power compensation (total acquisition
time of 5-16 mSec)
—Prevents voltage drop and flickering
—Used for Real Time applications, such as spot welding and
motor start-up
—Enhances capacity of local generator systems, such as diesel
and windmill generators
—Combination of one to three single-phase systems available
for unbalanced loads
Types Available
—Basic Systems: Include iron core reactors to limit the inrush
current with either:
—Detuned Systems: Include iron core reactors that detune the
network to prevent resonance and absorb up to 50% of the
5th harmonic, or
—Tuned Systems: Individually designed to absorb the 5th and
7th harmonics
BuyLog™ Catalog 24-27
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Automatic Fast-Switching LV Power Factor
Correction Capacitors
GEMATIC™ Quick Response
Controller Specifications
Power Supply 115/230V, 50/60 Hz
LCD Display Size 94 x 76 mm
LCD Display Resolution Graphic 160 x 128 pixels
LCD Display Type FSTN, LED backlight
Frequency 45 to 65 Hz
Power Consumption 10 VA
Operating Temperature -20° to +55°C
9 Analog Channels 3 current channels for mains load
2 current channels for Equalizer cabinet
4 voltage channels
Communications RS485/422 communications port
Protocol ELCOM, Modbus/RTU
Alarm Voltage free N.O./N.C. relay, max 2A @ 250 Vac
Protection Class IP 40
Dimensions 144 x 144 x 138 mm
Weight 1.4kg
Storage Temperature -25° to 70°C
Electromagnetic Compatibility EN50081-2, EN50082-2, EN55011,
EN61000-4-2/3/4/5, ENV50204, EN50141
Safety Standards EN61010-1, EN50439-1, UL508
Controller Features
Measurement Level
Parameter Phases Loads 1 2 3 4
Frequency Common Mains • • • •
Phase Current L1, L2, L3 Mains, Load, Cap. • • • •
Neutral Current Neutral Mains • • • •
Phase to Phase Current L1-2, L2-3, L3-1 Mains, Load • • • •
Phase Voltage L1, L2, L3 Mains • • • •
Neutral Voltage Neutral Mains • • • •
Phase to Phase Voltage L1-2, L2-3, L3-1 Mains • • • •
Active Power (kW) L1, L2, L3, Total Mains • • • •
Reactive Power (kVAr) L1, L2, L3, Total Mains, Load, Cap. • • • •
Apparent Power (kVA) L1, L2, L3, Total Mains, Load, Cap. • • • •
Power Factor L1, L2, L3, Total Mains, Load, Cap. • • • •
Time of use (TOU) — in, out, net, total:
Active Energy (kWh) Total Mains • • •
Reactive Energy (kVARh) Total Mains • • •
THD at Phase Current L1, L2, L3 Mains, Load, Cap. • • •
THD at Neutral Current Neutral Mains • • •
THD at Phase to Phase Current L1-2, L2-3, L3-1 Mains, Load • • •
THD at Phase Voltage L1, L2, L3 Mains • • •
THD at Neutral Voltage Neutral Mains • • •
THD at Phase to Phase Voltage L1-2, L2-3, L3-1 Mains • • •
Harmonics of Phase Current L1, L2, L3 Mains, Load, Cap. • •
Harmonics of Neutral Current Neutral Mains • •
Harmonics of Ph. to Ph. Current L1-2, L2-3, L3-1 Mains, Load • •
Harmonics of Phase Voltage L1, L2, L3 Mains • •
Harmonics of Neutral Voltage Neutral Mains • •
Harmonics of Ph. to Ph. Voltage L1-2, L2-3, L3-1 Mains • •
Waveforms of Phase Current L1, L2, L3 Mains, Load, Cap. • •
Waveforms of Neutral Current Neutral Mains • •
Waveforms of Ph. to Ph. Current L1-2, L2-3, L3-1 Mains • •
Waveforms of Phase Voltage L1, L2, L3 Mains • •
Waveforms of Neutral Voltage Neutral Mains • •
Waveforms of Ph. to Ph. Voltage L1-2, L2-3, L3-1 Mains • •
System Log • • • •
Event Log •
Data Log (future) •
Typical Screens
e
24-28 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Automatic Fast-Switching LV Power Factor
Correction Capacitors
GEMATIC™ Quick Response
Capacitor/Reactor Module
Iron Core Limiting Capacitors
Iron Core Tuned or Detuned Reactor Capacitors
Switching Module
Power IQ Measurement and Analysis Software
This software displays the system status as well as the measurement results on numerous screens running under Windows. All network parameters, including harmonics up to
the 63rd, can be recorded at preselected intervals. The duration of the recording is only
limited to the size of the computer’s hard disk. The software can be set to record data
based on selected triggers of various network parameters, such as voltage sags and/or
current spikes. The system records before and after the trigger event. The software has
intranet and internet support.
BuyLog™ Catalog 24-29
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Automatic Fast-Switching LV Power Factor
Correction Capacitors
GEMATIC™ Quick Response
Features
—Design
—Steel sheet cabinet
—Enclosure Finish
—Epoxy powder coated, in gray (RAL 7032)
—Internal parts rust proof aluzinc
—Rated Voltage
—400V/50 Hz and 480V/60 Hz
—Other voltage values are available upon request
—Output rating
—Refer to table
—Other output ratings are available upon request
—Capacitors
—Low loss, self-healing, IEC 831-1/2
—Ambient Temperature
— +40°C max short time
— +35°C average in 24 hours
— +20°C annual average
— -10°C low limit
—Protection class: IP 20. Standards:
—Electromagnetic—EN50081-2, EN50082-2, EN55011
—Compatibility—EN61000-4-2/3/4/5, ENV50204, ENV501 41
—Safety Standards—EN61010-1, EN50439-1, UL508
GEMATIC™ Quick Response – Fast Response (3-4 sec.)
Contact Factory for ratings and product numbers.
Standard Balanced Systems for 480V/60 Hz Networks
—Systems with inrush limiting reactors
—Detuned systems with tuning frequency of 245 Hz (4.08th
Harmonic at 480Vac/60 Hz) up to 100kVAR per group at
400V/50 Hz
—Tuned systems with tuning frequency of 282 Hz
(4.7th Harmonic at 480Vac/60 Hz)
Non-Standard Systems (550V-1000V 50/60 Hz or
100V-240V 50/60 Hz)
—With circuit breaker or load breaker
—With or without busbar connection
—Single cabinet
—Dual door single cabinet
—Mechanical structure and dimensions of larger systems are
available upon request
Option Packages
F Reactors
G Lights and Reactors
W Lights, Breaker and Reactors
For pricing, contact One-Stop or Factory.
GEMATIC™ Quick Response Ultra Fast Response (UFR) (5-16 mSec)
requires special application for selection and sizing. Contact factory for application assistance.
e
24-30 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Description
GEMATIC™ multi-step power factor control equipment automatically maintains desired power factor level, adjusting to system
load requirements in selected kVAR steps. The solid-state control
responds to a current signal from the optional current transformer and to a voltage signal from a potential transformer
included in the equipment.
GEMATIC™ equipments feature capacitors with a metallized
dielectric system providing a self-healing action and reduced
energy losses. The biodegradable impregnant is a class IIIB combustible fluid. Discharge resistors reduce the voltage to 50 volts or
less within one minute of de-energization. The capacitor cells are
3 phase and are designed for 110% of rated voltage, 135% of
rated current, and, 135% of rated kVAR.
The power factor controller requires a CT signal for operation. The
CT primary should be sized for the total phase current to be compensated (capacitor current and load current). Typically, the total
phase current should be 50% to 80% of the CT primary rating. The
CT secondary is rated 5A. The CT is connected to one phase of the
equipment and the factory installed PT is connected across the
other two phases.
Automatic LV Power Factor Correction Capacitors
Type GEMATIC™ Compact and GEMATIC™ Select
Three-phase, 60 Hertz
240, 480, 600 Volts
GEMATIC™ equipment includes:
—Solid-state multi-step power factory controller with digital
display and indication of loss of kVAR or blown fuse
—Three phase self-healing metallized capacitors
—Stage contactors
—Potential transformer
—Plated copper bus
—Three fuses for each stage
—Modular construction easily uprated
—UL and C-UL Listed
Additional Features
GEMATIC™ Compact
—NEMA 1 enclosure standard (NEMA 3R available)
—65 kAIC bracing
—Optional breaker (600 amp 35kAIC maximum)
—Optional blown fuse indicating lights
GEMATIC™ Select
—NEMA 1 enclosure standard (NEMA 4R and NEMA 12 available)
—100 kAIC bracing
—Optional breaker
—Optional blown fuse indicating lights
GEMATIC™ Compact GEMATIC™ Select
*60” enclosure available
for low kVAR ratings.
Consult factory.
BuyLog™ Catalog 24-31
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
kVAR
40
60
80
100
120
Basic Product No.
1
37FJ2040D20
37FJ3060D20
37FJ4080D20
37FJ5100D20
37FJ6120D20
kVAR/Step
20
20
20
20
20
*Breaker
Rating
400
400
400
400
600
1Suffix “L” (Indicating Lights); Suffix “B” (Circuit Breaker)
kVAR
50
75
100
125
150
175
200
225
250
275
300
Basic Product No.1
37FJ2050F25
37FJ2075F25
37FJ3100F25
37FJ3125F25
37FJ3150F50
37FJ4175F25
37FJ4200F50
37FJ5225F25
37FJ5250F50
37FJ6275F25
37FJ6300F50
kVAR/
Step
25
25
25
25
50
25
50
25
50
25
50
*480 V
Breaker
Rating
400
400
400
400
400
400
400
600
600
600
600
*600 V
Breaker
Rating
400
400
400
400
400
400
400
400
400
600
600
1Suffix “L” (Indicating Lights); Suffix “B” (Circuit Breaker)
kVAR
100
125
150
175
200
225
250
300
Basic Product No.
37FC4100D255
37FC5125D255
37FC6150D255
37FC7175D255
37FC8200D255
37FC9225D255
37FC10250D255
37FC12300D255
kVAR/Step
25
25
25
25
25
25
25
25
Breaker
Rating
400
600
600
800
800
1000
1000
1200
Automatic LV Power Factor Correction Capacitors
Type GEMATIC™ Compact and GEMATIC™ Select
Three Phase, 60 Hertz
240, 480, 600 Volts
GEMATIC™ Compact 480/600 volts
GEMATIC™ Compact 240 volts
GEMATIC™ Select 240 volts
Example of GEMATIC™ Select Product Number. 300kVAR, 480V, with Lights, Breaker and
copper bus, 37FC6300F505R0.
NOTE: For 600 volts, replace second “F” in the basic product number with “H”. Example:
37FJ3100F25 becomes 37FJ3100H25. Contact Factory for NEMA 3R.
e
24-32 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Suffix
L
B
R
Option
Indicating Lights
Breaker
Lights & Breaker
Ratio
Multitap w/ Ratio
800/1200/1500/2000/
2200/2500/3000 : 5
4000 : 5
Product Number
XT0-69752-0105G
XT0-69752-0011G
Automatic LV Power Factor Correction Capacitors
Type GEMATIC™ Compact and GEMATIC™ Select
Three Phase, 60 Hertz
240, 480, 600 Volts
GEMATIC™ Select 480/600 volts
kVAR
100
125
150
175
200
225
250
275
300
325
350
375
400
425
450
475
500
525
550
575
600
Basic Product No.
1
37FC3100F255
37FC3125F255
37FC3150F505
37FC4175F255
37FC4200F505
37FC5225F255
37FC5250F505
37FC6275F255
37FC6300F505
37FC7325F255
37FC7350F505
37FC8375F255
37FC8400F505
37FC9425F255
37FC9450F505
37FCA475F255
37FCA500F505
37FCB525F255
37FCB550F505
37FCC575F255
37FCC600F505
kVAR/
Step
25
25
50
25
50
25
50
25
50
25
50
25
50
25
50
25
50
25
50
25
50
480V
Breaker Rating
400
400
400
400
400
600
600
600
600
600
800
800
800
800
1000
1000
1000
1000
1200
1200
1200
600V
Breaker Rating
400
400
400
400
400
400
400
600
600
600
600
600
600
800
800
800
800
800
800
1000
1000
1Suffix “L” (Indicating Lights); Suffix “B” (Circuit Breaker)
CT, 600V, split core, 4” x 7” window
Option Packages
Note: Add only one suffix letter to the end of product numbers
For breakers add the following code for standard breaker option
Current Rating kAIC Rating Code for Standard Breaker Option
400 35 00003
600 35 00006
800 50 00009
1000 50 0000C
1200 50 0000F
1600 65 0000L
2000 65 0000N
2500 100 0000Q
3000 100 0000T
NOTE: For 600 volts, replace second “F” in the basic product number with “H”. Example:
37FJ3100F25 becomes 37FJ3100H25. Contact Factory for NEMA 3R.
For NEMA 12 enclosure, replace “C” in the basic product number with “O”,
(e.g., 37FC8400F505 becomes 37FO8400F505). For bottom entry last digit of Product
Number changes from “5” to “6” (e.g., 37FC8400F505 becomes 37FC8400F506).
BuyLog™ Catalog 24-33
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Type GEMATIC™ Custom
The GEMATIC™ Custom offers power factor correction with the
flexibility of including harmonic filter reactors initially or adding
them later if they are required.
Many of today’s power systems require modern solutions to
power factor correction. The rapid increase in variable speed
drive use and other solid state devices has resulted in severe
harmonic loads on power systems. GE has 10 years experience
in preventing the occurrence of non-sinusoidal resonance.
Successful integration in tuned L-C networks solves the problem
of parallel resonance.
GEMATIC™ Custom automatic power factor correction systems
with 3-phase harmonic suppression reactors are application
specific. Accordingly, each installation requires specific
information to aid GE application engineers in designing each
system to meet your requirements. This information should
include, but not be limited to, kVAR requirements, transformer size
and impedance, kVAsc of the transformer, and a harmonic profile
of your system. Load characteristic at the time of the survey and
worst case should also be included.
The GEMATIC™ Custom systems may be configured for the
addition of harmonic suppression reactors in the future to meet
the imminent needs of your system. This reduces initial
investment and provides a ready made retrofit package. This
system provides total flexibility in achieving maximum automatic
power factor correction. Please contact the local GE sales office
or the GE factory for any assistance with your particular power
factor correction and harmonic suppression needs.
Automatic LV Power Factor Correction Capacitors
and Harmonic Filter Equipment
Applicable Standards
—NEMA, IEEE/ANSI, NEC
GEMATIC™ Custom Optional Features
—Outdoor NEMA 3R enclosure
—Main breaker
—Iron core reactors
—Blown fuse indicating lights
GEMATIC™ Custom includes
—Solid-state multi-step power factor controller with digital
display and indication of loss of kVAR or blown fuse
—Three phase self-healing metallized capacitors
—Stage contactors
—Three fuses for each stage
—Potential transformer
—Plated copper bus, 100 kAIC bracing
—NEMA 1 enclosure
—UL and cUL listed
Ratings
—240 V; up to 300 kVAR
—480 V and 600 V; up to 1500 kVAR
—For larger kVAR ratings, contact factory
e
24-34 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Automatic LV Power Factor Correction Capacitors
and Harmonic Filter Equipment
Outline Dimensions (inches)
Optional Features: R—Outdoor NEMA 3R Enclosure (Change prefix 38FP to 38FR)
Selection Table 240 Volts
Suffix L
Blown Fuse Lts.
Suffix F
Harmonic Reactors
Suffix B
Circuit Breaker
Circuit Breaker
240 Volt Rating—Amps
Prefix R
NEMA 3R
Enclosure Width
(# of Sections)
400
600
800
1000
1000
1200
1
2
2
2
2
2
100
150
200
225
250
300
Total
kVAR
38FP3100D255
38FP6150D255
38FP5200D255
38FP5225D255
38FP5250D505
38FP6300D505
Product Number
25
25
25
25
50
50
kVAR/
Step
Selection Table 480/600 Volts
To order 600 Volt, change second “F” in product number to “H”. (e.g. 38FP4400FA05 becomes 38FP4400HA05)
Suffix L
Blown Fuse
Lts.
Suffix F
Harmonic
Reactors
Suffix B
Circuit
Breaker
Suffix B
Circuit
Breaker
Prefix R
NEMA 3R
Circuit Breaker
480 Volts
Rating
600
800
800
1000
1000
1200
1200
1600
1600
1600
1600
1600
2000
2000
2000
2500
2500
2500
3000
3000
Circuit Breaker
600 Volts
Rating
600
600
600
800
800
800
1000
1200
1200
1200
1600
1600
1600
1600
2000
2000
2000
2500
2500
2500
1Price includes cabinet adder for breaker. 2Enclosure width increases by one section with breaker.
For ratings not listed consult factory.
Add breaker code suffix shown on page 24-32 GEMATIC compact and select.
For reverse entry last digit of Product Number changes from "5" to "7."
For bottom entry "5" changes to "6" and "7" changes to "8."
Bottom entry may change equipment width. Consult factory
or e-catalog for dimension and pricing of bottom entry.
300
350
400
450
500
550
600
650
700
750
800
850
900
950
1000
1100
1200
1300
1400
1500
Total
kVAR
38FP3300FA05
38FP4350F505
38FP4400FA05
38FP5450F505
38FP5500FA05
38FP6550F505
38FP6600FA05
38FP7650F505
38FP7700FA05
38FP8750F505
38FP8800FA05
38FP9850F505
38FP9900FA05
38FPA950F505
38FPAA00FA05
38FPBB00FA05
38FPCC00FA05
38FPDD00FA05
38FPEE00FA05
38FPFF00FA05
Product
Number
100
50
100
50
100
50
100
50
100
50
100
50
100
50
100
100
100
100
100
100
kVAR/
Step
2
2
2
2
2
2
2
3
3
3
3
3
3
3
4
4
4
4
2
2 2
1 2
2
2
Enclosure Width
(# of Sections)
GEMATIC™ Custom
Three-phase, 60 Hz NEMA 1 or 3R
Enclosure supplied with or without
reactors tuned to the 4.7th Harmonic.
Option Suffix
Lights L
Breaker B
Reactors F
Lights and Breaker R
Lights and Reactors G
Lights, Breaker, and Reactors W
Breaker and Reactors K
Section Dimensions A B
NEMA 1 25” 35”
NEMA 3R 24 36
BuyLog™ Catalog 24-35
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
GE GEMACTIVE Active Harmonic Filter
—Dynamic current injection for harmonic cancellation and
power factor correction
—Reduces harmonics for IEEE 519 (1992) standard compliance
—Decreases harmonic related overheating of cables, switchgear
and transformers
—Reduces downtime caused by nuisance thermal tripping of
protective devices
—Increases electrical network reliability and reduces operating costs
—Compensates each phase independently
—UL and CSA approved
—Parallel connection allows for easy retrofit and installation
of multiple units for large networks
—Filters to the 50th harmonic
—Filters entire network or specific loads depending on
installation point
—Response to load fluctuations begins in 40 microseconds with
8 milliseconds for full response to step load changes
—IGBT based power electronic technology
—50, 100 and 300A models for 208 to 480V, 50/60 Hz threephase networks
GE GEMACTIVE reduces problematic harmonic levels and provides
instantaneous power factor correction. Cost savings result from
reduced downtime and maintenance. In addition, over-sizing of
distribution equipment to provide for harmonics and poor power
factor can be avoided. GE GEMACTIVE dynamically corrects
power quality by providing: Active Harmonic Filtration, Resonance
Prevention, Power Factor Correction and Dynamic VAR
Compensation.
Active Harmonic Filter
e
24-36 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Dynamic VAR Compensation by GEMACTIVE
Large inductive inrush currents typically cause voltage sags that
result in reduced productivity, poor process quality and possible
downtime due to undervoltage tripping of devices.
GEMACTIVE is able to inject peak current at two and a half times
its rms current rating for one cycle. For many applications this
level of compensation eliminates visible flicker and improves
voltage regulation resulting in better productivity and quality.
GEMACTIVE Sizing
A harmonic study is not required to select the size of the
GEMACTIVE installation. This is because when GEMACTIVE is
installed it becomes a lower impedance path for harmonics
than the existing power supply. For sizing, please contact GE.
To expedite the product selection process, please have a single
line diagram and/or details of the application including sizes of
transformers, non-linear and linear loads, and any existing filters
and capacitors.
Active Harmonic Filter
Fig. 1: Non-linear current waveform with poor power factor
Fig. 2: Corrected Current waveform with improved power factor and
reduced harmonic content after Active Harmonic Filter Installation
Fig. 3: Inrush Current without Active Harmonic Filter
Fig. 4: Inrush Current with Active Harmonic Filter
Active Filter Three-phase 60/50Hz
Current Enclosure 240/480V
Rating Type Product Number
50
NEMA 1 37GA050FG
Chassis 37GA050FC
100 NEMA 1 37GA100FG
Chassis 37GA100FC
300
NEMA 1 37GA300FG
Chassis 37GA300FC
Current Transformers
Ratio Product Number
Multi-tap 37GCT5000SC
BuyLog™ Catalog 24-37
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Application
Type HWT equipments are suitable for use on indoor or outdoor
primary circuits where small amounts of kVAR are required. They
may be installed at load centers or directly at the terminals of
2300 and 4000 volt motors. Permissible ambient temperatures
are –40° to +45°C. Discharge resistors in each capacitor reduce
the voltage to 50 volts or less within 5 minutes of de-energization.
Type HWT equipments contain less than three gallons of flammable liquid in a single container and therefore do not require
installation in a vault to meet the NEC.
Line Terminals
Solderless connectors are provided on each phase:
Assembly Connector Size
One unit #10 - #4
Two unit #14 - 1/0
Three unit #6 - 250 kcmil
Fixed MV Power Factor Correction Capacitors
Enclosed Indoor Dustproof and Outdoor Weatherproof
25-900 kVAR, 60 Hz
2400, 4160, 4800 Volts
1.0-200 kVAR, 240 Volt
Fuses
Protection is provided by 50,000 ampere interrupting capacity
current limiting fuses. A pop-up button on the fuse gives visual
indication of a blown fuse. GE recommends the use of three fuses
for the most complete protection against terminal-to-terminal
and terminal-to-ground failures on grounded systems. Two fuses
are sufficient to provide protection against terminal-to-terminal
failures on ungrounded systems.
Blown Fuse Lights
Blown fuse lights provide a positive external indication of an
operated fuse. A glowing light makes inspection of capacitors
easy, effective, and safe. A 120 VAC source must be supplied
externally. When ordered with this option, the HWT assembly
is supplied with one light per capacitor.
For higher voltage designs, contact factory or consult e-catalog.
e
24-38 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Fixed MV Power Factor Correction Capacitors
Complete Assemblies Including Terminal Box, Fuses and Mounting Frame
Individual Units—With Terminal
Box and 3 Fuses Per Unit
Two Units Interconnected—With Terminal Box,
3 Fuses Per Unit and Mounting Frame
Three Units Interconnected—With Terminal Box,
3 Fuses Per Unit and Mounting Frame
37F0520431
37F0520432
37F0520433
37F0520434
37F0520435
37F0520436
37F0520438
37F0520437
37F0520439
37F0520440
37F0520441
—
37F0521435
37F0521436
37F0521437
37F0521439
37F0521438
37F0521440
37F0521441
37F0521442
37F0521443
37F0521444
37F0521445
—
—
37F0522442
37F0522441
37F0522443
37F0522444
37F0522445
37F0522446
37F0522447
37F0522448
37F0522449
37F0522450
—
—
—
—
2400 Volt
Assemblies
Product
Number
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
3
3
3
Fig.
No.
225
200
175
150
125
100
75
50
25
250
275
300
300
325
350
375
400
425
450
475
500
525
550
575
600
575
600
625
650
675
700
725
750
775
800
825
850
875
900
kVAR
Wt.
Dimensions
in.
27.68
27.68
27.68
29.44
30.18
32.68
33.35
33.35
36.06
36.06
39.06
39.06
33.43
33.43
33.43
33.43
33.43
39.18
39.18
39.18
39.18
39.18
39.18
39.18
39.18
33.43
33.43
39.18
39.18
39.18
39.18
39.18
39.18
39.18
39.18
39.18
39.18
39.18
39.18
(mm)
(703)
(703)
(703)
(748)
(767)
(830)
(847)
(847)
(916)
(916)
(992)
(992)
(849)
(849)
(849)
(849)
(849)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
(849)
(849)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
(995)
C
in.
6.96
6.96
6.96
8.71
9.46
11.96
12.63
12.63
18.33
18.33
18.33
18.33
12.70
12.70
12.70
12.70
12.70
18.45
18.45
18.45
18.45
18.45
18.45
18.45
18.45
12.70
12.70
18.45
18.45
18.45
18.45
18.45
18.45
18.45
18.45
18.45
18.45
18.45
18.45
(mm)
(177)
(177)
(177)
(221)
(240)
(304)
(321)
(321)
(466)
(466)
(466)
(466)
(323)
(323)
(323)
(323)
(323)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
(323)
(323)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
(469)
E
Lb
64
64
64
69
76
81
86
92
103
103
114
114
149
154
159
165
171
181
192
192
192
203
214
214
214
248
254
265
276
287
298
298
298
309
320
331
331
331
331
(kg)
(29)
(29)
(29)
(31)
(35)
(37)
(39)
(42)
(47)
(47)
(52)
(52)
(68)
(70)
(72)
(75)
(78)
(82)
(87)
(87)
(87)
(92)
(97)
(97)
(97)
(113)
(115)
(120)
(125)
(130)
(130)
(130)
(130)
(135)
(140)
(145)
(145)
(145)
(145)
Approx.
37F0526431
37F0526432
37F0526433
37F0526434
37F0526435
37F0526443
37F0526445
37F0526444
37F0526446
37F0526447
37F0526448
37F0526449
4800 Volt
Assemblies
Product
Number
37F0527440
37F0527437
37F0527441
37F0527438
37F0527442
37F0527443
37F0527444
37F0527445
37F0527446
37F0527447
37F0527448
37F0527449
—
37F0528442
37F0528443
37F0528444
37F0528445
37F0528446
37F0528447
37F0528448
37F0528449
37F0528450
37F0528451
37F0528452
37F0528453
—
—
37F0523431
37F0523432
37F0523433
37F0523434
37F0523435
37F0523436
37F0523438
37F0523437
37F0523439
37F0523440
37F0523441
37F0523442
4160 Volt
Assemblies
Product
Number
37F0524436
37F0524437
37F0524439
37F0524438
37F0524440
37F0524441
37F0524442
37F0524443
37F0524444
37F0524445
37F0524446
37F0524447
—
37F0525443
37F0525444
37F0525445
37F0525446
37F0525447
37F0525448
37F0525449
37F0525450
37F0525451
37F0525452
37F0525453
37F0525454
—
—
F
in.
0.75
0.50
0.17
0.17
0.88
0.88
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
(mm)
(19)
(13)
(4)
(4)
(22)
(22)
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
To order Blown Fuse Light option add “100” to the last 3 digits of
the standard product numbers above.
Example: 37F0524436 becomes 37F0524536.
For units tested and labeled per CSA Standard, add 037 suffix.
BuyLog™ Catalog 24-39
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
HWT Assemblies Including Terminal Box, 3 Fuses Per Unit and Mounting Frame
1Top and Bottom fuse adapters needed, one each per fuse: Order Product No. 308A390100001.
This is a kit that contains one top and one bottom adapter.
For units tested and labeled per CSA Standard, add 037 suffix.
25
50
75
100
125
150
175
200
225
250
275
300
kVAR
2400 volts
52L301WS60
51L301WS60
51L304WS60
54L303WS60
54L306WS60
54L308WS60
54L317WS60
58L302WS60
16L0153WS3
16L0154WS3
16L0155WS3
Capacitor
Product No. Product No.
00653
00653
00653
00654
00654
00654
00654
00655
00655
00655
00655
Amps
35
35
35
75
75
75
75
100
100
100
100
Fuse Dwg. No. 115A1614
4160 volts
52L302WS60
51L302WS60
51L305WS60
54L304WS60
54L307WS60
54L309WS60
54L313WS60
58L303WS60
16L0156WS3
16L0157WS3
16L0158WS3
16L0159WS3
Product No.
Capacitor
Product No.
00656
00656
00656
00658
00658
00658
00658
00658
00658
00671
00671
00671
Amps
18
18
18
50
50
50
50
50
50
75
75
75
Fuse Dwg. No. 115A1614
4800 volts
52L303WS61
51L303WS60
51L306WS60
54L305WS60
54L310WS60
54L403WS60
54L311WS60
58L424WS60
16L0160WS3
16L0161WS3
16L0162WS3
16L0163WS3
Product No.
Capacitor
Product No.
00656
00656
00656
00666
00666
00658
00658
00658
00658
00658
00671
00671
Amps
18
18
18
25
25
50
50
50
50
50
75
75
Fuse Dwg. No. 115A1614
Fixed MV Power Factor Correction Capacitors
Enclosed Indoor Dustproof and Outdoor Weatherproof
25-900 kVAR, 60 Hz
2400, 4160, 4800 Volt
Dimensions
Fig. 1 Fig. 2 Fig. 3
Replacement Capacitor Units and Fuses1
e
24-40 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Film/Foil Dielektrol
™ is the GE non-PCB low loss power capacitor
dielectric system, developed to provide lower operating costs and
greatly enhanced fuse coordination for the prevention of case
ruptures. The Dielektrol
™ insulating liquid is a Class IIIB
combustible fluid.
—These capacitors are designed to meet ANSI Std 18
—Units for special applications (i.e. system harmonics) or other
non-standard capacitors, contact Product Department or visit
www.gedigitalenergy.com
—CSA labeling available upon request
High Voltage Capacitor Units, Single and Three-Phase
Standard Duty
(Film/Foil Designs w/Dielektrol
™)
50-600 kVAR, 60 Hertz
2400-24,940 Volts
Single Phase Standard Ratings and Product Numbers1
50 kVAR 100 kVAR 150 kVAR 200 kVAR
Voltage BIL 1 Bushing 2 Bushing 1 Bushing 2 Bushing 1 Bushing 2 Bushing 1 Bushing 2 Bushing
2400 95 51L221WC62 51L201WC62 54L221WC62 54L201WC62 54L521WC62 54L501WC62 58L121WC62 58L101WC62
2770 95 51L222WC59 51L202WC59 54L222WC60 54L202WC60 54L522WC60 54L502WC60 58L122WC60 58L102WC60
4160 95 51L223WC28 51L203WC28 54L223WC60 54L203WC60 54L523WC60 54L503WC60 58L123WC60 58L103WC60
4800 95 51L224WC60 51L204WC60 54L224WC62 54L204WC62 54L524WC62 54L504WC62 58L124WC62 58L104WC62
6640 95 51L225WC60 51L205WC60 54L225WC60 54L205WC60 54L525WC60 54L505WC60 58L125WC60 58L105WC60
7200 95 51L226WC60 51L206WC60 54L226WC60 54L206WC60 54L526WC60 54L506WC60 58L126WC60 58L106WC60
7620 95 51L227WC60 51L207WC60 54L227WC60 54L207WC60 54L527WC60 54L507WC60 58L127WC60 58L107WC60
7960 95 51L228WC60 51L208WC60 54L228WC60 54L208WC60 54L528WC60 54L508WC60 58L128WC60 58L108WC60
8320 95 51L235WC60 51L215WC60 54L235WC60 54L215WC60 54L535WC60 54L515WC60 58L129WC60 58L109WC60
9960 95 51L234WC60 51L214WC60 54L234WC60 54L214WC60 54L534WC60 54L514WC60 58L130WC60 58L110WC60
12470 95 51L229WC60 51L209WC60 54L229WC60 54L209WC60 54L529WC60 54L509WC60 58L131WC60 58L111WC60
13280 95 51L230WC60 51L210WC60 54L230WC60 54L210WC60 54L530WC60 54L510WC60 58L132WC60 58L112WC60
13800 95 51L231WC60 51L211WC60 54L231WC60 54L211WC60 54L531WC60 54L511WC60 58L133WC60 58L113WC60
14400 95 51L232WC60 51L212WC60 54L232WC60 54L212WC60 54L532WC60 54L512WC60 58L134WC60 58L114WC60
19920 150 51L255WC62 - 54L255WC62 - 54L555WC60 - 58L155WC60 -
21600 150 51L256WC62 - 54L256WC62 - 54L556WC60 - 58L156WC60 -
300 kVAR 400 kVAR 500 kVAR 600 kVAR
Voltage BIL 1 Bushing 2 Bushing 1 Bushing 2 Bushing 1 Bushing 2 Bushing 1 Bushing 2 Bushing
2400 95 NA NA NA NA NA NA NA NA
2770 95 NA NA NA NA NA NA NA NA
4160 95 59L123WC60 59L103WC60 98L123WC60 98L103WC60 NA NA NA NA
4800 95 59L124WC62 59L104WC62 98L124WC63 98L104WC63 NA NA NA NA
6640 95 59L125WC60 59L105WC60 98L125WC60 98L105WC60 98L525WC60 98L505WC60 98L585WC60 98L565WC60
7200 95 59L126WC62 59L106WC62 98L126WC63 98L106WC63 98L526WC62 98L506WC62 98L586WC60 98L566WC60
7620 95 59L127WC60 59L107WC60 98L127WC60 98L107WC60 98L527WC60 98L507WC60 98L587WC60 98L567WC60
7960 95 59L128WC60 59L108WC60 98L128WC60 98L108WC60 98L528WC60 98L508WC60 98L588WC60 98L568WC60
8320 95 59L129WC60 59L109WC60 98L129WC60 98L109WC60 98L529WC60 98L509WC60 98L589WC60 98L569WC60
9960 95 59L130WC60 59L110WC60 98L130WC60 98L110WC60 98L530WC60 98L510WC60 98L590WC60 98L570WC60
12470 95 59L131WC60 59L111WC60 98L131WC60 98L111WC60 98L531WC60 98L511WC60 98L591WC60 98L571WC60
13280 95 59L132WC60 59L112WC60 98L132WC60 98L112WC60 98L532WC60 98L512WC60 98L592WC62 98L572WC62
13800 95 59L133WC60 59L113WC60 98L133WC60 98L113WC60 98L533WC60 98L513WC60 98L593WC62 98L573WC62
14400 95 59L134WC62 59L114WC62 98L134WC62 98L114WC62 98L534WC62 98L514WC62 98L594WC62 98L574WC62
19920 150 59L155WC60 - 98L155WC62 - 98L555WC61 - 98L595WC61 -
21600 150 59L156WC60 - 98L156WC62 - 98L556WC61 - 98L596WC60 -
1Larger kVAR units, extra creep options and other voltages are available. Consult factory for product numbers and pricing.
50-600 kVAR, 2400-24940 Volt
Single-Phase Capacitor
BuyLog™ Catalog 24-41
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
High Voltage Capacitor Units, Single- and Three-Phase
Heavy Duty
(Film/Foil Designs w/Dielektrol
™)
50-600 kVAR, 60 Hertz
2400-24,940 Volts
GE Heavy Duty all-film capacitors are designed, manufactured, and tested to meet the requirements of all applicable ANSI/IEEE,
NEMA, and IEC standards. In addition they are designed to exceed the requirements of these standards in terms of continuous rms
and peak overvoltage withstand capabilities. They are good for 125% continuous rms overvoltage capability and 135% peak overvoltage capability. These capacitors are suitable for industrial power systems that have higher voltages or harmonic loads. CSA
Labeling available upon request and 50 HZ designs also available upon request.
GE Heavy Duty 125% Continuous Overvoltage Capability Product Numbers
50 kVAR 100 kVAR 150kVAR 200kVAR
Voltage BIL 1 Bushing 2 Bushing 1 Bushing 2 Bushing 1 Bushing 2 Bushing 1 Bushing 2 Bushing
2400 95 51L221WC10 51L201WC10 54L221WC10 54L201WC10 54L521WC10 54L501WC10 58L121WC10 58L101WC10
2770 95 51L222WC10 51L202WC10 54L222WC10 54L202WC10 54L522WC10 54L502WC10 58L122WC10 58L102WC10
4160 95 51L223WC10 51L203WC10 54L223WC10 54L203WC10 54L523WC10 54L503WC10 58L123WC10 58L103WC10
4800 95 51L224WC10 51L204WC10 54L224WC10 54L204WC10 54L524WC10 54L504WC10 58L124WC10 58L104WC10
6640 95 51L225WC10 51L205WC10 54L225WC10 54L205WC10 54L525WC10 54L505WC10 58L125WC10 58L105WC10
7200 95 51L226WC10 51L206WC10 54L226WC10 54L206WC10 54L526WC10 54L506WC10 58L126WC10 58L106WC10
7620 95 51L227WC10 51L207WC10 54L227WC10 54L207WC10 54L527WC10 54L507WC10 58L127WC10 58L107WC10
7960 95 51L228WC10 51L208WC10 54L228WC10 54L208WC10 54L528WC10 54L508WC10 58L128WC10 58L108WC10
8320 95 51L235WC10 51L215WC10 54L235WC10 54L215WC10 54L535WC10 54L515WC10 58L129WC10 58L109WC10
9960 95 51L234WC10 51L214WC10 54L234WC10 54L214WC10 54L534WC10 54L514WC10 58L130WC10 58L110WC10
12470 95 51L229WC10 51L209WC10 54L229WC10 54L209WC10 54L529WC10 54L509WC10 58L131WC10 58L111WC10
13280 95 51L230WC10 51L210WC10 54L230WC10 54L210WC10 54L530WC10 54L510WC10 58L132WC10 58L112WC10
13800 95 51L231WC10 51L211WC10 54L231WC10 54L211WC10 54L531WC10 54L511WC10 58L133WC10 58L113WC10
14400 95 51L232WC10 51L212WC10 54L232WC10 54L212WC10 54L532WC10 54L512WC10 58L134WC10 58L114WC10
19920 150 51L255WC10 - 54L255WC10 - 54L555WC10 - 58L155WC10 -
21600 150 51L256WC10 - 54L256WC10 - 54L556WC10 - 58L156WC10 -
300 kVAR 400 kVAR 500 kVAR
Voltage BIL 1 Bushing 2 Bushing 1 Bushing 2 Bushing 1 Bushing 2 Bushing
2400 95 NA NA NA NA NA NA
2770 95 NA NA NA NA NA NA
4160 95 59L123WC10 59L103WC10 98L123WC10 98L103WC10 NA NA
4800 95 59L124WC10 59L104WC10 98L124WC10 98L104WC10 NA NA
6640 95 59L125WC10 59L105WC10 98L125WC10 98L105WC10 98L525WC10 98L505WC10
7200 95 59L126WC10 59L106WC10 98L126WC10 98L106WC10 98L526WC10 98L506WC10
7620 95 59L127WC10 59L107WC10 98L127WC10 98L107WC10 98L527WC10 98L507WC10
7960 95 59L128WC10 59L108WC10 98L128WC10 98L108WC10 98L528WC10 98L508WC10
8320 95 59L129WC10 59L109WC10 98L129WC10 98L109WC10 98L529WC10 98L509WC10
9960 95 59L130WC10 59L110WC10 98L130WC10 98L110WC10 98L530WC10 98L510WC10
12470 95 59L131WC10 59L111WC10 98L131WC10 98L111WC10 98L531WC10 98L511WC10
13280 95 59L132WC10 59L112WC10 98L132WC10 98L112WC10 98L532WC10 98L512WC10
13800 95 59L133WC10 59L113WC10 98L133WC10 98L113WC10 98L533WC10 98L513WC10
14400 95 59L134WC10 59L114WC10 98L134WC10 98L114WC10 98L534WC10 98L514WC10
19920 150 59L155WC10 - 98L155WC10 - 98L555WC10 -
21600 150 59L156WC10 - 98L156WC10 - 98L556WC10 -
e
24-42 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
High Voltage Capacitor Units, Single- and Three-Phase
Contact factory for up to date Capacitor Outline Drawings.
Three Phase Cantilever Mount Units
These three-phase capacitor units use the same technology as our single-phase units
and when mounted directly to a pole offer a convenient single piece alternative to a
multi-unit pole mount rack.
Ungrounded Wye
Three-Phase Capacitor
Standard Ratings and Product Numbers
3 - Bushing
Grounded Wye
4 - Bushing
Ungrounded Wye
3 - Bushing
Grounded Wye
4 - Bushing
Ungrounded Wye
4160/2400 95 59L603WC29 59L623WC29 98L603WC29 98L623WC29
12470/7200 95 59L611WC59 59L631WC59 98L611WC59 98L631WC59
13200/7620 95 59L612WC59 59L632WC59 98L612WC59 98L632WC59
13800/7960 95 59L613WC59 59L633WC59 98L613WC59 98L633WC59
14400/8320 95 59L614WC59 59L634WC59 98L614WC59 98L634WC59
300 kVAR 400 kVAR
Voltage BIL (kV)
BuyLog™ Catalog 24-43
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Pole Mounted Racks Factory Assembled—Welded
Field Assembly—Bolted1
Bird Caps/Wildlife Protectors
Total Unit
Capacity
3
6
9
12
Product
Number
33F10AA002
33F10BA002
33F10CA002
33F10DA002
95kV-BIL
Product
Number
33F24AA004
33F26BA004
33F26CA004
33F26DA004
125kV-BIL
Total Capacity # of Units
3
3
6
6
Product Number
39F0083004
39F0083015
39F0086010
39F0086011
1Field assembly racks are for fixed applications only and will not support
the addition of switches.
BIL
125
125
95
95
Description Product Number
Capacitor Bird Caps with Sleeve 614A507000101
Fuse Holders
Flipper Springs
HV Fuses and Fuse Links
Drawing Number
248A695400001
248A695400002
Application
Upright
Edgemount
Drawing Number
115A162000078
115A162000079
115A162000080
115A162000063
115A162000081
115A162000035
115A162000053
115A162000036
115A162000043
115A162000024
115A162000059
115A162000025
EEI-NEMA
8T
10T
12T
15T
20T
25T
30T
40T
50K
65K
80K
100K
15
23
8
25
kV
31F2807001
31F2808001
115A161500041
115A161500049
Product Number Current
50
25
100
50
Interrupting
3600 amp. Sym
3600/1800 amp. Sym
7400 amp. Sym
1800 amp. Sym
Rating
High Voltage Capacitor Units, Single- and Three-Phase
Three-Phase Units and Accessories
e
24-44 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Pole Mounted Equipment Description
These equipments are pre-wired, factory assembled, and shipped ready for pole installation with single-phase units. Racks are of welded structural aluminum and are suitable
for mounting switches and junction box and cable assembly. Lightning arresters and/or
potential transformers can also be mounted.
Required Data for Pole-Type Quotation:
The following questions must be answered before contacting the factory for a quotation.
1. Total kVAR? ________
2. Line-to-line (system) voltage? ________
3. Line-to-neutral voltage? ________
4. Bank connection — Delta, Grounded Wye, or Floating Wye? ________
5. Fixed or switched? _________
(check one)
a. Fixed expandable (switches later) _________
b. Fixed nonexpandable (no switches later) ________
c. Switch type (vacuum or oil) ________
6. Number of capacitor bushings (1 or 2)? ______ BIL (Basic Insulation Level) ____
7. Options (specify):
a. Current transformer
b. Potential transformer
c. Lightning arresters
d. Switching controls (example: voltage, current, kVAR, time controls)
e. Other. Please specify __________________________________________________
Open Stack-Rack Equipment Description
This application is most popular for large blocks of three-phase Kilovar. Capacitor units
and individual fuses are installed in welded aluminum racks, either upright or edgemount. Racks are shipped ready for field installation with base and inter-rack insulators,
substructure, interconnecting bus wire and other accessories for a three-phase
equipment.
Harmonic filter banks are available. Submit complete specifications including harmonic
currents and voltages.
Required Data for Stack-Rack Quotation:
The following questions must be answered before contacting the factory for a quotation.
1. Total kVAR? ________
2. Line-to-line (system) voltage? ________
3. Bank connection — Floating Wye, Grounded Wye, Delta, or Double Wye1? ______
4. Fixed or switched2? ________
a. If switched, how many steps? _________________
b. If switched, how many kVAR per step? ________________
5. Is substructure required (8 ft. standard)? ________
6. Space limitations (if any). Please specify____________________________________
7. Options (specify):
a. Current transformer
b. Potential transformer
c. Ground switch (phase, neutral, both)
d. Other. Please specify __________________________________________________
8. When optional apparatus is requested, state the available short circuit current
for proper sizing of the options.
1Three-phase, 60 Hertz is assumed. Specify if different.
2If switched:
a. Supply specification on switch requested.
b. Advise if any parallel banks and ratings.
Typical in-line pole-type equipment,
single-phase units
Upright stack-rack equipment
Edgemount stack-rack equipment
High Voltage Pole-Mounted, Open Stack-Rack
and Metal Enclosed Equipment
Pole-type Equipment Metal Enclosed
150-3600 kVAR, 60 Hertz 2.4 through 38kV
Open Stack-rack Banks 150 kVAR and above
1200 kVAR and above, 60 Hertz
BuyLog™ Catalog 24-45
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
These power factor correction equipments are metal enclosed for indoor and outdoor
installations. These banks can be located on a distribution feeder as a small padmount
or at the workstation site. Banks are shipped ready for installation. Banks can be provided with the following options: oil or vacuum switching, automatic control and protection,
stainless steel housing, custom colors, key mechnical or electrical interlocks, capacitor
removal device, NEMA 1, 3R, 4, 4X or 12 enclosures.
Required Data for Metal Enclosed Quotation:
The following questions must be answered before contacting the factory for a quotation.
1.Total kVAR? ________
2.Line-to-line (system) voltage? ________
3. Bank connection - Floating Wye, Grounded Wye, Delta, or Double Wye ?________
When in doubt Floating Wye is typically the best choice to avoid fault
protection issues
4. Fixed or switched? ___________
a. If switched do you want automatic control? ________
b. If switched, how many steps? ________
c. If switched, how many kVAR per step? ________
5.Space or access limitations (if any). Please specify ________
6.Type of Enclosure (Indoor or Outdoor; is Stainless Steel required)
7. Options (specify):
Incoming Air Disconnect ________
Main Incoming fuses (capacitors will be individually fused as
standard practice) ___________
Ground switch (phase, neutral, both) ________
Power factor Controller (see 4a above) ________
Key Interlocks ________
Blown fuse Detection System ________
Control Power Transformer ________
Arresters - Distribution, Intermediate or Station class ________
Incoming Breaker ________
Power Quality Meter ________
Overload protection (Yes or No) ________
Overvoltage protection (Yes or No) ________
Relay requirememts (class, type, brand, other please specify) ________
Other. Please specify _________________________________________
8. When optional apparatus is requested, state the available short circuit current for
proper sizing of the options. ___________________________________
9. Harmonic Filter Bank (Yes or No) ________
If yes, tuning point (5th, 7th, 11th, ...) ________
High Voltage Pole-Mounted, Open Stack-Rack
and Metal Enclosed Equipment
Metal Enclosed Capacitor Banks
2.4 thru 38KV
Metal Enclosed Cabinet
e
24-46 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
This HESP design is intended for mounting in OEM equipment or
in an existing enclosure to offer protection against internally and
externally generated surges. UL-1449, Second Edition Recognized
Component designed and tested according to ANSI/IEEE C62.41
and C62.45.
Features
Energy Capability Options: This high energy capability option
permits survivability in demanding environments and a lower
clamping level for better protection.
High Surge Current Capability: The 76mm HESP protective elements are designed and tested at 100kA per mode.
Parallel or Series Connection: Unfused protectors are suitable
for series connection in circuits rated up to 100 amps continuous,
and T-connection (parallel) with no limitation on continuous load
current.
The ability to connect the units in the series configuration offers
optimum protection. This connection keeps lead length inductive
voltage to a minimum and provides the lowest protective levels
for each rating.
Dependable Protection: The unique zinc oxide "valve" element
inside each arrester gives you improved overvoltage protection.
These tough elements are designed so that they can handle
surge after surge without trouble, breakdown, or repairs. Your
Tranquell
™ arrester’s protective ability will remain unchanged
throughout its service life.
OEM High Energy Surge Protectors
9L10K Series
120-600 Volt Ratings
Common Mode Protection Option: In addition to normal mode
protection (L-L and L-N), HESP offers common mode protection
(L-G and N-G) for 3-phase wye and single-phase 1 or 2 pole
devices. This optional protection is recommended for devices
remotely located from the system neutral to ground bond.
9L10K Series is direct replacement for superseded 9L10M Series.
Selection and Ratings
Nominal Voltage Max. Continuous 1 second Diagram Energy Rating UL-1449, Second Edition Suppressed Voltage
and Configuration Operating Voltage Temporary Overvoltage Figure (Joules Rating (SVR) with 6 leads
Product
(Volts, rms) (Volts, rms) (Volts, rms) page 24-47 per Phase) L-N N-G2 L-G2,3 L-L Number1
120, 1 Phase 960 400 330 - - 9L10KAA112
2 Wire Line-Neutral 138 L-N 183 1 2688 400 330 - - 9L10KAA132NO
208 WYE/120 Line-Neutral 138 L-N 183 960 400 330 700 700 9L10KAB3144
3 Phase, 4 Wire Line-Line 239 L-L317 3, 4
2688 400 330 700 700 9L10KAB334NO
120/240 Line-Neutral 138 L-N 183 960 400 400 700 700 9L10KAC113
1 Phase, 3 Wire Line-Line 276 L-L367 2
2688 400 400 700 700 9L10KAC133NO
240/480 Line-Neutral 276 L-N 367 1920 700 700 1200 1200 9L10KAD113
1 Phase, 3 Wire Line-Line 552 L-L 734 2
5376 700 700 1200 1200 9L10KAD133NO
240, 1 Phase 1920 700 700 - - 9L10KAE112
2 Wire Line-Neutral 276 L-N 367 1 5376 700 700 - - 9L10KAE132NO
240 Delta 1920 - - 700 1200 9L10KAF3134
3 Phase, 3 Wire Line-Line 276 L-L 367 5, 6
5376 - - 700 1200 9L10KAF333NO
240 WYE/138 Line-Neutral 158 L-N 211 1108 400 400 800 800 9L10KAG3144
3 Phase, 4 Wire Line-Line 276 L-L 366 3, 4
3102 400 400 800 800 9L10KAG334NO
480, 1 Phase 3840 1500 1500 - - 9L10KAJ112
2 Wire Line-Neutral 552 L-N 734 1 10752 1500 1500 - - 9L10KAJ132NO
480 Delta 3840 - - 800 1500 9L10KAK3134
3 Phase, 3 Wire Line-Line 552 L-L 734 5, 6
10752 - - 800 1500 9L10KAK333NO
480 WYE/277 Line-Neutral 318 L-N 424 2216 800 800 1500 1500 9L10KAL3144
3 Phase, 4 Wire Line-Line 552 L-L 734 3, 4
6205 800 800 1500 1500 9L10KAL334NO
1For optional Common Mode Protection change the product numbers as follows: for single-phase devices substitute 2 in the 8th
position of the product number. For 3-phase WYE devices substitute 4 in the 8th position of the product number.
2N-G and L-G values for WYE product numbers are only applicable to those units with the optional common mode protection.
3For service entry applications where the neutral and ground are bonded, the L-G rating is equivalent to the L-N rating.
4Units indicated are not UL approved.
BuyLog™ Catalog 24-47
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
"H" Dimension
Product Number inches mm
9L10KAA112 1.75 44.5
9L10KAA132NO 2 50.8
9L10KAB314 2.75 69.9
9L10KAB334NO 3.38 85.9
9L10KAC113 2.50 63.5
9L10KAC133NO 3 76.2
9L10KAD113 2.50 63.5
9L10KAD133NO 3 76.2
9L10KAE112 1.75 44.5
9L10KAE132NO 2.25 57.2
9L10KAF313 2.25 57.2
9L10KAF333NO 3.75 95.3
9L10KAG314 2.75 69.9
9L10KAG334NO 3.38 85.9
9L10KAJ112 1.75 44.5
9L10KAJ132NO 2.25 57.2
9L10KAK313 2.25 57.2
9L10KAK333NO 3.75 95.3
9L10KAL314 2.88 73.2
9L10KAL334NO 4.38 111.3
9L10KAM313 2.62 66.5
9L10KAM333NO 4.50 114.3
9L10KAN314 2.88 73.2
9L10KAN334NO 4.38 111.3
OEM High Energy Surge Protectors
9L10K Series
120 – 600 Volt Ratings
4-terminal device shown
Dimensions (in/mm)
Fig. 1 Single Phase 2 or 3 Wire
Series Connection
Max. Continuous Current:
100A/Phase
“T” Connection
Max. Continuous Current:
Unlimited
Fig. 2 Single Phase 3 or 4 Wire
Fig. 3 Three Phase Wye Ungrounded
Fig. 4 Three Phase Wye/4 or 5 Wire/GND Neutral
Fig. 5 Three Phase Delta/Ungrounded
Fig. 6 Three Delta/One Phase Grounded
Connection Diagrams
e
24-48 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Tranquell™ Motor Surge Protector
Motor and Generator Surge Protection Equipment
Three-Phase, 60 Hz
2400 through 24,000 Volt Ratings
NEMA 12/3R Enclosure
Selection Table
Product No.
Grounded
Neutral Systems
—
—
—
—
—
—
—
—
38F2403
38F2408
38F2410
38F2412
Arrester
Rating kV rms
3
6.0
3
6
9.0
9
18
10
18
12
27
21
Arrester
MCOV kV rms
2.55
5.1
2.55
5.1
7.65
7.65
15.3
8.4
15.3
10.2
22.0
17.0
Capacitor
Microfarads
per Pole µF
0.5
0.5
0.5
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.125
0.125
Weight lbs
300
300
300
300
300
300
300
300
300
300
350
350
Contact factory for other ratings.
23"
23"
23"
23"
23"
23"
23"
23"
23"
23"
36"
36"
Dimension "D"
(side view)
2400
4160
4800
6900
7200
13200
13800
24000
Voltage Rating
rms Volts (L-L)
—
—
—
—
Product No.
Delta & Ungrounded
Neutral Systems
38F2401
38F2402
38F2404
38F2405
38F2406
38F2407
38F2409
38F2411
—
—
—
—
Description
Tranquell
™ Motor Surge Protector provides surge protection for
AC rotating machines including motors and generators. They
are typically applied directly at the motor terminals and consist of
GE Tranquell
™ Station Class arresters connected in parallel with
GE Dielektrol
™ Protective Capacitor(s). The arresters protect the
major insulation to ground by limiting the amplitude of applied
impulse waves or reflections within the machine windings, while
the protective capacitor(s) reduce the steepness of wave fronts.
Studies indicate that this dual protection approach results in
significant reduction of lightning stresses imposed on rotating
machines and contribute to increased security against failures
and downtime costs. Enclosure is suitable for indoor and outdoor
applications.
How to Select
1. Determine the nominal system voltage and connection at the
equipment being protected (Line-to-Line voltage, delta or wye,
grounded or ungrounded).
2. Select product number (column 2 or 3) based on the line to line
voltage (column 1).
Dimensions: (inches)
Front Side
BuyLog™ Catalog 24-49
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Assures Service Continuity
The GE Tranquell
™ secondary arrester is specifically designed to
protect utility, agricultural, and industrial installations and equipment in the 120-650 volt range from overvoltages caused by
lightning discharges. It is available for both single- and threephase application.
Applications that provide ideal installations for this arrester are:
—Exposed secondary circuits
—Watt hour meters
—Station auxiliary equipment and circuits
—Motors and control circuits
—Distribution transformer secondaries
Dependable Protection
The unique metal oxide element inside each Tranquell
™ arrester
gives you improved overvoltage protection. These tough elements
are designed so that they can handle surge after surge without
trouble, breakdown, or repairs. Your arrester’s protective ability
will remain unchanged throughout its service life.
Tranquell™ Secondary Surge Arresters
and Protective Capacitors
120-650 Vac
Series 9L15F
Figure 1
Tranquell™ Arrester
Fusing
To minimize the possibility of violent rupture in the unlikely event
of electrical failure of the arrester, current limiting fuses are recommended for all applications above 120 volts. A fuse must be
installed in series with each pole of the arrester (i.e. each black
wire). See Fuse Selection table below. The GEH-4982C instruction
book shipped with each arrester also includes fusing guidelines.
Secondary Arresters – Indoor or Outdoor Mounting
Circuit Max. Permissible
Voltage Line-to-Ground No. of Net Weight Product
Rating rms Voltage rms Poles (lbs/Kg) Number1
120 175 2 1.0/0.4 9L15HCB001
650 650 1 1.0/0.4 9L15GCA001
650 650 2 1.0/0.4 9L15GCB001
650 650 3 1.0/0.4 9L15GCC001
Non-PCB Secondary Protective Capacitors–
Indoor or Outdoor Mounting
Circuit Max. Permissible
Voltage Line-to-Ground No. of Net Weight Product
Rating rms Voltage rms Poles (lbs/Kg) Number1
0-650 650 3 4.00/1.8 9L18BBB301
1Quantity break pricing applies; consult factory or your GE sales representative.
Secondary Surge Arrester Protective Characteristics
Discharge Voltage kV Crest Discharge Energy
(8 x 20 Microsecond Current Wave)
Capabilities Handling
1.5 kA 5.0 kA 10.0 kA 20.0 kA 8 x 20 microsecond Capability
2.2 2.6 2.9 3.5 20,000 amp 900 joules
per pole
Fuse Selection – For 9L15E Series (above 120V)
Arrester Maximum Fuse Location Lightning Impulse2,3 Rating 4
A Long Branch Circuit
more than 20m from 200A
30 A; 600 V
Service Entrance U.L. Class T
with wires #14-10 200,000 A Interrupt
B Major Feeders and
Short Branch Circuits 3 kA 30 A; 600 V
less than 20m from 8x20 µs U.L. Class T
Service Entrance 200,000 A Interrupt
C Outside and 10 kA
30 A; 600 V
Service Entrance
4x10 µs
U.L. Class T
200,000 A Interrupt
Figure 2
Protective Capacitor 5
2Maximum impulse expected as described in ANSI/IEEE C62.41 for systems with
medium exposure to surges. Arresters have been design tested to impulses as
high as 20 kA, 8x20µs.
3Design tests for secondary arresters as required by ANSI/IEEE standards are limited
to a maximum of 10 kA, 4x10µs impulses.
4UL Class CC (Midget) 30 A fuses are also satisfactory for locations A and B.
5Secondary capacitor is a 3-pole device that can be applied with 1- and 2-pole arresters
by connecting the corresponding black leads and tying off the unused leads.
e
24-50 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Tranquell™ Station Arresters
Polymer and Porcelain High-Voltage
Indoor and Outdoor Service
Product Description
Tranquell
™ XE porcelain and XEP polymer station arresters
provide both excellent protective characteristics and temporary
overvoltage capability. Gapless construction results in a design
which is simple, reliable and economical while offering excellent
fault current capability to meet the most demanding service conditions. The GE arrester is based on the field-proven metal oxide
disks known for maintaining stable characteristics. Station
arresters are designed and manufactured in accordance with the
latest revision of ANSI/IEEE C62.11. Tranquell™ Polymer Station Arrester
Porcelain and Polymer Arresters (Station Class) for both Indoor and Outdoor Mounting (2.7-612 kVrms)
Normally Used on System Voltage Class (L-L)
High Impedance
Grounded, Porcelain Product Number Silicone4
Arrester MCOV Capability Ungrounded (Delta) Solidly Metal Top for
Rating (L-N) kVrms or Temporarily Grounded Metal Top; Porcelain Top for Indoor or Eyebolt
kVrms Porcelain Polymer Ungrounded Circuits Neutral kVrms Indoor / Outdoor Indoor or Cubicle Outdoor 4-hole NEMA Terminal
3 2.55 2.55 2.4 4.16 9L11ZGA003S 9L11ZGB003S 9L11XPA003AS 9L11XPB003AS
6 5.1 5.1 4.8 8.32 9L11ZGA006S 9L11ZGB006S 9L11XPA006AS 9L11XPB006AS
9 7.65 7.65 6.9 12.47 9L11ZGA009S 9L11ZGB009S 9L11XPA009AS 9L11XPB009AS
10 8.4 8.4 8.32 13.8 9L11ZGA010S 9L11ZGB010S 9L11XPA010AS 9L11XPB010AS
12 10.2 10.2 122 -- 9L11ZGA012S 9L11ZGB012S 9L11XPA012AS 9L11XPB012AS
15 12.7 12.7 13.82 20.78 9L11ZGA015S 9L11ZGB015S 9L11XPA015AS 9L11XPB015AS
18 15.3 15.3 13.8 24.94 9L11ZGA018S 9L11ZGB018S 9L11XPA018AS 9L11XPB018AS
21 17 17 -- -- 9L11ZGA021S 9L11ZGB021S 9L11XPA021AS 9L11XPB021AS
24 19.5 19.5 232 -- 9L11ZGA024S 9L11ZGB024S 9L11XPA024AS 9L11XPB024AS
27 22 22 23 34.5 9L11ZGA027S 9L11XPA027AS 9L11XPB027AS
30 24.4 24.4 24.94 -- 9L11ZGA030S 9L11XPA030AS 9L11XPB030AS
36 29 29 34.52 46 9L11ZGA036S 9L11XPA036AS 9L11XPB036AS
39 31.5 31.5 -- -- 9L11ZGA039S 9L11XPA039AS 9L11XPB039AS
45 36.5 36.5 34.5 -- 9L11ZGA045S 9L11XPA045AS 9L11XPB045AS
48 39 39 462 -- 9L11ZGA048S 9L11XPA048AS 9L11XPB048AS
54 42 42 -- 69 9L11ZTA054AS 9L11HMA054S 9L11XPA054AS 9L11XPB054AS
60 48 48 46 -- 9L11ZTA060AS 9L11HMA060S 9L11XPA060AS 9L11XPB060AS
66 53 53 -- -- 9L11ZTA066AS 9L11XPA072AS 9L11XPB072AS
72 57 57 692 -- 9L11ZTA072AS 9L11HMA072S 9L11XPA090AS 9L11XPB090AS
90 74 70 69 115 9L11ZTA090AS 9L11HMA090S 9L11XPA096AS 9L11XPB096AS
96 76 76 -- -- 9L11ZTA096AS 9L11HMA096S 9L11XPA108AS 9L11XPB108AS
108 84 84 -- 138 9L11ZXA108AS 9L11HMA108S 9L11SPA108AS 9L11SPB108AS
108 88 88 -- -- 9L11ZTA108AS 9L11HMA108S 9L11XPA120AS 9L11XPB120AS
120 98 98 1152 161 9L11ZTA120AS 9L11HMA120S 9L11XPA132AS 9L11XPB132AS
132 106 106 -- -- 9L11ZTA132AS 9L11HMA132S 9L11XPA144AS 9L11XPB144AS
144 115 115 1382 -- 9L11ZTA144AS 9L11HMA144S 9L11XPA168AS 9L11XPB168AS
168 131 131 138 -- 9L11ZTA168AS 9L11HMA168S 9L11XPA172AS 9L11XPB172AS
172 140 140 1612 230 9L11ZTA172AS 9L11HMA172S 9L11XPA180AS 9L11XPB180AS
180 144 144 -- -- 9L11ZTA180AS 9L11HMA180S 9L11XPA192AS 9L11XPB192AS
192 152 152 161 -- 9L11ZTA192AS 9L11HMA192S 9L11XPA228AS 9L11XPB228AS
228 180 180 -- -- 9L11ZTA228AS 9L11HMA228S
240 194 194 -- -- 9L11ZTA240AS 9L11HMA240S
258 209 For Nominal 345kV Systems 9L11ZTA258AS 9L11HMA258S
264 212 For Nominal 345kV Systems 9L11ZTA264AS 9L11HMA264S
276 220 For Nominal 345kV Systems 9L11ZTA276AS 9L11HMA276S
288 234 For Nominal 345kV Systems 9L11ZTA288AS 9L11HMA288S
294 237 For Nominal 345kV Systems 9L11ZTA294AS
300 243 For Nominal 345kV Systems 9L11ZTA300AS
312 245 For Nominal 400kV Systems 9L11ZTA312AS 9L11HMA312S
336 264 For Nominal 400kV Systems 9L11ZTA336AS
360 288 For Nominal 400kV Systems 9L11ZTA360AS
396 318 For Nominal 500kV Systems 9L11ZTA396AS 9L11HMA396S
420 335 For Nominal 500kV Systems 9L11ZTA420AS 9L11HMA420S
396 318 For Nominal 500kV Systems 9L11ZTA396AS
420 335 For Nominal 500kV Systems 9L11ZTA420AS
444 353 For Nominal 500kV Systems 9L11ZTA444AS 9L11HMA444S
588 470 For Nominal 765kV Systems 9L16GNS588S
612 485 For Nominal 765kV Systems 9L16GNS612S
1Tranquell
™ Arresters are designed to be operated at voltages equal to or less than their continuous capability as stated in column 2.
2Based on our recommended MCOV ratings for normal system voltages, for systems with ground faults lasting no more than 30 minutes.
3For underhung (or upside down) mounting, with eyebolt terminal on the bottom, change letter B of the product number to E. 4Special Ratings available on request.
BuyLog™ Catalog 24-51
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Porcelain, Metal Top Station Arrester Dimensions, Leakage Distances, Mounting Clearances and Weights
Standard Height "X" Creepage Distance Insulation Withstand Distance Weight
Arrester Catalog Duty Cycle MCOV Phase to Phase- Phase to GroundNumber (kV) rms (kV) rms in. mm in. mm in. mm in. mm lbs. kg
9L11ZGA003S 3 2.55 19.13 485.9 6.2 157.5 12 304.8 6 152.4 65 29.5
9L11ZGA006S 6 5.1 19.13 485.9 6.2 157.5 12 304.8 7 177.8 65 29.5
9L11ZGA009S 9 7.65 19.13 485.9 6.2 157.5 13 330.2 7 177.8 66 30
9L11ZGA010S 10 8.4 19.13 485.9 6.2 157.5 13 330.2 8 203.2 66 30
9L11ZGA012S 12 10.2 21.13 536.7 11.1 281.9 14 355.6 8.5 215.9 72 32.7
9L11ZGA015S 15 12.7 21.13 536.7 11.1 281.9 14 355.6 8.5 215.9 73 33.2
9L11ZGA018S 18 15.3 24.13 612.9 20 508 16 406.4 9 228.6 80 36.4
9L11ZGA021S 21 17 24.13 612.9 20 508 16 406.4 9 228.6 81 36.8
9L11ZGA024S 24 19.5 24.13 612.9 20 508 17 431.8 11 279.4 82 37.3
9L11ZGA027S 27 22 28.13 714.5 31.7 805.2 18 457.2 12 304.8 90 40.9
9L11ZGA030S 30 24.4 28.13 714.5 31.7 805.2 18 457.2 12 304.8 91 41.4
9L11ZGA036S 36 29 28.13 714.5 31.7 805.2 20 508 14 355.6 93 42.3
9L11ZGA039S 39 31.5 31.88 809.8 41 1041.4 21 533.4 14 355.6 105 47.7
9L11ZGA045S 45 36.5 31.88 809.8 41 1041.4 21 533.4 15 381 107 48.6
9L11ZGA048S 48 39 31.88 809.8 41 1041.4 22 558.8 15 381 109 49.5
9L11ZTA054AS 54 42 38.13 969 75 1905 16.4 418 14.8 376 175 80
9L11ZTA060AS 60 48 38.13 969 75 1905 18.1 459 16.3 413 178 81
9L11ZTA066AS 66 53 38.13 969 75 1905 19.4 491 17.4 442 180 82
9L11ZTA072AS 72 57 38.13 969 75 1905 20.5 520 18.4 467 183 83
9L11ZTA090AS 90 70 44.13 1121 100 2540 23.8 604 21.3 541 217 99
9L11ZTA096AS 96 76 44.13 1121 100 2540 25.4 646 22.8 578 220 100
9L11SXA108AS 108 84 50.63 1286 126.3 3208 27.6 700 24.6 626 256 116
9L11ZTA108AS 108 88 50.63 1286 126.3 3208 28.6 726 25.6 649 257 117
9L11ZTA120AS 120 98 50.63 1286 126.3 3208 31.2 793 27.9 709 263 120
9L11ZTA132AS 132 106 57.13 1451 152.5 3874 33.4 848 29.8 757 294 134
9L11ZTA144AS 144 115 57.13 1451 152.5 3874 35.8 908 31.9 810 299 136
9L11ZTA168AS 168 131 76.63 1946 175 4445 40 1015 35.6 905 391 178
9L11ZTA172AS 172 140 76.63 1946 175 4445 60.8 1545 56.2 1428 414 188
9L11ZTA180AS 180 144 82.63 2099 200 5080 62 1574 57.2 1453 442 201
9L11ZTA192AS 192 152 82.63 2099 200 5080 64 1626 59 1499 446 203
9L11ZTA228AS 228 180 95.63 2429 252.5 6414 71.4 1812 65.5 1664 523 238
9L11ZTA240AS 240 190 95.63 2429 252.5 6414 74 1880 67.9 1724 529 240
9L11ZTA258AS 258 209 102.13 2594 278.8 7082 93.1 2363 86.3 2193 574 261
9L11ZTA264AS 264 212 102.13 2594 278.8 7082 93.9 2385 87.1 2212 575 261
9L11ZTA276AS 276 220 108.63 2759 305 7747 96 2437 88.9 2258 606 275
9L11ZTA288AS 288 230 108.63 2759 305 7747 98.6 2505 91.3 2318 611 278
9L11ZTA294AS 294 235 127.63 3242 326.3 8288 99.9 2537 92.4 2347 698 317
9L11ZTA300AS 300 243 127.63 3242 326.3 8288 102.1 2593 94.4 2398 702 319
9L11ZTA312AS 312 245 127.63 3242 326.3 8288 102.5 2604 94.7 2405 703 320
9L11ZTA336AS 336 274 134.13 3407 352.5 8954 110.2 2799 101.5 2578 749 340
9L11ZTA360AS 360 288 140.63 3572 378.8 9621 113.9 2893 104.8 2662 788 358
9L11ZTA396AS 396 318 153.63 3902 431.3 10955 142.9 3629 132.8 3374 890 405
9L11ZTA420AS 420 335 160.13 4067 457.6 11623 147.4 3744 136.8 3475 927 421
9L11ZTA444AS 444 353 179.13 4550 478.8 12162 152.1 3863 141 3581 1024 465
9L16GNS588S 588 470 276.8 7031 595 15113 232.5 5906 215.4 5471 3674 1670
9L16GNS612S 612 485 286.1 7267 627 15919 237.1 6021 219.5 5575 3774 1716
Porcelain Top Station Arrester
Mounting Clearance1
Product "X" Overall Height Leakage Dist Phase to Phase Phase To Ground Weight
Number MCOV (kV) in mm in mm in mm in mm lb kg
9L11ZGB003S 2.55 19.13 485.9 6.2 157.5 12 304.8 6 152.4 65 29.5
9L11ZGB006S 5.1 19.13 485.9 6.2 157.5 12 304.8 7 177.8 65 29.5
9L11ZGB009S 7.65 19.13 485.9 6.2 157.5 13 330.2 7 177.8 66 30
9L11ZGB010S 8.4 19.13 485.9 6.2 157.5 13 330.2 8 203.2 66 30
9L11ZGB012S 10.2 21.13 536.7 11.1 281.9 14 355.6 8.5 215.9 72 32.7
9L11ZGB015S 12.7 21.13 536.7 11.1 281.9 14 355.6 8.5 215.9 73 33.2
9L11ZGB018S 15.3 24.13 612.9 20 508 16 406.4 9 228.6 80 36.4
9L11ZGB021S 17 24.13 612.9 20 508 16 406.4 9 228.6 81 36.8
9L11ZGB024S 19.5 24.13 612.9 20 508 17 431.8 11 279.4 82 37.3
9L11ZGB027S 22 28.13 714.5 31.7 508 17 431.8 11 279.4 90 40.9
9L11ZGB030S 24.4 28.13 714.5 31.7 805.2 18 457.2 12 304.8 91 41.4
9L11ZGB030S 24.4 28.13 714.5 31.7 805.2 18 457.2 12 304.8 91 41.4
9L11ZGB036S 29 28.13 714.5 31.7 805.2 20 508 14 355.6 93 42.3
9L11ZGB039S 31.5 31.88 809.8 41 1041.4 21 533.4 14 355.6 105 47.7
9L11ZGB045S 36.5 31.88 809.8 41 1041.4 21 533.4 15 381 107 48.6
9L11ZGB048S 39 31.88 809.8 41 1041.4 22 558.8 15 381 109 49.5
1These are recommended minimum clearances only and as such are not intended to take precedence over existing construction codes or specifications.
Tranquell™ Station Arresters
Porcelain High-Voltage
Indoor and Outdoor Service
e
24-52 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Porcelain, Metal Top Station Arrester – Insulation Characteristics
Minimum Power
Frequency Withstand (kVrms)
Duty Cycle MCOV Leakage Dist Strike Minimum 1.2 x 50µs Wet Dry
Product Number (kV) (kV) in mm in mm Withstand (kV crest) (10 sec) (1 min)
9L11ZGA003S 3 2.55 6.2 157.48 6 152.4 60 20 21
9L11ZGA006S 6 5.1 6.2 157.48 7 177.8 75 24 27
9L11ZGA009S 9 7.65 6.2 157.48 7 177.8 95 30 32
9L11ZGA010S 10 8.4 6.2 157.48 8 203.2 95 30 32
9L11ZGA012S 12 10.2 11.1 281.94 8.5 215.9 110 45 50
9L11ZGA015S 15 12.7 11.1 281.94 8.5 215.9 110 45 50
9L11ZGA018S 18 15.3 20 508 9 228.6 110 45 50
9L11ZGA021S 21 17 20 508 9 228.6 150 60 70
9L11ZGA024S 24 19.5 20 508 11 279.4 150 60 70
9L11ZGA027S 27 22 31.7 805.18 12 304.8 150 60 70
9L11ZGA030S 30 24.4 31.7 805.18 12 304.8 200 80 95
9L11ZGA036S 36 29 31.7 805.18 14 355.6 200 80 95
9L11ZGA039S 39 31.5 41 1041.4 14 355.6 250 100 120
9L11ZGA045S 45 36.5 41 1041.4 15 381 250 100 120
9L11ZGA048S 48 39 41 1041.4 15 381 250 100 120
9L11ZTA054AS 54 42 75 1905 18 457.2 194 81 NA1
9L11ZTA060AS 60 48 75 1905 19 482.6 221 91 NA1
9L11ZTA066AS 66 53 75 1905 29.5 749.3 262 108 NA1
9L11ZTA072AS 72 57 75 1905 20 508 262 108 NA1
9L11ZTA090AS 90 74 100 2540 29 736.6 337 139 NA1
9L11ZTA096AS 96 76 100 2540 31 787.4 348 144 NA1
9L11SXA108AS 108 84 126.3 3208 32 812.8 404 166 NA1
9L11ZTA108AS 108 88 126.3 3208 33 838.2 404 166 NA1
9L11ZTA120AS 120 98 126.3 3208 36 914.4 448 190 NA1
9L11ZTA132AS 132 106 152.5 3874 38 965.2 486 205 NA1
9L11ZTA144AS 144 115 152.5 3874 46 1168.4 524 223 NA1
9L11ZTA168AS 168 131 175 4445 54 1371.6 598 253 NA1
9L11ZTA172AS 172 140 175 4445 59 1498.6 637 271 NA1
9L11ZTA180AS 180 144 200 5080 64 1625.6 658 278 NA1
9L11ZTA192AS 192 152 200 5080 67 1701.8 693 296 NA1
9L11ZTA228AS 228 180 252.5 6414 73 1854.2 821 348 NA1
9L11ZTA240AS 240 194 252.5 6414 71 1803.4 885 375 NA1
9L11ZTA258AS 258 209 278.8 7082 92 2336.8 952 424 NA1
9L11ZTA264SS 264 212 278.8 7082 96 2438.4 966 429 NA1
9L11ZTA276AS 276 220 305 7747 100 2540 1001 447 NA1
9L11ZTA288AS 288 234 305 7747 91.5 2324.1 1069 474 NA1
9L11ZTA294AS 294 237 326.3 8288 91.5 2324.1 1082 480 NA1
9L11ZTA300AS 300 243 326.3 8288 91.5 2324.1 1100 492 NA1
9L11ZTA312AS 312 245 326.3 8288 110 2794 1119 496 NA1
1Minimum Dry Power Withstand not required by ANSI.
Porcelain Top Station Arrester – Insulation Characteristics
Minimum Power
Frequency Withstand (kVrms)
Duty Cycle MCOV Leakage Dist Strike Minimum 1.2 x 50µs Wet Dry
Product Number (kV) (kV) in mm in mm Withstand (kV crest) (10 sec) (1 min)
9L11ZGB003S 3 2.55 11.1 281.94 5.5 139.7 60 20 21
9L11ZGB006S 6 5.10 11.1 281.94 5.5 139.7 75 24 27
9L11ZGB009S 9 7.65 11.1 281.94 5.5 139.7 95 30 35
9L11ZGB010S 10 8.40 11.1 281.94 5.5 139.7 95 30 35
9L11ZGB012S 12 10.20 11.1 281.94 6.5 165.1 110 45 50
9L11ZGB015S 15 12.70 20 508 7.5 190.5 110 45 50
9L11ZGB018S 18 15.30 20 508 9 228.6 110 45 50
9L11ZGB021S 21 17 20 508 9 228.6 150 60 70
9L11ZGB024S 24 19.50 20 508 9 228.6 150 60 70
9L11ZGB027S 27 22 28.5 723.9 16.5 419.1 150 60 70
Tranquell™ Station Arresters
Porcelain High-Voltage
Indoor and Outdoor Service
BuyLog™ Catalog 24-53
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Tranquell™ Station Arresters
Porcelain High-Voltage
Indoor and Outdoor Service
Porcelain Station Arrester – Protective Characteristics
Arrester Ratings Continuous Maximum
Arrester Operating Maximum 0.5us Switching Surge Maximum Discharge Voltage using 8/20 Current Wave-kV
Product Rated Voltage Voltage (MCOV) Discharge Protective Level
Type Number (kV) kV rms Voltage kV1 kV2 1.5kA 3kA 5kA 10kA 20kA 40kA
9L11ZGA003S 3 2.55 9.1 6.3 6.9 7.2 7.5 8 9 10.3
9L11ZGA006S 6 5.1 17.9 12.4 13.6 14.2 14.8 15.8 17.7 20.3
9L11ZGA009S 9 7.65 26.6 18.4 20.2 21.1 22 23.5 26.4 30.2
9L11ZGA010S 10 8.4 29.3 20.3 22.2 23.3 24.2 25.9 29.1 33.3
9L11ZGA012S 12 10.2 35.5 24.6 26.9 28.2 29.4 31.4 35.2 40.4
9L11ZGA015S 15 12.7 44.2 30.6 33.5 35.1 36.6 39.1 43.9 50.3
9L11ZGA018S 18 15.3 53.3 36.8 40.4 42.3 44.1 47.1 52.8 60.6
9L11ZGA021S 21 17 59.1 40.9 44.8 46.9 48.9 52.3 58.7 67.2
9L11ZGA024S 24 19.5 67.8 46.9 51.4 53.8 56.1 60 67.3 77.1
9L11ZGA027S 27 22 76.5 52.9 58 60.8 63.3 67.7 75.9 87
9L11ZGA030S 30 24.4 84.9 58.7 64.3 67.4 70.3 75.1 84.2 96.5
9L11ZGA036S 36 29 101 69.7 76.4 80 83.4 89.2 100 115
9L11ZGA039S 39 31.5 110 75.8 83 86.9 90.6 96.9 109 125
9L11ZGA045S 45 36.5 128 88.3 96.8 102 106 113 127 146
9L11ZGA048S 48 39 136 93.8 103 108 113 120 135 155
9L11ZTA054AS 54 42 133 101 108 113 117 122 131 144
9L11ZTA060AS 60 48 152 116 124 129 134 140 150 165
9L11ZTA072AS 72 57 180 137 147 153 159 166 178 195
9L11ZTA090AS 90 70 221 167 180 187 194 203 217 239
Contact Factory 90 74 234 177 191 198 205 215 230 253
9L11ZTA096AS 96 76 240 182 196 204 211 221 236 260
9L11ZXA108AS 108 84 265 201 216 225 233 244 261 287
4 Hole NEMA 9L11ZTA108AS 108 88 277 210 226 235 243 255 273 300
9L11ZTA120AS 120 98 308 241 252 262 271 284 304 334
9L11ZTA132AS 132 106 334 261 273 284 294 308 329 362
9L11ZTA144AS 144 115 363 283 296 308 318 334 357 393
9L11ZTA168AS 168 131 412 322 337 350 362 380 406 447
9L11ZTA172AS 172 140 441 344 360 374 387 406 434 477
9L11ZTA180AS 180 144 454 355 370 385 398 418 447 491
9L11ZTA192AS 192 152 479 374 391 406 420 441 471 518
9L11ZTA228AS 228 180 566 443 462 481 497 522 557 613
9L11ZTA258AS 258 209 657 532 537 558 577 606 647 712
9L11ZTA264AS 264 212 667 540 545 566 586 615 657 723
9L11ZTA276AS 276 220 692 560 565 587 608 638 681 750
9L11ZTA288AS 288 230 724 585 591 614 635 667 712 784
9L11ZTA294AS 294 235 739 598 603 627 649 681 727 800
9L11ZTA300AS 300 243 765 619 624 649 672 705 753 828
9L11ZTA312AS 312 245 770 623 629 654 676 710 758 834
9L11ZTA336AS 336 274 861 697 703 731 756 794 848 933
9L11ZTA360AS 360 288 906 733 739 769 795 835 891 981
9L11ZTA396AS 396 318 1053 809 816 849 878 922 984 1083
9L11ZTA420AS 420 335 1109 852 860 894 925 971 1037 1140
9L11ZTA444AS 444 353 1169 898 906 942 974 1023 1092 1202
9L16GNS588S 588 470 1469 1143 1159 1193 1225 1283 1348 1442
9L16GNS612S 612 485 1516 1180 1196 1231 1264 1324 1391 1488
1Maximum discharge voltage for an impulse current wave which produces a voltage wave cresting in 0.5 µs. Discharge currents are 10 kA for 2.55 - 245kV MCOV. This can
be used for coordination where front-of-wave sparkover was formerly used.
2Discharge voltages are based on a 500A surge of 45 µs time to crest through 88kV MOV and 1,000A surge of 45 µs-time to crest through 180kV MCOV and 2,000A through
245kV MCOV.
e
24-54 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
9L11ZGBO##S Series
Rated Voltage 3-27kV
9L11ZGAO##S Series
Rated Voltage 3-48kV
9L11Z TA###AS Series
Rated Voltage 54-144kV
9L11Z TA###AS Series
Rated Voltage 168kV
9L11Z TA###AS Series
Rated Voltage 172-240kV
9L11Z TA###AS Series
Rated Voltage 258-312kV
Tranquell™ Station Arresters
Porcelain High-Voltage
Indoor and Outdoor Service
9L11Z TA###AS Series
Rated Voltage 336 – 360kV
9L11Z TA###AS Series
Rated Voltage 396 – 420kV
4 Hole NEMA Terminal
Polymer Station Arrester – Weights and Dimensions
Standard Standard
Arrester Product Arrester Product Insulation Withstand Distance Cantilever Strength
Number 4 Hole Number Single Duty Cycle MCOV Height "X"3 Creepage Distance Phase to Phase Phase to Ground Weight Note 1 Note 2
NEMA Eyebolt (kV) rms (kV) rms in mm in mm in mm in mm lbs kg ft-lbs Nm ft-lbs Nm
9L11XPA003AS 9L11XPB003AS 3 2.55 9.9 251 19.6 498 9 229 4.5 114 13 5.9 761 3383 1521 15039
9L11XPA006AS 9L11XPB006AS 6 5.1 9.9 251 19.6 498 9 229 4.5 114 13 5.9 761 3383 1521 15039
9L11XPA009AS 9L11XPB009AS 9 7.65 11.7 297 30.1 765 9 229 4.5 114 15 6.8 669 2974 1337 13221
9L11XPA010AS 9L11XPB010AS 10 8.4 11.7 297 30.1 765 9 229 4.5 114 15 6.8 669 2974 1337 13221
9L11XPA012AS 9L11XPB012AS 12 10.2 11.7 297 30.1 765 9 229 4.6 117 15 6.8 669 2974 1337 13221
9L11XPA015AS 9L11XPB015AS 15 12.7 13.5 343 35.4 899 9.7 246 5.4 137 17 7.7 595 2645 1190 11759
9L11XPA018AS 9L11XPB018AS 18 15.3 13.5 343 35.4 899 10.6 269 6.1 155 17 7.7 595 2645 1190 11759
9L11XPA021AS 9L11XPB021AS 21 17 17.2 437 40.5 1029 11.2 284 6.7 170 22 10 489 2174 977 9664
9L11XPA024AS 9L11XPB024AS 24 19.5 17.2 437 40.5 1029 12.1 307 7.4 188 22 10 489 2174 977 9664
9L11XPA027AS 9L11XPB027AS 27 22 17.2 437 40.5 1029 12.9 328 8.2 208 22 10 489 2174 977 9664
9L11XPA030AS 9L11XPB030AS 30 24.4 17.2 437 40.5 1029 13.8 351 8.9 226 22 10 489 2174 977 9664
9L11XPA036AS 9L11XPB036AS 36 29 20.9 531 50.9 1293 15.4 391 10.3 262 27 12.2 414 1840 829 8182
9L11XPA039AS 9L11XPB039AS 39 31.5 20.9 531 50.9 1293 16.2 411 11.1 282 27 12.2 414 1840 829 8182
9L11XPA045AS 9L11XPB045AS 45 36.5 24.5 622 61.5 1562 17.9 455 12.6 320 31 14 360 1600 720 7114
9L11XPA048AS 9L11XPB048AS 48 39 24.5 622 61.5 1562 18.8 478 13.3 338 31 14 360 1600 720 7114
9L11XPA054AS 9L11XPB054AS 54 42 24.5 622 61.5 1562 20.5 521 14.9 378 31 14 360 1600 720 7114
9L11XPA060AS 9L11XPB060AS 60 48 28.2 716 71.9 1826 22.1 561 16.2 411 36 16.3 313 1391 636 6186
9L11XPA072AS 9L11XPB072AS 72 57 31.9 810 82.4 2093 25.4 645 19.2 488 41 18.6 284 1263 569 5613
9L11XPA090AS 9L11XPB090AS 90 70 46.3 1176 123 3124 30.5 775 23.7 602 59 26.7 202 898 403 3992
9L11XPA096AS 9L11XPB096AS 96 76 46.3 1176 123 3124 32.2 818 25.2 640 59 26.7 202 898 403 3992
9L11XPA108AS 9L11XPB108AS 108 84 46.3 1176 123 3124 35.6 904 28.2 716 59 26.7 202 898 403 3992
9L11SPA108AS 9L11SPA108AS 108 88 46.3 1176 123 3124 35.6 904 28.2 716 59 26.7 202 898 403 3992
9L11XPA120AS 9L11XPB120AS 120 98 53.7 1364 143.9 3655 48.6 1234 36 914 73 33.1 176 782 351 3478
9L11XPA132AS 9L11XPB132AS 132 106 53.7 1364 143.9 3655 51.6 1311 38.7 983 73 33.1 176 782 351 3478
9L11XPA144AS 9L11XPB144AS 144 115 61 1549 164.8 4186 55 1397 41.7 1059 82 37.2 156 693 311 3083
9L11XPA168AS 9L11XPB168AS 168 131 72.5 1842 184.5 4686 61.7 1567 47.7 1212 97 44 66 293 264 1304
9L11XPA172AS 9L11XPB172AS 172 140 83.5 2121 215.8 5481 74.4 1890 60.5 1537 120 54.4 58 258 230 1146
9L11XPA180AS 9L11XPB180AS 180 144 83.5 2121 215.8 5481 76.3 1938 62.4 1585 120 54.4 58 258 230 1146
9L11XPA192AS 9L11XPB192AS 192 152 83.5 2121 215.8 5481 79.7 2024 65.8 1671 120 54.4 58 258 230 1146
9L11XPA228AS 9L11XPB228AS 228 180 94.5 2400 247.2 6279 89.7 2278 75.7 1923 133 60.3 51 227 205 1008
*Center line to center line is equivalent to phase-to-phase center line to ground is equivalent to phase-to-ground.
These are recommended minimum clearances only and as such are not intended to take precedence over existing construction codes or specifications.
1Cantilever Strength - Maximum Working Strength
2Cantilever strength - Rated Ultimate Cantilever Strength
3Add 3.30” to “X” dimension for 4 Hole NEMA terminal and 2.88” to “X” dimension for Eyebolt designs for overall height
BuyLog™ Catalog 24-55
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Polymer Station Arrester – Protective Characteristics 9L11XPAxxxAS and 9L11XPBxxxAS
Arrester Ratings
Maximum
Continuous Maximum
Operating Maximum 0.5us Switching Surge
Rated Voltage Voltage Discharge Protective Level Maximum Discharge Voltage Using 8/20 Current Wave-kV
kV rms (MCOV) kV rms Voltage kV1 kV2 1.5kA 3kA 5kA 10kA 20kA 40kA
3 2.55 10.5 6.01 6.41 6.74 7.06 7.58 8.19 9.34
6 5.1 18.6 12.02 12.82 13.47 14.12 15.15 16.38 18.69
9 7.65 27 18.03 19.23 20.21 21.19 22.73 24.57 28.03
10 8.4 29.4 19.79 21.12 22.19 23.26 24.96 26.98 30.78
12 10.2 35.1 24.04 25.64 26.95 28.25 30.31 32.76 37.37
15 12.7 43.4 29.93 31.93 33.55 35.17 37.74 40.79 46.53
18 15.3 51.6 36.05 38.46 40.42 42.37 45.46 49.15 56.06
21 17 57.8 40.06 42.74 44.91 47.08 50.52 54.61 62.29
24 19.5 65.7 45.95 49.02 51.51 54 57.94 62.64 71.45
27 22 73.6 51.84 55.31 58.12 60.93 65.37 70.67 80.61
30 24.4 81.2 57.5 61.34 64.46 67.57 72.5 78.38 89.4
36 29 97 68.63 73.22 76.94 80.66 86.55 93.56 106.71
39 31.5 105 74.35 79.32 83.35 87.39 93.76 101.36 115.61
45 36.5 121 86.01 91.76 96.42 101.08 108.46 117.25 133.73
48 39 129 91.9 98.04 103.03 108.01 115.89 125.28 142.89
54 42 145 103.68 110.61 116.23 121.86 130.75 141.34 161.21
60 48 160 114.39 122.03 128.24 134.44 144.25 155.93 177.86
72 57 192 137.38 146.56 154.01 161.46 173.24 187.27 213.6
90 74 245 174.37 186.03 195.48 204.94 219.89 237.7 271.13
96 76 257 183.8 196.08 206.05 216.02 231.78 250.55 285.78
108 84 289 207.36 221.22 232.47 243.71 261.49 282.67 322.42
108 88 289 207.36 221.22 232.47 243.71 261.49 282.67 322.42
120 98 322 240.54 246.36 258.88 271.41 291.21 314.8 359.06
132 106 350 262.14 268.48 282.13 295.78 317.36 343.06 391.3
144 115 382 286.19 293.12 308.02 322.92 346.48 374.54 427.21
168 131 447 334.3 342.39 359.8 377.2 404.72 437.5 499.02
172 140 462 343.87 352.2 370.1 388 416.31 450.03 513.31
180 144 480 357.45 366.1 384.71 403.32 432.74 467.8 533.57
192 152 510 381.42 390.66 410.52 430.37 461.77 499.18 569.37
228 180 605 452.85 463.81 487.39 510.96 548.24 592.65 675.98
Tranquell™ Station Arresters
Polymer High-Voltage
Indoor and Outdoor Service
e
24-56 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Tranquell™ Station Arresters
Silicone Station Arresters Protective Characteristics
Maximum Switching
Maximum 0.5µs Surge Protective Level
Rated Discharge At Classifying
Product Voltage MCOV Voltage1 Current Levels kV2 Maximum Discharge Voltage Using an 8/20 Current Wave-kV
Number kVrms kVrms kV kV 1.5kA 3kA 5kA 10kA 20kA 40kA
9L11HMA054S 54 42 133 94 103 108 113 121 131 146
9L11HMA060S 60 48 152 107 118 124 129 138 150 166
9L11HMA072S 72 57 181 127 140 147 153 164 178 198
9L11HMA090S 90 70 222 156 172 181 188 201 218 243
9L11HMA090S 90 74 235 165 182 191 199 213 231 256
9L11HMA096S 96 76 241 170 187 196 205 218 237 263
9L11HMA108S 108 84 266 187 207 217 226 241 262 291
9L11HMA108S 108 88 279 196 217 227 237 253 274 305
9L11HMA120S 120 98 311 228 241 253 264 282 305 340
9L11HMA132S 132 106 336 247 261 274 285 305 330 367
9L11HMA144S 144 115 365 268 283 297 310 330 358 399
9L11HMA168S 168 131 416 305 323 338 353 376 408 454
9L11HMA172S 172 140 444 326 345 362 377 402 436 485
9L11HMA180S 180 144 457 335 355 372 388 414 449 499
9L11HMA192S 192 152 482 354 374 393 409 437 473 527
9L11HMA228S 228 180 571 419 443 465 485 517 561 624
9L11HMA258S 258 209 663 519 515 540 563 601 651 724
9L11HMA264S 264 212 673 526 522 548 571 609 660 735
9L11HMA276S 276 220 698 546 542 568 592 632 685 762
9L11HMA312S 312 245 777 608 603 633 660 704 763 849
9L11HMA396S 396 318 1009 790 783 821 856 914 991 1102
9L11HMA420S 420 335 1063 832 825 865 902 963 1043 1161
9L11HMA444S 444 353 1120 876 869 912 950 1014 1100 1223
Silicone Station Arresters Dimensions and Mounting
Minimum Mounting
Maximum Continuous Minimum Spacing on Center3
Product Duty Cycle Operating Voltage Height Leakage Phase to Phase Phase to Net Weight
Number kV rms kV rms (in.) Distance In-line (in.) Ground (in.) (Lbs.)
9L11HMA054S 54 42 38.1 83 17 21 104
9L11HMA060S 60 48 38.1 83 19 23 107
9L11HMA072S 72 57 38.1 83 23 28 112
9L11HMA090S 90 70 44.4 113 28 34 125
9L11HMA090S 90 74 44.4 113 30 36 130
9L11HMA096S 96 76 44.4 113 30 37 128
9L11HMA108S 108 84 52.1 142 34 41 141
9L11HMA108S 108 88 52.1 142 35 42 144
9L11HMA120S 120 98 52.1 142 39 47 149
9L11HMA132S 132 106 58.8 171 42 51 167
9L11HMA144S 144 115 58.8 171 46 55 172
9L11HMA168S 168 131 76.9 196 52 63 231
9L11HMA172S 172 140 76.9 196 63 82 257
9L11HMA180S 180 144 76.9 196 65 84 257
9L11HMA192S 192 152 83.2 225 68 88 262
9L11HMA228S 228 180 90.9 254 79 101 291
9L11HMA258S 258 209 105.3 313 108 150 349
9L11HMA264S 264 212 105.3 313 109 151 351
9L11HMA276S 276 220 105.3 313 102 134 330
9L11HMA312S 312 245 129.7 367 112 146 406
9L11HMA396S 396 318 151.8 455 161 222 539
9L11HMA420S 420 335 158.5 484 168 230 564
9L11HMA444S 444 353 165.2 514 165 218 532
1 Maximum discharge voltage for an impulse current wave which produces a voltage wave cresting in 0.5 µs. Discharge Currents are 10kA for 42-353 kV MCOV. This can be
used for coordination where front-of-wave sparkover formerly was used.
2 Discharge voltages are based on a 500A surge of 45 µs time to crest through 88kV MCOV and a 1000A surge of 45 µs to crest through 180 kV MCOV and 2000A through
245 kV MCOV.
3 Minimum clearances are based on arrester protective levels and should be increased when necessary to meet local requirements for spacing of energized equipment.
BuyLog™ Catalog 24-57
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Tranquell™ Station Arresters
Polymer High-Voltage
Indoor and Outdoor Service
Polymer Arresters (Station Class)
for both Indoor and Outdoor Mounting (2.7-72 kVrms) 9L11XPMxxxS , 9L11XPNxxxS, and 9L11XPTxxxS
Pressure Relief Capability: 40 kA rms
Energy Handling Capability: 6.0kJ/kV mCOV
Cantilever Strength: 4,000 inch-pounds, rated ultimate cantilever moment
Product Number (Gray Polymer)
Arrester Maximum Continuous 4-hole NEMA Pad for Eyebolt Terminal for
Rating Voltage Capability Indoor or Outdoor Indoor or Outdoor Indoor or cubicle
kVrms (L-N) kVrms Upright Mounting Upright Mounting Terminal Mounting
2 2.2 9L11XPN002S 9L11XPT002S 9L11XPM002S
3 2.55 9L11XPN003S 9L11XPT003S 9L11XPM003S
4 3.7 9L11XPN004S 9L11XPT004S 9L11XPM004S
5 4.2 9L11XPN005S 9L11XPT005S 9L11XPM005S
6 5.1 9L11XPN006S 9L11XPT006S 9L11XPM006S
7 6.1 9L11XPN007S 9L11XPT007S 9L11XPM007S
8 6.9 9L11XPN008S 9L11XPT008S 9L11XPM008S
9 7.65 9L11XPN009S 9L11XPT009S 9L11XPM009S
10 8.4 9L11XPN010S 9L11XPT010S 9L11XPM010S
12 10.2 9L11XPN012S 9L11XPT012S 9L11XPM012S
15 12.7 9L11XPN015S 9L11XPT015S 9L11XPM015S
18 15.3 9L11XPN018S 9L11XPT018S 9L11XPM018S
21 17 9L11XPN021S 9L11XPT021S 9L11XPM021S
24 19.5 9L11XPN024S 9L11XPT024S 9L11XPM024S
27 22 9L11XPN027S 9L11XPT027S 9L11XPM027S
30 24.4 9L11XPN030S 9L11XPT030S 9L11XPM030S
36 29 9L11XPN036S 9L11XPT036S 9L11XPM036S
39 31.5 9L11XPN039S 9L11XPT039S
45 36.5 9L11XPN045S 9L11XPT045S
48 39 9L11XPN048S 9L11XPT048S
54 42 9L11XPN054S 9L11XPT054S
60 48 9L11XPN060S 9L11XPT060S
72 57 9L11XPN072S 9L11XPT072S
For weight, dimensional and other technical information, please visit the Arresters section of www.gedigitalenergy.com
Polymer Arresters (Station Class)—Protective Characteristics 9L11XPMxxxS, 9L11XPNxxxS and 9L11XPTxxxS
for both Indoor and Outdoor Mounting (2.7-72 kVrms) 9L11XPMxxxS , 9L11XPNxxxS, and 9L11XPTxxxS
Pressure Relief Capability: 40 kA rms
Energy Handling Capability: 6.0kJ/kV mCOV
Cantilever Strength: 4,000 inch-pounds, rated ultimate cantilever moment
Product Number
9L11XPNxxxS1 Rating voltage 0.5 µsec 10 kA Switching Surge Maximum Discharge Voltage - kV crest
9L11XPMxxxS* kV rms mCOV kV rms Max IR-kV crest Max IR-kV crest 1.5 kA 3 kA 5 kA 10 kA 20 kA 40 kA
9L11XPT003S 3 2.55 8.5 6.3 6.7 7.1 7.4 8 8.9 10
9L11XPT006S 6 5.1 16.9 12.5 13.4 14.2 14.8 16 17.7 20
9L11XPT009S 9 7.65 25.3 18.7 20.1 21.2 22.2 23.9 26.5 29.8
9L11XPT010S 10 8.4 27.6 20.5 21.9 23.1 24.2 26.1 28.9 32.5
9L11XPT012S 12 10.2 33.5 24.9 26.6 28.1 29.4 31.7 35.1 39.5
9L11XPT015S 15 12.7 42.2 31.3 33.5 35.4 37 39.9 44.2 49.8
9L11XPT018S 18 15.3 50.5 37.5 40.1 42.4 44.3 47.8 52.9 59.6
9L11XPT021S 21 17 55.3 41 43.9 46.3 48.5 52.3 57.9 65.2
9L11XPT024S 24 19.5 67 49.7 53.2 56.2 58.8 63.4 70.2 79.1
9L11XPT027S 27 22 75.9 56.3 60.2 63.6 66.6 71.8 79.5 89.5
9L11XPT030S 30 24.4 82.9 61.5 65.8 69.5 72.7 78.4 86.8 98
9L11XPT036S 36 29 101 74.6 79.8 84.3 88.2 95.1 105 119
9L11XPT039S 39 31.5 105.8 78.5 84 88.7 92.8 100.1 110.8 124.8
9L11XPT045S 45 36.5 122.3 90.7 97.1 102.5 107.3 115.7 128.1 144.3
9L11XPT048S 48 39 134 99.4 106.4 112.3 117.5 126.8 140.4 158.1
9L11XPT054S 54 42 144 106.8 114.3 120.7 126.3 136.2 150.8 169.8
9L11XPT060S 60 48 161.6 119.9 128.3 135.5 141.7 152.9 169.3 191
9L11XPT072S 72 57 195 144.7 154.9 163.6 171.1 184.6 204 230
For weight, dimensional and other technical information, please visit the Arresters section of www.gedigitalenergy.com
19L11XPNxxxS & 9L11XPMxxxS, the electrical characteristics in this table are applicable to these catalog numbers.
Outline drawings can be downloaded from the GE Arrester, E-Catalog on the web.
e
24-58 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Product Description
Tranquell
™ XEP polymer intermediate arresters provide both
excellent protective characteristics and temporary overvoltage
capability. Gapless construction results in a design which is
simple, reliable, and economical while offering excellent fault
current capability to meet the most demanding service conditions.
The GE Tranquell
™ arrester is based on the field-proven metal
oxide disks known for maintaining stable characteristics.
Tranquell
™ intermediate arresters are designed and manufactured
in accordance with the latest revision of ANSI/IEEE C62.11 and IEC
99-4.
Polymer Arresters (Intermediate-Class)
for both Indoor and Outdoor Mounting (3-144 kVrms)
Normally Used on System Voltage Class (L-L) Product Number (Gray Polymer)
Arrester Maximum Continuous High Impedance Grounded, Solidly Grounded 4-hole NEMA Pad Eyebolt Terminal
Rating Operating Voltage Capability1 Ungrounded (Delta), or Neutral Systems for Indoor or Outdoor for Indoor or Outdoor
kVrms (L-N) kVrms temporarily ungrounded circuits kVrms Upright Mounting Upright Mounting2
3 2.55 2.4 4.16 9L12PPA003S 9L12PPB003S
6 5.1 4.8 – 9L12PPA006S 9L12PPB006S
9 7.65 7.2 12.47 9L12PPA009S 9L12PPB009S
10 8.4 7.62 13.2 9L12PPA010S 9L12PPB010S
12 10.2 7.97 13.8 9L12PPA012S 9L12PPB012S
15 12.7 13.83 20.78 9L12PPA015S 9L12PPB015S
18 15.3 13.8 24.94 9L12PPA018S 9L12PPB018S
21 17 – 24.94 9L12PPA021S 9L12PPB021S
24 19.5 233 – 9L12PPA024S 9L12PPB024S
27 22 23 34.5 9L12PPA027S 9L12PPB027S
30 24.4 – 34.5 9L12PPA030S 9L12PPB030S
36 29 34.53 – 9L12PPA036S 9L12PPB036S
39 31.5 34.5 – 9L12PPA039S 9L12PPB039S
45 36.5 41.6 – 9L12PPA045S 9L12PPB045S
48 39 41.2 – 9L12PPA048S 9L12PPB048S
54 42 – 69 9L12PPA054S 9L12PPB054S
60 48 – 69 9L12PPA060S 9L12PPB060S
72 57 69 – 9L12PPA072S 9L12PPB072S
90 70 – 115 9L12PPA090S 9L12PPB090S
96 76 – 115 9L12PPA096S 9L12PPB096S
108 88 115 138 9L12PPA108S 9L12PPB108S
120 98 115 138/161 9L12PPA120S 9L12PPB120S
132 106 138 161 9L12PPA132S 9L12PPB132S
144 115 138/161 161 9L12PPA144S 9L12PPB144S
1Tranquell
™ Arresters are designed to be operated at voltages equal to or less than their continuous capability as stated in column 2. 2For underhung or upside down mounting with eyebolt terminal on the bottom change the letter B of the catalog number to E. 3Application of specified rating is permissible for ungrounded or resistance grounded systems where a single phase ground may be
tolerated for a substantial period of time not to exceed the Tranquell
™ arresters overvoltage capability.
Tranquell™ Intermediate Arresters
Polymer High Voltage
Indoor and Outdoor Service
9L12PPA Polymer
BuyLog™ Catalog 24-59
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Polymer Intermediate Arrester Weights and Dimensions
Product Number
Mounting Clearance1
4-hole NEMA Pad Single Eyebolt Rated Voltage MCOV "X" Height
Phase to Phase Phase to Ground Weight
Line Terminal Line Terminal (kVrms) (kVrms) inches mm (in) (mm) (in) (mm) lb kg
9L12PPA003S 9L12PPB003S 3 2.55 6.8 172.7 4.4 111.8 3.3 83.8 6.2 2.8
9L12PPA006S 9L12PPB006S 6 5.1 6.8 172.7 4.6 116.8 3.2 81.3 6.2 2.8
9L12PPA009S 9L12PPB009S 9 7.65 6.8 172.7 4.7 119.4 3.3 83.8 6.2 2.8
9L12PPA010S 9L12PPB010S 10 8.4 6.8 172.7 4.9 124.5 3.5 88.9 6.2 2.8
9L12PPA012S 9L12PPB012S 12 10.2 6.8 172.7 4.9 124.5 3.5 88.9 6.2 2.8
9L12PPA015S 9L12PPB015S 15 12.7 12.2 309.9 6.2 157.5 4.8 121.9 10.0 4.5
9L12PPA018S 9L12PPB018S 18 15.3 12.2 309.9 6.6 167.6 5.2 132.1 10.0 4.5
9L12PPA021S 9L12PPB021S 21 17 12.2 309.9 7.6 193.0 6.2 157.5 10.0 4.5
9L12PPA024S 9L12PPB024S 24 19.5 12.2 309.9 7.6 193.0 6.2 157.5 10.0 4.5
9L12PPA027S 9L12PPB027S 27 22 17.6 447.0 9.6 243.8 8.2 208.3 13.5 6.1
9L12PPA030S 9L12PPB030S 30 24.4 17.6 447.0 9.8 248.9 8.4 213.4 13.5 6.1
9L12PPA036S 9L12PPB036S 36 29 17.6 447.0 9.8 248.9 8.4 213.4 13.5 6.1
9L12PPA039S 9L12PPB039S 39 31.5 23.0 584.2 12.8 325.1 11.4 289.6 17.0 7.7
9L12PPA045S 9L12PPB045S 45 36.5 23.0 584.2 12.8 325.1 11.4 289.6 17.0 7.7
9L12PPA048S 9L12PPB048S 48 39 23.0 584.2 12.8 325.1 11.4 289.6 17.0 7.7
9L12PPA054S 9L12PPB054S 54 42 28.4 721.4 15.8 401.3 14.4 365.8 19.6 8.9
9L12PPA060S 9L12PPB060S 60 48 28.4 721.4 15.8 401.3 14.4 365.8 19.6 8.9
9L12PPA072S 9L12PPB072S 72 57 33.8 858.5 19.8 502.9 18.4 467.4 23.1 10.5
9L12PPA090S 9L12PPB090S 90 70 44.0 1117.6 40 1016.0 33 838.2 52 23.6
9L12PPA096S 9L12PPB096S 96 76 44.0 1117.6 42 1066.8 35 889.0 53 24.0
9L12PPA108S 9L12PPB108S 108 88 44.0 1117.6 46 1168.4 39 990.6 54 24.5
9L12PPA120S 9L12PPB120S 120 98 66.5 1689.1 51 1295.4 44 1117.6 67.5 30.6
9L12PPA132S 9L12PPB132S 132 106 66.5 1689.1 55 1397.0 47 1193.8 67.5 30.6
9L12PPA144S 9L12PPB144S 144 115 66.5 1689.1 58 1473.2 50 1270.0 67.5 30.6
1These clearances are recommended minimum clearances only and as such are not intended to take precedence over existing construction codes or specifications.
Placement of the units should be such that they do not physically touch each other.
Polymer Intermediate Arrester Protective Characteristics 9L12PPAxxxS and 9L12PPBxxxS
Insulation Withstand
Rated 0.5µsec, 500A Switching Min Wet Dry
Voltage MCOV 10kA Max. IR Surge Max IR 8/20µs Maximum Discharge Voltage - kVcrest Creep Strike 1.2x50µs 10 sec 1 min
(kVrms) (kVrms) (kVcrest) (kVcrest) 1.5kA 3kA 5kA 10kA 20kA 40kA in mm in mm (kV crest) (kVrms) (kVrms)
3 2.55 8.6 6.4 6.8 7.2 7.5 8.1 9 10.1 15.4 391.16 3.3 83.82 100 40 60
6 5.1 17.1 12.7 13.6 14.4 15 16.2 17.9 20.2 15.4 391.16 3.2 81.28 100 40 60
9 7.65 25.8 19.1 20.5 21.6 22.6 24.4 27 30.4 15.4 391.16 3.3 83.82 100 40 60
10 8.4 28.4 21.1 22.6 23.8 24.9 26.9 29.8 33.5 15.4 391.16 3.5 88.9 100 40 60
12 10.2 34.1 25.3 27.1 28.6 29.9 32.3 35.8 40.3 15.4 391.16 3.5 88.9 165 70 100
15 12.7 42.9 31.8 34.1 36 37.6 40.6 44.9 50.6 30.8 782.32 4.8 121.92 165 70 100
18 15.3 51.6 38.3 40.9 43.2 45.2 48.8 54 60.9 30.8 782.32 5.2 132.08 165 70 100
21 17 56.9 42.2 45.1 47.7 49.9 53.8 59.6 67.1 30.8 782.32 6.2 157.48 165 70 100
24 19.5 68.3 50.6 54.2 57.2 59.9 64.6 71.5 80.6 30.8 782.32 6.2 157.48 230 105 140
27 22 77.4 57.4 61.4 64.9 67.9 73.2 81 91.3 46.2 1173.48 8.2 208.28 230 105 140
30 24.4 85.3 63.3 67.7 71.5 74.8 80.7 89.3 101 46.2 1173.48 8.4 213.36 230 105 140
36 29 102 76 81.3 85.9 89.8 96.9 107 121 46.2 1173.48 8.4 213.36 310 140 180
39 31.5 108.4 80.4 86.1 90.9 95.1 102.6 113.6 127.9 61.6 1564.64 11.4 289.56 310 140 180
45 36.5 125.1 92.8 99.3 104.9 109.8 118.4 131.1 147.6 61.6 1564.64 11.4 289.56 390 180 230
48 39 136.6 101.3 108.4 114.5 119.8 129.2 143 161.1 61.6 1564.64 11.4 289.56 390 180 230
54 42 147.9 109.7 117.4 125 129.7 139.9 154.9 174.5 77.0 1955.8 14.4 365.76 450 220 260
60 48 165 122.4 131 138.3 144.7 156.1 172.8 195 77.0 1955.8 14.4 365.76 450 220 260
72 57 199 147.7 158.1 166.9 174.6 188.4 209 235 92.4 2346.96 18.4 467.36 520 250 300
90 70 250 185.7 198.7 209.8 219.5 236.8 262 295 108 2743.2 43.3 1099.82 580 320 400
96 76 261.7 194.1 207.7 219.4 229.5 247.6 274.1 308.8 108 2743.2 43.3 1099.82 580 320 400
108 88 296 219.5 234.9 248.1 259.6 280 310 349.2 108 2743.2 43.3 1099.82 580 320 400
120 98 327.7 243 260.1 274.7 287.4 310 343.2 386.6 162 4114.8 56.1 1424.94 831 335 543
132 106 375.2 278.3 297.8 314.5 329.1 355 393 443 162 4114.8 56.1 1424.94 831 335 543
144 115 392 290.9 311.3 328.7 343.9 371 411 463 162 4114.8 56.1 1424.94 831 335 543
Tranquell™ Intermediate Arresters
Polymer High Voltage
Indoor and Outdoor Service
e
24-60 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Polymer Arresters (Intermediate Class)
for both Indoor and Outdoor Mounting (2.7-72 kVrms)
9L12PPMxxxS and 9L12PPTxxxS
Pressure Relief Capability: 16.1 kA rms Energy Handling Capability: 3.6kJ/kV mCOV
Cantilever Strength: 3,000 inch-pounds, rated ultimate cantilever moment Product Number (Gray Polymer)
Arrester Rating Maximum Continuous Voltage Eyebolt Terminal for Indoor or Indoor or cubicle
kVrms Capability (L-N) kVrms Outdoor Upright Mounting Terminal Mounting
2 2.2 9L12PPT002S 9L12PPM002S
3 2.55 9L12PPT003S 9L12PPM003S
4 3.7 9L12PPT004S 9L12PPM004S
5 4.2 9L12PPT005S 9L12PPM005S
6 5.1 9L12PPT006S 9L12PPM006S
7 6.1 9L12PPT007S 9L12PPM007S
8 6.9 9L12PPT008S 9L12PPM008S
9 7.65 9L12PPT009S 9L12PPM009S
10 8.4 9L12PPT010S 9L12PPM010S
12 10.2 9L12PPT012S 9L12PPM012S
15 12.7 9L12PPT015S 9L12PPM015S
18 15.3 9L12PPT018S 9L12PPM018S
21 17 9L12PPT021S 9L12PPM021S
24 19.5 9L12PPT024S 9L12PPM024S
27 22 9L12PPT027S 9L12PPM027S
30 24.4 9L12PPT030S 9L12PPM030S
36 29 9L12PPT036S 9L12PPM036S
39 31.5 9L12PPT039S –
45 36.5 9L12PPT045S –
48 39 9L12PPT048S –
54 42 9L12PPT054S –
60 48 9L12PPT060S –
72 57 9L12PPT072S –
Polymer Arresters (Intermediate Class)—Protective Characteristics 9L12PPTxxxS and 9L12PPMxxx2
Product Number Rating voltage mCOV kV 0.5 µsec 10 kA Switching Surge Maximum Discharge Voltage - kV crest
9L12PPTxxxs1 kV rms rms Max IR-kV crest Max IR-kV crest 1.5 kA 3 kA 5 kA 10 kA 20 kA 40 kA
9L12PPT002S 2.7 2.2 9.9 6.6 7.2 7.8 8.2 9.1 10.4 12.3
9L12PPT003S 3 2.55 9.9 6.6 7.2 7.8 8.2 9.1 10.4 12.3
9L12PPT004S 4.5 3.7 20 13.3 14.6 15.7 16.6 18.4 21 24.8
9L12PPT005S 5.1 4.2 20 13.3 14.6 15.7 16.6 18.4 21 24.8
9L12PPT006S 6 5.1 20 13.3 14.6 15.7 16.6 18.4 21 24.8
9L12PPT007S 7.5 6.1 26.8 17.8 19.5 21 22.2 24.5 28.1 33.2
9L12PPT008S 8.5 6.9 26.8 17.8 19.5 21 22.2 24.5 28.1 33.2
9L12PPT009S 9 7.65 26.8 17.8 19.5 21 22.2 24.5 28.1 33.2
9L12PPT010S 10 8.4 29.5 19.6 21.5 23.1 24.4 27 31 36.6
9L12PPT012S 12 10.2 35.5 23.6 25.9 27.9 29.4 32.5 37.3 44
9L12PPT015S 15 12.7 44.2 29.4 32.2 34.7 36.7 40.5 46.5 54.8
9L12PPT018S 18 15.3 53.4 35.5 38.9 41.9 44.3 48.9 56.1 66.2
9L12PPT021S 21 17 60.7 40.3 44.3 47.6 50.3 55.6 63.8 75.3
9L12PPT024S 24 19.5 70.9 47.1 51.7 55.6 58.7 64.9 74.4 87.9
9L12PPT027S 27 22 78.6 52.2 57.3 61.7 65.2 72 82.6 97.5
9L12PPT030S 30 24.4 88.5 58.7 64.5 69.4 73.3 81 92.9 110
9L12PPT036S 36 29 105 69.7 76.5 82.4 87 96.1 110 130
9L12PPT039S 39 31.5 115 76.5 84 90 95 105 120.5 142.5
9L12PPT045S 45 36.5 133.5 88.5 97.5 105 110.5 122 140 165.5
9L12PPT048S 48 39 142 94.5 103.5 111.5 118 130 149.5 176
9L12PPT054S 54 42 160.5 107 117 126 133 147 169 199
9L12PPT060S 60 48 175 116 127.5 137.5 145 160 183.5 217
9L12PPT072S 72 57 214 142.5 156 168 177.5 196 225 265.5
For weight, dimensional and other technical information, please visit the Arresters section of www.gedigitalenergy.com
19L12PPMxxxs, the electrical characteristics in this table are applicable to these product numbers. Contact factory for outline drawings.
Tranquell™ Intermediate Arresters
Polymer High Voltage
Indoor and Outdoor Service
BuyLog™ Catalog 24-61
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Dimensions and Mounting
Minimum Mounting
Product Ratings "X" Leakage Spacing on Center (In.) Net
Number Voltage kV rms MCOV Dimension (In.) Distance (In.) Ph-Ph Ph-Grd Weight (Lbs.)
9L12PPT002S 2.7 2.2 4.5 8 4.4 3.3 5.1
9L12PPT003S 2.7 2.55 4.5 8 4.4 3.3 5.1
9L12PPT004S 4.5 3.7 6.9 15.4 4.6 3.2 5.8
9L12PPT005S 5.1 4.2 6.9 15.4 4.6 3.2 5.8
9L12PPT006S 6 5.1 6.9 15.4 4.6 3.2 5.8
9L12PPT007S 7.5 6.1 6.9 15.4 4.7 3.3 5.8
9L12PPT008S 8.5 6.9 6.9 15.4 4.7 3.3 5.8
9L12PPT009S 9 7.65 6.9 15.4 4.7 3.3 5.8
9L12PPT010S 10 8.4 6.9 15.4 4.9 3.5 5.8
9L12PPT012S 12 10.2 6.9 15.4 4.9 3.5 5.8
9L12PPT015S 15 12.7 9.9 26 6.2 4.8 8.8
9L12PPT018S 18 15.3 9.9 26 6.6 5.2 8.8
9L12PPT021S 21 17.0 9.9 26 7.6 6.2 8.8
9L12PPT024S 24 19.5 12.2 30.8 7.6 6.2 9.1
9L12PPT027S 27 22.0 18.6 52 9.6 8.2 14.8
9L12PPT030S 30 24.4 18.6 52 9.8 8.4 14.8
9L12PPT036S 36 29.0 18.6 52 9.8 8.4 14.8
9L12PPT039S 39 31.5 18.6 52 12.8 11.4 14.8
9L12PPT045S 45 36.5 27.1 78 12.8 11.4 20.8
9L12PPT048S 48 39.0 27.1 78 12.8 11.4 20.8
9L12PPT054S 54 42.0 27.1 78.0 15.8 14.4 20.8
9L12PPT060S 60 48.0 27.1 78.0 15.8 14.4 20.8
9L12PPT072S 72 57.0 36 104 19.8 18.4 26.8
*9L12PPMxxxs, the electrical characteristics in this table are applicable to these catalog numbers.
Outline drawings are available from the factory.
Tranquell™ Intermediate Arresters
Polymer High Voltage
Indoor and Outdoor Service
e
24-62 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Tranquell™ Station and Intermediate Arresters
Outline Drawings
Fig. 1- Polymer Station Arrester –
9L11XPA/XPBxxxAS
3kV through 72kV
Fig. 4- Polymer Station Arrester –
9L11XPA/XPBxxxAS
168kV through 228kV
Fig. 3- Polymer Station Arrester –
9L11XPA/XPBxxxAS
120kV through 144kV
4 Hole NEMA Line
Terminal
Eyebolt Line
Terminal
Fig. 2- Polymer Station Arrester –
9L11XPA/XPBxxxAS
90kV through 108kV
BuyLog™ Catalog 24-63
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Discharge Counters, Insulating Bases and Brackets
Weight
Description lbs kgs Product Number
Discharge Counter 6.6 3.0 9L26FBE005E
Discharge Counter with
leakage current ammeter 7.7 3.5 9L26FBE012E
Description -3 included,
1 for each foot of the arrester
Insulating Base for Polymer
Intermediate arresters and 5 2.27 9L11LGW804S Porcelain Station arresters
3-48kV rated voltage
Insulating Base for
Polymer Station arrester 5 2.27 9L11LGW805S
Insulating Base for
Porcelain Station arrester 47 21.4 9L11LGW807AS
(54-360 kV rated voltage)
Insulating Base for
Porcelain EHV arresters (>360kV) 47 21.4 9L16AAW110S
Distribution, Intermediate and Station Arrester – Application
Arrester Rated Housing Arrester Max. Current for Energy
Voltage (kV rms) Type Type Energy Rating (Amps) (kJ/kV of MCOV)
3-36 kV Polymer
Heavy Duty
Distribution 450 1.8
3-36 kV Polymer Riser Pole 650 2.2
3.0 - 144 kV Polymer Intermediate 650 6
3.0 - 144 kV Polymer Station 1000 9
3.0 - 48 kV Porcelain Station 1000 9
54 - 360 kV Porcelain Station 1500 13
396 - 612 kV Porcelain Station 2400 17
Station and Intermediate Class Arresters
Accessories
Terminals and Mounting Brackets
The energy capability for GE Surge Arresters is defined based
upon Switching Surges, 2 milliseconds, transmission line discharges,
with multiple discharges over a one-minute period and with current amplitudes that are no greater than listed below. Based upon
this definition GE arresters have an energy capability as follows:
To provide assurance that all disks used in GE arresters have this
capability, we perform a Low Current Long Duration Strength Test
on 100% of our disks applying the above energies. We apply two
groups of three shots per group. Each shot is a square wave,
which is 2 milliseconds wide. We allow 15 to 20 seconds between
shots, three are applied within 60 seconds, and we allow the disk
to cool between the two groups of three shots. This is followed by
three shots of a half sine wave, which is 14 milliseconds wide with
15 to 20 seconds between shots. These tests weed out any weak
disks and provide assurance that the disks used in the final product are indeed capable of withstanding the energy claimed.
GE arresters exceed the requirements of Seismic Zone 2 and have
Cantilever Strengths and fault current capabilities as follows:
Details of Discharge Counter,
Models 9L26FBE005E and 9L26FBE012E (Dimensions in mm)
Distribution, Intermediate and Station Arrester – Application
Arrester Rated Ultimate Maximum Working Fault Current
Rated Voltage Housing Arrester Cantilever Strength Cantilever Strength Capability
(kV rms) Type Type in-lbs N-m in-lbs N-m (kA sym)
3 - 36 kV Polymer Normal Duty Distribution 1,500 169 600 68 10
3 - 36 kV Polymer Heavy Duty Distribution 3,000 339 1,200 136 20
3 - 36 kV Polymer Riser Pole 4,000 452 1,600 181 20
3.0 - 72 kV Polymer Intermediate 4,000 452 2,000 226 20
3.0 - 144 kV Polymer Intermediate 10,000 1,130 5,000 565 20
3.0 - 144 kV Polymer Station 20,000 2,260 10,000 1,130 80
3.0 - 48 kV Porcelain Station - Metal Top 70,000 7,909 28,000 3,163 65
54 - 360 kV Porcelain Station 150,000 16,947 60,000 6,779 93
396 - 612 kV Porcelain Station 200,000 22,596 80,000 9,038 65
e
24-64 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Distribution and Riser Pole Arresters
9L20 Polymer Distribution
9L27 Polymer Riser Pole
0-12,000 ft. Altitude
Product Description
The GE Tranquell
™ distribution and riser pole polymer line of
surge arrester products provide excellent protective characteristics,
temporary overvoltage capability, and switching surge energy
withstand to power systems of voltages less than 46 kV rms.
GE polymer arresters are ideally suited for application in both
indoor and outdoor situations. They are designed and manufactured
in accordance with the latest revision of ANSI/IEEE C62.11 and
IEC 99-4.
Tranquell™ distribution arrester,
rated 10 kV, with disconnector)
Application Guide – Nominal System Suggested Arrester Rating
4 Wire 3 Wire Delta or WYE1
Line-to-Line Multi-Grounded Low Impedance High Impedance
Voltage Neutral System Ground or Ungrounded
4160 3 6 6
4800 6 6 6
6640 6 6 9
7200 6 9 9
7620 6 9 9
8320 6 9 10
9960 9 9 12
11000 9 10 12
11500 9 10 15
12000 9 12 15
12470 9 12 15
13200 10 12 15
13800 10 12 18
14400 12 15 18
17250 15 15 21
19750 15 18 21
20780 15 18 24
22860 18 21 27
24940 18 24 30
26400 21 24 30
27700 21 27 30
34500 27 30 36
36200 27 36 –
3-36 kV rms Polymer Heavy Duty Distribution Arresters 9L20
Note: kV rating fills positions 9 and 10 (**) of product number
Product Insulating Bird X-Arm Xformer 18" Line Ground
Number Bracket Disconnect Cap Bracket Bracket Lead Strap 3kV 6kV 9kV 10kV 12kV 15kV 18kV 21kV 24kV 27kV 30kV 36kV
9L20AXX0**AHS X X X
9L20AXX4**AHS X X X X
9L20AXA4**AHS X X X X X
9L20AXA0**AHS X X X X
9L20AXX0**XHS X X
9L20AXX4**XHS X X X
9L20AXA4**XHS X X X X
9L20AXA0**XHS X X X
9L20AXX0**BHS X X X
9L20AXX4**BHS X X X X
9L20AHA4**BHS X X X X X X
9L20AHX4**BHS X X X X X
9L20AHX0**BHS X X X X
9L20AFA4**BHS X X X X X X
9L20AFX4**BHS X X X X X
9L20AFX0**BHS X X X X
9L20BXX0**XHS X
9L20FXX0**XHS
**Denotes voltage in kV. Example: 3kV = 03; 18kV = 18.
BuyLog™ Catalog 24-65
Capacitors, Arresters and Harmonic Filters
Rev. 11/13 Data subject to change without notice
Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTRIAL SOLUTIONS.
FOR ORDER PLACEMENT GO TO HTTPS://STORE.GEGRIDSOLUTIONS.COM/ ! FOR SUPPORT, CONTACT THE SALES CENTER AT 1-704-561-5751 / UTILITY.REQUESTS@GE.COM
Heavy Duty Distribution Arresters 9L20 – Protective Characteristics
Rating 0.5 µsec 10kA Switching
Voltage MCOV Max. IrR Surge 8/20 Maximum Discharge Voltage (kV) Crest
kV rms kV rms kV Crest Max IR-kVCrest 1.5kA 3kA 5kA 10kA 20kA 40kA
3 2.55 10.6 7.6 8 8.5 9 9.9 11.1 13.2
6 5.1 21.3 15.3 15.9 17 18 19.8 22.3 26.5
9 7.65 31.2 22.4 23.3 24.9 26.4 29 32.6 38.8
10 8.4 34 24.4 25.4 27.1 28.8 31.6 35.6 42.3
12 10.2 40.4 29 30.3 32.3 34.2 37.6 42.3 50.3
15 12.7 51.4 36.9 38.5 41.1 43.5 47.8 53.5 64
18 15.3 60.6 43.5 45.4 48.4 51.3 56.4 63.5 75.5
21 17 68.3 49 51.1 54.5 57.8 63.5 71.4 85.5
24 19.5 81.9 58.8 61.3 65.6 69.3 76.2 85.7 102
27 22 91.9 65.9 68.8 73.4 77.8 85.5 96.2 114.4
30 24.4 101.1 72.5 75.7 80.7 85.5 94 105.8 125.8
36 29 121.4 87 97.9 97 102.7 112.9 127 151.1
Distribution and Riser Pole Arresters
9L20 Polymer Distribution
9L27 Polymer Riser Pole
0-12,000 ft. Altitude
Heavy Duty Distribution Arresters 9L20 – Insulation and Physical Characteristics
Min Power Mounting
Rating Min 1.2 x 50µs Frequency (kV rms) Clearance "x" Center Line Center Line Weights
Voltage MCOV Creep Strike Withstand Dry Wet Overall Height to Center Line to Ground (unit only)
kV rms kV rms in mm in mm (kV Crest) (1 sec) (10 sec) in mm in mm in mm lbs kgs
3 2.55 8 203 4.9 124 50 35 25 6.8 173 4.8 122 3 76 2.6 1
6 5.1 15.4 391 4.9 124 75 45 35 7.62 194 5.0 127 3.4 86 2.6 1
9 7.65 15.4 391 4.9 124 75 45 35 8.72 221 5.6 142 4 102 2.6 1
10 8.4 15.4 391 4.9 124 75 45 35 8.72 221 5.8 147 4.2 107 2.6 1
12 10.2 15.4 391 6.5 165 125 65 45 9.3 236 7.5 191 5.5 140 5.6 3
15 12.7 26 660 6.5 165 125 65 45 11.62 295 8.5 216 6.5 165 5.6 3
18 15.3 26 660 6.5 165 125 65 45 11.62 295 9.5 241 7.5 191 5.6 3
21 17 26 660 6.5 165 125 65 45 12.42 315 10.0 254 8 203 5.6 3
24 19.5 30.8 782 10 254 160 90 65 15.32 389 12.0 305 10 254 8.9 4
27 22 52 1321 10 254 160 90 65 16.42 417 13.0 330 11 279 8.9 4
30 24.4 52 1321 10 254 160 90 65 19.92 506 13.6 345 12 305 8.9 4
36 29 52 1321 14 356 160 90 65 19.32 491 16.2 411 14.5 368 12.2 6
3-36kV rms 9L27 Polymer Riser Pole Arresters
Product Insulating Bird X-Arm
Number Bracket Disconnect Cap Bracket 3 kV 6 kV 9 kV 10 kV 12 kV 15 kV 18 kV 21 kV 24 kV 27 kV 30 kV 36 kV
9L27HXX4**XHS X X X
9L27HXX4**AHS X X X X
**Denotes voltage in kV. Example: 3kV = 03; 18kV = 18.
Insulating Bracket w/ Bird Cap & Disconnect Insulating Bracket / Cross-arm Bracket w/ Bird Cap & Disconnect
e
24-66 BuyLog™ Catalog
Capacitors, Arresters and Harmonic Filters Section 24
EFFECTIVE 07/2018 – Price and Availability
AS A RESULT OF ABB’S ACQUISITION OF GE INDUSTRIAL SOLUTIONS, THIS PRODUCT IS NO LONGER SOLD THROUGH INDUSTR
xs130bIna12c
DC12-24V 100mA
感应距离 10mm常开点
4个。电感式接近传感器
xs130bIna12c
DC12-24V 100mA
感应距离 10mm常开点
9L11XPA010AS
GE Station Class Arrester, Polymer, 10 kVrms, 4 Hole
4个。电感式接近传感器
xs130bIna12c
DC12-24V 100mA
感应距离 10mm常开点
4个。
Steam Valve IPMA:755407 2 pcs
Cordless impact wrench IPMA:590922 1 pcs
Cordless impact wrench IPMA:590926 1 pcs
Putty knives IPMA:613671 20 pcs
Putty knives IPMA:613673 20 pcs
Disposable gloves IMPA:190135, size:XL;plastic 100pairs/pkt 30 pkt
Disposable gloves MPA:190135,size:XXL;plastic 100pairs/pkt 30 pkt
Paper tapes,double side gummed IMPA:471266 20 roles
Paper tapes,double side gummed IMPA:471268 20 roles
copper&brass tube cutters IMPA:612035 5 pcs
copper&brass tube cutters IMPA:612036 5 pcs
copper&brass tube cutters IMPA:612037 5 pcs
Blade for copper&brass tube cutters IMPA:612045 30 pcs
Blade for copper&brass tube cutters IMPA:612046 30 pcs
Blade for copper&brass tube cutters IMPA:612047 30 pcs
screw driver sets PICTURE ATTACHED 10 sets
mop complete with spring clamp handle IMPA:174275 15 pcs
spring clamp mop head only IMPA:174277 20 pcs
broom IMPA:510802 20 pcs
straight pipe wrenches IMPA:616531 4 pcs
Part Name ITEM DESCRIPTION/Makers Ref
stainless steel pipe clamp size:8-14mm;IMPA:614065
stainless steel pipe clamp size:11-17mm;IMPA:614066
stainless steel pipe clamp size:13-20mm;IMPA:614067
stainless steel pipe clamp size:15-24mm;IPMA:614068
stainless steel pipe clamp size:22-32mm;IPMA:614069
stainless steel pipe clamp size:32-44mm;IPMA:614070
stainless steel pipe clamp size:46-56mm;IPMA:614071
stainless steel pipe clamp size:58-75mm;IPMA:614072
stainless steel pipe clamp size:87-112mm;IPMA:614075
stainless steel pipe clamp size:200-220mm
stainless steel pipe clamp 300-320mm
Steam Valve IPMA:755402
Steam Valve IPMA:755407
Cordless impact wrench IPMA:590922
Cordless impact wrench IPMA:590926
Putty knives IPMA:613671
Putty knives IPMA:613673
Disposable gloves IMPA:190135, size:XL;plastic 100pairs/pkt
Disposable gloves MPA:190135,size:XXL;plastic 100pairs/pkt
Paper tapes,double side gummed IMPA:471266
Paper tapes,double side gummed IMPA:471268
copper&brass tube cutters IMPA:612035
copper&brass tube cutters IMPA:612036
copper&brass tube cutters IMPA:612037
Blade for copper&brass tube cutters IMPA:612045
Blade for copper&brass tube cutters IMPA:612046
Blade for copper&brass tube cutters IMPA:612047
screw driver sets PICTURE ATTACHED
mop complete with spring clamp handle IMPA:174275
spring clamp mop head only IMPA:174277
broom IMPA:510802
straight pipe wrenches IMPA:616531
straight pipe wrenches IMPA:616533
straight pipe wrenches IMPA:616535
copper s small end diameter:11mm;big end diameter:15mm;length:30mm
copper s small end diameter:12mm;big end diameter:18mm;length:40mm
rubber for making gasket thickness:5mm;length10m;width:2m
welding rods stainless steel 1.6mm
welding rods stainless steel 2.5mm
trolley for A40/0-40 cylinders unitor production No,176176016
arc welding potable machines type:UWI-200;unitor production No.191670455
VACUUM CUPS PICTURE ATTACHED
HEAD LAMP PICTURE ATTACHED
ear PICTURE ATTACHED
2114559-21 10
2160200-9 1
2347614 1
Outboard water pump for cooling main engine No. 1
IRON Type CNLB 125-125/315, Series 2634/1, YEAR 1998
Catalog Iron pump /Iron pump instruction manual
coupling flexibles pos 867
Shaft seal ring pos 420
Thrower pos 507
Mechanical seal pos 433
O-Ring for pump casing pos 412
Casing wear ring pos 502.1
Casing wear ring pos 502.2
Impeller screw pos 906
Fresh water pump NTK cooling DG
IRON Type CNLB 125-125/315, Series 2633/2.
Catalog Iron pump /Iron pump instruction manual
coupling flexibles pos 867
Shaft seal ring pos 420
Thrower pos 507
Mechanical seal pos 433
O-Ring for pump casing pos 412
Casing wear ring pos 502.1
Casing wear ring pos 502.2
Impeller screw pos 906
Impeller pos 230
Fresh water pump NTK circulating No. 1,2
IRON Type CNLB 200-200/315, Series 44784/1
Catalog Iron pump /Iron pump instruction manual
coupling flexibles pos 867
Shaft seal ring pos 420
Thrower pos 507
Mechanical seal pos 433
O-Ring for pump casing pos 412
Casing wear ring pos 502.1
Casing wear ring pos 502.2
Impeller screw pos 906
Fire pump No. 1
IRON Type CNLB 80-65/200
Catalog Iron pump /Iron pump instruction manual
coupling flexibles pos
Impeller screw pos 906
Fire pump No. 2
IRON Type CNLB 100-100/250, Series 3059348
Catalog Iron pump /Iron pump instruction manual
coupling flexibles pos 867
Shaft seal ring pos 420
Thrower pos 507
Casing wear ring pos 502.1
Casing wear ring pos 502.2
Impeller screw pos 906
Impeller pos 230
Drainage pump No. 1
IRON Type CNLBEA 150-125/250
Catalog Iron pump /Iron pump instruction manual
coupling flexibles pos 867
Shaft seal ring pos 420
Thrower pos 507
Mechanical seal pos 433
O-Ring for pump casing pos 412
Casing wear ring pos 502.1
Casing wear ring pos 502.2
Impeller screw pos 906
General purpose bilge pump No. 1
IRON Type CNLB 100-80/250
Catalog Iron pump /Iron pump instruction manual
coupling flexibles pos 867
Shaft seal ring pos 420 Advanced Energy 660-024637-026 RFDS Generator M/N:3155059-026G
Thrower pos 507
Mechanical seal pos 433 NYP2A-20460-12WC1000
O-Ring for pump casing pos 412
Casing wear ring pos 502.1
Casing wear ring pos 502.2
KLA-TENCOR
RS75的ceramic pad KT 的PN：28-0079
RS35/55/75
GE298А530Р7 2
(GE277F1802P1 Advanced Energy 660-024637-026 RFDS Generator M/N:3155059-026G
GE277A1801P1 Asentria
Sentria Siteboss S571-2/32M/DC
SMO 1558002 scott 系列4600mb, 型号 4651-1C-3-5-2-1
H3533A001 2
GE158А6151Р1 2
GE235А9677Р1 HIGH TEMP CABLE ASSEMBLY FOR MODEL 5485C
METRIX MODEL 4850-020
GE 329A3529P057
GE248A4441P4 2
GE277A2918P1 2
GE114A8218P6 1FK7042-2AF71-1RG0-Z SIEMENS 1
6SL3224-0BE21-5UA0 SIEMENS 1
1FK7100-2AF71-1BG0 SIEMENS 1
1LA7060-4AB11-ZD22+D 47 SIEMENS 1
6SL3224-0BE35-5AA0 SIEMENS 1
GE114A8275P3 2
GE917B496P16 2
BG00222262
BG00298030
BG00298087
BG00221310
70880244
80046049
77007515
73702847
76350015
79510274
70460803
76315057
76314029
78402024
70595129
79560038
88065959
77015441
BG00334337
GE114A8218P6 2
Impeller screw pos 906
Circulation pump for hot water boiler No. 1,2
IRON Type CHVM 40/170
Catalog Iron pump /Iron pump instruction manual
Mechanical seal pos 23
Fuel supply pump GD No. 1,2
IMO Type ACE 032N1 IVBP, Series 476786
Series pump instruction ACE/Pamp series ACE
instruction ( september 1997), Spare parts, page 2-3.
1.Minor kit pos (G053) part № 189192
MANUFACTURER NAME : TECHNOR
MANUFACTURER PART NUMBER : ZBWE101
MANUFACTURER PART NUMBER : B130700036
END ITEM NAME : SWITCHGEAR & CONTROLGEAR
ORDERING CODE : B1307.000369
2.Rotor set CW pos (G012) part № 100420
Lubricating oil pump GD standby
IMO Type ACF 110N4 1RBP, Series 475732
Series pump instruction ACF/Pamp series ACF
instruction ( April 2007 ), Spare parts, page 40-43.
1.Minor kit pos (G053) part № 191599
Oil priming pump GD
IMO Type ACG 052N6 1VBO, Series 476649
Series pump instruction ACG/Pamp series ACG instruction ( october 1997), Spare parts, page 2-3.
1.Minor kit pos (G053) part № 189198
Emergency fire pump
DESMI Type S80-70-220N/D07 № 381179-01-01, year 2013
Catalog DESMI spare parts list
1./SEAL RING ?100x12 ALBZ pos 4 №516042
2. SHAFT SEAL DS/?25-S50-BVPGG pos 10 №712094
3. V-RING 25S NITRIL pos 11 №704031
4. O-RING ?247.25x3.53 NITRIL pos 29 №710405
Gearbox pre-lube pump
TYRONE TP20.400-300C-1D
NO DATA !
Bilge separator pump
ROTOFLOW RDCZ511-R2CD1D, serial № Н-1001Х
NO DATA !
Oil separator pump
IMO Type ACP 032L1 NVBP, Series 478803
Series pump instruction ACР/Pamp series ACР
instruction ( october 1997), Spare parts, page 2-3.
1.Minor kit pos (G053)
Fuel separator pump
IMO Type ACP 032N3 NVBP
Series pump instruction ACР/Pamp series ACР
instruction ( october 1997), Spare parts, page 2-3.
1.Minor kit pos (G053)
Leak fuel pump NO DATA !
Water heater pump GD Grundfoss
Type TP-40-120/2-A-F-A-BUBE, Series 96405047P19731
Pump instruction Grundfos Lenntech part list TP 40-120/2
1. Shaft seal pos 105
2. O-ring pos 72а
Fuel transfer pump No. 1,2
IMO Type ACG 06O N5IVBP Series 420313,420314
Инструкция насосов серии ACG/Pamp series ACG
instruction ( octoder 1997 ), Spare parts, page 2-3.
1.Minor kit pos (G053) part № 189200
Incinerator Flue Gas Fan
Team Tec Instruction Manual Project: 2512 (10.03.99)
Flue Gas FAN Assembly PN 300 HzF, Drawings 1006062
Article no.6937
Seals, double Up - SKF TSNA 511G - Art № 5130
Circulating slurry pump
Team Tec Instruction Manual Project: 2512 (10.03.99) page122
Sludge circ.pump(Type Vercus VERCUR SN10075 Incinerator OG200C стр№122)
1)Pos 2 O-Ring R4500 Art.№2986
2)Pos 6-V-seal V-35-S Art.№ 2996
3)Pos 7- Mechanical seal,d-28,SIC Art.№ 9231
Slurry dosing pump
Team Tec Instruction Manual Project: 2512 (10.03.99) page 114
Sludge Dosage Pump incinirator /Sludge tk. type PCM 110 F4 Series 229676-18
Pos.6 Rubber coupingArt.№ 6764
Pos.20 Mechanical seal Art. №6571
Pos.15 O-Ring Art.№ 6772
Pos.17 Gasket Art.№ 6774
Pos.9 V-Ring Art.№ 6767
Pos.19 O-Ring Art.№ 6777
Fuel pump of stabilization tank
Fuel pump stab tank DESMI S100-80-275/A02 ,Series183852,1999 год
Catalog DESMI Modular S-N Revision:С(04/13)
1. SEAL RING pos 4
2. SHAFT SEAL pos 10
3. V-RING pos 11
4. O-RING pos 29
5. Bearing pos 13
6. Bearing pos 15
Steering Gear Pump #1,2
TENFJORD Type 2GM 620
Instruction Rolls-Royce TENFJORD Steering Gear
1. Oil seal ANGUS SMIM 30x47x10 pos GM6-01
2. Oil seal ANGUS SMIM 30x47x10 pos GM6-03
3. O-RING RM0645-30 pos GM6-05
4. Cooper ring pos GM6-07
5. Ball bearing SKF 6006 pos GM6-09
6. Cooper ring pos GM6-10
7. Bearing INA NK 3030 pos GM6-12
8. Bearing INA NK 3030 pos GM6-15
9. O-RING RM0645-30 pos GM6-34
10. Segment. sett pos GM- 29
Fresh water cooling pump for oil coolers of refrigerator compressors.
DESMI S70-50-175N/A02 , Pump №440089-01-6
Catalog DESMI Modular S-N Revision:С(04/13)
1. SEAL RING pos 4
2. SHAFT SEAL pos 10
3. V-RING pos 11
4. O-RING pos 29
5. Bearing pos 13
6.Bearing pos 15
Lubricating oil pump for refrigerant compressors No. 3,4
Rotan Pump GP 51 EM 1U3B1S № 228496
Manual Henry Soby SR128 Draw.№. K6641
1. Gasket B page T1026
2. Gasket C page T1026
3. Locking ring CC page T1026
4. Ball bearing 6307-2RS1 BC page T1026
Freon condenser cooling pump
BEVI CNLS 100-100/315 №1,2
No instructions for the pump.
BG00222262
BG00298030
BG00298087
BG00221310
70880244
80046049
77007515
73702847
76350015
79510274
70460803
76315057
76314029
78402024
70595129
79560038
88065959
77015441
BG00334337
"Sealing Set For LPU-D-V2a
Part No. 160G4281
Weight: 40g
HS Code: 84812010" 160G4281 2
Exworks
Liverpool"
"Set Of Seals For LPUM-D
Part No. 160G4276
Weight: 44g
HS Code: 84812010" 160G4276 2
Exworks
Liverpool"
"Set Of Seals For BRC 2000 B1
Part No. 160N1263
Weight: 76g
HS Code: 84129040" 160N1263 2
Exworks
Liverpool"
"Set Of Seals For BRC 500 B1
Part No. 160N1261
Weight: 54g
HS Code: 84129040" 160N1261 2
Exworks
Liverpool"
"Set Of Seals For BRC 1000 B1
Part No. 160N1262
Weight: 64g
HS Code: 84129040" 160N1262 2
Exworks
Liverpool"
"Set Of Seals For BRC 125 B1
Part No. 160N1259
Weight: 22g
HS Code: 84129040" 160N1259 2
Exworks
Liverpool"
MANUFACTURER NAME : TECHNOR
MANUFACTURER PART NUMBER : ZBWE101
MANUFACTURER PART NUMBER : B130700036
END ITEM NAME : SWITCHGEAR & CONTROLGEAR
ORDERING CODE : B1307.000369
445W5757P001
4
WHIT-900781
PLATE,RETAINER,PIN,WRSIT,WHITE SUPERIOR,900781
EACH
2
6
WHIT-900932
PIN,WRIST,WHITE SUPERIOR,900932
EACH
2
8
WHIT-901244
SHAFT,DRIVE,WHITE SUPERIOR,901244
EACH
1
9
WHIT-900838018
O-RING,VITON,WHITE SUPERIOR,900838018
AMAT / APPLIED MATERIALS DPS G5 Mesa Etcher
WHIT-900791
WASHER,WHITE SUPERIOR,900791
COOK-SMPV31
DISC,VALVE,POPPET,COOK COMPRESSION,SMPV31
Line
Item
Item Description
UOM
Quantity
4
WHIT-900781
PLATE,RETAINER,PIN,WRSIT,WHITE SUPERIOR,900781
EACH
2
6
WHIT-900932
PIN,WRIST,WHITE SUPERIOR,900932
EACH
2
8
WHIT-901244
SHAFT,DRIVE,WHITE SUPERIOR,901244
EACH
1
9
WHIT-900838018
O-RING,VITON,WHITE SUPERIOR,900838018
EACH
12
5
WHIT-900791
WASHER,WHITE SUPERIOR,900791
DSF 221 SHV Ex-atex
COOK-SMPV31
DISC,VALVE,POPPET,COOK COMPRESSION,SMPV31
DSF 221 SHV Ex-atex
COOK-Z01S188
SPRING,VALVE,#8,CHROME SILICON,COOK COMPRESSION,Z01S188
DSF 221 SHV Ex-atex
1MRK000005-492
1MRK000154-Fbr00
1MRK000157-GA
1MRK167-HB
1MRK000173-Bcr00
1MRK000179-DAr00
1MRK000195-AAr02
1MRK000284-ABr00
1MRK000446-AR
1MRK000508-BBr00
1MRK000614-ABR00
1MRK001162-CAr02
1MRK001434-KAr01
1MRK001434-KAr00
1MRK001434-LAr01
1MRK001434-NAr00
1MRK001506-CB
1MRK001987-AA
1MRK002122-ABr00
1MRK002133-ABR03
1MRK002239-BBr01
3HAB2211-1/1 DSQC256A
3HAB2214-1/2 DSQC315
3HAB2215-1 DSQC314A
3HAB2216-1 DSQC314B
SLO-SYN B84580806 X250-1024U
SLO-SYN B84580806 X250-1024U
SLO-SYN B84580806 X250-1024U
855017P0286
855017P0286
2657170730
95934550
95922894
95937413
2657608960
2656996499
95245049
95368536
50625938
95934816
2657433781
2658339281
2657194987
95934857
2695934766
2695301834
57762619
2652246154
2650463645
2652230828
57423782
95316972
95279089
Grundfos MS 6000I motor wear parts kit (product no.:96164191) 96164191 96164191
Bearing set for Grundfos MS 4000I 5.5 kW motor (product no.:96558322) 96558322 96558322
O-ring kit for Grundfos MS 4000I motor (product no.:96558323) 96558323 96558323
Thrust bearing set for Grundfos MS 4000I 5.5 kW motor (product no.:96558249) 96558249 96558249
Motor ADOR 90-4/75 400V, 1.5 kW, 3.6A, 1400 rpm, IP67 ADOR 90-4/75
Motor AF132S/4A-11 5.5 kW 440 V AF132S/4A-11
Baumuller RE22P2DK 31.1R electric motor 1.25 kW 440 V 2620 rpm RE22P2DK 31.1R
Flender M160L4X electric motor 15 kW, 1455 rpm, 380V M160L4X
Electric motor G90F/4D90SB4, 1.5kW, 1700 rpm, 420V, 1 shaft end G90F/4D90SB4
Electric motor GEAR-MOTORBREVINI MOT.3-KW 30.4P 200LTFECCL IP55 I.CI.F B85V.400/690 Hz 50 TipoalimentazionneFreno.FRENO V400 CA 200LTFECCL
Electric motor HK33/1M-Z5.2 0.8 kW, 380V, 1340 rpm, flanged, 1 shaft end HK33/1M-Z5.2
Electric motor HK43/1M-H0,9 1,5 kW, 380V, 1395 rpm, flanged, 1 shaft end HK43/1M-H0,9
Jost JV246-950 electric motor 3 kW, 975 rpm JV246-950
Loher BNGA-280-SG-04A electric motor 75 kW, 1470 rpm BNGA-280-SG-04A
Electric motor MP44 Z12.3/870TK 2,2 kW, 360/420V, 1450 rpm, flanged, 1 shaft end MP44 Z12.3/870TK
RACO T6Q6 electric motor 0.75 kW, 380V, 1490 rpm, flanged, 1 shaft end T6Q6
Sew DV100L4TF electric motor 3 kW, 1400 rpm DV100L4TF
Sew DV100M4TF electric motor 2.2 kW, 1410 rpm DV100M4TF
Sew DV160M4TF electric motor 11 kW, 1440 rpm DV160M4TF
Sew DV225M4TF electric motor 45 kW, 1470 rpm DV225M4TF
Sew-Eurodrive electric motor type DT90L4/HR 1.5 kW, 380V, 3.7A, 1410 rpm DT90L4/HR
Sew-Eurodrive electric motor type DV132S4/TF 5.5 kW, 380V, 11.4A, 1430 rpm DV132S4/TF
Sew-Eurodrive electric motor type DV160M4/RS 11 kW, 380V, 22.5A, 1440 rpm DV160M4/RS
Sew-Eurodrive electric motor type DV180L4/RS/TF 22 kW, 380V, 46A, 1465 rpm DV180L4/RS/TF
Sew-Eurodrive electric motor type DV225S4/RS 37 kW, 380V, 70A, 1470 rpm DV225S4/RS
Sew-Eurodrive electric motor type DV280S4/TF 75 kW, 380V, 142A, 1480 rpm DV280S4/TF
Electric motor SIEMENS 1LA 7166-4AA64, 15 kW, 380V, 1500 rpm, flanged version, one end shaft. 1LA 7166-4AA64
Siemens electric motor 1LA7107-4AA11 3 kW, 1420 rpm 1LA7107-4AA11
Siemens electric motor 1LA7164-6AA61 960 rpm, 11 kW 1LA7164-6AA61
Siemens electric motor 1LA7166-6AA90 960 rpm, 11 kW 1LA7166-6AA90
Siemens 1LG4183-2AA60Z electric motor 22 kW, 2945 rpm 1LG4183-2AA60-Z
Siemens 1LG4206-2AA60Z electric motor 30 kW, 2945 rpm 1LG4206-2AA60-Z
Electric motor VEM B21R 160 L6 LEN HL KR TWS HW BP 11kW, 400B, 965 rpm, with brake BFK 458-18E B21R 160 L6
Electric motor ZM 505 3 0,25 kW, 380V, 685 rpm, flanged, 1 shaft end ZM 505 3
Electric motor K22R355M10LL 135kW 595rpm IM1004 K22R355M10LL
Siemens electric motor 1LE1601-3AD23-3AB4-Z 75kW 800 rpm 1LE1601-3AD23-3AB4-Z
95219713
2652192556
95928982
57266181
Drive mechanism for disconnector, 110VDC Siemens
Grundfos MS 6000I motor wear parts kit (product no.:96164191) 96164191 96164191
Bearing set for Grundfos MS 4000I 5.5 kW motor (product no.:96558322) 96558322 96558322
O-ring kit for Grundfos MS 4000I motor (product no.:96558323) 96558323 96558323
Thrust bearing set for Grundfos MS 4000I 5.5 kW motor (product no.:96558249) 96558249 96558249
Motor ADOR 90-4/75 400V, 1.5 kW, 3.6A, 1400 rpm, IP67 ADOR 90-4/75
Motor AF132S/4A-11 5.5 kW 440 V AF132S/4A-11
Baumuller RE22P2DK 31.1R electric motor 1.25 kW 440 V 2620 rpm RE22P2DK 31.1R
Flender M160L4X electric motor 15 kW, 1455 rpm, 380V M160L4X
Electric motor G90F/4D90SB4, 1.5kW, 1700 rpm, 420V, 1 shaft end G90F/4D90SB4
Electric motor GEAR-MOTORBREVINI MOT.3-KW 30.4P 200LTFECCL IP55 I.CI.F B85V.400/690 Hz 50 TipoalimentazionneFreno.FRENO V400 CA 200LTFECCL
Electric motor HK33/1M-Z5.2 0.8 kW, 380V, 1340 rpm, flanged, 1 shaft end HK33/1M-Z5.2
Electric motor HK43/1M-H0,9 1,5 kW, 380V, 1395 rpm, flanged, 1 shaft end HK43/1M-H0,9
Jost JV246-950 electric motor 3 kW, 975 rpm JV246-950
Loher BNGA-280-SG-04A electric motor 75 kW, 1470 rpm BNGA-280-SG-04A
Electric motor MP44 Z12.3/870TK 2,2 kW, 360/420V, 1450 rpm, flanged, 1 shaft end MP44 Z12.3/870TK
RACO T6Q6 electric motor 0.75 kW, 380V, 1490 rpm, flanged, 1 shaft end T6Q6
Sew DV100L4TF electric motor 3 kW, 1400 rpm DV100L4TF
Sew DV100M4TF electric motor 2.2 kW, 1410 rpm DV100M4TF
Sew DV160M4TF electric motor 11 kW, 1440 rpm DV160M4TF
Sew DV225M4TF electric motor 45 kW, 1470 rpm DV225M4TF
Sew-Eurodrive electric motor type DT90L4/HR 1.5 kW, 380V, 3.7A, 1410 rpm DT90L4/HR
Sew-Eurodrive electric motor type DV132S4/TF 5.5 kW, 380V, 11.4A, 1430 rpm DV132S4/TF
Sew-Eurodrive electric motor type DV160M4/RS 11 kW, 380V, 22.5A, 1440 rpm DV160M4/RS
Sew-Eurodrive electric motor type DV180L4/RS/TF 22 kW, 380V, 46A, 1465 rpm DV180L4/RS/TF
Sew-Eurodrive electric motor type DV225S4/RS 37 kW, 380V, 70A, 1470 rpm DV225S4/RS
Sew-Eurodrive electric motor type DV280S4/TF 75 kW, 380V, 142A, 1480 rpm DV280S4/TF
Electric motor SIEMENS 1LA 7166-4AA64, 15 kW, 380V, 1500 rpm, flanged version, one end shaft. 1LA 7166-4AA64
Siemens electric motor 1LA7107-4AA11 3 kW, 1420 rpm 1LA7107-4AA11
Siemens electric motor 1LA7164-6AA61 960 rpm, 11 kW 1LA7164-6AA61
Siemens electric motor 1LA7166-6AA90 960 rpm, 11 kW 1LA7166-6AA90
Siemens 1LG4183-2AA60Z electric motor 22 kW, 2945 rpm 1LG4183-2AA60-Z
Siemens 1LG4206-2AA60Z electric motor 30 kW, 2945 rpm 1LG4206-2AA60-Z
Electric motor VEM B21R 160 L6 LEN HL KR TWS HW BP 11kW, 400B, 965 rpm, with brake BFK 458-18E B21R 160 L6
Electric motor ZM 505 3 0,25 kW, 380V, 685 rpm, flanged, 1 shaft end ZM 505 3
Electric motor K22R355M10LL 135kW 595rpm IM1004 K22R355M10LL
Siemens electric motor 1LE1601-3AD23-3AB4-Z 75kW 800 rpm 1LE1601-3AD23-3AB4-Z
Transmitter 8-100-3000P814-20m4 D010-307接口: 内纹1/2 NPT 两线
Grundfos MS 6000I motor wear parts kit (product no.:96164191) 96164191 96164191
Bearing set for Grundfos MS 4000I 5.5 kW motor (product no.:96558322) 96558322 96558322
O-ring kit for Grundfos MS 4000I motor (product no.:96558323) 96558323 96558323
Thrust bearing set for Grundfos MS 4000I 5.5 kW motor (product no.:96558249) 96558249 96558249
Motor ADOR 90-4/75 400V, 1.5 kW, 3.6A, 1400 rpm, IP67 ADOR 90-4/75
Motor AF132S/4A-11 5.5 kW 440 V AF132S/4A-11
Baumuller RE22P2DK 31.1R electric motor 1.25 kW 440 V 2620 rpm RE22P2DK 31.1R
Flender M160L4X electric motor 15 kW, 1455 rpm, 380V M160L4X
Electric motor G90F/4D90SB4, 1.5kW, 1700 rpm, 420V, 1 shaft end G90F/4D90SB4
Electric motor GEAR-MOTORBREVINI MOT.3-KW 30.4P 200LTFECCL IP55 I.CI.F B85V.400/690 Hz 50 TipoalimentazionneFreno.FRENO V400 CA 200LTFECCL
Electric motor HK33/1M-Z5.2 0.8 kW, 380V, 1340 rpm, flanged, 1 shaft end HK33/1M-Z5.2
Electric motor HK43/1M-H0,9 1,5 kW, 380V, 1395 rpm, flanged, 1 shaft end HK43/1M-H0,9
Jost JV246-950 electric motor 3 kW, 975 rpm JV246-950
Loher BNGA-280-SG-04A electric motor 75 kW, 1470 rpm BNGA-280-SG-04A
Electric motor MP44 Z12.3/870TK 2,2 kW, 360/420V, 1450 rpm, flanged, 1 shaft end MP44 Z12.3/870TK
RACO T6Q6 electric motor 0.75 kW, 380V, 1490 rpm, flanged, 1 shaft end T6Q6
Sew DV100L4TF electric motor 3 kW, 1400 rpm DV100L4TF
Sew DV100M4TF electric motor 2.2 kW, 1410 rpm DV100M4TF
Sew DV160M4TF electric motor 11 kW, 1440 rpm DV160M4TF
Sew DV225M4TF electric motor 45 kW, 1470 rpm DV225M4TF
Sew-Eurodrive electric motor type DT90L4/HR 1.5 kW, 380V, 3.7A, 1410 rpm DT90L4/HR
Sew-Eurodrive electric motor type DV132S4/TF 5.5 kW, 380V, 11.4A, 1430 rpm DV132S4/TF
Sew-Eurodrive electric motor type DV160M4/RS 11 kW, 380V, 22.5A, 1440 rpm DV160M4/RS
Sew-Eurodrive electric motor type DV180L4/RS/TF 22 kW, 380V, 46A, 1465 rpm DV180L4/RS/TF
Sew-Eurodrive electric motor type DV225S4/RS 37 kW, 380V, 70A, 1470 rpm DV225S4/RS
Sew-Eurodrive electric motor type DV280S4/TF 75 kW, 380V, 142A, 1480 rpm DV280S4/TF
Electric motor SIEMENS 1LA 7166-4AA64, 15 kW, 380V, 1500 rpm, flanged version, one end shaft. 1LA 7166-4AA64
Siemens electric motor 1LA7107-4AA11 3 kW, 1420 rpm 1LA7107-4AA11
Siemens electric motor 1LA7164-6AA61 960 rpm, 11 kW 1LA7164-6AA61
Siemens electric motor 1LA7166-6AA90 960 rpm, 11 kW 1LA7166-6AA90
Siemens 1LG4183-2AA60Z electric motor 22 kW, 2945 rpm 1LG4183-2AA60-Z
Siemens 1LG4206-2AA60Z electric motor 30 kW, 2945 rpm 1LG4206-2AA60-Z
Electric motor VEM B21R 160 L6 LEN HL KR TWS HW BP 11kW, 400B, 965 rpm, with brake BFK 458-18E B21R 160 L6
Electric motor ZM 505 3 0,25 kW, 380V, 685 rpm, flanged, 1 shaft end ZM 505 3
Electric motor K22R355M10LL 135kW 595rpm IM1004 K22R355M10LL
Siemens electric motor 1LE1601-3AD23-3AB4-Z 75kW 800 rpm 1LE1601-3AD23-3AB4-Z
Transmitter 8-100-3000P814-20m4 D010-307接口: 内纹1/2 NPT 两线
CE07 Siemens 8WL4600-1
CE09 Siemens 8WL4517-1M
CE14 Siemens 8WL1580-2
Advanced Energy 660-024637-026 RFDS Generator M/N:3155059-026G
CM07 Siemens 8WL1524-1
CM09 Siemens 8WL2142-8
CM23 Siemens 8WL1203-0
CM33 Siemens 8WL6225-0
Contact wire stringing grips Siemens 8WL7140-0
ED20 Siemens 8WL6538-1
ED21 Siemens 8WL6541-4
Electric control unit for disconnector, 110VDC(ED10) Siemens 8WL6256-7E
Electric operated mechanism 110VDC(ED10) Siemens 8WL6254-3A
FC06 Siemens 8WL2116-6B
FC21 Siemens 8WL2036-3A
Insulating rod for section insulator 3 kV Siemens 8WL5548-0C
2695245221
56275431
52192564
95922183
95096350
50623065
95245049
DET-TRONICS" ULTRAVIOLET FLAME DETECTOR
REF. DET-TRONICS
TYPE X2200-S-4M-23-W1, MAT. SS316,
4 PORT M25,OUT:4-20 MA
2657170730
95934550
95922894
95937413
2657608960
2656996499
95245049
95368536
50625938
95934816
2657433781
2658339281
2657194987
95934857
2695934766
2695301834
57762619
2652246154
2650463645
2652230828
57423782
95316972
95279089
95219713
2652192556
95928982
57266181
2695245221
56275431
52192564
95922183
95096350
50623065
95245049
3HAB2236-1 DAQC321
1MEK002238-CA
3144P "Temperature Transmitter 3144P with sensor 214C
and Thermowell 114C according to attached datasheet and drawing" ROSEMOUNT
1LA91642KA90-ZN02 Siemens
ABM G71F\4D71B-4 0,37кВт 125rpm ABM
OiltechSLH 80 4B2 0,75kw Oiltech
WEG 250S/M4 55кВт 1440rpm WEG
WEG112-M4 4kW 1475rpm WEG
1LA91642KA90-ZN02 Siemens
ABM G71F\4D71B-4 0,37кВт 125rpm ABM
OiltechSLH 80 4B2 0,75kw Oiltech
WEG 250S/M4 55кВт 1440rpm WEG GE 902464107 DETECTOR,LEAK,INSTRUMENT,GASO TO 2000CI2,CO,CO2,H2,H2S,HCN,NH3,NO,NO2, PH3,SO2 and organicvaporsDETECTORBULK NOUN:PARENT EQUIPMENT/FUNCTION: LEAKINSTRUMENTGASRATING: 0 TO 2000 PPM:SIZE: 47 WD WD X 129 MM LG X31MM THSTANDARD/SPECIFICATION: UL CLASSIAND IIADDITIONAL DATA:
ITEM ADDITIONAL DESCRIPTION:COMBINATION INSTRUMENT FOR EXPLOSION MONITORINGTOXICGASES AND OXYGEN MEASUREMENTRELIABLE MONITORING OFAMBIENT AIR AND PROVIDES A FAST WARNING AGAINST HARMFULCONCENTRATIONS OF CARBON MONOXIDE.HYDROGENSULPHIDE OR OXYGEN(CO,H2S,CO2,CL2,HCN,NH3,NO2,PH3.AND SO2);SYSTEM PARENT EQUIPMENT INFORMATION:TO BE USED IN NAJRAN POWERPLANTDRAGER LTD:Model# X-AM 5000
WEG112-M4 4kW 1475rpm WEG
Klingelnberg Hydraulic Motor克林贝格液压马达
MODULE CONTROL:MIGHTY CONTROLLERPROCESSMODULE,CONTROL:
FUNCTION:PROCESS CONTROLLER:EQUIPMENT DEVICE/EQUIPMENT APLICATION:MIGHTY CONTROLLER:
STANDARDISPECIFICATION:EN6100042,3.4.5.6.8,11,EN55024，HEAVY INDUSTRY LEVEL SURGELN1KV CRITERIA AADDITIONAL DATA
A-T CONTROLS,INC.
P/N#MVC-5000-23011*FOR THIS ITEM YOU ARE REQUIRED TOAFFIX SEC SPECIFIED BARCODELABEL WITHGS1DATAMETRICS AND HUMAN READABLEINFORMATION.SEC WILL NOT ACCEPTUNLABELED GOODS.*THE BARCODELABEL SHOULD INCLUDE QRCODE.MATERIAL NO.PURCHASE ORDER NOVENDOR NO.EXPIRY DATE (IF APPLICABLE)*THE GS1 QR CODE SHOULD BE PRINTEDALONG WITH THE MANUFACTURER INFORMATIONON THE RIVETED METAL PLATE AS APPLICABLEAND THE BARCODE/LABEL SHOULD BE AFFIXEDON EACH PACKAGING.PLEASE VISIT THE E-BIDDING PORTAL FORMORE SPECIFICS REGARDING THEBARCODE/LABEL FORMAT AND TECHNICALASPECTS OF THE QR CODE.
4M011-12-M1105, 090747A, FOR SNC30 Machine
DETECTOR; MODEL NUMBER: CL4/03-36/2US, MNFR: BIDDLE; TYPE: DETEXTVOLTAGE; FFT: END EQUIPMENT DETAILS: MV SWITCHGEARS SG-0000-110, SG-0000-210, SG-0000220; DETEX VOLTAGE DETECTOR, 4.16-34.5 KV, 514440-2, BIDDLE INSTRUMENTS, MADE IN FRANCE; TAG/EQUIP NO: SG-0000110, SG-0000210, SG-0000-220, EQUIP/TAG SERIAL NO: M123090/038
Klingelnberg Hydraulic Motor克林贝格液压马达
ELEMENT,FILTER OIL, PORTABLE OIL PURIFIELEMENTBULK NOUN:
PARENT EQUIPMENT/FUNCTION:
FILTER, OIL, PORTABLE OIL PURIFIER:RATING: 100 PSID.
SIZE: 70 MM ID X 155 MM OD X 915 MM LG
MATERIAL: STL/FIBER.
STANDARD/SPECIFICATION: ANSIADDITIONAL DATA:
ITEM ADDITIONAL DESCRIPTION:
OIL PORTABLE OIL PURIFIER QUANTITY PER EQUIPMENT 3: SECDWG NO: KA-450070 001 OF 001 PAGE 5-10..SYSTEM PARENT EQUIPMENT INFORMATION:USED FOR PP7.KAYDON CORPORATION:K1100
KAYDON CORPORATION:P/N#A910266
4M015-A2-M1105, 104603A, FOR SNC30 Machine
DETECTOR; MODEL NUMBER: CL4/03-36/2US, MNFR: BIDDLE; TYPE: DETEXTVOLTAGE; FFT: END EQUIPMENT DETAILS: MV SWITCHGEARS SG-0000-110, SG-0000-210, SG-0000220; DETEX VOLTAGE DETECTOR, 4.16-34.5 KV, 514440-2, BIDDLE INSTRUMENTS, MADE IN FRANCE; TAG/EQUIP NO: SG-0000110, SG-0000210, SG-0000-220, EQUIP/TAG SERIAL NO: M123090/038
1MRK002339-BBr02
3HAB2245-1/28 DSQC236H
1MRK002246-BD
1MRK002247-BGr00
1MRK002252-AAr00
GE Panametrics PM880 (PM880 PKG-2.00.00) and full accessories contain:
Panametrics PM880 portable hygrometer and Panametrics portable sample system (Standard range 0~70 bar) and Swagelok connection (1/4 in male and female connection ss316)
And Panametrics MISP2 probe (2pcs)
And cable type sweat able for M series probe (2pcs)
And Panametrics battery pack for PM880 (contain charger) (2pcs)
3HAA3563-ALA/2 DSQC252
3HAA3563-AGA/2 DSQC249
3HAA3563-ARA
3BHB003681R0001
3BHB005922R0001
3HAB6182-1 DSQC335
3BHB006208R0001
3BHB006309R0001
3BHB006338R001
3BHB006338R002
3BHB006309R0001
3HAB8796-1/2B DSQC266A
3HAB8796-1 DSQC236B
3HAB8797-1/2B DSQC266B
3HBA8798-1/2B DSQC266C
3HAB8801-1/1 DSQC266G
3HAB8002-1/2B DSQC266T
WHIT-P900015
BUSHING,FOR CROSSHEAD,WHITE SUPERIOR,900015
SPECTRO (AMETEK旗下)
用于光谱仪型号 SPECTROLAB LAV M10 - 零件号 ：EK0014B2带 DMB 的测量/控制板，带系统软件 ARC/SPARK
ROCKWELL AUTOMATION:
541-4996-02 or 541-4996-02 AKRON STANDARD Uniformity control processor (UCP) – 1 个
适用于 SPECTROLAB LAVM12 光谱仪的 DSP 以太网控制器 零件号：EK0808 -
SG INTELLISYS CONTROLLER_M250（空气压缩机智能集成电子控制器） - 制造商：INGERSOLL-RAND - P.NO.：39253265 -SER。 编号：08078-99298-GCE - CPN:39875158
ROCKWELL AUTOMATION:
541-4996-02 or 541-4996-02 AKRON STANDARD Uniformity control processor (UCP) – 1 个
EXT-175425
BEARING,ROLLER,TAPERED,WITH RACE,STRAIGHT BORE,SINGLE ROW,LUBRICATOR DRIVE,ENDYN,929805
SPECTRO (AMETEK旗下)
用于光谱仪型号 SPECTROLAB LAV M10 - 零件号 ：EK0014B2带 DMB 的测量/控制板，带系统软件 ARC/SPARK
适用于 SPECTROLAB LAVM12 光谱仪的 DSP 以太网控制器 零件号：EK0808 -
WHIT-P900763
PIN,CYLINDRICAL,WHITE SUPERIOR,P900763
COOK-Z01S188
SPRING,VALVE,#8,CHROME SILICON,COOK COMPRESSION,Z01S188
WHIT-P900015
BUSHING,FOR CROSSHEAD,WHITE SUPERIOR,900015
EXT-175425
BEARING,ROLLER,TAPERED,WITH RACE,STRAIGHT BORE,SINGLE ROW,LUBRICATOR DRIVE,ENDYN,929805
EACH
2
3
WHIT-P900763
PIN,CYLINDRICAL,WHITE SUPERIOR,P900763
EACH
2
洗衣机，型号：HF185C 滚筒配件，型号：HF185C
445W5757P002
GE :2114559-21 锂电池L-120 C尺寸，3.6 VDC 1400010-001，Triconex
2160200-9 1 螺母，PN # 005402052
2347614 1 323A2354P12 5
7657610301 2
Electric motor AF112M4/L-11 4 kW 380 V 1480 rpm
Electric motor AF112M4/L-11 4 kW 380 V 1480 rpm
Electric motor Sew-Eurodrive DV100M4 2,2 kW, 380V, 4,9A, 1410 rpm
Electric motor 7АА 160 М02 15 kW, 440/690V, 2930 rpm, flanged, 1 shaft end
Electric motor Loher AMGA-160 MD02C 11 kW, 380V, 20А, 2920 rpm
Electric motor Sew-Eurodrive DV100L4 3 kW, 380V, 6,3A, 1400 rpm
Electric motor Sew-Eurodrive DV100M4 2,2 kW, 380V, 4,9A, 1410 rpm
Electric motor Sew-Eurodrive DV132M4 7,5 kW, 380V, 15,5A, 1430 rpm
Electric motor Sew-Eurodrive DV132ML6/RS 5,5 kW, 380V, 13,8A
Electric motor Siemens 1LA45044CM00-Z 690V, 1650 rpm, 1491 rpm, IP55
Electric motor Siemens 1LA71062AA60-Z 3 kW, 380V, 6А, 890 rpm
Electric motor AF112M4/L-11 4 kW 380 V 1480 rpm
Electric motor AF112M4/L-11 4 kW 380 V 1480 rpm
Electric motor Sew-Eurodrive DV100M4 2,2 kW, 380V, 4,9A, 1410 rpm
Electric motor 7АА 160 М02 15 kW, 440/690V, 2930 rpm, flanged, 1 shaft end
Electric motor Loher AMGA-160 MD02C 11 kW, 380V, 20А, 2920 rpm
Electric motor Sew-Eurodrive DV100L4 3 kW, 380V, 6,3A, 1400 rpm
Electric motor Sew-Eurodrive DV100M4 2,2 kW, 380V, 4,9A, 1410 rpm
Electric motor Sew-Eurodrive DV132M4 7,5 kW, 380V, 15,5A, 1430 rpm
Electric motor Sew-Eurodrive DV132ML6/RS 5,5 kW, 380V, 13,8A
Electric motor Siemens 1LA45044CM00-Z 690V, 1650 rpm, 1491 rpm, IP55
Electric motor Siemens 1LA71062AA60-Z 3 kW, 380V, 6А, 890 rpm
375-3382 10
705100 4 Refurb
76576103 3
76576103 3
Economizer On/Off Solenoid valve
FY-38201A/B NFB223B005T Connection size: 3/4" ASCO
78579003 9
4081150 2 Refurb
445W5757P001 5
445W5757P002
5117866-25 2
5728958 3 抗咬合剂\Dynatex 49560\454g/瓶
5117866-25 2
5728958 3
BLACK DUCK TAPE PICTURE ATTACHED
o-ring kit IMPA:813072
copper ring kits IMPA:813080
non-spark socket wrench sets IMPA:615671
ALLEN HEXAGON WRENCH SETS IMPA:611282
stainless steel threaded elbows，90° IMPA:732505
stainless steel threaded elbows，90° IMPA:732506
stainless steel threaded tees IMPA:732525
stainless steel threaded tees IMPA:732526
" Pneumatic impact wrench" IMPA:590102
Air dusters 2MMXL100MM IMPA:270612
Air dusters 2MMXL300MM IMPA:270613
Multifunctional key Five-in-one multi-function key
Hydraulic pipe 250 centimeters in length and three-eighths of an inch in diameter
straight pipe wrenches IMPA:616533 4 pcs
straight pipe wrenches IMPA:616535 2 pcs
copper s small end diameter:11mm;big end diameter:15mm;length:30mm 100 pcs
copper s small end diameter:12mm;big end diameter:18mm;length:40mm 40 pcs
rubber for making gasket thickness:5mm;length10m;width:2m 2 pcs
welding rods stainless steel 1.6mm 10 packs
welding rods stainless steel 2.5mm 10 packs
trolley for A40/0-40 cylinders unitor production No,176176016 1 pcs
arc welding potable machines type:UWI-200;unitor production No.191670455 1 unit
VACUUM CUPS PICTURE ATTACHED 10 pcs
HEAD LAMP PICTURE ATTACHED 10 pcs
ear PICTURE ATTACHED 5 packs
BLACK DUCK TAPE PICTURE ATTACHED 5 pcs
o-ring kit IMPA:813072 5 sets
copper ring kits IMPA:813080 5 sets
non-spark socket wrench sets IMPA:615671 5 sets
ALLEN HEXAGON WRENCH SETS IMPA:611282 8 sets
stainless steel threaded elbows，90° IMPA:732505 20 pcs
stainless steel threaded elbows，90° IMPA:732506 20 pcs
stainless steel threaded tees IMPA:732525 20 pcs
stainless steel threaded tees IMPA:732526 20 pcs
" Pneumatic impact wrench" IMPA:590102 2 pcs
Air dusters 2MMXL100MM IMPA:270612 2 pcs
Air dusters 2MMXL300MM IMPA:270613 2 pcs
Multifunctional key Five-in-one multi-function key 20 pcs
Hydraulic pipe 250 centimeters in length and three-eighths of an inch in diameter 8 pcs
MIFⅡ\GE\MIFⅡPI51E10H100
Vertiv SU56721AA000AA0 PARALLEL KIT UP TO 4
Vertiv АР РОВ 90-NET, ADAPTER BUS
Vertiv 451909987000 – AP POB90-NET
Vertiv 477470900000 – ADAAPTER BUS
Vertiv 00B46158P49 – W 13m
Vertiv 10B54549P58 – CABLE FLAT 26 WAY TOROID 570mm
Vertiv 10H46691P04 – LAB PVC IDENTIF. HW-SW OPTION
Vertiv 10H46649P02 – CARTON 270x230x100
Vertiv 10H46559P06 – LAB PVC IDENTIF. EDP90/80/100
Test Reticle 测试光照R1755A
Main contact LA5F400803 to LC1F330 Schneider Electric set 4
Vertiv SU56721AA000AA0 PARALLEL KIT UP TO 4
Vertiv АР РОВ 90-NET, ADAPTER BUS
Vertiv 451909987000 – AP POB90-NET
Vertiv 477470900000 – ADAAPTER BUS
Vertiv 00B46158P49 – W 13m
Vertiv 10B54549P58 – CABLE FLAT 26 WAY TOROID 570mm
Vertiv 10H46691P04 – LAB PVC IDENTIF. HW-SW OPTION
Vertiv 10H46649P02 – CARTON 270x230x100
Vertiv 10H46559P06 – LAB PVC IDENTIF. EDP90/80/100
Ariel А-18845
Ariel А-18845
Ariel KB-7277-HH
Ariel KB-7278-JJ
Ariel KB-7640-HP
Ariel KB-7641-HP
Ariel KB-7646-HQ
Ariel KB-7647-HQ
Ariel KB-8029-HP
Ariel KB- 8030-HN
Ariel KB-8990-HN
Ariel UB-8990-HN Vertiv SU56721AA000AA0 PARALLEL KIT UP TO 4
Vertiv АР РОВ 90-NET, ADAPTER BUS
Vertiv 451909987000 – AP POB90-NET
Vertiv 477470900000 – ADAAPTER BUS
Vertiv 00B46158P49 – W 13m
Vertiv 10B54549P58 – CABLE FLAT 26 WAY TOROID 570mm
Vertiv 10H46691P04 – LAB PVC IDENTIF. HW-SW OPTION
Vertiv 10H46649P02 – CARTON 270x230x100
Vertiv 10H46559P06 – LAB PVC IDENTIF. EDP90/80/100
Ariel А-20537-К
Ariel B-9397-K
Ariel B-9415-K
Ariel В-7916-К
Ariel А-7158
Ariel B-3456-K
ABB 1SAM150000R1005
ABB 1SAM150000R1008
ABB 1SAM150000R1010
ABB 1SAM150000R1011
ABB 1SAM150000R1012
ABB 1SAM150000R1013
ABB 1SAM160000R1010
ABB 1SAM160000R1009
ABB 1TGB100052A7080
ABB 1TGB120050P0001
Control Pitch Propeller
VBS 1280
ALPHA DIESEL DENMARK
Code/Part No. FULL DESCRIPTION, FABRIC DETAILS
Slide ring (Piston seal), d=565 mm Drw. No: P31005-9338 Pos : 5
Sealing ring - non glued Drw. No: P31005-9338 Pos : 7
O-ring (Sealing ring) Drw. No: P31005-9338 Pos : 12
Sealing ring Drw. No: P31005-9338 Pos : 15
Throw off ring d=475 mm (Rubber cord) Drw. No: P31005-9338 Pos : 17
Glue Drw. No: P31005-9338 Pos : 17_2
Zinc-anode VBS1280 (Ring anode, Aluminium) Drw. No: P31505-09 Pos : 3
Sealing ring Drw. No: P31505-09 Pos : 6
Stanless steel 10 mm (Coor.resisting 10 mm) Drw. No: P31505-09 Pos : 16А
Sealing ring, VBS1280 Drw. No: P31505-09 Pos : 17
Slide ring, VBS1280 Drw. No: P31505-09 Pos : 18
Sealing ring Drw. No: P31505-09 Pos : 20
Sealing ring d=760 mm (Piston seal) Drw. No: P31505-09 Pos : 29
O-ring (Sealing ring) Drw. No: P31505-09 Pos : 30
Sealing ring Drw. No: P31505-09 Pos : 32
Rod seal d=110/130 mm Drw. No: P31505-09 Pos : 34
Wiper d=110/120 mm Drw. No: P31505-09 Pos : 36
screw 2"MS, Nylock Drw. No: P31505-09 Pos : 39
Sealing ring - non glued Drw. No: P31505-09 Pos : 47
Rod sealing d=340 mm Drw. No: P31505-09 Pos : 51
O-ring (Sealing ring) Drw. No: P31505-09 Pos : 52
Sealing ring Drw. No: P31505-09 Pos : 55
Sealing ring Drw. No: P31505-09 Pos : 71
Sealing ring Drw. No: P31505-09 Pos : 74
Rod guide ring d=110 mm (Rod slide ring d=110 mm) Drw. No: P31505-09 Pos : 85
Rod sealing d=110 mm Drw. No: P31505-09 Pos : 86
O-ring (Sealing ring) Drw. No: P31505-09 Pos : 87
Sealing ring Drw. No: P31505-09 Pos : 96
Sealing ring Drw. No: P31505-09 Pos : 99
Securing device (Securing stud) Drw. No: P33005-05 Pos : 1
Guide plate Drw. No: P33005-05 Pos : 2
Hydraulic hose with certificate Drw. No: P33005-05 Pos : 13
Filter element Drw. No: P35014-09 Pos : 190
Hydraulic hose with certificate Drw. No: P35014-09 Pos : 257
Filter cartridge Drw. No: P35014-09 Pos : 300
Set of O-rings Drw. No: P35014-09 Pos : 301
Filter cartridge Drw. No: P35014-09 Pos : F1
Molykote G-N Plus
Silicone paste
Locking wire
Check valve complete Drw. No: P31505-09 Pos : 100A
Check valve complete Drw. No: P31505-09 Pos : 100B
Service kit Drw. No: P35005-06 Pos : 12
VBS1280 Rotor complete Drw. No: 3 5005-05 Pos : 50
VBS1280 Slide bracket Drw. No: 3 5005-05 Pos : 31
VBS 1280 SPRING Drw. No: 3 5005-03 Pos : 30
VBS1280 WASHER Drw. No: 3 5005-05 Pos : 29
VBS1280 HEXAGONE SOCKET HEAD CAP SCREW Drw. No: 3 5005-05 Pos : 28
Rotor rim Drw. No: 3 5005-05 Pos : 47
Hex. socket countersunk head screw Drw. No: 3 5005-05 Pos : 48
STOP MAGNET, 24 V. DWG. 38S-645-5 ORDER NO : 8366 31900
Ariel B-9396-K
Ariel А- 0661
SU56721AA000AA0 PARALLEL KIT UP TO 4 5套
АР РОВ 90-NET, ADAPTER BUS
451909987000 – AP POB90-NET
477470900000 – ADAAPTER BUS
00B46158P49 – W 13m
10B54549P58 – CABLE FLAT 26 WAY TOROID 570mm
10H46691P04 – LAB PVC IDENTIF. HW-SW OPTION
10H46649P02 – CARTON 270x230x100
10H46559P06 – LAB PVC IDENTIF. EDP90/80/100
STAHL 8562/52-2040-100
Positioner DVC 6205, DVC 6215, (AD), relay A, M20x1.5, 1/4 NPT, CUTR, IP66, with mounting kit for drive EL-O-MATIC EMERSON
2-3-0710-101 通阀组件艾默生 2-3-0710-100通阀组件艾默生
压力变送器 PMC51-8C22QA1HDJCZJM+AK 0~100KPa DN80 E+H
压力变送器 PMC51-8C22QA1HDJCZJM+AK E+H
2-3-0710-101 20800 禇、
滤芯 1020930-5
火花塞 1018328
BEDIA 600132 147199328 0000003294 15/32
GE MIFⅡ\GE\MIFⅡPI51E10H100\电网能量管理系统
Emerson Rosemount 2088G2-S33A1M5IMQ4P9029 -- 1 set
Emerson Rosemount 3051SAM2PT3A2B11A1AD4IMM5Q4
Emerson Rosemount 3051SAM-2ST3A2B11A2AD4IMQ4
Emerson Rosemount 1199WDA95DRFWBGDBA5JSSG
艾默生罗斯蒙特2088G2-S33A1M5IMQ4P9029 -- 1台
艾默生罗斯蒙特3051SAM2PT3A2B11A1AD4IMM5Q4
艾默生罗斯蒙特3051SAM-2ST3A2B11A2AD4IMQ4
艾默生罗斯蒙特1199WDA95DRFWBGDBA5JSSG
SM1500-D03 三星韩华
FC18-002218 三星韩华
9100201021 三星韩华
CMA00490 三星韩华
SM1500-B03 三星韩华
AM10-000640A 三星韩华
CST13022-01 三星韩华
CST13022-01 三星韩华
CST13024-01 三星韩华
CST13025-01 三星韩华
SVI2AP-21143121梅索尼兰船舶阀
244LD-SX2FERNNHGA1-ML1236 FOXBORO-ECKARDT
ROSEMOUNT设备通讯器TREX系列其他常用型号：
ROSEMOUNT TREXCHPKLWP3S
ROSEMOUNT TREXCHPKLWP3
ROSEMOUNT TREXCHPKLWP3T
ROSEMOUNT TREXCHPNAWS1
